minkaAire CONTRACTOR Series User manual

Model NO. F670L
AIRETOR III

©2021 Minka Lighting Inc. Manual design and all elements of manual design are
protected by United States Federal and/or State Law including Patents, Trademark,
and/or Copyright Laws.

Date Purchased
Store Purchased
Model Number
The Minka-Aire® warranty is for one (1) year from the
date of purchase from an authorized Minka-Aire® dealer.
This warranty is only valid to the original purchaser or user
against all defects in material and workmanship (light bulbs
excluded) for one (1) full year. Additionally, Minka-Aire® warrants the motor only for
the lifetime of the Minka Aire ceiling fan (excluding wall controls and electrical
components), to the original purchaser or user.
F670L
Warranty Service Information
To obtain warranty service during the warranty period, the purchaser should
return the fan with the sales receipt to the original place of purchase. The authorized
Minka-Aire® dealer, at its sole discretion, will either repair or replace the fan after
verifying the legitimacy of the warranty claim. Replacement is subject to availability
of the same model. If the model is unavailable it will be replaced by one of equal
value. This is a limited warranty; the original purchaser or user is responsible for the
cost of removal and reinstallation of repaired or replacement product.
To obtain the name of the Minka-Aire® authorized dealer nearest you call the
Minka-Aire® customer care department at 1-800-307-3267, or contact Minka-Aire®
through www.minkagroup.net and select FAQ to answer any questions or if you
require additional assistance submit the question form found there.
The warranty is voided with the use of any non- Minka-Aire®electrical devices, e.g.,
wall controls or electrical dimmer switches, etc…
The warranty is void once the original purchaser or user ceases to own the fan or the
fan is moved from its original point of installation.
The warranty is void with the use of any hanger bracket (non-Minka Aire or non-fan
specific) other than the hanger bracket supplied & installed with this specific fan.
*
*
*

14
INSTALLING THE GLASS SHADE
6
8
10
INSTALLING THE LIGHT KIT PLATE
INSTALLING THE 16W LED ASSEMBLY
9

WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR OTHER PERSONAL INJURY, MOUNT FAN
ONLY TO A U.L. LISTED OUTLET BOX OR SUPPORTING SYSTEM MARKED ACCEPTABLE FOR FAN
SUPPORT AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX IN CONJUCTION
WITH THE LOCK WASHERS PROVIDED WITH THE FAN. MOST OUTLET BOXES COMMONLY
USED FOR FAN SUPPORT OF LIGHTING FIXTURES ARE NOT ACCEPTABLE FOR FAN SUPPORT
AND NEED TO BE REPLACED. CONSULT A QUALIFIED ELECTRICIAN IF IN DOUBT.
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE HOLDERS WHILE
INSTALLING, BALANCING THE BLADES OR CLEANING THE FAN. DO NOT INSERT FOREIGN
OBJECTS BETWEEN ROTATING FAN BLADES.
NOTE: The important safeguards and instructions appearing in this manual are not
meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution and care are factors which can not be built
into this product. These factors must be supplied by the person (s) installing, caring
for and operating the unit.
NOTE:READ AND SAVE ALL INSTRUCTIONS!
1
TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, DO NOT USE THIS FAN WITH ANY
SOLID-STATE SPEED CONTROL DEVICE.
READ AND SAVE THESE INSTRUCTIONS.
1. To reduce the risk of electric shock, ensure electricity has been turned off at the
circuit breaker or fuse box before beginning.
2. All wiring must be in accordance with the National Electrical Code “ANSI/NFPA 70-
1999” and local electrical codes. Electrical installation should be performed by a
qualified licensed electrician.
3. The outlet box and support structure must be securely mounted and capable of
reliably supporting a minimum of 35 Ibs. Use only UL-listed outlet boxes marked
“FOR FAN SUPPORT.“
4. The fan must be mounted with a minimum of 7 ft. clearance from the trailing edge
of the blades to the floor.
5. Avoid placing objects in the path of the blades.
6. To avoid personal injury or damage to the fan and other items, be cautious when
working around or cleaning the fan.
7. Do not use water or detergents when cleaning the fan or fan blades. A dry dust
cloth or lightly dampened cloth will be suitable for most cleaning.
8. After making electrical connections, spliced conductors should be turned upward
and pushed carefully up into the outlet box. The wires should be spread apart with
the grounded conductor and the equipment-grounding conductor on one side of the
outlet box and ungrounded conductor on the other side of the outlet box.
9. All setscrews must be checked and retightened where necessary before installation.
10. Turn the fan off and wait for the blades to stop completely before performing any
maintenance or cleaning.

3/16”x12.7 mm blade screws
(9+1 spare)
11.
3
10. Glass shade
2
Fiber washer (9+1 spare)
8. Light kit plate
9. 16W LED assembly

Tools Required: Phillips screw driver; slotted screw driver; step-ladder; wire cutters;
electrical tape.
MOUNTING OPTIONS
If there isn't an existing mounting box, then read
the following instructions. Disconnect the power
by removing fuses or turning off circuit breakers.
Secure the outlet box directly to the building
structure. Use appropriate fasteners and building
materials. The outlet box and its support must be
able to fully support the moving weight of the fan
(at least 50 lbs.). Use a UL Listed metal outlet box.
Do not use a plastic outlet box.
Figure 1, 2 and 3 are examples of different ways to
mount the outlet box.
NOTE: You may need a longer downrod to maintain
proper blade clearance when installing on a steep,
sloped ceiling. Longer downrods are available from
your Minka-Aire
®
dealer.
To hang your fan where there is an existing fixture
but no ceiling joist, you may need to install a
hanger bar as shown in Fig. 4 (available at your
Minka-Aire
®
dealer).
Fig. 1
CROSS
BRACE
CEILING
JOIST
OUTLET BOX
Fig. 2
PARALLEL WOOD BRACE
(MIN. 2" THICK)
OUTLET
BOX
CEILING JOIST OR
CROSS BRACE
Fig. 3
ANGLED CEILING
MAXIMUM 18° ANGLE
PROVIDE
STRONG
SUPPORT
RECESSED
OUTLET BOX
HANGER
OPENING
must be
FACING
UPSIDE
Fig. 4
OUTLET BOX
HANGER BAR
(OPTIONAL)
HANGER
BRACKET
CEILING
JOIST
CEILING
JOIST
3

WARNING: All of the parts, hardware and components such as the hanger bracket
and hanger ball have been provided for your safety and the proper installation of
your new ceiling fan. The use of other parts, hardware or components not supplied
by Minka Aire® with the fan will void the Minka Aire Warranty.
REMEMBER to turn off the power. Follow the steps below to hang your fan
properly:
Secure the hanger bracket to the ceiling outlet box
using screws included with your outlet box, lock
washers included with the fan. (Fig.5)
Carefully feed fan wires up through the downrod.
(Fig. 8) Thread the rod into the coupling, next line
up holes and replace lock pin and hitch pin. Tighten
set screws.
Remove hanger ball from downrod assembly by
loosening set screw, removing the cross pin, and
sliding ball off rod. (Fig.7)
Loosen the two set screws and remove the hitch pin
and lock pin from the top coupling of the motor
assembly. (Fig. 6)
Step 1.
Step 2.
Step 3.
Step 4.
Fig. 8
DOWNROD
SUPPLY
WIRES
Fig. 6
HITCH
PINLOCK
PIN
SET SCREWS
Fig. 7
CROSS PIN
HANGER
BALL
DOWNROD
SET SCREW
OUTLET BOX
HANGER BRACKET
Fig. 5
®
4

5
Step 5.
Step 6.
Slip coupling cover, canopy cover
and canopy onto downrod. (Fig.
9) Carefully reinstall hanger ball
onto rod being sure that cross
pin is in the correct position, set
screws are tighten and wires are
not twisted.
Now lift motor assembly into
position and place hanger ball
into hanger bracket. Rotate until
the check groove has dropped
into the registration slot and
seats firmly. (Fig. 10) Rod should
not rotate if this is done
correctly.
Fig. 10
REGISTRATION
SLOT
Fig. 9
CANOPY COVER
DOWNROD
CANOPY
SET SCREWS
HITCH PIN
LOCK PIN
COUPLING COVER

6
Step 2. Connect the ground wire (Green or Bare Copper) to the ground wire from
hanger ball and the ground wire from hanger bracket. (Fig.11)
Fig. 11
.11

Step 1. Insert the blade through the slot on the fan motor assembly. (Fig.13)
Step 2. Attach the fan blade to the fan motor assembly using the three blade
screws and three fiber washers securely. (Fig.13)
Step 3. Repeat this step with the other two blades. (Figure 13)
BLADE SCREW
BLADE
12
12
7
Fig. 12
OUTLET BOX
HANGER BRACKET
HANGER BALL
CANOPY
CANOPY COVER
Fig. 13
FAN MOTOR
ASSEMBLY
FIBER WASHER

14
1
3
8
CAUTION: To Reduce The Risk Of Electric Shock, Disconnect The Electrical Supply
Circuit To The Fan Before Installing Light Kit.
Step 2. While holding the light kit plate under your fan, firmly snap the wire connection
plugs together. (Fig.14)
14
INSTALLING THE LIGHT KIT PLATE
SCREW
CONNECTION
PLUG
Fig. 14
MOUNTING
RING
LIGHT KIT
PLATE
CONNECTION
PLUG

9
15
216W LED assembly
BLACK WHITE
Step 1. Remove 1 of 3 screw from the pillar of light kit plate and loosen the other 2
screws. (Do not remove) (Fig.15)
Step 3. Place the key holes from the 16W LED assembly over the 2 screws previously
loosened from the pillar of light kit plate, Turn the 16W LED assembly until it locks in
place at the narrow section of the key holes. Secure by tightening the 2 screws
previously loosened and the one previously removed. (Fig.15)
CAUTION: To Reduce The Risk Of Electric Shock, Disconnect The Electrical Supply
Circuit To The Fan Before Installing Light Kit.
INSTALLING THE 16W LED ASSEMBLY
Fig. 15
PILLAR OF
LIGHT KIT
PLATE
CONNECTION
PLUG
16W LED
ASSEMBLY
SCREW

17
PULL CHAIN FOB
Attach the glass shade to the light kit plate by twisting tightly. (Fig.16)
16
INSTALLING THE GLASS SHADE
GLASS SHADE
LIGHT KIT PLATE
10
(Fig.17)

18
19 20
19
20
The Reverse switch is located on light kit assembly (Fig.18). Slide the switch
to the Left for warm weather operation. Slide the switch to the Right for cool
weather operation.
11
FAN LIGHT

WARNING!
MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX BEFORE
YOU ATTEMPT ANY REPAIRS. REFER TO THE SECTION, “ELECTRICAL
CONNECTIONS”.
12

13

1,988 14.36 138
4,495 63.67 70
6.68 9.28 1.939'
14
54
120 0.26 14.36 81
120 0.53 63.67 178
11
3,320
82
41
