Mintpass Mintpad MP100 User manual

www.mintpass.co.kr
3107$

■THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
■Caution : Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
■NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, any cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC RF
“CAUTION” : Exposure to Radio Frequency Radiation.”
Antenna shall be mounted in such a manner to minimize the potential for human contact during normal operation.
The antenna should not be contacted during operation to avoid the possibility of exceeding the FCC radio
frequency exposure limit.
To comply with FCC RF exposure compliance requirements, for mobile configurations, a separation distance of at
least 20 cm must be maintained between the antenna of this device and all persons.
SAFETY
“CAUTION”
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instruction.
“This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.”
Safety rules

Copyrights©2008 mintpass.co., LTD. All rights reserved.
Mintpad is a Wi-Fi enabled portable network device. It has communica-
tion functions, such as Internet blogging and chatting; and multimedia
functions, such as movies, music, and pictures. Users can create various
contents from the web and enjoy them on Mintpad. It is an outstanding
portable network device that has strong memo function, and it can take
pictures and upload them to the web directly.
Product Introduction

Locating components
3
LED Display
72.644mm Touch-screen
Microphone
TTA USB connector
Hold-Switch
Used for displaying battery, Wi-Fi,
and other status.
Used for various actions and functions.
Used to recharge
or to connect with PC.
Used for voice recording.
Used to lock the touch screen
or the buttons.
FRONT
4
Smart button
Stylus pen
Camera
Earphones jack
Speaker
Battery cover
Power button
Strap hole
Used to add a strap. Used to connect earphones.
Used to power on/off.
Used to take pictures
and capture videos.
Used on the touch-screen.
Used to display status bar
or other actions according
to the assigned setting.
Slide open to change battery
or micro SD card.
Used for audio.
BACK

The side with ( ) sign is the front side.
Push the battery cover to the direction
shown ( ) to remove.
Place the battery front side up and
then push it all the way.
Inserting battery
5
Take out the battery by using a finger
nail to lift the part with sign.
Removing battery
Battery Micro SD card
Once the battery is removed, the Micro SD card slot will be found.
If properly inserted, there will be a “click” sound.
To remove the Micro SD card, push the card and it will be pulled out.
Insert/remove Micro SD card
6
The side with Micro SD logo is
the front.

Menu scrolling
7
Turn the power button on and the menu screen will appear soon.
Slide on the screen with left, right, up, down direction to scroll through menus.
As if flipping to the next page, slide on the screen from right to left to proceed
to the chosen menu.
The above actions are the basic operational instruction
for Mintpad.
Although most of the actions will comply
with the above instruction, they do not apply to
all of the applications, so actions may differ depending on the situations.
Play (next)
Move up the menu
Previous (back)
Move down the menu
Basic operations
sliding on the screen
8
TIP
A finger can replace the stylus pen for any action.

Using quick-menu
Quick-Menu
Current position display
Quick-Menu area
Quick scrolling through the menu
View all the menus
Moving thru menu
Click on the left side of the menu and
the Quick-Menu will appear.
For the Quick-Menu, up/down scroll is possible
like the menu screen. It displays current menu selection,
and it can scroll through the each menu quickly.
The Quick-Menu will disappear if no particular action is taken.
From the main menu screen, slide right on the screen to
view the menu thumbnails list. Double click on the desired
menu icon to proceed to that menu.
To go back to the menu thumbnails list, slide right on the
screen again.
9
If the menu screen is scrolled up/down, the current menu selection on the Quick-Menu
will be indicated accordingly.
TIP
Status Bar
Using the Status Bar
Shortly press the “Smart Button” to
display the Status Bar on the bottom of
the screen.
Current time, Wi-Fi status, volume, and
battery status are displayed on the Status
Bar on a real-time basis.
Through multitasking icon, you can use
other functions while listening to music.
Touch each of the area to set the
corresponding option.
Short-press the Smart Button
Current time & Alarm
Wi-Fi status Volume
multitasking icon
Battery status
10
To remove the Status Bar, simply push the Smart Button again or click on the area
other than the bar.
Press and hold the Smart Button for action that was assigned.
(Go to the Menu Setting > Smart Button to assign the button’s action)
TIP

LED Display
The LED display on the top-left side of Mintpad
shows the device’s status.
A user can recognize the status by the color and the
blinking type of LED.
11
Product status according to LED color
Battery
Low Battery Red LED on +
Green LED Blinking Red LED is on
Orange LED is on
Green LED is on
Orange LED on +
Green LED Blinking
5HG/(' 2UDQJH/('
* On - Light is constantly on
* Blinking - Light on and off repeatedly
*UHHQ/('
Green LED on +
Green LED Blinking
Recharging
Fully
recharged
Wi-Fi On Wi-Fi Off
12

Taking Memo
A new memo screen is pulled out, if the “Memo” is selected from the menu screen.
Take Memo
The page is displayed yellow
when taking a memo
13
Click on the Memo option tab to select font
size and color.
To save the Memo, simply click on the
“save” tab or shake the device.
If the memo is saved, the background color will change
to white. At this mode, memo-by-memo viewing is
possible.
Slide on the screen up or down to view other memo
from here.
Memo taking and saving
Viewing the Memo
14
For quick saving the memo, shake the device.
TIP
Click on the tab and option window will appear;
click on the tab to go back.
Save
(memo-by-memo view)
Calendar
Memo Option
Cancel memo

New Memo
New Memo
Calendar
Edit
Delete
15
Taking Memo
From the memo-by-memo view, slide on the screen from
left to right( )to view the thumbnails list.
You can view the saved memo or take a new memo.
Selected thumbnail can be edited or deleted.
Click the yellow tab on the left side or double-click the
memo icon on the bottom right side to take a new memo.
Slide on the screen up or down to view more saved memo on the next
thumbnails list.
Managing memo from thumbnails list
Scrolling through thumbnails list
(
(
16
From thumbnails list, double-clicking on the memo that you want to see will convert to
memo-by-memo view.
You can make a back up file for your memo by going on to the Mintpass homepage’s
memo category
TIP

%QPPGEVKPIYKTGNGUUPGVYQTM
17
Some of the Mintpad’s functions can only be used with Wi-Fi connection.
Once wirelessly connected, the list of Wi-Fi connection and USB connection will appear.
Making wireless network connection
It shows the list of
available networks.
It turns on/off and
set auto-connection.
It shows currently
connected network information.
It shows your Mintpad’s
MAC address.
It is used to configure USB cable
connection to recharge while playing
In order to make a connection, double-click or scroll from right to left( )
on the selected wireless network.
Password need to be entered for making a connection to the network with
a lock icon.
Connecting to the selected network
18
To view more wireless networks,
scroll up or down on the screen.
This network is
secured with password.
( )

Enjoying Mintpad
Mint Chat
wi-fi
Schedule
Camera
Multi-fun,
Device-to-Device memo chatting
is possible.
The camera can capture motion pictures
as well as take pictures.
Personal name/business card & schedule making
is possible using the memo function.
19
Mint Blog
wi-fi
Mint Life
Contents
Multimedia
wi-fi
Various multimedia functions
like music, videos, photo album,
and voice recording can be enjoyed.
Photo, message, or personal memo can be directly
uploaded to a blog without using PC.
Mint Life contests can be enjoyed
with other Mintpad users.
Various contents created from the web
can be downloaded.

Safety precautions
For safety reasons,
please read carefully the followings.
Please do not let any liquids, such as water, juice, coffee, oil, or pet’s
urine, contact with or smear into the device. In case the liquid has
smeared into the device, take out and wipe the battery immediately
and contact the mintpass customer support center.
If no action is taken when wet, it may cause fire, electric shock, and
malfunctions.
Avoid liquids at all times
Please do not disassemble, modify, or fix the device yourself.
Please do not damage the battery pack’s label, for it can cause
leakage, fire, electric shock, and malfunctions.
Do not disassemble or modify
21
Do not use the stylus pen for other than the intended purpose. It may
cause injuries in some occasion.
The device may be damaged using the pen that is damaged or bent.
Precautions with using Stylus pen
Avoid using the device under the strong sun rays or in a freezing
weather.
Please avoid situation where dew forming from sudden temperature
change is possible. Moisture formed inside the machine may cause
problems.
Do not use in extreme weather
Please avoid dropping or applying strong force to the device.
It may cause internal damage or battery leakage; there may be
overheating or even fire as a result.
Do not impact the device
22

If the battery liquid is contacted with skin, rinse with water immedi-
ately and contact your physician.
What to do if the battery leaks
Avoid licking or contacting the negative (anode) and positive
(cathode) electrodes with metallic objects. Possible explosion or
overheating may occur.
Battery electrodes precaution
Please do not tie the USB cable too tight.
Please do not forcefully pull the cable nor damage the cable with
sharp items.
Do not damage the USB cord
23
Operational precautions Screen precautions
Normal operation may be difficult, if the screen panel is damaged.
Please exercise caution or it may damage the LCD. Handle with care.
Sharp objects should be restricted
Other object can inadvertently damage the device or its screen to
cause problems or malfunctions.
Avoid storing the device in the pocket with other objects
It may cause internal damage or screen damage; it may cause injuries
or malfunction.
Avoid applying heavy force to the screen
24
To avoid damaging the screen,
please read carefully.

25
When using Wi-Fi,
pay attention to the following.
According to the in-flight regulation, the use of all wireless communi-
cation devices is prohibited by law, unless instructed otherwise by the
navigating officer.
Do not use inside the airplane
The radio signal from Mintpad can inadvertently affect the medical
devices.
Do not use in hospitals
It may inadvertently affect the persons wearing the heart pacemaker.
Do not use in crowded area
Wi-Fi Precautions

oV~GzG zV~GzG
G pG zG G pG zG
jw|G {G{jj^`WXO[WWto¡PG vzG vGzG ~puGjlG\UWGwG
vG ~GjlG\UWGwG mG{G ZSGSGSGSGG
zG
tG XY_tiGzkyhtG iGG
ZSGSGaG_G¥GZYWGSG
GaGxXWG
{G YU_]”GjG{m{GsjkGG{GzG {G pkZG}XG{SGpkZG}YGYUWSGpkZG}YGZUW
kG
yG x}nhOZYWY[WPG lxG XYGGlxSGX]GwGlxG
uhukGmG _niSG[niG
hG
mGyG YWo¡G¥GYWo¡G
zG
tGzG tzkGzGzkojOGG_niPG mG{G SGSG[G
~TshuG _WYUXXGVG
}G
mG ZWGgGx}nhG
~TmG
hG pGhGOjGhPG pG qGVG qwlnSGitwG
{G sTpGyGiGwG {G {GG {GSG|G
iG
jG `WWGhG G G G
|ziG |ziGkGYUWGGG G G G
zG tGzGO\WW~PG G G G
tG iTGtG G G G
z¡G ^_UZGG]_U]GGX\UZGG G G G
l{jG
~G hUG`WG G G G
