Xtreme XBDM Series Guide

XBDM-1520RHW
15A, 20A Models
User & Installaon Manual
www.xpcc.com | © 2014 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 10/23/14)

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 2
Bypass Distribuon Module
Table of Contents
Introducon.................................................................................................6
Product Descripon......................................................................................6
Bypass Distribuon Descripon.......................................................................................................6
System Conguraon...................................................................................7
LED Descripon................................................................................................................................8
Hardware Installaon Guide.........................................................................9
Installaon.......................................................................................................................................9
Wiring and Connecng...............................................................................11
Inial Connecon..........................................................................................................................11
Startup Sequence..........................................................................................................................11
User’s Operaons.......................................................................................12
Normal Operaon..........................................................................................................................12
Bypass Operaon...........................................................................................................................12
Specicaons.............................................................................................14
Shipping List.............................................................................................. 14
Obtaining Service.......................................................................................15
Xtreme Power Conversion Limited Warranty...............................................16

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 3
Bypass Distribuon Module
Thank you for selecng this bypass distribuon module. It is designed to work in conjuncon with a UPS to provide
you with protecon for connected equipment. Please read this manual before installing the XBDM-Series models
XBDM-15RHW/XBDM-20RHW as it provides important informaon that should be followed during installaon
allowing you to correctly set up your system for the maximum safety and performance. Included is informaon
on customer support and service. If you experience a problem with the XBDM, please contact technical support.
WARNING: Incorrect installaon, operaon, and/or modicaons made to the XBDM will void the manufactures
warranty. Xtreme Power Conversion is not liable for personnel or equipment damages as a result.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 4
Bypass Distribuon Module
IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS)
CAUTION! Two sources of power are present in the XBDM: UPS power and Ulity power.
CAUTION! (UPS has Internal Baeries): Risk of electrical shock – Hazardous live parts inside the UPS are energized
from the baery supply even when the input AC power is disconnected.
CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover. No user serviceable parts
inside. Refer servicing to qualied service personnel.
WARNING! Unit intended for installaon in a controlled environment per installaon instrucons.
CAUTION! If ammable substances such as gases or fumes are present, or if the room is airght, a hazardous situ-
aon may exist in which no electrical equipment should be operated.
WARNING!
It is strongly recommended that the XBDM not be opened as components have very high voltage and
touching those components may be fatal. Only a qualied technician or authorized agent may service the
unit.
The XBDM unit’s output receptacles can carry live voltage even when not connected to an input voltage
source. The UPS has its own internal energy source.
CAUTION!
The unit has a dangerous amount of voltage. If either the UPS or BYPASS indicator is on, the unit’s outlets
may have a dangerous amount of voltage even when not plugged into the wall outlet because the baery
from the UPS may connue to supply power.
Care should be taken to undertake installaon indoors, free from electrically-conducve parcles which
are under temperature and humidity control, in order to reduce the risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the equipment is placed in a
posion near the outlet where easily accessible.
All servicing on this equipment must be carried out by qualied service personnel.
The Xtreme Bypass Distribuon Module (XBDM) is intended to allow replacement of the UPS connected
without having to shut down the equipment connected to the load circuits on the XBDM. Cauon should
be observed as the XBDM is always supplied with power by either the UPS or UTILITY.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 5
Bypass Distribuon Module
Environment
Ensure that all environmental concerns and requirements are met according to specicaons listed in
this document, otherwise the safety of installaon personnel cannot be guaranteed, and the unit may
malfuncon.
Ensure that you remember the following when locang the XBDM:
• Avoid extremes of temperature and humidity.
»Operang temperature: 0°C to +50°C (+32° to +122° F)
»Operang elevaon: 0 to 3000m (0-10,0000 )
»Relave humidity: 0-90%, non-condensing
»Storage temperature: 0-65° C (+32 to +149° F)
»Storage elevaon: 0 to 15,000m (0 to +50,000 )
• Provide protecon for the equipment from moisture.
• Space and venlaon requirements must be met.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 6
Bypass Distribuon Module
Introducon
The informaon provided in this manual covers single phase hardwired 15/20A bypass distribuon module, its
basic funcons, operang procedures, opons available and emergency situaons. It also includes informaon on
how to ship, store, handle, and install the equipment. Only detailed requirements of the XBDM unit are described
herein, and installaon must be carried out in accordance with this manual. Refer to the associated UPS manual for
UPS operang instrucons. Electrical installaon must also carefully follow local legislaon and regulaons. Only
qualied personnel should conduct these installaons as failure to acknowledge electrical hazards could prove to
be fatal.
Product Descripon
Many dierent kinds of sensive electrical equipment can be protected by an Uninterrupble Power Supply (UPS)
including computers, workstaons, process control systems, telecommunicaons systems, sales terminals, other
crical instrumentaon, etc. The purpose of the XBDM is to provide an extra level of protecon in allowing for the
replacement of a UPS without powering down the loads connected. The XBDM can work with most single phase
topologies. It will not work with topologies that have a phase shi between input and output (like ferro of UPS
with an isolaon transformer).
Electrical interference exists in many forms, causing problems in AC power, from lightning, power company ac-
cidents and radio transmission motors, air condioners, and vending machines. Protecon of sensive electrical
equipment is vital to protect against power outages, low or high voltage condions, slow voltage uctuaons,
frequency variaons, dierenal and common-mode noise, transients, etc.
To prevent power line problems from reaching crical systems causing damage to soware, hardware, and equip-
ment malfuncons, the UPS maintains constant voltage, isolang crical load output and cleaning the ulity AC
power. When a UPS fails or needs maintenance, many mes it is necessary to turn o the UPS and disconnect it
from incoming electrical circuits. With the XBDM installed between the incoming Ulity and the UPS, you can re-
place the UPS and/or Baeries without dropping the load. You simply switch the XBDM from UPS power to Ulity
power and remove the UPS while the load connected to the XBDM connues to operate temporarily from Ulity
power.
Bypass Distribuon Descripon
The Xtreme Bypass Distribuon Module (XBDM) is designed to operate with a single-phase UPS up to 30Amps in
output capacity. The XBDM allows you to:
• Replace or upgrade the UPS without losing power to the protected equipment
• Provide surge protecon if the UPS is not present
• Provide extra surge protecon when the UPS is present
As shown in the block diagram below:
• Under normal operaon, the UTILITY INPUT ows through the XBDM to the UPS and then out to the CON-
NECTED LOADS.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 7
Bypass Distribuon Module
Block Diagram with UPS
As shown in the block diagram below:
• Under maintenance operaon, the UTILITY INPUT ows through the XBDM to the CONNECTED LOADS –
the UPS is not in the circuit.
Block Diagram without UPS
System Conguraon
The diagrams shown give front, top and rear view of the XBDM.
XBDM-15RHW/XBDM-20RHW Front View
XBDM-1020LV Rear View
XBDM-1015LV Top View

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 8
Bypass Distribuon Module
LED Descripon
The XBDM has three LED’s on the front control panel. These LED’s allow the user to quickly understand the status
of the unit.
Red LED = UPS power is available
Orange LED = Ulity is available for Bypass operaon
Green LED = Surge Protecon is available.
XBDM Front Panel LED’s
CAUTION: The Orange LED must be illuminated before transferring to BYPASS power.
The Red LED must be illuminated before transferring to UPS power.
XBDM Front Panel Bypass Switch

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 9
Bypass Distribuon Module
Hardware Installaon Guide
Inspect the XBDM upon receipt. The packaging is recyclable; keep it for reuse or dispose of properly.
Installaon
The XBDM supports horizontal 1U rack mount and vercal rack mount installaon.
Horizontal Installaon (1U)
1. Aach the two (2) XBDM horizontal mounng brackets (included) on each end of the XBDM using four (4)
retaining screws (included).
XBDM-15RHW/XBDM-20RHW Horizontal Mounng
2. Install the XBDM in a suitable horizontal locaon in the rack rail using four (4) user-provided mounng screws.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 10
Bypass Distribuon Module
Vercal Installaon (0U)
1. Aach the two (2) XBDM horizontal mounng brackets (included) on each end of the XBDM using four (4)
retaining screws (included).
XBDM-15RHW/XBDM-20RHW Vercal Mounng
2. Aach the two vercal mounng brackets (included) to the horizontal rack mounng brackets on each end of
the XBDM using four (4) retaining screws (included) see Figure 2.
3. Install the XBDM in a suitable vercal locaon on the side of the rack rail with four (4) user provided mounng
screws.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 11
Bypass Distribuon Module
Wiring and Connecng
Inial Connecon
1. The XBDM-15RHW/XBDM-20RHW is a hardwired input and output Bypass Distribuon Module. It must be
installed in conjuncon with all local electrical codes, with work performed by a licensed electrician.
2. All connecons should be completed prior to providing input ulity power to the XBDM-15RHW/XBDM-
20RHW.
3. Input and Output wiring to the XBDM-15RHW/XBDM-20RHW should be routed through the terminal box
knock-out as shown in gure 12. The terminal box cover can be removed for ease of conduit connecon and
wire roung.
XBDM-15RHW/XBDM-20RHW Input and Output Roung
4. Please refer to the drawing below for input and output wiring terminal locaons.
XBDM-15RHW/XBDM-20RHW Terminal Block View
Startup Sequence
1. Turn the UPS OFF in accordance with UPS manufacturers’ documentaon. Verify the correct wiring to the
XBDM prior to proceeding to step 2.
2. Unplug the UPS from ulity source. Depending on the model of UPS it may take a few seconds for the UPS
to completely shut down. All indicators on the UPS front panel should shutdown.
3. Disconnect the protected equipment power cord(s) from the UPS.
4. Verify that the BYPASS switch on the XBDM is in the UPS posion.
5. Energize the circuit breaker providing input ulity to the XBDM-15RHW/XBDM-20RHW from a properly
sized distribuon panel.
The orange bypass available light should illuminate on the Bypass Distribuon Module.
6. Plug the UPS INPUT cord into the 5-20R receptacle labeled FOR UPS INPUT on the rear of the XBDM-
15RHW/XBDM-20RHW.
7. Connect the UPS output receptacle to the XBDM-15RHW/XBDM-20RHW C20 plug labeled UPS OUTPUT
using the appropriate 15 or 20A cord supplied with the XBDM-15RHW/XBDM-20RHW.
8. Assure that the distribuon for the loads to be connected to the XBDM-15RHW/XBDM-20RHW is properly
connected to the XBDM-15RHW/XBDM-20RHW.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 12
Bypass Distribuon Module
9. Press the ON BUTTON on the UPS. All indicators on the UPS should operate normally. The red UPS avail-
able light should illuminate on the Bypass Distribuon Module. Power should now be supplied to the
equipment connected to the UPS via the XBDM-15RHW/XBDM-20RHW.
User’s Operaons
The purpose of this BYPASS DISTRIBUTION MODULE is to allow servicing of the UPS so as not to aect the LOADs
connected and protected. To transfer between UPS and ulity sources, swily actuate the bypass switch to the
opposite posion. Both the UPS, and Ulity lights available must be illuminated to prevent transferring to a non-
powered source.
Normal Operaon
When operang in NORMAL mode the switch on the front of the XBDM will be in the UPS posion
XBDM-15RHW/XBDM-20RHW Bypass Switch – UPS
CAUTION: The red LED on the bypass module must be illuminated before transferring to the UPS posion.
Bypass Operaon
To transfer your equipment to Maintenance Bypass (AC Line operaon) and remove the UPS:
1. Turn the Bypass Switch on the XBDM to BYPASS posion. The XBDM is now powering your equipment from
Ulity power.
CAUTION: The Orange LED must be illuminated before transferring to BYPASS operaon.
CAUTION: When the XBDM is operang in UTILITY MODE, the LOAD connected is not protected from power
outages.
2. Press the OFF BUTTON on the UPS per the UPS manufacturers’ documentaon.
3. If any oponal Extended Baery Packs or Modules are connected to the UPS, turn o the circuit breaker
on the baery pack or module (if applicable), and disconnect the cable from the baery pack or module
to the UPS.
4. Disconnect the UPS output cord from the XBDM to the UPS output receptacle.
5. Disconnect the UPS INPUT CORD from the UPS INPUT RECEPTACLE on the XBDM.
6. Remove the UPS.
To reinstall the UPS and transfer your equipment from Maintenance Bypass (AC Line operaon) to the UPS:
1. If oponal Extended Baery Packs or Modules are installed, reconnect the cable from the baery pack or
module to the UPS, and turn on the circuit breaker on the baery back or module (if applicable) per the
UPS manufacturers’ documentaon.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 13
Bypass Distribuon Module
2. Connect the UPS output cord from the XBDM to a UPS output receptacle
3. Plug the UPS INPUT POWER CORD into the XBDM UPS INPUT RECEPTACLE.
4. Start the UPS per the manufactures instrucons. The red UPS available light should illuminate on the By-
pass Distribuon Module.
5. Toggle the Bypass Switch on the XBDM to UPS posion. The XBDM is now powering your equipment from
UPS power.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 14
Bypass Distribuon Module
Specicaons
MODEL NUMBER XBDM-15RHW XBDM-20RHW
POWER RATING Voltage/current 120VAC/15A 120VAC/20A
INPUT Ulity input Hardwired terminal block
Breaker N/A
OUTPUT Output Hardwired terminal block + (6) 5–15R
TRANSFER SWITCH Capacity 20A break before make
rocker switch
Transfer me 8ms
UPS INPUT Input connecon 5–20R
UPS OUTPUT Connecon to UPS output 3  cord with 3  cord with
5–15P plug 5–20P plug
AC SURGE Capacity 6500A, 114J, 330VAC
INDICATORS LED indicators Ulity, surge, UPS
PHYSICAL Dimensions (W x D x H) 17 x 3.5 x 1.75 in
Weight 3.6 lbs
WARRANTY 3 years (2 years outside of USA)
INCLUDED IN BOX Standard 19" rack mounng hardware, user manual
AVAILABLE OPTIONS Input cord sets and connectors
Shipping List
1. (1) XBDM
2. Standard 19” rack mounng hardware
3. User’s Manual

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 15
Bypass Distribuon Module
Obtaining Service
If the UPS requires Service:
1. Use the TROUBLESHOOTING secon in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem, call Xtreme
Power Conversion Corp Technical Support at 800.582.4524. Technical support inquiries can also be made at
[email protected]. Please have the following informaon available BEFORE calling the Technical Support
Department:
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model informaon about your UPS.
• Any informaon on the failure, including LED’s that may or may not be illuminated.
• A descripon of the protected equipment, including model numbers if possible.
• A technician will ask you for the above informaon and, if possible, help solve your problem over the
phone. In the event that the unit requires factory service, the technician will issue you a Return Mate-
rial Authorizaon number (RMA).
If you are returning the UPS to Xtreme Power for service, please follow these procedures:
1. Pack the UPS in its original packaging. If the original packaging is no longer available, as the Technical Sup-
port Technician about obtaining a replacement set of packaging material. It is important to pack the UPS
properly in order to avoid damage in transit. Never use Styrofoam beads for a packing material.
2. Include a leer with your name, address, dayme phone number, RMA number, a copy of your original
sales receipt, and a brief descripon of the problem.
3. Mark the RMA number on the outside of all packages. Xtreme Power cannot accept any package without
the RMA number marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address provided by the Technician.
5. Refer to the Warranty statements in this manual for addional details on what is covered.

Xtreme Power Conversion Corporaon
XBDM-1520RHW User’s Manual
Page 16
Bypass Distribuon Module
Xtreme Power Conversion Limited Warranty
Xtreme Power Conversion (XPC) Corporaon warrants Xtreme Power Conversion equipment, when properly ap-
plied and operated within specied condions, against faulty materials or workmanship for a period of three years
for XBDM-Series products from the date of purchase. For equipment sites within the United States and Canada,
this warranty covers repair or replacement, at the sole discreon of XPC Corporaon. The customer is responsible
for the costs of shipping the defecve product to XPC Corporaon. XPC Corporaon will pay for ground shipment
of the repaired or replacement product. This warranty applies only to the original purchaser.
If equipment provided by XPC Corporaon is found to be Dead-on-Arrival (DOA), XPC Corporaon will be respon-
sible for the costs of shipping product to and returning equipment from the customer in a mely manner as agreed
to with the customer, once the customer has requested and received a Return Material Authorizaon (RMA)
number. DOA equipment is dened as equipment that does not properly funcon according to user documenta-
on when inially received and connected in conjuncon with proper procedures as shown in the user documen-
taon or via support provided by XPC Corporaon personnel or authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than XPC Corporaon or
a XPC Corporaon approved third party; (b) the equipment is damaged by the customer, is improperly used or
stored, is subjected to an adverse operang environment, or is operated outside the limits of its electrical speci-
caons; or (c) the equipment has been used or stored in a manner contrary to the equipment’s operang manual,
intended use or other wrien instrucons. Any technical advice furnished by XPC Corporaon or a XPC Corpora-
on authorized representave before or aer delivery with regard to the use or applicaon of Xtreme Power Con-
version equipment is furnished on the basis that it represents XPC Corporaons best judgment under the situaon
and circumstances, but it is used at the recipient’s sole risk.
EXCEPT AS STATED ABOVE, XPC Corporaon DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL XPC Corporaon BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCI-
DENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF Xtreme Power Conversion EQUIPMENT,
including but not limited to, any costs, lost prots or revenue, loss of equipment, loss of use of equipment, loss
of soware, loss of data, cost of substutes, or claims by third pares. Purchaser’s sole and exclusive remedy for
breach of any warranty, expressed or implied, concerning Xtreme Power Conversion equipment, and the only
obligaon of XPC Corporaon under this warranty, shall be the repair or replacement of defecve equipment,
components, or parts; or, at XPC Corporaons sole discreon, refund of the purchase price or substuon of an
equivalent replacement product.
