MISURA M16TB User manual

USER MANUAL ENGLISH
TOUCHSCREEN
PORTABLE MONITOR 16“
Model: M16TB with built in battery
Multi-Gesture
Touch screen
Battery
8000 mAh
Working time
3–4 hrs
1080 HDR
High Dynamic
Range
IPS
Super TFT
display
Ultra Wide
Viewing Angle
178°
Ultra slim
monitor

Copyright © 2020 MISURA Store s. r. o. All rights reserved.
No part of this manual, including the products and software described
in this manual, may be reproduced, transmitted, transcribed, stored
in adata storage system, or translated into any language in any form and
by any means, except for documentation stored by the Buyer for backup
purposes without the written permission of MISURA Store s. r. o. (“MISURA”).
The warranty for the product or service becomes void if: (1) the product
is repaired, modified or altered without the written permission of MISURA
or (2) the serial number of the product is illegible or missing.
The technical data and information in this manual are provided for
information only, are subject to change at any time without notice,
and should not be construed as acommitment by MISURA.
MISURA is not responsible for any errors or inaccuracies that may appear in
this manual, including the products and software described in this manual.
SAFETY INFORMATION
 Read all supplied documentation carefully before preparing this
portable USB-C monitor for use.
 To reduce the risk of fire or electric shock, do not expose this portable
USB-C monitor to rain or moisture.
 Do not attempt to disassemble the cover of this portable USB-C
monitor.
 Before using this portable USB-C monitor, make sure that all cables
are connected properly.
 Avoid extremely dusty environments, changes in temperature and
humidity. Do not place the portable USB-C monitor in areas where
there is arisk of moisture/splashing.
 Do not allow objects or liquids to enter the holes / cutouts on the cover
of the portable USB-C monitor.
 In the event of technical problems with the portable USB-C monitor,
contact aqualified service technician or dealer.
 Do not dispose of this product in afire.
 Do not use this monitor near heating devices or in places subject
to high temperatures.
 Keep this monitor away from sharp objects.

WHAT’SIN THE BOX
1
2 3 4 5 6
1. Portable monitor (FHD)
2. HDMI to mini HDMI
3. USB-C to USB-C cable
4. User manual
5. QC 3.0 USB-C cable and 18W charger
6. Magnetic case

DEVICE LAYOUT
RIGHT SIDE
1 2 3 4 5 6 7
7 8 9 10
LEFT SIDE
1. Micro-USB Port
Used to connect to keyboard /
mouse (may need USB-A
to micro USB adapter).
2. Power Indicator Light
3. USB-C Port (Input Power Only)
5V, 4A or Quick Charge 18W
Input.
4. Input Indicator Light
5. USB-C Port (Touch signal)
While connected by HDMI cable
need Plug in USB A-C cable to
enable Touch function.
No Input Power through port
– make sure to charge via other
USB-C port. Output Power: 5V.
6. Mini HDMI Port
Video / Audio input port.
7. Speakers
Audio.
8. Power
Press and hold to turn off
and on monitor.
Tap to return while in menu.
9. Wheel Button
Rotate to increase and decrease;
the previous and the next. Press
to open menu or select option
while in menu.
10. Auxillary 3.5 mm
Connect with external audio
devices.

USING MONITOR BUTTONS
Power On / Off:
Hold power button for 3 seconds to turn on and off.
Return / Exit:
Click power button while menu open to return or exit menu.
Show Menu / Settings:
Press wheel button.
Select Menu Option:
Click wheel button while menu open to confirm / select
highlighted option. While on menu status, short press
to confrm and save your setting.
Open Volume Settings:
Toggle wheel button up and press wheel button.
Open Brightness Settings:
Toggle wheel button down and press wheel button.
Toggle On-Screen Battery Level:
With valid input signal, toggle wheel button down and press
wheel button to show current battery level.
Open Input Source:
Press power button.

LED INDICATOR LIGHT
MONITOR MENU SETTINGS
Blue Color: ON / Input source detected.
Red Color: No source / Standby status.
Dark: OFF.
Green Color: Charging / Not fully charged.
Dark: Fully charged.
INPUT INDICATOR LIGHT
• Brightness: Select brightness level between 0 (lowest) to 100 (highest).
• Contrast: Select contrast level between 0 (lowest) to 100 (highest).
• Volume: Select loudness levels 0 (lowest) to 100 (highest).
• Color Gamut: Select Color Gamut from the following (sRGB, ADOBE,
USER, NATIVE)
COLOR
• Red: Select Red level between 0 (lowest) to 100 (highest).
• Green: Select Green level between 0 (lowest) to 100 (highest).
• Blue: Select Blue level between 0 (lowest) to 100 (highest).
• Temperature: 9300k (coolest), 6500k (cool), sRGB (standard Red
Green Blue), User (custom).
POWER INDICATOR LIGHT
ADVANCE
• Saturation: Select saturation levels 0 to 100.
• Hue: Select hue levels 0 to 100.
• Ultra HDR: Select On, Auto, Off
• Language: Select language.

• 3D Sound: Select 3D Sound
• Sharpness: Select sharpness
• Mute: Toggle ON (muted) or OFF (unmuted).
• EyeProtection: ON or OFF. Low Blue Light Technology reduces the
emission of the harmful low-blue lights on a display in order to prevent
eye fatigue.
• DCR: Dynamic contrast ratio (ON or OFF). Selecting ON will allow
higher contrast ratios.
• Crosshair: Toggle ON or OFF
• Reset: Reset all settings to factory default.
• Game Mode: Toggle ON or OFF
• Bat Info: ON or OFF
• Auto Select (recommended)
• Type-C
• HDMI
• H.Position: Menu horizontal position. (Set by Wheel button)
• V.Position: Menu vertical position. (Set by Wheel button)
• Transparency: Menu transparency settings (0 to 100).
• Menu Time: How long menu will stay on screen for when turned
on (5 to 60 seconds).
OTHER
INPUT
OSD SETTINGS
PORTS AND CONNECTION
VIDEO
Connect Monitor to valid source via mini HDMI or USB-C port .
Ensure you do not use the Power Input Only USB-C port .
Please note that not all PC, laptop, or mobile phone USB-C ports output
display or video signal. Please see the FAQ for more information.
Input video source information
INFORMATION
Exit Menu setting
EXIT

POWER AND CHARGING
Connect USB-C to Input Power USB-C Port: Note the Input Data Only
port cannot charge or provide power to the monitor.
The monitor most likely will not be able to be charged by your laptop as it
requires QC 18W or 5V, 4A input power, which is ahigher output than PCs
and laptops have. This is the case even if your monitor is not on and your
laptop is being charged as it will still not output sufficient power.
The monitor does not support two-way fast charging. This means you
cannot use the monitor to charge your laptop. However, it can charge
mobile phones at 5V / 3W output power via the Input Data Only port-
perfect for charging your phone while casting or mirroring to the monitor.
Other combinations will not work. We strongly recommend charging
and using your Monitor only with our supplied charger.
Expected battery life is approximately 3–4 hours depending on your
volume and brightness setting and the usage (i.e. videos and animated
content played on screen consumer battery more quickly than astatic
screen).
Monitor uses avery specific battery to optimize for power efficiency, size,
and weight. You can ONLY charge your Monitor with a5V / 4A or QC
18W charger.
User Remind
1. Press the power button to turn off the monitor when you stop using it, as
standby status will drain the battery build in
2. First time get the monitor , do remember to charger over 12 hours to
make sure the battery work fine
3. If you don‘t use it for a long time, charge your monitor once a month to
avoid overrunning of the battery
TOUCH SCREEN
Connect via USB-C Port: Touch signal can only be processed via USB-C
connection.

HOW TO CONNECT YOUR MONITOR
HDMI will only input / output display and audio signal. However, you
touch signal can work if you connect both HDMI and USB-C at the same
time. Alternatively you can USB 3.0A to USB C can also transfer touch
signal in conjunction with HDMI.
Input
Mini HDMI PC / Game Consoles / TV Box / etc.
Input Data Only
USB-C Port Input Video / Audio / Touch ScreenPort.
Input Power Only
Power Port 18W QC / 5V – 4A.
Input
Micro USB Port Keyboard / Mouse (needs Female
USB Ato Male micro USB adapter).
Output
Speakers / Earphones AUX 3.5 mm
Connect via USB-C Port: You can use single-finger touch or multi-finger
touch for up to 70 simultaneous touch points.
If your laptop or device is NOT touch screen enabled, Monitor touch
function may not be compatible. Some Macbooks are not touch
screen enabled due to Apple’sown OS limitations.

USB-C
USB-C
HDMI
HDMI
USB-C
(USB-C
to power
the monitor)
USB-C
(USB-C
to power
the monitor)
Touch function is NOT
avaible.
Monitor is charged.
Touch function is avaible.
Will consume built-in battery
life without input power.
Touch function is avaible.
Will consume built-in battery
life without input power.
Touch function is avaible.
NOTICE: Check if the USB-C of your laptop/phone is a full featured
USB-C port. Your device should support Thunderbolt 3.0 or USB 3.1
Gen2, USB-C DP ALT-MODE. If it is just a USB-C for charging, it will
not be available.

USB-C
Input power optional. Will consume
built-in battery life without input power.
Input power optional. Will consume
built-in battery life without input power.
iPhone / iPad
Lightning
to HDMI adapter
NOTE:
•Touchscreen function is only enabled when connecting to your device via
USB-C as the HDMI connection does not output touch signal.
•If monitor is not being charged via Input Power port it will automatically
power itself with the built-in battery. This means if you connect your
laptop or external device via the Input Data port only, it will consume
battery life.
•Not all mobile devices output video signal and may not work with
external devices like the monitor.

TROUBLESHOOTING (FAQ)
1. My screen does not turnon or I’m seeing ablack / blank screen.
It is likely your device is out of battery or you are connecting your external
device to the Input Power port rather than the Input Data port.
Monitor uses avery specific battery to optimize for power efficiency,
size, and weight. You can ONLY charge your Monitor with a5V / 4A or
QC18W charger. Other combinations will not work. We strongly recommend
charging and using your Monitor only with our supplied charger.
Please use make sure to charge and connect to your device with our
included cables as some generic cables may not carry sufficient power.
It is also possible that your external device does not support external
displays or requires specific hardware. For example, iPhones and iPads
require aspecific Lightning to HDMI adapter to connect to external
displays. Some mobile devices also do not support external displays
from their USB-C ports or at all (e. g. Google Pixel, Windows Surface
Pro). This is alimitation by the manufacturer that is unavoidable with
many monitors.
Some devices do NOT support USB-C output display signal and you may
need to use the HDMI port.
2. Audio is playing from my Monitor screen instead of my laptop
or headphones.
Please go into the audio / volume settings on your computer and switch
output back to your laptop or headphones.
3. Why isn’t my mobile device / tablet connected to the tablet?
•Some phone brands, by design, do not output any display signal.
Unfortunately, this means you will not be able to connect the your
smartphone to your Monitor. However, you can use devices like the
Chromecast, Amazon Fire Stick, or any other media player attachments
to connect wirelessly with your monitor.
•For Apple tablets and smartphones, you will need to use aspecial
Lightning-to-HDMI adapter available on our site due to Apple’slimitations.
•Make sure your monitor is charged and has power.

4. Why doesn’t the touchscreen work?
•Touchscreen will only work on devices that have been designed to
receive touchscreen signal. For example some MacBooks cannot receive
touchscreen inputs. Other devices that are not already touchscreen
enabled will also not be able to receive input touchscreen signal. If your
connected laptop is not already touchscreen compatible, Monitor will not
be touchscreen compatible.
•External devices generally cannot accept output touchscreen signal via
HDMI. If you are connecting via HDMI, you will need to connect both
the HDMI and USB-C Input Data ports on your monitor.
•Many mobile devices do not have touchscreen input signal for external
monitors. Some devices such as some Samsung and Huawei mobile
phone models for example have been desig ned to take touchscreen input.
5. The speakers aren’t working.
Make sure your monitor’svolume is not at 0 or muted in the settings.
6. The Power LED Light is on, but there is no screen image.
• Ensure your monitor and input source have power and are on.
• Check that your video input (USB-C or mini HDMI) are properly
connected.
• Inspect the signal cable and make sure the pins are not bent
or damaged.
• Connect the computer to another monitor to ensure the computer
and output port is working properly.
• Your monitor may not be charged. Recharge your monitor with included
QC 18W charger for at least 4 hours and try again.
• Your device may not be compatible with external monitors.
7. Screen image is too light or dark.
Adjust brightness settings to increase or decrease brightness.
8. Screen image bounces or awave pattern is present in the Image.
• Try connecting another input device to your Monitor to ensure the issue
is not with your device or accessories.
• Make sure the USB-C cable or HDMI cable is properly connected.
• Move monitor away from other magnetic or electric devices that may
cause interference.

9. Screen image has color defects (white does not look white).
• Try connecting another input device to your Monitor to ensure the issue
is not with your device or accessories.
• Inspect the USB-C Cable and make sure that none of the p ins are bent.
• Use another USB-C or HDMI cable to connect your device to the Monitor.
10. Screen image has color defects (white does not look white).
• The monitor will shut down when the battery is out of power.
• Make sure the device that powers Monitor has sufficient power.
Model number
Panel Type
Touch function
Size
Backlight
Brithgness
Contrast
EDP
Pitch
Resolution
Aspect
Response time(typ)
View angle
Surface
Display color
LOW BLUE LIGHT MODE / HDR10
miniHDMI / Type-C
Earphone Jack
Speaker
Built-in battery
Power range
Power adapter
Size of monitor
Weight
Front control
Windows 7/8/8.1/10/MAC OS
Power
M16TB touch monitor with battery
IPS
Yes
16
WLED
300cd/m2
1200:1
eDP (2 Lanes), eDP1.2
0.0607×0.1821 mm (H×V)
1920×1080
16/9
30ms
H:85º,V:85º(CR≥ 10)
Glare
16.7M (8-bit)
Yes / Yes
1920x1080@60Hz
Yes
Yes (2 *1,0W)
General(≤13W)
Stand by ≤0.5W
YES – 8000mAh
AC 110-240V 50/60Hz
QC18W
430*280*90 mm
1.4 kg
MENU(Brigthness+/-, Volume+/-); Power( return)
Windows, Mac, Xbox, PlayStation
SPECIFICATIONS

Declaration of conformity according to the EMC Directive 2014/30 / EC
on the harmonization of legal regulations
of Member States related to electromagnetic compatibility.
Manufacturer / importer:
MISURA Store s.r.o.
KPošte 429/2
252 67 Tuchomerice
Person responsible for completing the technical documentation:
Ing. Jirí Mihel – executive director of the company
Description and identification of machinery:
Title: portable USB monitor
Type: M16TB
The device described above has been tested in accordance with the
above standards and found to comply with the EMC 2014/30/ES. The
observations and test results given in this certificate are only relevant for
the test sample.
The product complies with the following European Community
regulations:
Directive EN 55032: 2015 of the European Parliament and of the Council
- Electromagnetic compatibility of multimedia equipment – Emission
requirements.
Directive EN 55035: 2017 of the European Parliament and of the Council
- Electromagnetic compatibility of multimedia devices – Immunity
requirements.
HARMONIZED STANDARDS USED:
EN IEC 62368-1:2020, IEC 62321-4:2017, IEC 62321-5:2013, IEC 62321-6:2015,
IEC 62321-7-1:2015, IEC 62321-7-2:2017, IEC 62321-8:2017, EN 62368-1

Manuál vČeštině otevřete zde /
Manuál vo Slovenčine otvoríte tu /
Open the English manual from here /
Das Handbuch in Deutsch können Sie öffnen hier /
Amagyar nyelvű kézikönyvet itt tudja megnyitni /
Odprite priročnik vslovenščini tukaj /
Aprire il manuale in italiano qui /
URL: www.misura.shop/en/advisor/m16tb-manual-for-download
