PAGE 1MIRATRON 866-417-5008 503-352-0654 www.miratron.com
Externally powered data radio with field-selectable analog inputs.
INSTALLATION MANUAL - T8-LTE-E
WIRING/CONFIGURATION
TX ACTIVE
ON
OFF
mA V TH
INPUT 1
INPUT 2
RATE
10 SEC
10 MIN
PROG
THERMISTOR
10K TYPE 2 or 3
POWER
0-5/10V
GROUND
TYPICAL
3-WIRE
SENSOR
POWER
4-20mA OUT
TYPICAL
2-WIRE
SENSOR
CONSULT SENSOR INSTRUCTIONS
FOR SPECIFIC INSTALLATION REQUIREMENTS
X
V+ (OUT)
INPUT
COMMON
X
SET SWITCHES
TO MATCH SENSOR
OUTPUTS
V+ (OUT) INPUT 1 COMMON V+ (OUT) INPUT 2 COMMON
V+ (OUT)
INPUT
COMMON
V+ (OUT)
INPUT
COMMON
EXTERNAL SENSOR WIRING:
mA V TH
+ -
EXT.
POWER
9-30VDC
OA RH/T
PLUG
MAIN
POWER
SWITCH

PAGE 2MIRATRON 866-417-5008 503-352-0654 www.miratron.com
OPERATION
Configuration settings:
Rate switch - Set for desired transmit rate. 10 SEC mode transmits every 10 seconds for setup and troubleshooting. 10 MIN mode trans-
mits every 10 minutes for improved battery life. Auto mode can be factory configured or user programmable via serial receiver to transmit
on programmed interval or on alarm event. Refer to receiver point-map document for details on programmable rate feature.
Integrated options:
Features 2 universal, switch selectable analog inputs. Wire external sensors as shown in diagram. Consult sensor manufacturers instructions.
Set input scaling switches to match sensor output type (ermistor, 0-5v/0-10v, or 4-20mA)
RHT: Integrated air RH/T sensor probe is factory installed. Sensing element is field replaceable. Compact probe design features solar shield
and sintered metal media filter. Polymer sensing element is factory calibrated and recovers from saturation. No service is required under
normal operating conditions.
Accessory options:
T8-VAC: Vacuum sensor for use with soil tensiometer. Includes sensor, armored cable, and plumbing for use with popular soil tensiometer
tubes. Consult factory for other options. Connect to analog input as shown in diagram.
T8-IMM: Immersion temperature probe with armored cable and potted 10k type III thermistor. Connect to either thermistor input.
T8-ANE: Pulse to analog converter for use with Met One Instruments 014MINI cup anemometer. Connect to any unused analog input set
to 0-5v scaling.
Antennas:
Standard SMA connector is provided on all models for use with factory approved antennas. A variety of antenna options are available,
including a directional Yagi, and omni-directional whip types. All models include 1/2 wave “rubber duck” antenna.
SPECIFICATIONS
Power External power (-E) 9-30vdc, 100mA Min.
Inputs Switch Selectable mA setting for 4-20mA devices
V setting for 0-5v/0-10v devices
Temperature setting for 10k-ohm thermistor, type 2 or 3 (Jumper selectable)
RH/T Serial interface for Miratron integrated RH/T sensor probe option
Configuration/Setup Power On/Off switch
Transmit rate Switch selectable, 10 sec or 10 min fixed or programmable automatic interval
Analog input 2 x Switch selectable 0-5v, 0-10v, or 4-20mA
Indicators Internal transmit and charging status LEDs
Radio Frequency, Standard Range 2.4GHz, Unlicensed ISM band, spread spectrum
Frequency, Extended Range 902-928MHz, Unlicensed ISM band, spread spectrum
Range Up to 3 miles outdoor line-of-sight with optional directional antenna
Enclosure UV stable polycarbonate, NEMA 4X, 5-3/4”x 3-1/2”x 2-1/4”, with molded-in mounting brackets
