Milnor Mwf100c7 Manual

Published Manual Number/ECN: MPIMWF100YAE/2021305A

• Publishing System: TPAS2

• Access date: 07/30/2021

• Document ECNs: Latest

Installation and Service

MWF100C7, MWF100Y7

MWF125CY, MWF125Y7

PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.

Table of Contents

MPIMWF100YAE/21305A

Page Description Document

1 Limited Standard Warranty BMP720097/2019036

2 How to Get the Necessary Repair Components BIUUUD19/20081231

3 Trademarks BNUUUU02/2021104A

5 1. Installation

6 Safety—Tilting Washer-Extractors BIUUUS27OT/20051111

12 How To Use the Safety Stands on 48" Air-tilting

Washer-extractors BIUUUS06F4/20060106

13 Safety Supports MWF100C7, MWF100Y7, MWF125C7,

MWF125Y7 BMP180035/2021295A

15 Shipping Brackets BMP180034/2021295A

17 Guards and Covers BMP180033/2021295A

20 Installation Tag Guidelines - MWF Series Machines BNWMAI01/2018423A

23 Safety Placards and Locations - MWF100C7,Y7,

MWF125C7,Y7 BMP180049/2021295A

25 Safety Placards and Locations ISO - MWF100C7,Y7,

MWF125C7,Y7 BMP180048/2021295A

27 Handling a Washer-extractor from Delivery to Final

Location BNWUUI03/2019426A

33 Prevent Damage from Chemical Supplies and Chemical

Systems BIWUUI03/2019296A

37 Vital Information About the Forces Imparted to Supporting

Structures by Laundering Machines BNUUUI01/2019392A

39 2. Service and Maintenance

40 Connection Precautions for Washer-extractors BNWUUI04/2019426A

44 Torque Requirements for Fasteners BNUUUN02/2019125A

51 2.1. Drive Assemblies

52 Drive Components BPWMJI01/2021295A

53 Brake Components - 4840F7B,F7D, F7J,F7Z (AZ);

MWF125J7, Z7, C7, Y7 BMP150014/2021295A

56 Cylinder & Bearing Installation BPWMEB01/2021134A

59 Bearing Housing Components & Installation BPWMEB02/2021134A

65 Air Injection Components BPWHUI01/2021242A

67 2.2. Suspension Assemblies

68 Suspension BMP180037/2021134A

71 2.3. Tilt Assemblies

72 Tilt Components BMP180038/2021295A

77 2.4. Door Assemblies

78 Manual Door BMP180039/2021305A

Table of Contents, continued

MPIMWF100YAE/21305A

Page Description Document

83 Door Latch BPWG4D02/2021034A

84 Door Latch Small BPWD6D02/2020356A

85 2.5. Water, Steam & Drain

86 Water and Steam Schematic and Components BMP180047/2021134A

88 Water Inlet Components and Installation BMP180040/2021134A

90 Steam BMP180041/2021134A

91 Drain Valve to Bottom BMP180042/2021134A

93 2.6. Chemical Supply Assemblies

94 Soap Chute BMP180044/2021134A

96 Peristaltic Chemical Inlets BMP180045/2021134A

99 2.7. Pneumatic Assemblies

100 Pneumatic Schematic BMP180046/2021295A

103 2.8. Control and Sensing Assemblies

104 Water Level & Temperature Sensor BMP180058/2021134A

105 3. Reference

107 3.1. Dimensional Drawings

109 Dimensional Drawing - MWF100C7, MWF100Y7 BDMWF100CYAE/2020135D

111 Dimensional Drawing - MWF125C7, MWF125Y7 BDMWF125CYAE/2019182D

112 Dimensional Drawing - MWF125C7, MWF125Y7 Options BDMWF125CYAB/2019166D

BMP720097/19036

PELLERIN MILNOR CORPORATION

LIMITED STANDARD WARRANTY

We warrant to the original purchaser that MILNOR machines including electronic hardware/software

(hereafter referred to as “equipment”), will be free from defects in material and workmanship for a

period of one year from the date of shipment (unless the time period is specifically extended for

certain parts pursuant to a specific MILNOR published extended warranty) from our factory with no

operating hour limitation. This warranty is contingent upon the equipment being installed, operated

and serviced as specified in the operating manual supplied with the equipment, and operated under

normal conditions by competent operators.

Providing we receive written notification of a warranted defect within 30 days of its discovery, we

will—at our option—repair or replace the defective part or parts, EX Factory (labor and freight

specifically NOT included). We retain the right to require inspection of the parts claimed defective in

our factory prior to repairing or replacing same. We will not be responsible, or in any way liable, for

unauthorized repairs or service to our equipment, and this warranty shall be void if the equipment is

tampered with, modified, or abused, used for purposes not intended in the design and construction

of the machine, or is repaired or altered in any way without MILNOR's written consent.

Parts damaged by exposure to weather, to aggressive water, or to chemical attack are not covered

by this warranty. For parts which require routine replacement due to normal wear—such as gaskets,

contact points, brake and clutch linings, belts, hoses, and similar parts—the warranty time period is

90 days.

We reserve the right to make changes in the design and/or construction of our equipment (including

purchased components) without obligation to change any equipment previously supplied.

ANY SALE OR FURNISHING OF ANY EQUIPMENT BY MILNOR IS MADE ONLY UPON THE EXPRESS

UNDERSTANDING THAT MILNOR MAKES NO EXPRESSED OR IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE OR PURPOSE OR ANY OTHER

WARRANTY IMPLIED BY LAW INCLUDING BUT NOT LIMITED TO REDHIBITION. MILNOR WILL NOT

BE RESPONSIBLE FOR ANY COSTS OR DAMAGES ACTUALLY INCURRED OR REQUIRED AS A RESULT

OF: THE FAILURE OF ANY OTHER PERSON OR ENTITY TO PERFORM ITS RESPONSIBILITIES, FIRE

OR OTHER HAZARD, ACCIDENT, IMPROPER STORAGE, MIS-USE, NEGLECT, POWER OR

ENVIRONMENTAL CONTROL MALFUNCTIONS, DAMAGE FROM LIQUIDS, OR ANY OTHER CAUSE

BEYOND THE NORMAL RANGE OF USE. REGARDLESS OF HOW CAUSED, IN NO EVENT SHALL

MILNOR BE LIABLE FOR SPECIAL, INDIRECT, PUNITIVE, LIQUIDATED, OR CONSEQUENTIAL COSTS

OR DAMAGES, OR ANY COSTS OR DAMAGES WHATSOEVER WHICH EXCEED THE PRICE PAID TO

MILNOR FOR THE EQUIPMENT IT SELLS OR FURNISHES.

THE PROVISIONS ON THIS PAGE REPRESENT THE ONLY WARRANTY FROM MILNOR AND NO OTHER

WARRANTY OR CONDITIONS, STATUTORY OR OTHERWISE, SHALL BE IMPLIED.

WE NEITHER ASSUME, NOR AUTHORIZE ANY EMPLOYEE OR OTHER PERSON TO ASSUME FOR US,

ANY OTHER RESPONSIBILITY AND/OR LIABILITY IN CONNECTION WITH THE SALE OR FURNISHING

OF OUR EQUIPMENT TO ANY BUYER.

How to Get the Necessary Repair Components

PELLERIN MILNOR CORPORATION

BIUUUD19 (Published) Book specs- Dates: 20081231 / 20081231 / 20081231 Lang: ENG01 Applic: UUU

How to Get the Necessary Repair Components

This document uses Simplified Technical English.

Learn more at http://www.asd-ste100.org.

You can get components to repair your machine from the approved supplier where you got this

machine. Your supplier will usually have the necessary components in stock. You can also get

components from the Milnor®factory.

Tell the supplier the machine model and serial number and this data for each necessary component:

• The component number from this manual

• The component name if known

• The necessary quantity

• The necessary transportation requirements

• If the component is an electrical component, give the schematic number if known.

• If the component is a motor or an electrical control, give the nameplate data from the used

component.

To write to the Milnor factory:

Pellerin Milnor Corporation

Post Office Box 400

Kenner, LA 70063-0400

UNITED STATES

Telephone: 504-467-2787

Fax: 504-469-9777

Email: [email protected]

— End of BIUUUD19 —

Pellerin Milnor Corporation

Trademarks

BNUUUU02.R01 0000158093 F.2 E.2 3/3/21 9:47 AM Released

These words are trademarks of Pellerin Milnor®Corporation and other entities:

Table 1. Trademarks

AutoSpot™ GreenFlex™ MilMetrix®PulseFlow®

CBW®GearTrace™ MilTouch™ RAM Command™

Drynet™ GreenTurn™ MilTouch-EX™ RecircONE®

E-P Express®Hydro-cushion™ MILRAIL™ RinSave®

E-P OneTouch®Mentor®Miltrac™ SmoothCoil™

E-P Plus®Mildata®PBW™ Staph Guard®

Gear Guardian®Milnor®

End of document: BNUUUU02

IBNUUUU02 / 2021104A BNUUUU02 0000158094 F.2 3/3/21 9:47 AM Released

Installation 1

Safety—Tilting Washer-Extractors

PELLERIN MILNOR CORPORATION

BIUUUS27 (Published) Book specs- Dates: 20051111 / 20051111 / 20060323 Lang: ENG01 Applic: EOT

Safety—Tilting Washer-Extractors

1. General Safety Requirements—Vital Information for

Management Personnel[Document BIUUUS04]

Incorrect installation, neglected preventive maintenance, abuse, and/or improper repairs, or

changes to the machine can cause unsafe operation and personal injuries, such as multiple

fractures, amputations, or death. The owner or his selected representative (owner/user) is

responsible for understanding and ensuring the proper operation and maintenance of the machine.

The owner/user must familiarize himself with the contents of all machine instruction manuals.

The owner/user should direct any questions about these instructions to a Milnor® dealer or the

Milnor® Service department.

Most regulatory authorities (including OSHA in the USA and CE in Europe) hold the owner/user

ultimately responsible for maintaining a safe working environment. Therefore, the owner/user

must do or ensure the following:

• recognize all foreseeable safety hazards within his facility and take actions to protect his

personnel, equipment, and facility;

• work equipment is suitable, properly adapted, can be used without risks to health or safety,

and is adequately maintained;

• where specific hazards are likely to be involved, access to the equipment is restricted to those

employees given the task of using it;

• only specifically designated workers carry out repairs, modifications, maintenance, or

servicing;

• information, instruction, and training is provided;

• workers and/or their representatives are consulted.

Work equipment must comply with the requirements listed below. The owner/user must verify

that installation and maintenance of equipment is performed in such a way as to support these

requirements:

• control devices must be visible, identifiable, and marked; be located outside dangerous zones;

and not give rise to a hazard due to unintentional operation;

• control systems must be safe and breakdown/damage must not result in danger;

• work equipment is to be stabilized;

• protection against rupture or disintegration of work equipment;

• guarding, to prevent access to danger zones or to stop movements of dangerous parts before

the danger zones are reached. Guards to be robust; not give rise to any additional hazards; not

be easily removed or rendered inoperative; situated at a sufficient distance from the danger

zone; not restrict view of operating cycle; allow fitting, replacing, or maintenance by

restricting access to relevant area and without removal of guard/protection device;

• suitable lighting for working and maintenance areas;

• maintenance to be possible when work equipment is shut down. If not possible, then

protection measures to be carried out outside danger zones;

• work equipment must be appropriate for preventing the risk of fire or overheating; discharges

of gas, dust, liquid, vapor, other substances; explosion of the equipment or substances in it.

Safety—Tilting Washer-Extractors

PELLERIN MILNOR CORPORATION

1.1. Laundr

Facilit

—Provide a supporting floor that is strong and rigid enough to support–with

a reasonable safety factor and without undue or objectionable deflection–the weight of the fully

loaded machine and the forces transmitted by it during operation. Provide sufficient clearance fo

machine movement. Provide any safety guards, fences, restraints, devices, and verbal and/or

posted restrictions necessary to prevent personnel, machines, or other moving machinery from

accessing the machine or its path. Provide adequate ventilation to carry away heat and vapors.

Ensure service connections to installed machines meet local and national safety standards,

especially regarding the electrical disconnect (see the National Electric Code). Prominently post

safety information, including signs showing the source of electrical disconnect.

1.2. Personnel—Inform personnel about hazard avoidance and the importance of care and

common sense. Provide personnel with the safety and operating instructions that apply to them.

Verify that personnel use proper safety and operating procedures. Verify that personnel

understand and abide by the warnings on the machine and precautions in the instruction manuals.

1.3. Safety Devices—Ensure that no one eliminates or disables any safety device on the machine

or in the facility. Do not allow machine to be used with any missing guard, cover, panel or door.

Service any failing or malfunctioning device before operating the machine.

1.4. Hazard Information—Important information on hazards is provided on the machine safety

placards, in the Safety Guide, and throughout the other machine manuals. Placards must be kept

clean so that the information is not obscured. They must be replaced immediately if lost or

damaged. The Safety Guide and other machine manuals must be available at all times to

the appropriate personnel. See the machine service manual for safety placard part numbers.

Contact the Milnor Parts department for replacement placards or manuals.

1.5. Maintenance—Ensure the machine is inspected and serviced in accordance with the norms of

good practice and with the preventive maintenance schedule. Replace belts, pulleys, brake

shoes/disks, clutch plates/tires, rollers, seals, alignment guides, etc. before they are severely

worn. Immediately investigate any evidence of impending failure and make needed repairs (e.g.,

cylinder, shell, or frame cracks; drive components such as motors, gear boxes, bearings, etc.,

whining, grinding, smoking, or becoming abnormally hot; bending or cracking of cylinder, shell,

frame, etc.; leaking seals, hoses, valves, etc.) Do not permit service or maintenance by

unqualified personnel.

2. Safety Alert Messages—Internal Electrical and Mechanical

Hazards[Document BIUUUS11]

The following are instructions about hazards inside the machine and in electrical enclosures.

WARNING 1 : Electrocution and Electrical Burn Hazards—Contact with electric powe

can kill or seriously injure you. Electric power is present inside the cabinetry unless the main

machine power disconnect is off.

• Do not unlock or open electric box doors.

• Do not remove guards, covers, or panels.

• Do not reach into the machine housing or frame.

• Keep yourself and others off of machine.

• Know the location of the main machine disconnect and use it in an emergency to remove

all electric power from the machine.

Safety—Tilting Washer-Extractors

PELLERIN MILNOR CORPORATION

WARNING 2 : Entangle and Crush Hazards—Contact with moving components normally

isolated by guards, covers, and panels, can entangle and crush your limbs. These components

move automatically.

• Do not remove guards, covers, or panels.

• Do not reach into the machine housing or frame.

• Keep yourself and others off of machine.

• Know the location of all emergency stop switches, pull cords, and/or kick plates and use

them in an emergency to stop machine motion.

WARNING 3 : Crush Hazards—Tilting machines only—The machine housing will crush

your body or limbs if it descends or falls while you are under it. Housing can descend with powe

off or on. Manual operation of tilting valves overrides safety interlocks. Improper operation of

manual tilting valves may cause the housing to descend.

• Do not remove guards, covers, or panels.

• Do not reach into the machine housing or frame.

3. Safety Alert Messages—External Mechanical Hazards[Document

BIUUUS12]

The following are instructions about hazards around the front, sides, rear or top of the machine.

WARNING 4 : Strike and Crush Hazards—Machines with power operated door—The

moving door can strike you or crush or pinch your limbs if caught between the door and machine.

Some doors move automatically.

• Keep yourself and others clear of movement areas and paths.

• Keep both hands on the controls while operating.

• Do not operate the machine with malfunctioning two-hand manual controls.

WARNING 5 : Crush Hazards—Tilting machines only—The machine can crush your body

or limbs if you are caught between the tilting housing and a stationary object. Some machines tilt

automatically.

• Keep yourself and others clear of movement areas and paths.

• Keep both hands on the controls while operating.

• Do not operate the machine with malfunctioning two-hand manual controls.

WARNING 6 : Crush Hazards—Suspended machines only—Spaces between the shell and

housing can close and crush or pinch your limbs. The shell moves within the housing during

operation.

• Do not reach into the machine housing or frame.

• Keep yourself and others clear of movement areas and paths.

4. Safety Alert Messages—Cylinder and Processing Hazards

[Document BIUUUS13]

The following are instructions about hazards related to the cylinder and laundering process.

DANGER 7 : Entangle and Sever Hazards—Contact with goods being processed can

cause the goods to wrap around your body or limbs and dismember you. The goods are normally

isolated by the locked cylinder door.

Safety—Tilting Washer-Extractors

PELLERIN MILNOR CORPORATION

• Do not attempt to open the door or reach into the cylinder until the cylinder is stopped.

• Do not touch goods inside or hanging partially outside the turning cylinder.

• Do not operate the machine with a malfunctioning door interlock.

• Open pocket machines only—Do not jog the cylinder and pull the goods at the same time.

• Open pocket machines only—Keep yourself and others clear of cylinder and goods during

jogging operation.

• Do not operate the machine with malfunctioning two-hand manual controls.

• Know the location of all emergency stop switches, pull cords, and/or kick plates and use

them in an emergency to stop machine motion.

• Know the location of the main machine disconnect and use it in an emergency to remove

all electric power from the machine.

WARNING 8 : Crush Hazards—Contact with the turning cylinder can crush your limbs. The

cylinder will repel any object you try to stop it with, possibly causing the object to strike or stab

you. The turning cylinder is normally isolated by the locked cylinder door.

• Do not attempt to open the door or reach into the cylinder until the cylinder is stopped.

• Do not place any object in the turning cylinder.

• Do not operate the machine with a malfunctioning door interlock.

• Open pocket machines only—Keep yourself and others clear of cylinder and goods during

jogging operation.

• Do not operate the machine with malfunctioning two-hand manual controls.

WARNING 9 : Confined Space Hazards—Confinement in the cylinder can kill or injure

you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration,

biological contamination, electrocution, and crushing.

• Do not attempt unauthorized servicing, repairs, or modification.

WARNING 10 : Explosion and Fire Hazards—Flammable substances can explode or

ignite in the cylinder, drain trough, or sewer. The machine is designed for washing with water,

not any other solvent. Processing can cause solvent-containing goods to give off flammable

vapors.

• Do not use flammable solvents in processing.

• Do not process goods containing flammable substances. Consult with your local fire

department/public safety office and all insurance providers.

5. Safety Alert Messages—Unsafe Conditions[Document BIUUUS14]

5.1. Damage and Malfunction Hazards

5.1.1. Hazards Resulting from Inoperative Safety Devices

DANGER 11 : Entangle and Sever Hazards—Cylinder door interlock—Operating the

machine with a malfunctioning door interlock can permit opening the door when the cylinder is

turning and/or starting the cycle with the door open, exposing the turning cylinder.

• Do not operate the machine with any evidence of damage or malfunction.

Safety—Tilting Washer-Extractors

PELLERIN MILNOR CORPORATION

WARNING 12 : Multiple Hazards—Operating the machine with an inoperative safety device

can kill or injure personnel, damage or destroy the machine, damage property, and/or void the

warranty.

• Do not tamper with or disable any safety device or operate the machine with a

malfunctioning safety device. Request authorized service.

WARNING 13 : Electrocution and Electrical Burn Hazards—Electric box doors—

Operating the machine with any electric box door unlocked can expose high voltage conductors

inside the box.

• Do not unlock or open electric box doors.

WARNING 14 : Entangle and Crush Hazards—Guards, covers, and panels—Operating

the machine with any guard, cover, or panel removed exposes moving components.

• Do not remove guards, covers, or panels.

WARNING 15 : Crush Hazards—Down limit switches (machines with front and rear tilt

cylinders)—Failure of both front or both rear limit switches allows the seated tilt wheels on a

tilted machine to lift from their cradles. The housing will fall and lunge forward or rearward.

• Do not operate the machine with any evidence of damage or malfunction.

5.1.2. Hazards Resulting from Damaged Mechanical Devices

WARNING 16 : Multiple Hazards—Operating a damaged machine can kill or injure

personnel, further damage or destroy the machine, damage property, and/or void the warranty.

• Do not operate a damaged or malfunctioning machine. Request authorized service.

WARNING 17 : Explosion Hazards—Cylinder—A damaged cylinder can rip apart during

extraction, puncturing the shell and discharging metal fragments at high speed.

• Do not operate the machine with any evidence of damage or malfunction.

WARNING 18 : Explosion Hazards—Clutch and speed switch (multiple motor

machines)—A damaged clutch or speed switch can permit the low speed motor to engage during

extract. This will over-speed the motor and pulleys and can cause them to rip apart, discharging

metal fragments at high speed.

• Stop the machine immediately if any of these conditions occur: • abnormal whining sound

during extract • skidding sound as extract ends • clutches remain engaged or re-engage

during extract

5.2. Careless Use Hazards

5.2.1. Careless Operation Hazards—Vital Information for Operator Personnel

(

see also

operator hazards throughout manual)

WARNING 19 : Multiple Hazards—Careless operator actions can kill or injure personnel,

damage or destroy the machine, damage property, and/or void the warranty.

• Do not tamper with or disable any safety device or operate the machine with a

malfunctioning safety device. Request authorized service.

• Do not operate a damaged or malfunctioning machine. Request authorized service.

• Do not attempt unauthorized servicing, repairs, or modification.

Safety—Tilting Washer-Extractors

PELLERIN MILNOR CORPORATION

• Do not use the machine in any manner contrary to the factory instructions.

• Use the machine only for its customary and intended purpose.

• Understand the consequences of operating manually.

5.2.2. Careless Servicing Hazards—Vital Information for Service Personnel (see also

service hazards throughout manuals)

WARNING 20 : Electrocution and Electrical Burn Hazards—Contact with electric

power can kill or seriously injure you. Electric power is present inside the cabinetry unless the

main machine power disconnect is off.

• Do not service the machine unless qualified and authorized. You must clearly understand

the hazards and how to avoid them.

• Abide by the current OSHA lockout/tagout standard when lockout/tagout is called for in

the service instructions. Outside the USA, abide by the OSHA standard in the absence of

any other overriding standard.

WARNING 21 : Entangle and Crush Hazards—Contact with moving components

normally isolated by guards, covers, and panels, can entangle and crush your limbs. These

components move automatically.

• Do not service the machine unless qualified and authorized. You must clearly understand

the hazards and how to avoid them.

• Abide by the current OSHA lockout/tagout standard when lockout/tagout is called for in

the service instructions. Outside the USA, abide by the OSHA standard in the absence of

any other overriding standard.

WARNING 22 : Crush Hazards—Tilting machines only—The machine housing will crush

your body or limbs if it descends or falls while you are under it. Housing can descend with powe

off or on. Manual operation of tilting valves overrides safety interlocks. Improper operation of

manual tilting valves may cause the housing to descend.

• Secure both red safety supports in accordance with the instructions furnished, then lock

out and tag out power at the main machine disconnect before working under the tilted

machine.

• Do not operate the manual tilt valves with anyone under the machine.

• Do not operate the tilt controls with anyone under the machine.

WARNING 23 : Crush Hazards—Tilting machines with front and rear tilt cylinders—The

housing will fall and lunge forward or rearward if the tilt wheels on the non-tilted end lift out of

their cradles, even with safety supports in place.

• Understand the consequences of operating manually.

WARNING 24 : Confined Space Hazards—Confinement in the cylinder can kill or injure

you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration,

biological contamination, electrocution, and crushing.

• Do not enter the cylinder until it has been thoroughly purged, flushed, drained, cooled,

and immobilized.

— End of BIUUUS27 —

PELLERIN MILNOR CORPORATION

BIUUUS06 (Published) Book specs- Dates: 20060106 / 20060106 / 20060106 Lang: ENG01 Applic: 48040F7B 48040F7N

How To Use the Safety Stands on 48" Air-tilting Washer-

extractors

These machines are provided with two safety stands (painted red) for maintenance. After the

housing is tilted up, the stands are placed under the raised tilt wheels (front or rear). Use the

safety stands to perform maintenance on the machine while it is tilted.

WARNING 1 : Crush Hazard—The safety stands provide protection against the un-powered

descent of the housing during maintenance in the event of a leak in the pneumatic system. Such a

condition can cause the housing to fall quickly.

• Never work under the raised housing unless both safety stands are installed and power is

locked out/tagged out. Do not work near the raised housing with power on unless both

safety stands are installed.

• Install these safety components using the procedure prescribed in this document.

• Maintain these safety components in good condition.

• Designate a convenient, secure area to stow these safety components when not in use.

Figure 1: Safety Stands for 48" Air-tilting Washer-extractors

Install the safety stands as follows:

1. At the controls, tilt the machine as in normal operation. Tilt up only as far as needed to insert

the stands securely.

2. Referring to the figure, place the safety stands under the tilt wheels. Always use both stands.

3. At the controls, carefully lower the housing just until it is resting on the stands.

4. Lock out/tag out power to the machine.

— End of BIUUUS06 —

Page (1 / 2)

PELLERIN MILNOR CORPORATIONPELLERIN MILNOR CORPORATION

Note. Front wheels and cradles are used as

the pivot assembly for this model and do

not rise.

Legend

A. Safety Support. Use two under rear

raised tilt cradles.

B. ,Rear Wheels two locations

C. ,Rear Cradles two locations

Detailed view

Figure 1: Safety Supports MWF100C7,Y7, MWF125C7,Y7 Air-tilt Washer-extractors

BMP180035/2021295A

MWF100C7, MWF100Y7, MWF125C7, MWF125Y7

Safety Supports

Milnor supplies safety supports with this machine. This document shows the safety supports,

identifies the safety support components, and tells how to install them.

A,1

Item

Part Number Description Comments

Used In

Findthecorrect assemblyfirst, thenfindtheneeded components.Theitem letters(A,B,C, etc.)assigned toassemblies arereferredtoin the

"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the

partslisttotheillustration.

Parts List

PELLERIN MILNOR CORPORATION

Page (2 / 2)

-------------------------------------------------------------------------------------------COMPONENTS-------------------------------------------------------------------------

all 1 98MW21822A SAFETY SUPPORT, MWF100C7

BMP180035/2021295A

Safety Supports

How to Use the Safety Supports

Safety supports have a red color. You must keep and use safety supports for maintenance as told

in this document.

machine. Install

their positions.

3. Carefully operate the Manual controls to lower the mechanism until it touches the safety

supports. Immediately release the controls when the components touch.

1. Operate the Manual controls to lift the mechanism sufficiently to put the safety supports in

2. Put each support in its position from the nearest side of the machine. Do not go across the

Install the safety supports as follows:

the supports as shown in the figure. Use both supports.

4. Remove electrical power form the machine.

WARNING : Crush Hazard —This mechanism can fail is there is a mechanical

problem.

Replace damages safety supports.

Stow the safety supports properly.

Always install the safety supports and remove power from the machine before you do

maintenance in the machine.

Do not hit the safety supports while you do maintenance.

•

MWF100C7, MWF100Y7, MWF125C7, MWF125Y7

Page (1 / 2)

PELLERIN MILNOR CORPORATIONPELLERIN MILNOR CORPORATION

Figure 1: Left Side View

BMP180034/2021295A

MWF100J7, MWF100Z7, MWF100C7, MWF100Y7, MWF125J7, MWF100Z7, MWF100C7, MWF100Y7

Shipping Brackets

Left Side View - brackets are the same on the left and right sides.

View A-A (4 Places) Alternate Shipping Bolts: Tilt Frame to Base

2,3,4

(4 Places)

7,8,9 Before operating, remove the shipping

brackets or bolts (painted red). The shipping

brackets may be retained in the event the

machine must be moved. See BIIFLI01.

Item

Part Number Description Comments

Used In

Findthecorrect assemblyfirst, thenfindtheneeded components.Theitem letters(A,B,C, etc.)assigned toassemblies arereferredtoin the

"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the

partslisttotheillustration.

Parts List

PELLERIN MILNOR CORPORATION

Page (2 / 2)

all 3 98CX773515 FLATWASHER, D16 ZINC

all 2 98CX770164 HEXCAPSCR M16X70, ZINC8.8

all 4 98CX773115 HEXNUT M16, ZINC

--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------------

all 1 98MW25161A HOLD DOWN WELDMENT, MWF77

all 7 98CX770202 HEXCAPSCR M24X230, ZINC8.8

all 5 98MW06406C PLATE=SHIPPING BRACKST, MEF77

all 6 15K253N HEXCAPSCR M24-3.0X280 ZINC 8.8

all 8 15G250M HEX NUT M24-3 ZINC

all 9 98CX7735175 FLATWASHER, D24 ZINC

BMP180034/2021295A

Shipping Brackets

MWF100J7, MWF100Z7, MWF100C7, MWF100Y7, MWF125J7, MWF100Z7, MWF100C7, MWF100Y7
