Mircom RAX-LCD User manual

RAX-LCD
Remote FX-2000 Annunciator Panel
LT-856 Rev 9
February 2018
Installation and Wiring Manual
Mircom FX-2000
Fire Control System
- System Normal -
Feb 21, 2018 12:21 PM
SIGNAL
SILENCE
FIRE
DRILL
SYSTEM
RESET
GENERAL
ALARM
ACKNOW-
LEDGE
LAMP
TEST
ENTER
TROUBLE
QUEUE
SUPV.
QUEUE
ALARM
QUEUE
MENU
CANCEL
INFO
MONITOR
QUEUE
A.C.
ON
PRE-
ALARM
GROUND
FAULT
REMOTE ANNUNCIATOR

i
Table of Contents
1.0 Introduction 1
2.0 Installation Instructions 2
3.0 Wiring Instructions 3
4.0 DIP Switch Settings 4
4.1 The RAX-1048TZDS Adder Annunciator Chassis .......................................................... 6
4.2 The IPS-2424DS Programmable Input Switches Module ............................................... 6
4.3 The RAX-LCD Shared Display Chassis ......................................................................... 6
5.0 Specifications and Features 7
5.1 Enclosure Models ........................................................................................................... 7
5.2 Module Models ............................................................................................................... 7
5.2.1 RAX-LCD Remote FX-2000 Shared Display LCD Annunciator ...................................... 7
5.2.2 RAX-1048TZDS Adder Annunciator Chassis (48 Display Points) .................................. 7
5.3 Current Drain for Battery Calculations ............................................................................ 8
5.4 Environmental Specifications ......................................................................................... 8
6.0 Warranty and Warning Information 9

ii
List of Figures and Tables
Table 1 Backboxes ...................................................................................................................... 2
Figure 1 Mechanical Assembly Diagram ...................................................................................... 2
Figure 2 Wiring Diagram ............................................................................................................... 3
Figure 3 Annunciator Panel Connections ..................................................................................... 3
Table 2 Maximum Wiring Run to Last Annunciator ..................................................................... 4
Table 3 Annunciator “Address” Settings ...................................................................................... 5
Figure 4 Annunciator Connections ................................................................................................ 6
Table 4 Enclosure Model Descriptions ........................................................................................ 7

1
1.0 Introduction
Mircom's FX-2000's remote shared display is the RAX-LCD. The RAX-LCD shared display
provides an exact replica (less 16 zone LEDs) of the main FX-2000 Fire Alarm Panel display
at a remote location. It is equipped with a large 4 line x 20 character back-lit alphanumeric
LCD display that uses a simple menu system complete with a directional keypad and switches
for Enter, Menu Cancel and Info. The display expands with up to a total of four RAX-
1048TZDS Adder Annunciator or six IPS-2424DS Programmable Input Switches Modules.
There are five types of enclosure available: the BB-1001D/R, BB-1002D/R, BB-1003D/R, BB-
1008D/R, and BB-1012D/R which can take 1,2,3,8,12 chassis respectively. It may also be
mounted in the BB-5008 and the BB-5014.

2
2.0 Installation Instructions
Figure 1 Mechanical Assembly Diagram
The RAX-1048TZDS is supplied with the NP-681 Blank Laser Printable Label Sheet.
Table 1 Backboxes
Backbox Height H (in.) Width (in.) Mounting A (in.) Mounting B (in.)
BB-1001D/R 9.0” 12.75” 9.95” 7.5”
BB-1002D/R 18.0” 12.75” 9.95” 16.5”
BB-1003D/R 26.5” 12.75” 9.95” 24.9”
BB-1008D/R 33.0” 22.5” 20.9” 35.2”
BB-1012D/R 45.0” 22.5” 20.9” 52.0”
Note: The RAX-1048TZDS displays Initiating circuit status and trouble indication.
Indicating and relay circuits are not remotely displayed. For more details, see the
fire alarm control panel manual that the annunciator is connected to.
BACKBOX CAN BE MOUNTED
WITH STANDARD 4" X 4"
ELECTRICAL BOXES
BB-1001D/R BACKBOX IS SHOWN
ANNUNCIATOR CHASSIS
GB-1001RAX GUARD BRACKET
B
12.75”
H
A
#6-32
HEXNUTS
1.85”
WALL
DOOR
BACKBOX
i

3
3.0 Wiring Instructions
The RS-485 wiring to the RAX-
LCD Display Module is
recommended to be twisted
shielded pair as shown in the
diagram to the right. The wire
gauge may be:
• 22 AWG up to 2000 ft.
• 20 AWG up to 4000 ft.
The RS-485 wiring from the
fire alarm control panel to
the annunciator(s) must be
point-to-point from the fire
alarm panel to the first
annunciator, then to the next
annunciator, and so on. No
star wiring or T-tapping is
allowed. Each RAX-LCD
Shared Display has a 120
ohm end-of-line resistor on
its RS-485 output terminals.
This is removed on all
except the last wired
module.
The 24 VDC field wiring needs to be of an appropriate gauge for the number of annunciators
and the total wiring run length. Use the Current Drain for Battery Calculations on page 8 to
calculate the maximum current for all annunciators summed together.
24 VDC
INPUT
-
+
-
+
24 VDC
OUTPUT
24 VDC POWER FROM FIRE ALARM CONTROL
PANEL OR PREVIOUS ANNUNCIATOR
24 VDC POWER TO
NEXT ANNUNCIATOR
+
-
S
S
-
+
RS-485
INPUT
RS-485
OUTPUT
RS-485 TO NEXT ANNUNCIATOR
(TWISTED SHIELDED PAIR)
RS-485 FROM FIRE ALARM OR PREVIOUS
ANNUNCIATOR (TWISTED SHIELDED PAIR)
Figure 2 Wiring Diagram
RS-485 TERMINALS 24V POWER TERMINALS
ADDRESS DIP SWITCHES
SW1
P1 P2
ALARM
QUEUE
SUPV.
QUEUE
TROUBLE
QUEUE
MONITOR
QUEUE
MGC Network
Fire Alarm Control System
System Normal
February 21, 2018 2:24PM
SIGNAL
SILENCE
GENERAL
ALARM
ACKNOW-
LEDGE
FIRE
DRILL
SYSTEM
RESET
LAMP
TEST
Figure 3 Annunciator Panel Connections

4
4.0 DIP Switch Settings
Each RAX-LCD Shared Display Annunciator needs to be assigned a unique address via the
switch SW1. The RAX-LCD DIP switches are set as:
The OFF setting is active. The addresses available for the RAX-LCD are 33 to 63. Set the
address as follows in the table below:
Note: All circuits are power limited and must use type FPL, FPLR, or FPLP power
limited cable.
Attention: Accidentally connecting any of the 24 VDC wires to the RS-485 wiring
will result in damage to the annunciator and/or to the fire alarm control
panel to which it is connected.
Table 2 Maximum Wiring Run to Last Annunciator
Max for all
Annunciators
Max Loop
Resistance
18AWG 16AWG 14AWG 12AWG
Amperes ft mft mft mft mOhms
0.12 1180 360 1850 567 3000 915 4250 1296 15
0.30 470 143 750 229 1200 366 1900 579 6
0.60 235 71 375 114 600 183 850 259 3
0.90 156 47 250 76 400 122 570 174 2
1.20 118 36 185 56 300 91 425 129 1.5
1.50 94 29 150 46 240 73 343 105 1.2
1.70 78 24 125 38 200 61 285 87 1.0
SW1-1 = Address A0
SW1-2 = Address A1
SW1-3 = Address A2
SW1-4 = Address A3
SW1-5 = Address A4
DIP switches are for assigning an address to the RAX-LCD.
Binary addresses 33 to 63 are available with the least
significant bit being switch SW-1 and the most significant bit
being SW-6. The OFF setting is active binary. DIP switches
SW1-7 and SW1-8 are not used. For example, address 33 is
set by setting SW1-6 and SW1-1 OFF and all the other DIP
switches are ON.
SW1-6 = Address A5(OFF)
SW1-7 = not used
SW1-8 =
Put in “OFF” position
for firmware restore
during power up. At
all other times put in
“ON” state.
i
!
SW1
18
DIP SWITCH SETTINGS
ON
OFF

5
Table 3 Annunciator “Address” Settings
Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5
33 OFF ON ON ON ON 49 OFF ON ON ON OFF
34 ON OFF ON ON ON 50 ON OFF ON ON OFF
35 OFF OFF ON ON ON 51 OFF OFF ON ON OFF
36 ON ON OFF ON ON 52 ON ON OFF ON OFF
37 OFF ON OFF ON ON 53 OFF ON OFF ON OFF
38 ON OFF OFF ON ON 54 ON OFF OFF ON OFF
39 OFF OFF OFF ON ON 55 OFF OFF OFF ON OFF
40 ON ON ON OFF ON 56 ON ON ON OFF OFF
41 OFF ON ON OFF ON 57 OFF ON ON OFF OFF
42 ON OFF ON OFF ON 58 ON OFF ON OFF OFF
43 OFF OFF ON OFF ON 59 OFF OFF ON OFF OFF
44 ON ON OFF OFF ON 60 ON ON OFF OFF OFF
45 OFF ON OFF OFF ON 61 OFF ON OFF OFF OFF
46 ON OFF OFF OFF ON 62 ON OFF OFF OFF OFF
47 OFF OFF OFF OFF ON 63 OFF OFF OFF OFF OFF
48 ON ON ON ON OFF

6
4.1 The RAX-1048TZDS Adder
Annunciator Chassis
P1: Connects to the main annunciator
chassis, or to the previous RAX-
1048TZDS or IPS-2424DS.
P2: Connects to the next RAX-1048TZDS
or IPS-2424DS.
4.2 The IPS-2424DS
Programmable Input
Switches Module
P1: Connects to the main annunciator
chassis, or to the previous RAX-
1048TZDS or IPS-2424DS.
P2: Connects to the next RAX-1048TZDS
or IPS-2424DS.
4.3 The RAX-LCD Shared
Display Chassis
P1: Connects to the first RAX-1048TZDS or IPS-2424DS.
P2: BDM port.
Terminals: See Wiring Instructions on page 3 for details.
SW1: See above for details.
Note: The last annunciator must have 120 ohm E.O.L. resistor connected to RS-485
output terminals.
P2
RAX-1048TZDS Adder Annunciator or
IPS-2424DS Programmable Input Switches Module
P1
POWER
TERMINALS
SW1
P1
RAX-LCD SHARED DISPLAY BOARD
RS-485
TERMINALS
P2
ALARM
QUEUE
SUPV.
QUEUE
TROUBLE
QUEUE
MONITOR
QUEUE
MGC Network
Fire Alarm Control System
System Normal
February 21, 2018 2:24PM
SIGNAL
SILENCE
GENERAL
ALARM
ACKNOW-
LEDGE
FIRE
DRILL
SYSTEM
RESET
LAMP
TEST
Figure 4 Annunciator Connections
