miniBatt miniBatt ULTRA-C User manual

ENGLISH
1
USER
MANUAL
Model:
miniBatt ULTRA-C
Thank you for choosing the MINIBATT ULTRA-C jump starter!
Always follow basic safety precautions when using electrical
appliances. Read all instructions carefully, Please keep this
instruction manual for easy reference.

ENGLISH
2
A. PRODUCT LAYOUT:
B. DISPLAY DESCRIPTION:
Battery Clamps
5V 2A input port
LED Flash Light
Backup Battery
(boost) Switch
12V 10A input port
LCD Display
Switch
LED Switch
Car battery voltage
Capacitor voltage
Car battery inner
resistance
Backup battery
percentage

ENGLISH
3
1. Switch button: touch switch button , LCD screen lights up.
2. Backup battery button: Press backup battery button over 2
seconds to charge the ultra-capacitor.When LCD screen shows
“JUMP STARTREADY”and backup battery can automatically output
for ultra-capacitor after 10 seconds.
3. LED light button:Touch the LED switch to start the LED flashlight.
There are 4 modes of LED light appear in order (normal. strobe. SOS.
off) if you press slightly.
1. Connect the jumper clamp to the car battery terminal, detect the
voltage and internal resistance of the car battery(Fig1 shows)
2. Connect the jumper clamp to the car battery terminal, the LCD
display shows“JUMP START READY”, the ultra capacitor can jump
start the car.The LCD display shows“CHARGING”, after 45 to 60S, the
LCD display will show“JUMP START READY”, the ultra capacitor can
jump start the car.
D. FLEXIBLE CHARGING METHODS AND JUMP
START STEPS:
C. KEY INSTRUCTIONS:
Fig 1

ENGLISH
4
Fig 2
Backup
Battery
3. Press the backup battery button to charge it by the backup
6000mAh battery (Fig 2 shows) , after 4min, when the LCD display
shows ”JUMP START REDAY”, the ultra capacitor can jump start the
car.
4. Use 12V cigarette lighter to charge it(Fig 3 shows) after two
minutes, the MINIBATT ULTRA-C voltage shows 15V,it can jump
start the car.
Fig 3
Fig 4

ENGLISH
5
5. Use the AC adapter to charge it(Fig 4 shows) after 20min and the
LCD displayer shows the ultra capacitor voltage 15V, it can jump
start the car.
6. Use the power bank to charge it(Fig 5 shows, optional）after 20min,
and the LCD displayer shows the ultra capacitor voltage 15V, it can
jump start the car.
Fig 5
ATENTION! Not charge when car battery goes below 5V
Connect Red Clamp to the positive (+)battery terminal）Black Clamp
to the negative(-)battery terminal, check the voltage and inner
resistance to determine if the car battery needs to be charged or to
be replaced.
E. CAR BATTERY DETECTION:

ENGLISH
6
F. LISTA DE PIEZAS:
G.TECHNICAL SPECIFICATIONS:：
#
2
Parts Name Quantity
1
Size: 250x120x50mm
Input: 5V 2A,12V 10A
Weight:） 1300g
Peak current: 700A
Backup Battery Capacity: 6000 mAh
Output: 12V cars Jump Start
1.Q. Why LCD screen shows“JUMP START READY” but can’t start the
vehicle?
A. After 10 seconds“JUMP START READY”showing on the LCD
screen, then can start the vehicle
H. FAQ:
3
Host
Switch cable
Car adapter
4 User Manual
1
1
1
1
Operating temp: -20ºC~60ºC/-4ºF~140ºF
Charging time for capacitor
Charging time for back-up battery:
Charging time from back-up
battery to ultral-capacitor:
6
20min(5V2A),2min(12V10A)
45S(car battery),4min(back-up battery)
4 hours (5V 2A)
50mins (12V 10A)

ENGLISH
7
2.Q. How many ways can charge this product? And how long for
each way?
A. Total 4 ways: this product can be charged with 5V/2A USB
cable (20minutes), 12V/10A car charger (2 minutes), backup
battery inside(4minutes) and normal car battery(45 seconds).
3.Q. Why super capacitor with 12V/10A or 5V/2A is full charging, but
LCD screen still shows”CHARGING”?
A. This is charging for backup battery inside the product, and
battery percentage will be displayed on the LCD screen.
4.Q. How many times can this product jump start the vehicle?
A. After using this product to start the vehicle, running car engine
5-10 seconds, super capacitor can be full charged again and
ready to start another vehicle.
5.Q. What is the lifetime for this product?
A. Generally 8-10 years.
I.TROUBLE SHOOTING:
J.TOXIC AND HARMFUL SUBSTANCES:
Finding Cause Remedies
No response when
pressing the switch
button.
Low voltage protection of
product is started.
Plug the adaptor into the
12V 10A or 5V 2A input port
to activate.
O: Indicate all homogeneous materials’hazardous substances content are below the
MCV limit specified in the Standard 2002/95/EC(RoHs).
Pb
0
Hg
0
Cr (Vi)
0
PBDE
0
Composition and amount of toxic and harmful substances in product.
Cd
0
PBB
0

ENGLISH
8
1. Read the instruction manual carefully before using this unit.
2. Jump for 12V vehicles only, it would be hazard if for other jumping.
It is forbidden to use for other machines such as aircraft,ship and so
on.
3. Caution while using this unit.
4. DO NOT use this unit if any cable clamp or cord is damaged.
5. DO NOT use in place of a vehicle battery.
6. DO NOT use as a battery charger.
7. Never remain the unit on car battery after cranking the car success.
8. Use the jumper cable provided with this unit only.
9. Make sure the BLUE plug of the jumper Cable is plugged fully into
jumping socket, Otherwise, the blue plug would be melted.
10. Make sure to check all the battery connections are CLEAN before
Jump Starting! Make sure the battery clamps are well connected! If
the battery terminals on the vehicle are dirty or corroded, the power
of the unit will be lessened.
11. DO NOT Jump Start more than 3 times in a row. It could damage
the unit by overheating. Give two minutes between attempts.The
jumping cable can become overheated and detach as a safety
measure.
12. Remove the product from the vehicle battery within 30 seconds
of Jump Starting. If not, it could lead to damage.
13. DO NOT connect the two clamps together.
14. Only jump start when 3 to 4 indicator lights are illuminated.
K.Warning:

ENGLISH
9
15. DO NOT use by young or infirm persons without supervision.
16. DO NOT use as a toy.
17. DO NOT allow the product to become wet.
18. DO NOT immerse the product in water.
19. DO NOT operate the product in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust.
20. DO NOT modify or disassemble MINIBATT ULTRA-C. Only a repair
technician may repair this unit.
21. DO NOT expose product to extreme heat or fire.
22. Make sure someone should be within range of your voice or close
enough to come to your aid when working with batteries.
23. Remove personal metal items like rings, bracelets, necklaces, etc.
When using the products.
24. DO NOT drop unit. If unit receives a sharp blow or is otherwise
damaged in any way have it checked by a qualified battery technician.
25. DO NOT store in locations where the temperature may exceed
70ºC.
26. Charge only at ambient temperature between 0ºC. and 60ºC.
27. Charge only using the charger provided with this unit.
28. DO NOT use the unit to jump start a vehicle while charging the
internal battery.
29. If this unit is leaking liquid dispose of at proper recycle facility
immediately.

ENGLISH
10
We offer a limited warranty for this product against any defects in
material and workmanship for a period of 2 years from the date of
purchase by the end user/consumer.The conditions of the warranty
are as follows:
1. The warranty is only valid upon presentation of the original receipt
(from dealer/retailer) by the original purchaser with the product to be
repaired or replaced.
2. The warranty is void if the serial number, date of purchase and label
has been removed.
3. The warranty does not cover damage or product failure resulting
from normal wear and tear, physical abuse, improper installation,
misuse, modification or repairs by nauthorized
third parties.
4. We do not assume responsibility for any loss or damage incurred
during shipment or as a result of a force majeure.
5. We are not liable for any incidental or consequential damages
arising from the use or misuse of this product.
6. All warranty claims are limited to repair or replacement of the
defective product and at the sole discretion of us.
7. If we repair or replace the product, the product will be covered
for the remaining time of the original warranty period.Repair or
replacement may involve the use of reconditioned units which
are equivalent in function. Replaced part or product becomes the
property of us.
8. Warranty on consumable components such as batteries are
covered for a period of 6 months from the date of purchase.
L.WARRANTY INFORMATION:

ENGLISH
11
Applied Standard: GB/T 18287 - 2000
Overcharge and
Overdischarge Protection
Fuse Protection Against-reverse Plug
MINIBATT Europe
VAT: ESB-08882151
Ctra. de Vic 99-101
08160 Montmeló
SPAIN
www.miniBatt.com
