miniBatt POCKET VR User manual

ENGLISH
1
USER
MANUAL
Model:
miniBatt POCKET VR
E
Thank you for choosing the MINIBATT POCKET VR! Always follow
basic safety precautions when using electrical appliances. Read
all instructions carefully, please keep this instruction manual for
easy reference.

ENGLISH
2
Indicator
Press the switch to check the storage level of MINIBATT POCKET VR
A. PRODUCT LAYOUT:
B. OPERATION GUIDANCE:
Indicator Unlit 1 Solid 2 Solid 3 Solid 4 Solid
Storage level 0% 25% 50% 75% 100%
Intelligent jumper
cable
Jump starts socket USB5V 2.4A Output
port
Jump start socket
Switch
LED Flash Light
USB5V 2.4A Output port
5V 2A input port
Indicator

ENGLISH
3
The indicator will flash one by one during the period of charging.
Different number of solid indicators show different storage level of
MINIBATT POCKET VR. All indicators light off when the charging is
paused or completed.
1. Plug the USB charger cable to the home charger USB output port.
2. Connect the Micro USB to the 5V2A Input port.
MINIBATT POCKET VR Charging Instruction:
1. Connect the blue plug fully seated into the host, and make sure the
Cable Indicator is off.
2. Connect Red Clamp to the positive (+) battery terminal, Black
Clamp to the negative (-) battery terminal.
Jump start 12V vehicle Instruction:

ENGLISH
4
3. Operate following the instruction of the Cable Indicator:
GREEN LIGHT on: Telling the connection is correct and the circuit is
working, you can turn on the engine to jump-start directly.
RED LIGHT on with buzzing: Telling the connection is wrong, and
buzzing to alarm to correct the clamps as step 2 mentioned above,
wait until the GREEN LIGHT is on to turn on the engine.
GREEN LIGHT blinking with buzzing: Saying the vehicle battery is
low, press the“BOOST”button, wait GREEN LIGHT becomes solid, then
turn on the engine within 30s.
No Lights on, No buzzing: Saying the vehicle’s battery maybe
damaged, after confirm the clamps connection is correct, press the
“BOOST”button, wait GREEN LIGHT is on, and then turn on the engine
within 30s.
4. Start the vehicle.
5. When the vehicle is started, remove the jumper cable from the
vehicle battery. Leave the vehicle’s engine running.
GREEN LIGHT RED LIGHT GREEN LIGHT
blinking with
buzzing
No Lights on
No buzzing

ENGLISH
5
1. Plug the switch cable to USB 5V 2.4A output port.
2. Select appropriate connector and connect it to your mobile
phones or tablet.
3. Press the switch button to charge.
Press the switch 3 seconds to start the LED flash light.
There are 4 modes of LED light appear in order (normal. strobe.SOS.
off) if you press slightly.
Charging Cell Phone or Tablet Instruction:
LED flash light

ENGLISH
6
C. PARTS LIST:
D.TECHNICAL SPECIFICATIONS::
#
2
Parts Name
Switch cable
Quantity
1
#
4
Parts Name
User Manual
Quantity
1
1Host 1 3 Intelligent jumper
cable 1
Size: 150x79x14mm
Input: 5V 2A
Weight: 190g
Full charging time: About 2 hours
Peak current: 400A
Battery Capacity: 4000 mAh (14.8Wh)
Output: 5V 2A ; 12V Jump Start
Starting current: 200A
Operating temperature: -20ºC ~ 60ºC
Q. How to turn off this appliance?
A. This appliance will power off automatically when no load or
charging is complete
Q. How long time to full charge the MINIBATT POCKET VR?
A. Approx. 2 hours through the 5V2A input port.
E. FAQ:

ENGLISH
7
Q. How many times can this appliance charge for my cell phone?
A. Approx. 2 times for iPhone6.
Q. How many times can this appliance jump start the vehicle if it is
in full battery?
A. Approx. 10 times.
Q. How about the lifetime of this appliance?
A. About 3-5 years.
Q. How long the storage of battery will remain?
A. 6-12 months, however, we suggest to recharge it every 3 months.
F.TROUBLE SHOOTING:
G.TOXIC AND HARMFUL SUBSTANCES:
Finding Cause Remedies
No response when
pressing the switch
button.
Low voltage protection of
product is started.
Plug the adaptor into
the 5V2A input port to
activate.
O: Indicate all homogeneous materials’hazardous substances content are below the
MCV limit specified in the Standard 2002/95/EC(RoHs).EC (RoHs).
Pb
0
Hg
0
Cr (Vi)
0
PBDE
0
Composition and amount of toxic and harmful substances in product.
Cd
0
PBB
0

ENGLISH
8
1. Read the instruction manual carefully before using this unit.
2. Jump for 12V vehicles only, it would be hazard if for other jumping.
It is forbidden to use for other machines such as aircraft,ship and so
on.
3. Caution while using this unit.
4. DO NOT use this unit if any cable clamp or cord is damaged.
5. DO NOT use in place of a vehicle battery.
6. DO NOT use as a battery charger.
7. Never remain the unit on car battery after cranking the car success.
8. Use the jumper cable provided with this unit only.
9. Make sure the BLUE plug of the jumper Cable is plugged fully into
jumping socket, Otherwise, the blue plug would be melted.
10. Make sure to check all the battery connections are CLEAN before
Jump Starting! Make sure the battery clamps are well connected! If
the battery terminals on the vehicle are dirty or corroded, the power
of the unit will be lessened.
11. DO NOT Jump Start more than 3 times in a row. It could damage
the unit by overheating. Give two minutes between attempts.The
jumping cable can become overheated and detach as a safety
measure.
12. Remove the product from the vehicle battery within 30 seconds
of Jump Starting. If not, it could lead to damage.
13. DO NOT connect the two clamps together.
14. Only jump start when 3 to 4 indicator lights are illuminated.
H.Warning:

ENGLISH
9
15. DO NOT use by young or infirm persons without supervision.
16. DO NOT use as a toy.
17. DO NOT allow the product to become wet.
18. DO NOT immerse the product in water.
19. DO NOT operate the product in explosive atmospheres,such as in
the presence of flammable liquids, gases or dust.
20. DO NOT modify or disassemble MINIBATT POCKET VR. Only a
repair technician may repair this unit.
21. DO NOT expose product to extreme heat or fire.
22. Make sure someone should be within range of your voice or close
enough to come to your aid when working with batteries.
23. Remove personal metal items like rings, bracelets,necklaces, etc.
When using the products.
24. DO NOT drop unit. If unit receives a sharp blow or is otherwise
damaged in any way have it checked by a qualified battery technician.
25. DO NOT store in locations where the temperature may exceed
70ºC.
26. Charge only at ambient temperature between 0ºC. and 60ºC.
27. Charge only using the charger provided with this unit.
28. DO NOT use the unit to jump start a vehicle while charging the
internal battery.
29. If this unit is leaking liquid dispose of at proper recycle facility
immediately.

ENGLISH
10
30. Under extreme conditions, battery leakage can occur. If a liquid is
noticed coming from product do not handle with bare hands. In case
of skin contact wash with soap and water immediately. If liquid comes
in contact with eyes rinse eyes with cold running water for at least 10
minutes and get medical attention immediately.
31. Product contains lithium based battery, at end of product life
dispose of product according to local regulation.

ENGLISH
11
We offer a limited warranty for this product against any defects in
material and workmanship for a period of 2 years from the date of
purchase by the end user/consumer.The conditions of the warranty
are as follows:
1. The warranty is only valid upon presentation of the original receipt
(from dealer/retailer) by the original purchaser with the product to be
repaired or replaced.
2. The warranty is void if the serial number, date of purchase and label
has been removed.
3. The warranty does not cover damage or product failure resulting
from normal wear and tear, physical abuse, improper installation,
misuse, modification or repairs by nauthorized
third parties.
4. We do not assume responsibility for any loss or damage incurred
during shipment or as a result of a force majeure.
5. We are not liable for any incidental or consequential damages
arising from the use or misuse of this product.
6. All warranty claims are limited to repair or replacement of the
defective product and at the sole discretion of us.
7. If we repair or replace the product, the product will be covered
for the remaining time of the original warranty period.Repair or
replacement may involve the use of reconditioned units which
are equivalent in function. Replaced part or product becomes the
property of us.
8. Warranty on consumable components such as batteries are
covered for a period of 6 months from the date of purchase.
I.WARRANTY INFORMATION:

ENGLISH
12
Applied Standard: GB/T 18287 - 2000
Overcharge and
Overdischarge Protection
Fuse Protection Against-reverse Plug
MINIBATT Europe
VAT: ESB-08882151
Ctra. de Vic 99-101
08160 Montmeló
SPAIN
www.miniBatt.com
