MIRAX MDVR-301 User manual

Vehicle SD Card Video Recorder
Installation Manual
Maintenance contacts

Contents
I、Insta llati on specifi cation and Rules
II、System element
III、Equipment syste ms insta llati on and te sting
3-1 Mainfra me fixed
3-2 The installation of camera s
3-3 The installation of magnetic switch on the door(M enci)
3-4 System Linked Dra wing
3-5 The function and re joining method of all kind of re cord er wire
3-6 The installation and debugging of vehicle speed signal
3-7 System debugging
IV、Manipulate
3-8 Host interf ace
3-9 The function instru ction of the video re cord er
4-1 The corre ct way to take and put the card
4-2 The corre ct way to format and restoration SD Card
V、Video Record er Technical Target
V、Video Recorder Technical Target
Number Item Technical Target
1 WVDC 9V ~ 36V (be applicable to all vehicle)
2 Rated operational current <300mA
3 Ambient Operating Range -40oC ~ 85 oC ( be applicable
to from coast to coast)
4 the humidity in the environment 20% ~ 95% RH
5 Video input 1-channel; 2-channel (1.0V
p-p/75Ω SYS:PAL/NTSC)
6 Audio Input 1-channel(frequency coverage:300-5KHZ;
frequency response:2.5dB)
7 Obligate input signal one pulse value signal (Velocity); one
switching value (footbrake)
8 Video output 1-channel (TVOUT) (1.0V p-p/75Ω
SYS:PAL/NTSC)
9 Audio output DC12V/1A
10 Support SD Card capacity 256M - 16G
11 file format AVI
12 Video frame rate 15 - 30 FBS(cycles per second)
13 Audio resolving capability
VGA (640X480) or QVGA (320X240)
14 Audio Dimension of frame Length118mm×Width83mm×Height42mm

1) Use the bad SD card insert to video recorder slot,the car
ignition, and close the doors (or press the manual/auto button),
waiting for the recorder automatically shutdown after over 2 0
seconds, press the "Power" button . And reboot the system.
2)When the screen appears "Welcom" interface,manualpop up the SD
card quickly.
don’t
3)When the screen is blue and display "Card
Errorr" prompt characters, press the card
inside the video recorder slot once again
quick.
4) Recorder into the main interface, choose
"Settings" function, according to the "OK"
button, enter into the setting interface
(Figure41).
5) Affter into the setting interface, choose the
"format", according to the "OK" button,
enter into the memory card select interface
(Figure 42).
6) And affter into the memory card select
interface, select "SD Card", according to
the "OK" button, choose "Yes", then press
the "OK" button (Figure 43).When the
screen display "funnel "icon that is working
to format implement(have a longer time).
7) When the screen display "Successful" red
characters, said SD card format has been
successful as FAT 3 2 format, from this
point should be shutdown, and the card in
the computer press over the operation to
re-format.
Figure 41
Figure 42
8) When the monitor display "Memory
Errorr" prompt red characters, said SD
card not format ,and now need to repeat 1 -
6 of the steps, or can’t be repeated three
times to format, the SD card can only send
to the factory repair.
2 To force repair SD card
Figure 43
20
1. The product of the wiring and installation needs of the professional
skills and experience, with professional staff to carry out the
installation of wiring and installation to ensure the safety of this
product is installed.
2. The product can only be applied in the operating voltage 12 V - 36V
of vehicles.
3. The installation of wiring when drilling will not touch, damage,
airway obstruction and wires, so as not to cause an accident.
4. When all the wires are connected ,must to use the electronical
wrap plastic sheets to bind the bare copper wire, not short-circuit
with the other wires, take good wires application truss ties, so that
they do not curl or entanglement in order to avoid sharp or sharp
vehicle parts cause electrical damage have accidents outside.
tion of cameras, to choose the location and camera wire
put in inconspicuous places hat the passengers is not easy damage;
it is not easy for people to damage and pressure off;adjustable
camera angle to the right point of view, then fixed it , attached seals;
from the camera equipped with infrared light can not exceed 1 2
lights.
6. When installation of recorder, it must be installed on the local of
waterproof and moisture.
7. The wiring should be first connect to the power and signal line of
the camera and microohone; followed 'Signal Bus' ignition, video
control, reversingand so on the signal lines,then the last connect is
recorder, and input of power supply box.
8. Don’t install the microphone in the wind, because the microphone
is the higher sensitivity.
9.When installation of Menci , attention away from the action is less
than 10 mm, after closed the door the distance of Menci can not be
more than 10 mm, or else they might make the video recorder in a
long working state; Menci wiring, the one side of the Menc connect
to the video control lone,fllowed the other side of Menci shoud
connect to the power to prevent a short circuit occurred on Menci.
5. The installa
I、Instal lat ion sp eci ficat ion and Rul es
01
(6)To the format 100%would show this SD card is good and formatted
successful.

(4) Click on the left button of format then show the Figure 31 and
Figure32, if the SD card is at 4G or below 4G, file system should
be choose 'FAT','distribut the unit size' should be choose 6 4 K
(Figure 36); if the SD card is the 8 G or above 8G,'file syste should
be choose 'FAT 3 2', 'distribut the unit size' should be shoose 3 2 K
(Figure 37) press the "OK"’ button began to identify format.
' '
(5) If the SD card is the 4G or below4G,there will show a dialpg ,press
the"OK"button to show the Figure38, then press the 'OK 'button
start to format; If the SD card is the 8G or above8G , there will
show the Figure 39 , And then press the'OK' button start to
format .
Figure 36 Figure 37
Figure 38
19
Rules
1. Not allow to inset or take out the SD card when the video recorder is
working,if do that must according to the normal shutdown
recorder and then inset or take out the SDcard , because SD card is
very easy to damage and loss of the machine program.
2. The proposed use of each card after the inspection,reformat the
SD card again.
3. Attention to the SD card format correctly operation, as detailed in
the SD card format operation.
4. In accordance with the provisions of the original SD card, SD card to
protect the appearance of the plastic shell can not draw trace badly,
otherwise the manufacturer don’t supply warranty.
二、System element
Host System Camera SD Card
三、Equipment systems installation and testing
3-1 Mainframe fixed
Shown in Figure 2, the host at the bottom of the
groove with double-sided adhesive paste to
quakeproof.In the vehicle to find a relatively
stable temperature, water is’t easy to reach,
close to the instrument panel, ventilation, with 4
screws will be fixed host, and truss video
recorder bus with tie.
3-2 The installation of cameras
Shown in Figure 3, installation of cameras,
requirements of the first camera to carry out
wiring, as far as possible all the camera signal
line wiring in the interior of vehicle, should not
be exposed or visible camera signal line place.
Figure 2
Figure 3
02
Figure 1

(
(3) Click on the left of what have been selected the SD card disk, click
on the right and then show the following options, select the
format and click the lef key (Figure 35).
Figure 34
Figure 35
18
Don’t vigorously pull the wire when wiring to prevent pull off wire,
and also be careful to don’t damage wires to prevent short-circuit
when twisted the screws.Then adjustable the video location of with
cameras angles.With drill make more than 3 screw holes, using screws
to a fixed base of the camera, the camera covered with a shield fragile
stickers affixed.
3-3 The installation of magnetic switch
on the door(Menci)
Shown in Figure 4, install Menci switches
Before drill the screw holes must make sure that
the distance between Menci A and Menci B the
relative position of principle is not to shut the
door after the oppression Menci A or Menci B,
Menci A and B among the best distance of about
2mm.Requested Menci switch wire connect the
absence(non-power-state) after closed the door,
also Menci switch line for the power after open
the door. Ensure the position, with drill make 2
screw holes . With 2 screws to fix switch Menci .
The Menci switch wire wiring with the same cameras.
Figure 4
03

04
2) Press the OK button enter into the next directory, press the button
to select'1 0 0 COACH 'folder, and then press the "Ok" utton again
enter into the;'1 0 0 COACH' folder inside all of the video
footage,through the up/ down button to choice which footage first
play. According to the"OK" button to start playing.
" "
b
3) Enter into the video after the broadcast, according to the right
button fast-forward, every click of a speed increase, a total of 4-
speed, according to the left is a fast-forward back, every click of a
speed increase, a total of 4-speed.
4) In the fast-forward mode, press OK the fast-forward to
stop and stop playing, and then press the"OK" button again to open
as normal player; according to press the"Exit" button to stop the
broadcast and return to the 1 0 0 COACH 'folder of the directory.
" " button
4-1 The correct way to take and put the card
1. Take card
First, the car stop and non ignition,then close the door, waiting for
the system automatic shutdown (or press the manunal/auto
button), in the shutdown state, with hand to press the "SD card" by
gently down .The "SD card" will automatically pop up affter
go , and slowly took out the card, the card has finished check.
Not allow to inset or take out the SD card when the video recorder is
working, that must according to the normal shutdown the
recorder and then inset or take out the SDcard , or SD card is very
easy to damage and loss of the machine program.
2. Loaded card
First, the car stop and non ignition,then close the door, waiting for
the system automatic shutdown (or press the manunal/aut button),
in the shutdown state,with hand slowly to press the "SD card" to
insert the card slots that make a smaller
sound,the "SD card" not automatically pop
u after hand let go,finished card installed.
hand let
4-2 The correct way to format and
restoration SD Card
1.In the computer format (WinXP systems)
(1) Right-click 'My Computer’, appears under
the map, select management (Figure 33).
Figure 33
17
Figure 5
(2) There are computer management interface
map, click on the left side of the disk
management (Figure 34).

3)
interface settings have been saved, and then startup to check
whether there have set up to preserve.
Press the"power" button off affter setup, the normal shutdown
4 Setup language
1)
the host at the manual state,after over 2 0
seconds ,then press the "Power"button
again reboot the system,return to the main
interface(Figure 13) then press the
left/right button to select 'set', according to
the "OK" button to enter'set menu' ,and then
through the up/ down button to
select"language" (Figure 29).
) First insert the USB key on the host , make
2) Press the ok button to enter into the 'language
menu' (Figure 30) in the ‘menu display' were
'Chinese,' English 'in two languages, through
the up/ down button to set the language
mode.
" "
Figure 29
Figure 30
3)
interface settings have been saved, and then startup to check
whether there have setup to preserve. 2) There are computer
Press the "power" button off affter setup, the normal shutdown
5 On-site playback
1) First insert the USB key on the host , m
the host at the manual state,,after over 2 0
seconds ,then press the "Power"button again
reboot the system,return to the main
interface(Figure 31) then press the left/right
button to select 'Multimedia ', according to
the "OK " button to enter 'Multimedia menu'
and then through the up/ down button to
select 'DCIM' folder (Figure 32).
ake
Ffigure 31
Figure 32
16
Figure 6
05

▲ Power input bus is red wire, when all the circuit wiring must be
connected correctly,only can connect this power red wire.
▲ Camera to be correct, the wiring can not take the wrong wire or
short-circuit, or else they will burn with the host camera.
▲ Infrared camera lights power wires (red, black) and the camera's
power wires (red, black) to be received together With the power
supply Box is negative.
3-5 The function and rejoining method of all
kind of recorder wire《Host part》
06
2) Setup time
1) To enter "Date Time" menu interface, through the button
to select the 'set-up time' .According to the "OK" button to enter the
“time set menu “(Figure 26), with the left/right button to select the
hour、min,and with the buttom to setup the hour、min
scores.
up/ down
up/ down
Figure 26
1) Enter into the Date Time menu interface, through the
button to select the "date formatted". According to the "OK" button
to enter the setup time menu, use the up/ down button to set the
date format.
" " up/ down
(3) Setup date format
3 Setup the display of video recorder
1) First insert the USB key on the host , make
the host at the manual state,,after over 2 0
seconds ,then press the "Power"button
again reboot the system,return to the main
interface(Figure 13) then press the
left/right button to select 'set', according to
the "OK" button to enter 'set menu' ,and
then through the up/ down button to select
'show' (Figure 27).
Figure 27
2)Press the OK to 'menu display' (Figure28)
in the 'menu display’ were 'LCD', 'PAL',
'NTSC' three display mode, ( 'LCD' is the
model of the host own 2. 5-inch liquid
crystal display screen, 'PAL' external model
is the P-screen display, 'NTSC' external
model is the N-screen display), through the
up/ down button to set the display mode.
" "
Figure 28
2) Press the "power" button off affter setup, the normal shutdown
interface settings have been saved, and then startup to check
whether there have set up to preserve.
15
A、The Red Wire(the power of positive)
Function: The normal use of the total input power wire’s positive
for machine , the operating voltage 12 V -36 V.
Connection: Access only regular-power, that is the vehicle battery
positive electrode.
B、The Blue Wire(the power of negative)
Function:The normal use of the total input power wire’s negative
for machine.
Connection: The only grounded of vehicle, that is the vehicle battery
negative or the ground wire of vehicle.
C、The Purple Wire(ignition wire)
Function:The machine could startup and enter to the surveillance
state but don’t video ,the operating voltage 12V-36V.
Connection:Usually connect to the vehicle unlock ignition to the
first file,the file is ON shift,the machine will auto startup when
connect to the high level of above 12V.
D、The Green Wire(recorded in the wire of control)
Function: It can automatically startup and video when high level,
have the startup and video features, the operating
voltage 12V - 36 V.
Connection: To be a long time can be recorded from the car unlock
ignition to the first file, the file is ON shift.
E The Brown Wire-reversing wire(camar a signal switching)
Function:It can automat ically switching the front view and
the back view of camar a sngnal when high level.The operating voltage
、
12V - 36 V.
Connection:Usually connect with the video control wire on the Men ci.
When door opened will recording the coin box and door closed
recording in-vehicle
(1) Power signal bus(6-core: red black purple green brown white)、 、 、 、 、
F The White Wire(12V control wire)
Funtion:Use to control 12V power box ON or OFF,make the 12V power box
output with the recorder syncronously.
、

2) Enter into the settings menu after the
resolution (Figure 22) with the up/ down
button to select video resolution, 3 2 0 X 2
4 0 and 6 4 0 X 4 8 0 two optionals, higher-
resolution the better the efect, but the
record will become a bigger document, the
time will be reduced.
Figure 22
3) Press the power button off affter setup,
the normal shutdown interface settings
have been saved, and then startup to check
whether there have set up to preserve.
" "
2. Video recorder setup time
(1) Setup date
1)
the host at the manual state,,after over 2 0
seconds ,then press the "Power"button
again reboot the system,return to the main
interface (Figure 13) ,through the right
button to select "setting".According to
the"OK" button to enter into "set menu”
(Figure 23).
First insert the USB key on the host , make
Figure 23
2) On the Set Menu interface through the
down button to select "Date Time" by the
"OK" button to enter the "Date Time" menu
interface (Figure 24).
" " up/
3) Enter to "Date Time" menu interface,
through the up/ down button to select
"Date Set".According to the "OK" button to
enter the "date set menu" (Figure 25), with
the left/right button to select the year,
month, day, and with the up/ down button
to setup year, month, the number of days.
Figure 24
Figure 25
4)
interface settings have been saved, and then startup to check
whether there have set up to preserve.
Press the "power" button off affter setup, the normal shutdown
1) Press to enter through the "AV IN" menu interface (Figure 20).Used
the up/ down button to select resolution options, according to enter
into the resolution settings menu.
14 07
(2) Camara bus(4-core: blue gray brown white )、 、 、 、
A The Blue Wire(12 V posit ive wire)
Funtion:The posit ive wire output 12V and the output maxmum curre nt
not than 1A,for a long time work not than 0.6A.
Connecttion:co nnect to the posit ive power wire of camara,tah t only
allowly connect 2 camaras with 12 infrare d lights
B The Gray Wire(gr ound wire)
Funtion:Have output 12V of negative wire connect to the intern al ground
wire of video recorder.
Connection:Connect to the ground wires of camara and micro phone .
、
、
C The Orange Wire (camara1 is CAM1 signal line)
Funtio n:When the video recorder is the switc hing mode,th is wire will be a
front signal wire ;But when the video recorder is 4 channel mode,th is line is
a foot- brake signal line.
Connectio n:At the video recorder switc hing mode state ,orange wire connect
to the camara1’s(CAM1) signal line.when is 4 channel mode the orange wire
will be connected to the green wire of speed foot-b rake amplifire output bus.
、
D The Yello w Wire(camara2 is CAM2 signal lin e)
Fountio n:When the video recorder is the switc hing mode,th is wire will be a
front signal wire;But when the video recorder is 4 channel,th is wire is a
speed signal lin e.
Connectio n:Connectio n:At the video recorder switc hing mode state ,orange
wire connect o the camara2’s( CAM2) signal lin e.when is 4 channel mode the
orange wire will be connected to the yello w wire of speed foot-brake amplifir e
output bus.
、
(3)MIC wire- audio signal line
A、Funct ion: Connect to the audi o signal line, the center is a signal line,
and the out side is shielded ground.
Connect ion: Aud io of the ce nter wire and the microphone center
wire connect , audi o line with the microohone shielding wire connect ion.
(4)TVOUT wire - analog video signal output line
A、Function: Output video signals line, center is the signal line,and the
outside is shielded ground.
Connection: TVOUT center line connect to the video signals center
line of external monitor , TVOUT shielded wire and monitor shielded
wire connection.
Speed foot-brake amplifire connetion(optional)
Output bus(4-core)(red black yellow green)、 、 、
A The Red Wire-power supply positive
Funtion:Mmplifire power wire,the operating voltage 12V-36V.
Connection:When the video recorder is the switching mode should be
、

3-6 Vehicle speed signal installation and debugging
(1) Vehicle speed signal and speed amplifier
linked drawing:(Figure 8)
(2) Speed amplifier debugging:
The first is me asureme nt before start to debugging:
1) The speed sensor signal line will connect to the
voltage of ground when the vehicle stopped, and
when the vehicle is running too.
2) According to these two measure value and then
select the corresponding of adjustable means.
The first method: (Figure 9)
Use the multimeter to measure the vehicle speed
08
(2)SD card interface:Insert or take out the storage medium SD card.
Nose: Not allow to inset or take out the SD card when the video
recorder is working,must waiting for the host had power off just
can take out the SD card.
(3)TV out interface function: Debugging for the Procedures of manuf -
acturer.Don’t the TVOUT output video wire!
(4)Press the manual/auto button and shells up could shutdown when
the recorder is normal working. And now,the auto startup function
have been canceled. Re-boot must through the manual button next
time.
3-9 The function instruction of the video recorder
1. Setup the video quality and resolution
(1) Setup the quality of video
2)Through the left/right button to select
"record" according to press the "OK"
button to enter the "record" menu
interface (Figure 18).
Figure 18
3) Enter into the "record" after the menu
interface (Figure 19), use the left/right select
"AV IN" and press "OK" button to
displayback screen, then press the "Menu"
button to enter the "AV IN" menu interface
(Figure 20 ); through the up/ down button to
Figure 19
4) Access to quality after the set menu (Figure
21), with the up/down button to select the
quality of the video, there are three types of
high-middle-low options, the higher the
quality of the images, the better the effect,
but the record will become a document of
great time reduced.
Figure 20
5)
the normal shutdown interface settings
have been saved, and then startup to check
whether there have set up to preserve.
(2) Setup the resolution of video
Press the "power" button off affter setup,
Figure 21
1) First insert the USB key on the host , make
the host at the manual state,,after over 2 0
seconds ,then press the "Power"button
again reboot the system,return to the
main interface
13
Figure 7
connect o the blue wire(+12V)of power output bus,and when the video
recorder is 4 channel mode should be connect to the red wire(+12V) of 12V
output bus of power box.
BThe Black Wire-power supply negative
Fountion:Amplifire power negative.
Connection:Connect to the internal grounding of the video recorder or power box
t
、
C、The Yellow Wire-after to amplify speed signal line
Funtion:Affter to amplify the speed signal line.
Connection:When is the 4 channel only could connect to the yellow
wire of the host camara signal bus.
D、The Green Wire-after to amplify foot-brake signal line
Funtion:Affter to amplify the foot-brake signal line.
Connection:When is the 4 channel only could connect to the orange
wire of the host camara signal bus.
Input bus(single yellow core and single orang core)
A The Yellow Wire-vehicle speed signal wire
Funtion:The speed signal line of vehicle eletronic pulse sensor.
Connection:Only connect to the electronic pulse sensor speed signal
、
B The Orange Wire-vehicle foot-brake signal wire
Funtion:Vehicle brake light signal line(brake will have high voltage
and no brake will low voltage).
Connection:Only connect with the vehicle brake light signal line.
、
Figure 7
Figure 8

四、Manipulate
3-8 Host interface(Figure 17)
Functional interface that:
（1）USB interface function: Debugging for the Procedures of
manufacturer
Nose: Please don't use the USB interface connect to your computer or
any moving device, otherwise will cause the host have the
potential to a permanent death of phenomenon .
3. And then closed the door, test the host can automatically switch the
camera and video (blue character displayon the screen), and image
display also, a period of time (system latency video time) after the
upper left corner of the screen automatically red spots
disappeared,and then display video on the screen.
4. And then the door opened, it can automatically test the engines for
video (the blue screen time), and image display. Note this system is
normal.
5. To use open or close the door, adjust camera angle to survelling the
position, and colored plastic screw, cover the protection of camera
cover, closed a good seal.
6. The data bus, the total power supply are received on-board power
supply on the negative electrode , The door to switch the system to
work normally, after commissioning of the entire system.
12
Figure 17
The second mefthod: (Figure 10)
Use the multimeter to measure the vehicle speed sens
or signal line and the voltage of<0.5V when in the
absence of speed, the voltage of speed signal line
voltage of>2.5V when the vehicle is running, NO.1
And NO.4 of the DIP should be opened at this time
synchronous , debugging the adjustable resistance until
have the signal of speed, and then measuring resistor R5
close to ICpoints when driving. so that the points voltage
Less than 2.5V.
The third method: (Figure 11)
Use the multimeter to measure the vehicle speed
sensor signal line and the voltage of between 0.5V-
2.5V when in the absence of speed, the voltage of
speed signal line voltage of<2.5V when the vehicle
is running and need to open NO.2 of the DIP switch
and debugging the adjustable resistance until have
the signal of speed on the screen.
Figure 9
The fourth method: (Figure 12)
Use the multimeter to measuring the vehicle speed
sensor signal line and the voltage of between 0.5V-
2.5V when in the absence of speed, the vehicle
speed sensor signal when the voltage of > 2.5V and
at this time must open NO.2 and NO.4 of the DIP
switches. Adjusting resistor until have speed, and
then measuring resistor R5 close to IC points when
driving, so that the points voltage less than 2.5V.
Note:(Figure 12)
(1) Hav’t connected to the head of line must be
packed with insulation adhesive tape, avoid bare
head happed accident.
(2) If the speed amplifier failure, can be pull NO.3 of
DIP switch, and start to use the backup amplifier.
(3) When open the NO.1 switchR5 close to IC point's
voltage could be selected to debugging in the1.5V;
Figure 10
Figure 12
Figure 11
09
The abs enc e of spee d, the vol tage of spee d Signa l line Vol tage of<2. 5V
when the vehicle is runni ng, NO.1 ofthe DIP switch shoul d be ope ned .At
this time,deb ugg ing the adj ustabl e esistanc e Until display r spee d on the
screen..
Sensor signal line, and the voltage of <0.5V when in the absence of
speed,the voltage of speed signal line.

(3) Seting the pulses approach of vehicle
manual to set the pulses approoach of vehicle
1) To manually startup : Press the machine’s power button (red button)
when the video recorder is shutdown (vehicle no ignition and door
are closed).
2) And then enter to the setting interface:
through the left/right button to select
setting menu, press the"OK" button to enter
the setting interface (Figure 13)
Figure 13
3) Enter to the vehicle parameter setting
interface:through the up/down button to
select vehicle parameter menu, press
the"OK" button to enter the setting the
vehicle interface (Figure 14)
figure 09
4) Setting of vehicles characteristics
coefficient: through the up/down button to
select " Pulse Test " (Figure 15) press
the"OK" enter to " pulse test setting "
interface (Figure 16), through the left/right
button to select "the accumulated pulse"
use the up/down button to set pulse count,
and that is all right, then press "OK"
confirm to exit the interface. And then
press the shutdown button (red button)
.There will see the shutdown interface if
your operation all right. Next you must
startup again to check the pulse what have
been set just now. After shutdown for a
minute , the right preservation. express to
the setting is successful (Not normal
shutdown cann't save settings).Figure15
5) The method for estimate calculating of
t h e actual pulse:
Will record the content at the same time
When the vehicle is uniform speed running
Record video recorder current display speed and the
vehicle speed table actual speed
actual pulse=video recorder current speed×video recorder
current pulse
Vehicle speed table actual speed
Figure 14
10
2) The vehicle drive to the beginning of actual road that has been
measured , the front of vehicle must align to the beginning of
measured road;
Figure 16
6) Accumulated total of the pulse display on the screen should be save
the pulses count at this time after the vehicle driving the actual test
of road. And then press two "OK" button to confirm all are right. At
this time will automatically jump back to the vehicle parameters
interface.
Host, camera, Menci switch, speed amplifier are installed,check all
the correct circuit connections, can debug the system work.
1. Inser the USB key then press the"Power" manual boot the host
,there will normally startup,press the"Power" again the host will
have a normal shutdown;
2. To open the door, use the"Power Testing" Positive connect to the
data bus of the total power positive t(red wire), the negative
electrode to connect data bus, the total power supply negative
(black wire) to test whether the host will automatically open and
automatically recording (blue character dispaly on the screen), and
image display on the monitor.
3-7 System debugging
1) Measured the distance on the ground how far will actual road test
meters , and the distance must keep a straight line. (Usually 100 or
200 meters).
3) Then the vehicle don't ignition and close the door, press the host's
Manual/ Automatic button after 20 seconds and then press the
power button reboot the machine.
4) Enter to the set interface of pulse (Figure16)
in the 'test mileage'item , using the up/down
button to select the test meters of road , and
then press the "OK" button, the host system
will automatically accumulative total of the
pulse and the cumulative. Total of the number
of auto-zero pulse.
5) Vehicle ignition, so that the vehicle driving at the end of actual
measured road in the uniform speed state .The front of vehicle must
align to the end of measured road.
7) Press the power button to shutdown, settings have been saved if the
shutdown interface display is normal, and then startup the host to
check the boot settings are saved just now.
11
when opening NO.2 switchR5 close to IC point's voltage could be
selected to debugging in 1.5V.
