WHITEHAVEN CANTILEVER UMBRELLA
ASSEMBLY GUIDE AND
OPERATING INSTRUCTIONS

MIMOSA CANTILEVER
UMBRELLA
WARRANTY CONDITIONS
WARRANTY EXCLUSIONS
Any claim under this warranty must be made within 3 years of
the date of purchase of the product. To make a claim under the
warranty, take the product (with proof of purchase) to any Bunnings
store
(see www.bunnings.com.au for store locations) or contact Gale
Pacic.
Gale Pacic bears reasonable, direct, expenses of claiming under
the warranty.
You may submit details and proof to Gale Pacic for consideration.
The warranty covers manufacturer defects in materials, workmanship
and nish under normal use.
This warranty is provided in addition to other rights and remedies
you may have under law: our goods come with guarantees
which cannot be excluded under the Australian Consumer
Law or Consumer Guarantees Act 1993 (NZ). You are entitled to
replacement or refund for a major failure and to compensation for
other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure.
The warranty excludes damage resulting from product misuse or
product neglect.
The warranty covers domestic use only and does not apply to
commercial applications.
This warranty is given by Gale Pacic, ABN 80 082 263 778, 145
Woolands Dr Braeside Vic 3195, 1800 331 521, galepacic.com,
New Zealand #: 0800 555 171.
Fading due to weather exposure or damage to the frame and
fabric through accident, misuse or negligence. Your umbrella is a
non-permanent structure. Always ensure the umbrella is properly
weighted down. Damage caused by not following the instructions
will void your warranty.

MIMOSA CANTILEVER
UMBRELLA
Please check all parts against the parts list before commencing
construction of umbrella.
PARTS LIST
Make the most of your outdoor
living area with your very own
Mimosa cantilever umbrella. Relax
and enjoy the outdoors while being
protected from the sun.
The Mimosa powder coated
aluminium frame cantilever
umbrella is perfect for shading
your garden, deck, courtyard or
swimming pool.
IMPORTANT
This structure is a non-permanent
structure and the warranty does
not cover damage incurred under
extreme weather conditions
including heavy rain, high winds
or if exposed to high heat from
heaters or BBQs.
Safety precautions should always
be followed when assembling and
using this product to reduce the
risk of personal injury and damage
to equipment.
Please read all instructions before
assembly and use. Never leave
children unattended around/under
this umbrella.
Do not attempt to assemble or use
the umbrella in moderate or heavy
wind conditions. Always close
the umbrella and secure it during
heavy winds or extreme weather
conditions to avoid damage to the
umbrella or personal injury.
CODE PART QTY
A
Cross Base Bottom
1
B
Cross Base Top
1
C
Lower Pole
1
D
360° Swivel System
1
E
M8X14 Screw
4
F
M8X20 Screw
4
G
Washers
8
CODE PART QTY
H
Frame & Canopy
1
I
Crank Handle
1
J
Screw w/ Plastic Cap
1
K
Allen Key
1
L
Plastic Cone
1
M
Stay Pole
1
N
Cover
1

STEP BY STEP INSTRUCTIONS
Step 1: Using the allen key (K),
take screws (F) and washers (G)
to ix the 360 degree swivel
system to the cross base.
Step 2: Fix the lower pole (C )
to the 360 degree swivel system
using screws (E ) and washers (G).
MIMOSA CANTILEVER
UMBRELLA
Step 3: Place the plastic cone (L)
over the lower pole and position
over the 360 degree swivel system
so that the notch for the foot
pedal is located correctly and the
plastic cone sits straight.
Step 4: Lower the umbrella frame
and canopy onto the base
ensuring that the screw hole for
the screw with plastic cap (J)
lines up.

STEP BY STEP INSTRUCTIONS
Step 5: Secure the poles together
using the screw with plastic cap
(J). Tighten by turning clockwise.
Step 6: Operating the umbrella:
Using the easy glide handle, grip
the trigger and push the handle
upwards towards the top of the
umbrella pole until it locks into
place.
MIMOSA CANTILEVER
UMBRELLA

Step 7: Open the umbrella by
inserting and winding the rotating
crank handle (I).
Step 9: The umbrella can be
rotated 360 degrees by stepping
on the foot pedal and rotating
the umbrella pole to the preferred
locking position.
Step 8: Adjust the angle of the
canopy by pulling the trigger and
sliding the easy glide handle up
and down the post. Lock into
desired position.
STEP BY STEP INSTRUCTIONS
MIMOSA CANTILEVER
UMBRELLA
2

Step 10: To close the umbrella,
wind the canopy down with
the crank handle. Move the
easy glide handle to the bottom
position and wrap the velcro
straps around the canopy.
Step 11: Extend the stay pole
and insert it into the hem of the
umbrella cover. With the cover
unzipped, use the stay pole to
position the cover over the closed
umbrella. Use the string to close
the zip over the canopy.
* Ensure canopy is closed
when not in use. Close in windy
conditions or when a storm
approaches. Never allow the
umbrella to ap in the wind; this
could damage the canopy.
STEP BY STEP INSTRUCTIONS
MIMOSA CANTILEVER
UMBRELLA
