CYP CED-2M User manual

CED-2M
4K UHD+ EDID Manager
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2016 by Cypress Technology.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 08/11/16 Draft

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 OSD Menu.........................................5
7. Connection Diagram .......................... 12
8. Specications ...................................... 13
8.1 Technical Specication.................13
8.2 Video Specication Support.........14

1
1. INTRODUCTION
This 4K UHD HDMI EDID Emulator is designed to manage and
manipulate the EDID information provided to a connected HDMI
source device. EDID contains critical information about the
capabilities of the connected display, including audio and video
format support, HDMI feature support, etc. and this unit aims to simplify
the technical complications that often arise when performing video
system integration, home theater installation, display room setup, or
audio/video equipment testing. This unit provides the ability to not
only select between the display’s native EDID and pre-made EDIDs,
but it also allows the user to copy EDIDs from other displays and use
them, or to create their own customized EDID using the PC-based
EDID management software.
2. APPLICATIONS
• HDMI/DVI EDID management
• AV system integration and home theater installation
• AV equipment testing
3. PACKAGE CONTENTS
• 1 x 4K UHD HDMI EDID Emulator
• 1 x 5V DC Power adaptor
• Operational Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.

2
5. FEATURES
• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compliant with the use of an HDMI-DVI adaptor
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3840x2160@60 Hz (4:4:4, 8-bit) &
4096x2160@60 Hz (4:4:4, 8-bit)
• Supports 48-bit Deep Color up to 1080p60
• Supports pass-through of LPCM 7.1, bitstream and HD bitstream
audio formats
• 8 built-in standard EDIDs, 8 slots for user-created or learned EDIDs,
and EDID bypass support
• Supports CEC pass-through
• PC-based EDID management tool support
• Supports four distinct EDID functions:
 Read: Read and copy the connected display’s EDID into the
unit
 Write: Overwrite connected display’s EDID (only available on
displays which explicitly support the overwrite function)
 Emulation: The HDMI input device reads the EDID stored
within the unit (built-in, learned, or created)
 Bypass: The HDMI input device reads the EDID directly from
the connected display
Note: 4K UHD sources with HDR or equivalently high-bandwidth signals
require an appropriate compatible display and HDMI cables in
order to achieve the best image quality. The use of “Premium
High Speed HDMI” cables is highly recommended.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1
5
2
6
3
7
4
8
MENU –+ENTER
EDID MODE INFO
User
Internal
HDCP Ver.
HDCP Mode
3
1 6 7 8 92
5
4
1LEDs 1~8: These LEDs illuminate to indicate which EDID from the
currently selected EDID mode is active.
2Internal: This LED will illuminate when the unit is in Internal EDID
mode.
3User: This LED will illuminate when the unit is in User EDID mode.
Note: When both the User and Internal LEDs are lit, the unit’s EDID is
in External bypass mode.
4HDCP Mode: This LED illuminates to indicate the current HDCP
management mode selected for the HDMI input port. A red
LED indicates “Follow In” mode, and the unit will enforce HDCP
based on the requirements of the connected source. A green
LED indicates “Follow Out” mode, and the unit will enforce HDCP
based on the capability of the connected display. An un-lit LED
indicates that HDCP support has been completely disabled.
5HDCP Ver.: This LED illuminates to indicate the HDCP version used
by the connected source. A red LED indicates that the source is
using HDCP v1.x (1.0~1.4). A green LED indicates that the source is
using HDCP v2.2. When LED concealed it indicates no HDCP from
input source.
6MENU: Press to enter the OSD menu, or to back out from menu
items.
Note: Press and hold the menu button for 3 seconds to reset the
unit to factory defaults.
7-/EDID: Press to move down or adjust selections within OSD menus.
While not in a menu, press this button to sequentially switch

4
through the available EDIDs from 1 to 8.
8+/MODE: Press to move up or adjust selections within OSD menus.
While not in a menu, press this button to sequentially switch
through the available EDID modes (User, Internal and External
bypass).
9ENTER/INFO: Press to conrm a selection within the OSD or to go
deeper into a menu item. While not in a menu, press this button to
display basic information about the currently connected source
on the OSD. When output HDMI is not connected, press this button
to select HDCP Mode. When output HDMI is not connected, press
this button to select HDCP Mode.
6.2 Rear Panel
HDMI IN USB POWER DC 5VHDMI OUT
1 2 3 4
1HDMI OUT: Connect to HDMI TVs, monitors or ampliers for digital
video and audio output. If there is no valid HDMI source the output
will display a blue screen.
2HDMI IN: Connect to HDMI source equipment such as a media
player, game console or set-top box. DVI sources are supported
with the use of an HDMI to DVI adapter.
3USB: This slot is used for PC software control, EDID upload and
rmware updates. (see section 6.5)
4DC 5V: Plug the 5V DC power adapter into the unit and connect
it to an AC wall outlet for power. The LED will illuminate to indicate
the unit is on and receiving power.

5
6.3 OSD Menu
First Layer Second Layer Third Layer
EDID Emulator
EDID Mode
Internal
User
External
EDID Select
1: 1080P@60/8/RGB/LPCM
2: 4K2K_30/8/RGB/LPCM
3: 4K2K_30/8/YUV/Bitstream
4: 4K2K_30/12/RGB/HDR/LPCM
5: 4K2K_30/12/YUV/HDR/Bitstream
6: 4K2K_60_Y420/8/LPCM
7: 4K2K_60_Y420/8/Bitstream
8: 4K2K_60/8/RGB/LPCM
Copy TV EDID
1: DVI/1080P
2: 1080P@60/8/3D/YUV/Bitstream
3: 1080P@60/8/YUV/Bitstream
4: 4K2K@60/8/RGB/Bitstream
5: Star
6: Lucky
7: Sunny
8: Sonic
Program EDID To
TV Select : Internal 1~8, User 1~8
[EDID INFO]
OUTPUT UHD To 1080P :
BYPASS, FIXED
HDCP
HDCP : Apple
Mode, Follow In,
Follow Out

6
OSD
DISPLAY
INFORMATION :
ON, OFF
OSD TIMEOUT :
OFF, 5 ~ 40 SEC
(10)
INFORMATION
RESOLUTION
HDCP MODE
HDCP OUTPUT
HDMI IN +5V
EDID MODE
FIRMWARE
SINK INFO.
FACTORY
DEFAULT
YES
NO
Default settings are marked in a bold italic font.

7
6.4 EDID Management
This unit uses an EDID Management application which allows the user
to copy the EDID from an attached display, edit an existing EDID le
stored on the PC or create a basic EDID from scratch. The EDID can
then be uploaded to the unit for use. Please obtain the EDID Manage-
ment software from your authorized dealer and save it in a directory
where you can easily nd it.
Before connecting the unit to your PC, please install the appropriate
Virtual COM Port Driver depending on your Windows version. Next,
install the EDID Management software. After the installation has suc-
cessfully completed an icon for it will appears on the windows desk-
top. Launch the software by double-clicking on the icon and the EDID
Management device detection window will open up on your screen.
After launching the software, power the unit on and then connect it
to the PC/laptop using a USB cable. Click on the “Search” button and
any detected units will be displayed in the list. Clicking on a detected
unit will open the EDID Commander window.

8
EDID Controller Tab
Mode Select: Under the EDID Controller tab the user may select the
EDID to be sent to the connected HDMI source from 8 Internal, 1 Exter-
nal (bypass) or 8 User EDID options. When selected, the LED lights on
the unit will change accordingly.

9
Save/Upload/Analysis: EDIDs may also be saved, uploaded or ana-
lyzed.
• Any EDID from the unit or a connected HDMI display can be
saved to your PC as a *.bin le by selecting the EDID source
from the drop down menu and then clicking the “Save” icon.
• Previously saved EDID les (*.bin format) can be re-uploaded
into any of the “User” EDID slots by selecting the User EDID to re-
place from the dropdown and then clicking the “Upload” icon.
Before accepting the upload, the software will check and verify
that the EDID’s header and checksum values are acceptable.
• To analyze any EDID stored within the unit, select the EDID to
view from the dropdown and click on the “Analysis” icon. From
the Analyzer window it is possible to open the currently ana-
lyzed EDID in the EDID Creator by clicking the “Edit” button.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

10
EDID Creator Tab
Click on the EDID Creator tab to begin designing a new EDID from
scratch (select the “New” icon), to modify an existing EDID stored on
the PC as a .bin le (select the “Load” icon) or to edit an EDID copied
from the unit via the EDID Analyzer’s edit option. Selecting “New” will
automatically populate the various EDID elds with basic information
that can be easily edited to match the user’s preferences. Clicking
on the “Load” icon will open a le load window and after the *.bin le
has been selected and loaded the EDID elds will be populated with
the information from that le. The same will happen when the EDID is
copied from the EDID Analyzer window.

11
The following tabs provide access to a wide range of EDID information
which can be edited:
• Descriptor: This tab allows for the editing of various description
and information elds within the EDID le such as Manufacturer
Name, Monitor Name, etc.
• PC Timing and SD/HD/UHD: These tabs allow for the selection of
the resolutions and refresh rates that the EDID will report as sup-
ported.
• Audio1 and Audio2: These tabs allow for the selection of which
audio formats, audio frequencies, channels and speaker loca-
tions are supported.
• Color Space: This tab allows for the selection of which color for-
mats and bit depths are supported, including BT.2020 and HDR
support options.
• Others: This tab contains options for supporting 3D and dening
the CEC Address.
Once the user is nished editing or creating an EDID it can be saved
to a *.bin le locally or uploaded directly to the unit using the “Save”
and “Upload” icons respectively.
System Tab
Select the System tab to edit the software’s description, to reset the
unit to factory defaults and to view the unit’s current hardware and
rmware version information.

12
7. CONNECTION DIAGRAM
HDMI IN USB POWERDC 5VHDMI OUT
DVD or Blu-ray Player
PC or NotebookUHD TV

13
8. SPECIFICATIONS
8.1 Technical Specication
Video Bandwidth 600MHz/18Gbps
Input Ports 1 x HDMI, 1 x Mini-USB
Output port 1 x HDMI
Power Supply 5VDC/2.6A (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body Model: ±8KV (Air Discharge),
±4KV (Contact Discharge)
Dimensions 110mm x 25mm x 75mm (W×H×D) [Case
Only]
128mm x 25mm x 83mm (W×H×D) [All
Inclusive]
Weight 268g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F
Storage temperature -20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (no condensation)
Power Consumption 2.8w
Note: HDMI cable distance can be impacted by the materials and
design of the cable used. The use of “Premium High Speed
HDMI” cables is highly recommended.

8.2 Video Specication Support
Supported Timings (Hz) Input Output
640x480@60/72/75/85  
720x480@60  
720x576p@50  
800x600@56/60/72/75/85  
1024x768@60/75/85  
1280x720@50/60  
1280x720p@60  
1280x768@60/70/75/85  
1280x800@60  
1280x1024@60  
1360x768@60  
1600x1200@60  
1920x1080i@50/60  
1920x1080p@24/25/30/50/60  
1920x1200@60(RB)  
3840x2160@24/25/30/50/60  
3840x2160@50/60 (YUV 4:2:0)  
4096x2160@24/25/30/50/60  
4096x2160@50/60 (YUV 4:2:0)  

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
MPM-CED2M
