Minuteman Endeavor 5 User manual

User's Manual
Endeavor 5 - 10KVA
Step Down Transformer
Para Systems, Inc.
1455 Lemay Dr.
Carrollton, TX 75007
Phone: [phone]
Fax: [phone]
Internet: minutemanups.com
UPS Sizing: sizemyups.com
PN - 34000473 R2

1
1. Introduction 2
2. Rear Panels 6
3. Installation 8
4. Operation 14
5. Obtaining Service 16
6. Specifications 17
7. Limited Product Warranty 18
A1. Declaration of Conformity 19
Table Of Contents

3
2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS !
WARNING: This ED-XFR contains potentially hazardous voltages. Do not
attempt to disassemble the unit. This unit contains no user serviceable parts.
Repairs must be performed by QUALIFIED SERVICE PERSONNEL ONLY.
Chapter 1: Introduction
Thankyouforpurchasingthispowerprotectionproduct. Ithasbeendesigned
and manufactured to provide many years of trouble free service. Please read
this manual before installing your Endeavor Series step down transformer
(ED-XFR), models ED5000RT-XFR, ED6000RT-XFR, ED8000RT-XFR and
ED10000RT-XFRasit provides important information that should befollowed
during installation and maintenance of the ED-XFR allowing you to correctly
set up your system for the maximum safety and performance. Included is
information on customer support and factory service if it is required. If you
experienceaproblemwiththeED-XFR please refer to Obtaining Service sec-
tion in this manual to collect enough information so that the Technical Support
Department can rapidly assist you.
CAUTION! TheED5000RT-XFRandED6000RT-XFRcomewithanattached
#10 AWG input power cord. Connect the input power cord to the output
terminal block on the UPS. TheAC inputs of these Step Down Transformers
are ONLY intended to be connected to the output of their respective UPS
models. Do not use extension cords, adapter plugs, or surge strips. The
installation of upstream and downstream protective devices is highly recom-
mended when the UPS system is connected to the mains and the load.
CAUTION! TheED8000RT-XFRandED10000RT-XFRcomewith an#6AWG
input power cable in the box. The pins for the input and output cables are
included. Connectoneendofthe input power cable to the input terminal block
on the ED-XFR. Connect the other end of the input power cable to the output
terminal block on the UPS. TheAC inputs of these Step Down Transformers
are ONLY intended to be connected to the output of their respective UPS
models. Do not use extension cords, adapter plugs, or surge strips. The
installation of upstream and downstream protective devices is highly recom-
mended when the UPS system is connected to the mains and the load.
CAUTION! To reduce the risk of electrical shock with the installation of this
unit and the connected equipment, the user must ensure that the ED-XFR is
properly grounded due to a possible risk ofAC current leakage.
CAUTION! This ED-XFR series is ONLYintended to be installed in an indoor
temperature controlled environment that is free of conductive contaminants.
This ED-XFR series is not intended for use in a computer room as defined in
theStandardfor the Protection ofElectronicComputer/DataProcessingEquip-
ment ANSI/NFPA 75. The AC inputs of these Step Down Transformers are
ONLY intended to be connected to the output of their respective UPS models.
TheED-XFR's input voltagesetting must bethe same asthe UPS'soutput voltage
setting.
CAUTION! The maximum ambient operating temperature for this ED-XFR
series is 40°C (“0 ~ 40°C” for Ambient Operation).
Theexternalventsand openings on the unit are provided for ventilation.
To ensure reliable operation of the unit and to protect the unit from over-
heating,these vents and openingsmustnotbeblocked or covered.Donot
insert any object into any of the vents or openings that may hinder the ve-
ntilation.
Install the unit in a well ventilated area, away from excess moisture, heat,
dust,flammable gas or explosives.
Leave adequate space (at least 15cm) around all sides of the unit for pr-
operventilation.
Donotmounttheunit with its front or rear panel facing down at any angle.
Before usage, you must allow the unit to adjust to room temperature
(20°C~25°C or 68°F~77°F) for at least one hour to avoid moisture cond-
ensing inside the unit.
WARNING: Qualified Service Personnel ONLY must perform the Installa-
tionandServicing of these ED-XFR. MINUTEMAN acceptsnoliabilitiesand is
not limited to: injury to the Service Personnel, or damages to; the Step Down
Transformer, the UPS, the Battery Pack, or the connected equipment caused
by the incorrect installation or servicing of the UPS system. These ED-XFR
MUSTbeoperatedwiththeirrespectiveUPSmodels,seethetablebelow:
ED-XFR ED8000RT-XFR
ED10000RT-XFR
UPS
ED5000RT-XFR
ED6000RT-XFR
ED8000RT-CU
ED10000RT-CU
ED5000RT-CU
ED6000RT-CU
WARNING: When using these Step Down Transformers with their respective
UPS models, the load capacity of the UPS MUST be derated as follows:
ED8000RT-CU
ED8000RT-XFR
ED6000RT-CU
ED6000RT-XFR
6889VA
6200Watts
5556VA
5000Watts
ED5000RT-CU
ED5000RT-XFR
4556VA
4100Watts
ED10000RT-CU
ED10000RT-XFR
8889VA
8000Watts
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE STEP
DOWN TRANSFORMER. The mounting brackets are ONLYfor securing the
unit to the rack.

5
4
LIFE SUPPORT POLICY
As a general policy, Para Systems does not recommend the use of any of our
productsinlifesupport applications where failure or malfunction of the product
can be reasonably expected to cause failure of the life support device or to
significantlyaffect its safety oreffectiveness. Wedonot recommend theuseof
any of our products in direct patient care. We will not knowingly sell our prod-
uctsforuseinsuch applications unless it receives in writing assurances satis-
factoryto us that (a)therisksofinjury or damage havebeenminimized, (b)the
customer assumes all such risks, and (c) our liability is adequately protected
underthecircumstances.
Examplesof devicesconsideredtobe lifesupportdevicesare neonataloxygen
analyzers,nervestimulators(whether used for anesthesia, pain relief, or other
purposes), auto transfusion devices, blood pumps, defibrillators, arrhythmia
detectorsandalarms,pacemakers,hemodialysissystems,peritonealdialysis
systems,neonatalventilatorincubators, ventilators for both adults and infants,
anesthesiaventilators,and infusion pumps as well asanyotherdevicesdesig-
nated as “critical” by the United States FDA.
Once you receive the product it should be visually inspected for damage that
may have occurred in shipping. Immediately notify the carrier and place of
purchase if any damage is found. Warranty claims for damage caused by the
carrier will not be honored by the manufacturer. The packing materials that
the product was shipped in were carefully designed to minimize any shipping
damage. In the unlikely case that the product needs to be returned to the
manufacturer, use the original packing material. Since the manufacturer is
not responsible for shipping damage incurred when the product is returned,
the original packing material is inexpensive insurance. PLEASE SAVE THE
PACKINGMATERIALS!
RECIEVING INSPECTION
NOTICE: Thisequipmenthasbeentested and found to comply with the limits
for a Class B computing device in accordance with the specifications in Sub-
partJof Part 15 of FCC Rules and the Class Blimitsforradio noise emissions
fromdigital apparatus setoutin the RadioInterferenceof the CanadianDepart-
ment of Communications. These limits are designed to provide reasonable
protection against such interference in a residential installation. This equip-
mentgenerates andusesradio frequencyandif notinstalledandusedproperly,
that is, in strict accordance with the manufacturer's instructions, this equip-
ment may cause interference to radio and television reception. If this equip-
ment does cause interference to radio or television reception, which can be
determinedby turningtheequipment offandon,the userisencouraged totryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
Re-orientthe receivingantenna.
Relocatethecomputerwithrespect to the receiver.
Movethe computer away fromthereceiver.
Plugthecomputerintoadifferent outlet so that the computer and receiver
areondifferentbranchcircuits.
Shieldedcommunicationsinterface cables must be usedwiththisproduct.
WARNING: Changes or modifications to this unit not expressly approved by
thepartyresponsiblefor compliance could void the user's authority to operate
theequipment.
© COPYRIGHT 2014 BY PARASYSTEMS, INC.
AllRightsReserved.Allrightsof this User Manual (“Manual”), including but not
limited to the content, information, and figures are solely owned and reserved
by Para Systems, Inc. (“Para Systems”). The Manual can only be applied to
the operation or the use of this product.Any disposition, duplication, dissemi-
nation, reproduction, modification, translation, extraction, or usage of this
Manual in whole or in part is prohibited without the prior written permission of
ParaSystems. Given thatParaSystems will continuouslyimproveand develop
the product, changes may be made to the information in this Manual at any
time without obligation to notify any person of such revision or changes. Para
Systems will make all possible efforts to secure the accuracy and the integrity
of this Manual. Para Systems disclaims any kinds or forms of warranty, guar-
antee,orundertaking,either expresslyorimplicitly,includingbut not limited to
thecompleteness,faultlessness,accuracy,non-infringement, merchantability
or fitness for a particular purpose of the Manual.
CAUTION! To de-energize the outputs of the ED-XFR:
1. Turn off the Load breakers on the rear panel of the ED-XFR.
2. If the UPS is on press and release the On/Off/Test button after the sec-
ond beep.
2. Turn off the input circuit breaker on the rear panel of the UPS.
3. Turn off the DC breaker on the rear panel of the Battery Pack.
4. Disconnect the UPS from theAC source.

7
6
Chapter 2: Rear Panels
1. The Load 4 circuit breaker will trip in the event the load exceeds the power
rating.
2. Load4: 120V output receptacles (3 - 5-15/20R).
3. The Load 3 circuit breaker will trip in the event the load exceeds the power
rating.
4. Load3: 120V output receptacles (3 - 5-15/20R).
5. The Load 2 circuit breaker will trip in the event the load exceeds the power
rating.
6. Load 2: 208V output receptacle (1 - L6-20R). NOTE: The default output
voltage is 208V. 240V is available, but must be configured at the factory.
7. The Load 1 circuit breaker will trip in the event the load exceeds the power
rating.
8. Load 1: 208V output receptacle (1 - L6-30R).
9. The input circuit breaker will trip in the event the load exceeds the ED-
XFR'spowerrating.
10. The input power cord is for connecting to the output terminal block on the
UPS.
11. ED-XFR's circuit breaker will trip in the event that the ED-XFR becomes
overheated.
12. Input voltage selection switch (208 / 240V). The default setting is 208V.
1. The Load 4 circuit breaker will trip in the event the load exceeds the power
rating.
2. Load 4: 120V output receptacles (4 - 5-15/20R).
3. The Load 2 circuit breaker will trip in the event the load exceeds the power
rating.
4. Load 2: 120V output receptacles (4 - 5-15/20R).
5. The Load 2 circuit breaker will trip in the event the load exceeds the power
rating.
6. Load 3: 208V output receptacle (1 - L6-20R).
7. The Load 1 circuit breaker will trip in the event the load exceeds the power
rating.
8. Load 1: 208V output receptacle (1 - L6-30R).
9. The input circuit breaker will trip in the event the load exceeds the ED-
XFR'spowerrating.
10. ED-XFR's circuit breaker will trip in the event that the ED-XFR becomes
overheated.
11. Input terminal block (208V / 240V) is for connecting the input power cable
that comes from the output terminal block of the UPS.
12. Outputterminal block foroptionalhardwiringthe load. The availableoutput
voltages are 120V / 208V / 240V. NOTE: The two 120V outputs are ind-
ividual 5KVAoutputsand they CANNOT beparalleled.

9
8
INSTALLATIONPLACEMENT
ThisED-XFRseriesisONLYintendedto be installedinanindoortemperature
controlledenvironment that is freeofconductivecontaminants. DONOT oper-
ate the unit in: extremely dusty and/or unclean areas, locations near heating
devices, water or excessive humidity, or where the unit is exposed to direct
sunlight. Selectalocation,whichwillprovidegood air circulation for the unit at
all times. Route power cords so they cannot be walked on or damaged. The
AC inputs of these Step Down Transformers are ONLY intended to be con-
nected to the output of their respective UPS models. This ED-XFR series is
not intended for use in a computer room as defined in the Standard for the
Protection of Electronic Computer/Data Processing Equipment ANSI/NFPA
75.
Operating Temperature (Maximum): 0 to 40°C (+32 to +104°F)
Operating Elevation: 0 to 2,000m (0 to +6,562 ft)
Operatingand StorageRelativeHumidity: 95%,non-condensing
Storage Temperature: -15 to +50°C (+5 to +122°F)
Storage Elevation: 0 to 15,000m (0 to +49,213 ft)
INSTALLATION
Besuretoreadtheinstallationplacementand all the cautions before installing
the ED-XFR. Place the unit in the final desired location and complete the rest
oftheinstallationprocedure. Seethe“RackmountConfiguration”toinstallthe
unit into the rack. USE CAUTION: The ED-XFR, UPS and Battery Pack are
extremelyheavy. Use the appropriatenumberofpersonnel when installingthe
UPSsystem.
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE STEP
DOWN TRANSFORMER. The mounting brackets are ONLYfor securing the
unit to the rack.
Chapter 3: Installation RACKMOUNT CONFIGURATION
Use the included rackmount brackets and screws to mount the ED-XFR in a
rack by following the steps below.
USECAUTION: TheED-XFRis extremelyheavy. Usetheappropriate number
ofpersonnelwheninstallingtheUPSsystem.
CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE
STEP DOWN TRANSFORMER. The mounting brackets are ONLYfor se-
curing the unit to the rack.
1. Attach the rackmount brackets to the mounting holes on the side panel of
theED-XFRasshownbelow.
2. Follow steps 1 through 4 to install the ED-XFR into the Rail kit. See the
figurebelow.
Step 1: Adjust the length of the rail according to the rack.
Step 2: Securely tighten the wing nuts.
Step 3: Secure the rail to the rack with the enclosed screws.
Step 4: Slide the ED-XFR onto the rail and secure to the rack with the
enclosedscrews.
NOTE: The ED-XFR, UPS and Battery Pack are extremely heavy. Use the
followingplacementwhen rack mounting:
1. The ED-XFR should be installed close to the bottom of the rack.
2. Then install the Battery Pack right above the ED-XFR.
3. Then install the UPS right above the Battery Pack.

11
10
TOWER CONFIGURATION
The tower configuration allows the user to install the ED-XFR in the up-right
position. The tower stands are provided with the UPS. The tower stand ex-
tenders are provided with the ED-XFR. WARNING: Use two or more people
when installing the ED-XFR. USE CAUTION: The ED-XFR is extremely
heavy. Use the appropriate number of personnel when installing the UPS
system.
1. Once the location of the ED-XFR has been determined, place the tower
stands in the desired location.
WARNING: The ED-XFR must be installed in the proper up-right position.
Once the ED-XFR is placed in the tower stands, the vent holes on the side
panelsmustbe facing upwards to provide proper ventilation.
2. Slide the ED-XFR into the tower stands. Make sure that the ED-XFR is
stable.
3. Thename plate panel can be rotated to readintheup-rightposition. Rem-
ove the front panel from the ED-XFR. On the backside of the front panel,
pushthenameplatepanel outwards, the panel will pop out. Rotate the
name plate panel counter clockwise so that it reads in the upright position.
Re-installthe front panel on the ED-XFR.
CONNECTING THE STEP DOWN TRANSFORMER TO THE UPS
WARNING: Qualified Service Personnel ONLY must perform the Installa-
tion and Servicing of these ED-XFR.
1. Before connecting to the input / output terminals read all of the Cautions
and Warning, then observe the following:
a) Ensure that the UPS is turned off and not connected to theAC sour-
ce or the battery source before any connections are made.
b) Calculate the power consumption of the load to ensure that an over-
load condition does not occur.
c) Ensure that the terminal block screws are secured after connecting
the input / output wires. The terminal block screws should be torque
to 18±2Kgf.cm (requires a 3/16" flat-head screwdriver).
d) Ensure that the ED-XFR and the UPS are properly grounded.
2. The input power for the ED-XFR must be single-phase in accordance with
its rating label and the specifications in this manual. The ED-XFR's input
voltagesetting must be thesame as the UPS'soutput voltage setting.
NOTE: TheAC inputsof these StepDownTransformers areONLYintend-
ed to be connected to the output of their respective UPS models.
The ED5000RT-XFR and ED6000RT-XFR come with an attached #10 AWG
input power cord. Connect the input power cord to the output terminal block
on the UPS. The AC inputs of these Step Down Transformers are ONLY
intendedtobe connected to the output of theirrespectiveUPSmodels. Donot
use extension cords, adapter plugs, or surge strips. The installation of up-
stream and downstream protective devices is highly recommended when the
UPS system is connected to the mains and the load.

13
12
INPUT / OUTPUT CONNECTIONS:
WARNING: Qualified Service Personnel ONLY must perform the Installa-
tion and Servicing of these ED-XFR.
1. Remove the terminal block cover box from the rear panel of the UPS (re-
quires a phillips screwdriver). Refer to the figure below for the input / out-
put connections for the UPS. See the UPS user's manual for connecting
theUPS'sinputand output cables.
2. Input / Output cable selection:
60°C / 75°C
TemperatureRating 5/6KVA
#10 AWG (Cu) 8/10KVA #6 AWG (Cu)
(In accordance with National Electrical Code (NEC), install suitable con-
duit and bushing.) NOTE: Use copper wire only.
3. Beforeconnecting tothe input / outputterminals read allof the Cautions and
Warning. TheAC inputs of theseStep Down Transformers are ONLYintend-
ed to be connected to the output of their respective UPS models. NOTE:
The ED-XFR's input voltage setting must be the same as the UPS's output
voltagesetting.
ED5000RT-XFR and ED6000RT-XFR:
See the UPS users manual for UPS input and output connections. Connect the
attached#10AWGinputpower cordon theED-XFR tothe outputterminal blockon
theUPS.
1. Connect the black wire labeled L on the attached input power cord to the UPS
outputterminal block labeledL and secure.
2. Connect the white wire labeled N on the attached input power cord to the UPS
outputterminal block labeledN and secure.
3. Connectthe green wire labeled G on theattached input power cord to theUPS
outputterminal block groundterminal andsecure.
4. Beforere-installing the terminal blockcover box on the UPS, seethe UPS us-
ersmanual forthe UPS inputand output connections.
5. SettheinputvoltageselectswitchontherearpaneloftheED-XFRtotheappropr-
iate voltage (208V / 240V). NOTE: The default setting is 208V. The ED-
XFR'sinput voltage settingmust be the sameas the UPS'soutput voltage set-
ting.
6. Plugthe equipmentinto the output receptacleson the rear panelof the ED-
XFR.
NOTE: Default voltages for the output receptacles are 120V and 208V. Load 2
ouputreceptacle canbe changed tosupply 240V,but thischange must bedone at
thefactory.
ED8000RT-XFR and ED10000RT-XFR:
1. Remove the terminal block cover plate from the rear panel of the ED-XFR
(requiresa phillips screwdriver). Referto the figure belowfor the input/ output
connections for the ED8000RT-XFR / ED10000RT-XFR. Connect the end of
the #6AWG input power cable labeled "TO XFR" to the appropriate terminals
on theAC input terminal block on the ED-XFR and secure. The pins for thein-
putcable are included.
a) Connectthe blackwire labeledL1 / L2on theinput powercable tothe ED-
XFRAC input terminal block labeled L1 for 240V or L2 for 208V and se-
cure. NOTE: The ED-XFR's input voltage setting must be the same as
theUPS's output voltagesetting.
b) Connect the white wire labeled L3 on the input power cable to the ED-
XFRAC input terminal block labeled L3 and secure.
TheED8000RT-XFR andED10000RT-XFRcome withan#6AWGinput power
cable in the box. The pins for the input cable are included. Connect one end
of the input power cable to the input terminal block on the ED-XFR. Connect
theotherendoftheinputpowercabletotheoutputterminalblockontheUPS.
The AC inputs of these Step Down Transformers are ONLY intended to be
connectedtotheoutputof their respective UPS models. Do not use extension
cords, adapter plugs, or surge strips. The installation of upstream and down-
stream protective devices is highly recommended when the UPS system is
connected to the mains and the load.

15
14
TURNING OFF THE STEP DOWN TRANSFORMER IN THE NORMAL AC
MODE:
1. Press and release the On/Off/TestButtononthefrontpanelof the UPS aft-
er the second beep to transfer the UPS to the Bypass mode.
2. Turn off all of the connected equipment.
3. Turn off all of the Load breakers on the rear panel of the ED-XFR.
4. Turn off the input breaker on the rear panel of the UPS.
5. Turn off the DC breaker(s) on the rear panel of the Battery Pack(s).
TURNING OFF THE STEP DOWN TRANSFORMER IN THE BATTERY
MODE:
1. Turn off all of the connected equipment.
2. Turn off all of the Load breakers on the rear panel of the ED-XFR.
3. Press and release the On/Off/TestButtonafterthe second beep to turn the
UPS off.
4. Turn off the input breaker on the rear panel of the UPS.
5. Turn off the DC breaker(s) on the rear panel of the Battery Pack(s).
START-UP IN THE BATTERYMODE:
The Battery Pack(s) must be connected to the UPS and the DC breaker(s) on
the rear panel of the Battery Pack(s) must be in the on position. The input of
theED-XFRmust be connected to the output of theUPS.Theequipmentmust
be plugged into the output receptacles on the ED-XFR.
1. Turn on the input breaker on the rear panel of the UPS.
2. Press and release the On/Off/Test Button after the first beep to turn the
UPS on.
3. The fans will turn on, then the UPS will start-up and perform a self-diagno-
sis for approximately 10-seconds.
4. Turn on all of the Load breakers on the rear panel of the ED-XFR.
5. Turn on the connected equipment one at a time. See the UPS user's ma-
nual for more information.
1. Turn on the input breaker on the rear panel of the UPS. The fans will turn
on, theAC normal icon will flash off/on and the LCD will display ‘bPS’. The
UPS is now in the Bypass mode. NOTE: If there is a power interruption
while the UPS is in the Bypass mode the load will not be backed up.
2. Turn on all of the Load breakers on the rear panel of the ED-XFR.
3. Turn on the connected equipment one at a time.
4. Press and release the On/Off/Test Button after the first beep to turn the
UPS on.
5. The UPS will start-up and perform a self-diagnosis for approximately 10-
seconds. The UPS system is ready for normal opeartion. See the UPS
user's manual for more information.
120Voutputs:
La - N: 50A max, Lb - N: 50A max, the combined total for both: 83.4A max
208V output: Lc - Ld: 48.1A max
240V output: La - Lb: 41.7A max
NOTE: Default voltages for the output receptacles are 120V and 208V. 240V is
available,but only asa hardwire optionat the output terminalblock.
Chapter 4: Operation
START-UP IN THE NORMAL AC MODE:
The UPS must be connected to utility power and there must be an acceptableAC
voltage present. The Battery Pack(s) must be connected to the UPS and the DC
breaker(s)on the rearpanel of theBattery Pack(s) mustbe in theon position. The
inputofthe ED-XFRmust beconnected totheoutput ofthe UPS. Theequipment is
pluggedinto the output receptacleson the ED-XFR.
c) Connect the green wire labeled G on the input power cable to the ED-
XFRAC inputterminal block ground terminal and secure.
2. Connect the other end of the #6AWG input power cable labeled "TO UPS" to
theoutput terminal blockon the UPSand secure.
a) Connectthe blackwire labeled Lon theinput power cableto theUPS out-
putterminal block labeled Land secure.
b) Connectthe whitewire labeledN onthe inputpower cableto theUPS out-
putterminal block labeled Nand secure.
c) Connectthegreen wirelabeled Gonthe inputpower cabletothe UPSout-
putterminal block groundterminal and secure.
3. Re-installthe terminalblock cover plate onthe ED-XFR.
4. Beforere-installing the terminal blockcover box on the UPS, seethe UPS us-
ersmanual forthe UPS inputand output connections.
5. Plugthe equipmentinto the output receptacleson the rear panelof the ED-
XFR.TheED8000RT-XFRand ED10000RT-XFRhavea terminal blockfor ha-
rdwiringthe output. Referto thefigure below forthe input/ output connections.
Thepins for theoutput cable areincluded.
NOTE: The two 120V outputs are individual 5KVAoutputs and they CANNOT be
paralleled.
Input/ Output terminalblock for the ED8000RT-XFRand ED10000RT-XFR:

17
16
Chapter 6: Specifications
WaveformType TrueSineWave
>95%(FullLoad)
50 / 60Hz 208VAC - 49Amps
240VAC- 42.5Amps
208& 120VAC (Default)/ 240VAC (Optional)
Efficiency
Voltage(Selectable)
Frequency
ModelNumber
SYSTEMSPECIFICATIONS
Current(Max)
Topology Isolation, StepDown Tansformer,SineWave
OUTPUT
INPUT
Numberof Phase Single (1∅2W +G)
Voltage(Selectable) 208(default) /240VAC
Protection ResettableCircuit Breaker
VoltageRegulation Nominal+/-3%
Frequency 50 / 60Hz
Protection ResettableCircuit Breaker
208VAC - 24Amps
240VAC - 21Amps
Audible Noise at 1 m (3 ft.)
ENVIRONMENTAL
OperatingTemperature(max)
Operating/Storage Humidity
OperatingElevation
0to 40°C(+32to +104°F)
0~ 95%Non-Condensing
0 to 2,000m (0 to +6,562 ft)
PHYSICAL
Weight - Net
Size - Net
L X W X H
Size - Shipping
L X W X H
Weight-Shipping
82.7 lbs / 35.5 Kgs 158.7 lbs / 72.0 Kgs
123.5 lbs / 56.0 Kgs 196.2 lbs / 89.0 Kgs
REGULATORYCOMPLIANCE
SafetyandApprovals
EMCVerification
cTUVus
(Conforms to UL60950-1:2007 R12.11, CSA-C22.2 No.60950-1-07-A1:2011)
FCC Class B, CE certified
StorageElevation 0 to 15,000m (0 to +49,213 ft)
StorageTemperature -15 to +50°C (+5 to +122°F)
<60 dBA
26.2 x 17.3 x 3.5"
665 x 440 x 88.5 mm
31.6 x 24.4 x 9.1"
802 x 620 x 230 mm
ED8000RT-XFR
ED10000RT-XFR
ED5000RT-XFR
ED6000RT-XFR
25.9 x 17.3 x 5.14"
659 x 440 x 130.6 mm
30.7 x 23.6 x 10.9"
780 x 600 x 276 mm
NOTE: Specifications are subject to change without notice.
Connection Attached2' open-end
#10AWGpower cord TerminalBlock Hardwireonly
10KVA/10KWatts
Power(Max) 5KVA/5KWatts
<50 dBA
HarmonicDistortion <3% (FullLinear Load)
IF THE STEP DOWN TRANSFORMER REQUIRES SERVICE
1. Use theTroubleshootingsection in the UPS user's manual to eliminate ob-
viouscauses.
2. Verify there are no tripped circuit breakers. A tripped circuit breaker is
themostcommonissue.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they
cannot resolve the issue call or fax the Technical Support department at
the following numbers; Voice phone [phone], FAX line (972) 446-
9011 or visit our Web site at www.minutemanups.com the "Discussion
Board". Before calling the Technical Support Department have the follow-
inginformationavailable:
a) Contact name and address.
b) Where and when the unit was purchased.
c) All of the model information about your unit.
d) The serial number of your unit.
e) Any information on the failure, including LEDs that may be illuminat-
ed or error codes displayed.
f) A description of the protected equipment including model numbers, if
possible.
g) A technician will ask you for the above information and if possible,
helpsolvethe issue over the phone. In the event that theunitrequires
factory service, the technician will issue you a Return MaterialAutho-
rizationNumber(RMA#).
h) If the unit is under warranty, the repairs will be done at no charge. If
the unit is not under warranty there will be a charge for the repair.
4. Pack the unit in its original packaging. If the original packaging is no lon-
geravailable,asktheTechnical SupportTechnician about obtaining a new
set. It is important to pack the unit properly in order to avoid damage in
transit. Never use Styrofoam beads for a packing material.
a) Include a letter with your name, address, day time phone number,
RMAnumber, a copy of your original sales receipt, and a brief desc-
ription of the problem.
5. Mark the RMA #ontheoutsideofallpackages. Thefactorycannotaccept
any package without the RMA # marked on the outside.
6. Return the unit by insured, prepaid carrier to:
Para Systems Inc.
MINUTEMANUPS
1809 W. Frankford Road, Suite 150
Carrollton,TX75007
ATTN:RMA# _______
Chapter 5: Obtaining Service

19
18
A1. DECLARATION OF CONFORMITY
Application of Council Directive(s): 2004/108/EC
Standard(s) to which Conformity is declared:
Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS)
Manufacturer’sAddress: 1455LeMay Drive
Carrollton,Texas 75007 USA
Type of Equipment: Uninterruptible Power Supplies (UPS)
ModelNo: ED5000RT-XFR, ED6000RT-XFR,
ED8000RT-XFR, ED10000RT-XFR
I hereby declare that the equipment specified above conforms to the above
Directive(s).
Place:Carrollton,Texas, USA Date: April 1, 2014
RobertCalhoun
(Name) ManagerEngineering
(Position)
Year of Manufacture: Beginning April 1, 2014
EN 50091-2:1995 Class A, IEC61000-4-2: level4, IEC61000-4-3: level3,
IEC61000-4-4:level4, IEC61000-4-5: level4,IEC61000-4-6:level3, IEC61000-
4-8: level3, IEC 62040-2: 2005, IEEE C62.41 CategoryA1
ParaSystems,Inc.(ParaSystems) warrants this equipment, when properlyappliedand
operated within specified conditions, against faulty materials or workmanship for a pe-
riod of three years from the date of purchase. For equipment sites within the United
StatesandCanada,thiswarrantycovers depot repairorreplacementofdefectiveequip-
mentatthediscretionof Para Systems. Depot repair will befromthenearestauthorized
service center. The customer pays for shipping the product to Para Systems. Para
Systems pays ground freight to ship the product back to the customer. Replacement
partsandwarrantylabor will be bornebyParaSystems. For equipment located outside
oftheUnited StatesandCanada,ParaSystems only covers faultyparts. ParaSystems
products that are depot repaired or replaced pursuant to this warranty shall only be
warrantedfortheunexpiredportionofthe warranty applying to the original product. This
warranty applies only to the original purchaser who must have properly registered the
productwithin 10 daysof purchase.
Thewarranty shall be void if(a) the equipmentis damaged by the customer, isimprop-
erlyused, is subjectedto an adverseoperating environment, oris operated outside the
limitsofits electrical specifications;(b)the equipment is repairedormodified by anyone
otherthanPara Systems orParaSystems approved personnel;or(c) has been usedin
amanner contrary tothe product’s User'sManual or otherwritten instructions.
Anytechnical advice furnishedbefore or afterdelivery in regardto use orapplication of
ParaSystems’equipmentisfurnished without charge and on thebasisthatitrepresents
Para Systems’ best judgment under the circumstances, but it is used at the recipient’s
solerisk.
EXCEPTAS PROVIDED HEREIN,PARASYSTEMS MAKES NOWARRANTIES, EX-
PRESSEDORIMPLIED,INCLUDINGWARRANTIESOFMERCHANTABILITYANDFIT-
NESSFORAPARTICULARPURPOSE. Somestatesdo notpermitlimitationof implied
warranties;therefore, the aforesaid limitation(s)maynotapply to thepurchaser.
EXCEPTAS PROVIDED ABOVE, IN NO EVENTWILL PARASYSTEMS BE LIABLE
FORDIRECT,INDIRECT,SPECIAL, INCIDENTAL, OR CONSEQUENTIALDAMAGES
ARISINGOUTOFTHEUSEOFTHISPRODUCT,EVEN IFADVISEDOFTHEPOSSI-
BILITYOF SUCHDAMAGE. Specifically, Para Systems isnotliableforany costs,such
as; labor for on-site installation, on-site maintenance or on-site service, lost profits or
revenue,lossofequipment, loss of use ofequipment,lossof software, loss of data,cost
ofsubstitutes, claims by third parties,or otherwise. Thesole and exclusive remedy for
breachof any warranty,expressed or implied,concerning Para Systems’products and
theonly obligation of Para Systemshereunder, shall be depotrepairor replacement of
defective equipment, components, or parts; or, at Para Systems’ option, refund of the
purchase price or substitution with an equivalent replacement product. This warranty
givesyou specific legalrightsand you mayalso have otherrights which vary fromstate
tostate.
No employee, salesman, or agent of Para Systems is authorized to add to or vary the
terms of this warranty.
Chapter 7: Limited Product Warranty

21
20
Notes:
Notes:
