MiTAC Magellan RoadMate 3065 Commuter Instruction Manual

C
M
Y
CM
MY
CY
CMY
K
MRM3065_PKMC(12Feb10)En.pdf 1 2/12/10 3:32 PM

Safety
This Magellan receiver is a vehicle-navigation aid designed to
assist you in arriving to your selected destinations. When using
this Magellan product, these safety rules must be followed to
prevent accidents that can result in injury or death to yourself or
others:
• Please check with your state or local law enforcement for
applicable regulations regarding mounting to the windshield.
Go to www.magellanGPS.com for alternate mounting
solutions.
• When driving, the need to view the display is minimal. Voice
prompts will guide you to your destination. The driver should
enter data or program the Magellan receiver only when the
vehicle is stopped. Only a vehicle passenger should enter
data or program the receiver while the vehicle is moving.
• It is your responsibility to comply with all traffic laws.
• Every attempt is made to ensure that the database is
accurate. However, roadways, points of interest (POIs), and
business and service locations may change over time. The
database does not include, analyze, process, consider, or
reflect any of the following: legal restrictions (such as
vehicular type, weight, height, width, load and speed
restrictions); road slope or grade; bridge height, width,
weight, or other limits; population density; neighborhood
quality or safety; availability or proximity of law enforcement,
emergency rescue, medical, or other assistance;
construction work zones or hazards; road or lane closures;
road, traffic, or traffic facilities’ safety or condition; weather
conditions; pavement characteristics or conditions; special
events; traffic congestion. It is your responsibility to
605-0323-001 B detail.fm Page 2 Wednesday, March 17, 2010 2:35 PM

disregard any unsafe, hazardous, or illegal route
suggestions.
• Keep the receiver safe from extreme temperature conditions.
For example, do not leave it exposed to direct sunlight for an
extended period of time. The maximum operating
temperature is 140°F (60°C).
• Take care when mounting the receiver in your vehicle,
whether using the windshield mount or other mount or
accessories, that it does not obstruct the driver's view of the
road, interfere with the operation of the vehicle's safety
devices such as air bags, or present a hazard to occupants
of the vehicle should the receiver be dislodged while driving.
You assume the risks associated with damage to your
vehicle or vehicle occupants as the result of your choices in
mounting the receiver.
• The battery is rechargeable and should not be removed. In
the event it should need to be replaced, please contact
Magellan Technical Support.
Please do not return this product to the place of purchase
without Technical Support at www.magellanGPS.com/
support/.
Register your Magellan RoadMate at
www.magellanGPS.com/ to keep updated on the latest
offers.
Download the User Manual from the
www.magellangps.com/support for detailed information.
605-0323-001 B detail.fm Page 3 Wednesday, March 17, 2010 2:35 PM

Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for class
B digital devices, in accordance with part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
In order to maintain compliance with FCC regulations, shielded cables must
be used with this equipment. Operation with non-approved equipment or
unshielded cables is likely to result in interference to radio and TV reception.
The user is cautioned that changes and modifications made tothe equipment
without the approval of manufacturer could void the user's authority to
operate this equipment.
605-0323-001 B detail.fm Page 4 Wednesday, March 17, 2010 2:35 PM

The Magellan RoadMate receiver must be installed and operated at a
distance no closer then 8 inches (20 cm) from the user.
This Class B digital apparatus complies with Canada ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
The abbreviation, IC, before the registration number signifies that registration
was performed based on a Declaration of Conformity indicating that Industry
Canada technical specifications were met. It does not imply that Industry
Canada approved the equipment.
To prevent radio interference to the licensed service, this device is intended
to be operated indoors and away from windows to provide maximum
shielding. Equipment (or its transmit antenna) that is installed outdoors is
subject to licensing.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
IC statement
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits established for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
605-0323-001 B detail.fm Page 5 Wednesday, March 17, 2010 2:35 PM

This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
Bluetooth QD ID B016475
605-0323-001 B detail.fm Page 6 Wednesday, March 17, 2010 2:35 PM

Installation
Choose a Location. The Magellan RoadMate receiver needs a clear
view of the sky to receive signals from the GPS satellites so choose a
location with an unobstructed view of the sky, commonly on or near the
windshield.
Clean the Surface. Clean the area on the windshield and allow the
surface to dry before attaching the mount.
Install the Car Cradle.
Attach the USB connector to
the cradle as shown. Hold
the cradle assembly firmly
against the window surface
and push lever towards the
base.
Attach the Receiver.
Connect Power. It is recommended that you connect the Magellan
RoadMate using the vehicle power cable before using it for the first time.
The internal battery will begin charging as soon as power is supplied to
the Magellan RoadMate receiver through the vehicle power cable.
(When the light on the vehicle power cable illuminates, it is properly
connected to vehicle power. Note some vehicles require that the ignition
be on before power is delivered to the power receptacle.)
605-0323-001 B detail.fm Page 7 Wednesday, March 17, 2010 2:35 PM

General Information
Please refer to this handbook for questions on using the Magellan
RoadMate receiver. If you are still unable to answer your questions,
check our technical support web page at: http://www.magellanGPS.com/
support/. Magellan RoadMate
Power On
Slide the power switch (A) to the left to turn the receiver on.
The first time you use the Magellan RoadMate it may take up to 4
minutes to compute your location under normal conditions. With
adverse conditions (not having a clear view of the sky) the time to
compute your location the first time can greatly increase.
Pairing Bluetooth®
The instructions shown here are for pairing a phone during normal use.
The first time you use Bluetooth in your Magellan RoadMate receiver,
the receiver will automatically ask you if you want to pair a phone.
After selecting Yes the receiver is in pairing mode. Follow the
instructions in your phone manual to set it in pairing mode. After the
phone has searched for new devices, select “Magellan” from the list.
Your phone will ask for a passcode. Enter ‘1234’.
Tap Yes on the Magellan RoadMate.
A screen will confirm the successful pairing.
A - Power Switch
B - Micro-SD slot
C - Power Input
(USB)
A
BC
605-0323-001 B detail.fm Page 8 Wednesday, March 17, 2010 2:35 PM

Satellite Signal Strength
To view the satellite signal strength indicator, tap on the Menu button.
The signal strength indicator can be found in the upper right corner.
If you are not getting your current location, use these tips to improve
satellite signal reception.
Leave the garage or parking structure so the GPS receiver has a
clear view of the sky.
Satellite signals can be blocked by tall buildings, trees or
mountains. You may intermittently see a drop in signal strength
in these types of environments.
Battery
The Magellan RoadMate receiver has an internal battery that is charged
when it is being powered by the vehicle power cable or an external
(optional) AC power adapter. It is estimated that a receiver can operate
for 2 hours from a fully charged battery.
To view the battery strength indicator, access the Main menu. The
battery strength is shown below the signal strength indicator.
It can take up to 4 hours to fully charge the battery, depending on the
battery level. However, the battery does not need to be fully charged to
use the Magellan RoadMate receiver.
Traffic Notice
Your Magellan RoadMate comes equipped with lifetime traffic but
requires that you use the supplied vehicle power adapter to work. Traffic
warnings will not appear if you are using a power adapter other than the
one supplied or operating the receiver on internal batteries.
4 bars green:
Strong signal
Blank: No satellite
signals. Unable to
compute position.
605-0323-001 B detail.fm Page 9 Wednesday, March 17, 2010 2:35 PM

Map Screen while Routing
ADisplays distance and street for next maneuver. Tap to
repeat last instruction.
BNext Turn instruction.
CTraffic icon with the route delay time if traffic warnings
appear on route.
DDisplays ETA (estimated time of arrival). Tap to select
distance to destination, arrival time, speed or time
remaining in the route.
EZoom Out
FZoom In
GAccess Main Menu
HPress to display POIs found on next few highway exits.
(Displayed only while traveling on a highway.)
IAccess Volume/Mute Controls
JAccess OneTouch Menu
KCurrent Position Icon
A
B
C
DEFG
H
I
J
K
605-0323-001 B detail.fm Page 10 Wednesday, March 17, 2010 2:35 PM
