Minitor EW-01 User manual

-1--4- 2018.02.07 IME-EW-01
EW-01 WORK MARKER
Read following instructions thoroughly before attempting to use.
Keep this manual always in the vicinity of use for your reference.
Before using the unit, check if there are any damages on the unit due to
transport conditions.If any damages are found, contact our minimo dealer.
WARNING
(Indicates that incorrect operations presents significant danger of
accident resulting in death or serious injury to the user.)
SAFETY PRECAUTIONS
Wear an appropriate eye protection and a dust protecting mask when using the
handpiece.
Use the compressed air with the pressure 4
～ 7 kgf / ㎠ (56 ～ 99psi)
Do not disassemble and remodel the unit.
Any accident or malfunction caused by disassembling and/or remodeling will
not be covered by our responsibility.
Do not touch the point tool when vibrating.
○
○
○
○
WARNING
(Indicates that incorrect operations presents significant danger of
accident resulting in death or serious injury to the user.)
CAUTION
(Indicates that incorrect operation presents possibility of injury to the
user or damage to the unit.)
Never push the point tool hard onto the workpiece.
Excessive force on the tool will cause damage to the tool and also reduce the
cutting power.
Employ the air filter and/or dryer to eliminate water, water vapor and any other
dust particle in the compressed air.
Avoid any heavy impact to the unit. Do not drop it!
Keep the unit away from children.
○
○
○
○
6. PARTS LIST
1.Point Tool EW-101
2.Bush EW-102
3.O-Ring EW-103
4.Front Housing EW-104
5.Front Spring EW-105
6.O-Ring (7.66×1.78) EW-106
7.O-Ring (12.1×1.6) EW-107
8.O-Ring (2.5×1.8) EW-108
9.Valve Ball EW-109
10.Switch Valve EW-110
11.O-Ring (3.1×1.6) EW-111
12.Ball Guide EW-112
13.Rear Spring EW-113
14.Housing EW-114
15.O-Ring (11.1×1.6) EW-115
16.Rear Housing EW-116
17.Hose Connector M7 EW-117
18.Air Hose Black 2.5m EW-118
19.Hose Connector 1/4 EW-119
20.Coupler EW-120
21.Bronze Bush EW-121

-3--2-
1. PACKING LIST
◇ WORK MARKER (EW-01) with air hose
◇ Instruction Manual
・・・・・・・・・・・・・・・・・ 1 PC.
・・・・・・・・・・・・・・・・・ 1 PC.
2. FEATURE
＊To make a marking on hardened surface such as high speed steel, bearing
steel, and other metals; also on glass and plastic.
＊The point tool is made out of tungsten carbide, and easy to replace.
3. INSTALLATION
1）First, make sure that the switch valve is off.
2）With the off position of the switch valve, connect the coupler to an air
compressor.
※Caution : Never connect the coupler to an air compressor when the switch
valve is in the state of “ON” .
It may cause an unexpected accident.
The state of “OFF”
The state of “ON”
4. OPERATION
1）Push the switch valve on to start.
2）Hold the handpiece close to the point as possible and put it straight up to
make a better carving.
3）Push the switch valve off to stop.
5. MAINTENANCE
5-1. Lubrication
Once a day, or once at a time (depends on the frequency of use), put a small
amount of lubricating oil at a mouth of the air hose.
It lubricates with the air.
5-2. Exchange the point tool
To exchange the point tool(EW-101),
＊When exchanging the parts, use our genuine parts to get a right
characteristics and dimensions of the parts.
＊Please pay attention not to get any foreign substances into the handpiece
when exchanging the tool and/or other parts.
1）Hold the center part of the handpiece,
and turn the front housing to loosen.
If it is too hard to turn, clamp the
handpiece softly by a small vise, and
try to turn it loose.
＊Do not clamp it too hard.
The housing may be broken.
2）Then, take out the point tool from front
housing.
Amount the O-Ring and the front
spring on the new point tool as the
figure on the right.
3）Put the new point tool into the front
housing.
Then, tighten the front housing back to
the handpiece.
Loosen
Tighten
Housing EW-114
Front Housing EW-104
Front Spring EW-105
Point Tool EW-101
O-Ring EW-106
