Mitchell uStreamTT2 User manual

Belt-Drive Bluetooth Turntable
User Guide

Important Safety Instruction
CAUTION: To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture.
WARNING: To prevent electric shock, do not use this (polarized) plug with an extension cord,
receptacle
or other outlet unless the blades can be fully inserted to prevent blade exposure.
Important Safety Instructions
1. Read these instructions – All the safety and operating instructions should be read before this
product is operated.
2. Keep these instructions– The safety and operating instructions should be retained for future
reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be
4. adhered to.
5. Follow all instructions – All operating and use instructions should be followed.
6. Do not use this apparatus near water – The appliance should not be used near water or
moisture –
7. for example, in a wet basement or near a swimming pool, and the like.
8. Clean only with dry cloth.
9. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
10. Do not install near any heat sources such as radiations, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
11. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two
blades with one wider than the other. A grounding plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
12. Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
13. Only use attachments/accessories specified by the manufacturer.
14. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart or rack is used,
15. use caution when moving the cart/apparatus combination to avoid

16. injury from tip-over.
17. Unplug the apparatus during lighting storms or when unused for
18. long periods of time.
19. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled
20. or objects have fallen into the apparatus has been exposed to rain or moisture, does not
21. operate normally, or has been dropped.
22.
-This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electric shock.
-Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no
user-serviceable parts inside. Refer servicing to qualified personnel.
-The exclamation point within and equilateral triangle is intended to alert the user to the
presence of important operating and maintenance instructions in the literature accompanying
the appliance.
23.
This equipment is a Class Ⅱ or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.
24. The mains plug is used as disconnect device, the disconnect device shall remain readily
operable.
25. WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall not be placed on apparatus.
26. The use of the equipment in moderate climate.
27. The ventilation should not be impeded by covering the ventilation openings with items such
as, newspapers, tablecloths, curtains, etc.
28. No naked flame sources, such as lighted candles, should be placed on the apparatus.
29. The symbol with Indication AC voltage.
30. CAUTION: These servicing instructions are for use by qualified service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that contained in
the operating instructions unless you are qualified to do so.
31. WARNING: Please refer the information on exterior bottom enclosure for electrical and
safety information before installing or operating the apparatus.

Before Use
1. Choose unit installation location carefully. Avoid placing it in direct sunlight or close to a
source of heat. Also avoid locations subject to vibrations and excessive dust, cold or
moisture. Keep away from sources that hum, such as transformers or motors.
2. Do not open the cabinet as this may result in damage to the circuitry or electrical shock. If a
foreign object should get into the set, contact Customer Service.
3. Be sure not to handle record with dirty fingers. Never play a record that has a crack on the
surface.
4. When removing the power plug from the wall outlet, always pull directly on the plug, never
pull the cord.
5. To protect the stylus, don’t forget to put on the white protective needle cover after use.
6. Do not attempt to clean the unit with chemical solvents as this might damage the finish.
Use a clean, dry cloth.
7. In order to shut off the power to this product completely, unplug the power cord from the
wall outlet. Be sure to unplug the unit if you do not intend to use it for an extended period
of time, such as a vacation.
8. Keep this manual in a safe place for future reference.

Product Overview
Top view
#
ITEM
DESCRIPTION
1
Spindle
Place a record onto the spindle to play.
2
Turntable
Aluminum alloy turntable.
3
Counterweight
Turn to adjust the needle pressure.
4
Anti-skate control
Turn to adjust the inward tracking forces that occur with
certain pick-up when the stylus nears the center of the record.
5
Tone arm lifter
Push forward and pull back to raise and lower tone arm.
6
Tone arm rest holder
Place the tone arm on this holder when not in use.
7
Tone arm
Holds the stylus that produces sound from the record.
8
RPM selector switch
Turn to select the record type (33 or 45) or OFF to turn off
your turntable.(The default OFF)
9
Status indicator
Displays status:
. Blinking red and blue indicates Bluetooth i in pairing mode.
. Solid blue indicates Bluetooth is connected.
. Solid red indicates is connected fail.
10
Bluetooth paring
button
Press and hold for two seconds to start Bluetooth pairing. Your
turntable pairs to audio devices(such as Bluetooth speakers,
headphones, and receivers).The Bluetooth indicator blinks red
and blue until a link is made. After you connect to a Bluetooth
speaker, your turntable automatically reconnects to the
speaker each time you turn on your turntable and set it to 33
or 45 RPM.
11
Stylus
Generates sound from a playing record.

Back view:
#
ITEM
DESCRIPTION
1
Line-out jack
Plug the included RCA cable into this jack. Make sure red to red and
white to white.
2
PRE-AMP
ON/OFF switch
Make sure the pre-amp switch is “ON”when the
connected external device is line input. When the
connected external device is Phono input，the pre-amp
switch switches to "OFF". Improper setting of pre-amp
switch can result in no sound or explosive sound.
3
USB jack
Plug USB cable to connecting a PC to recording.
4
AC power jack
Plug the AC power cord into this jack and into a power outlet.
Setting up your turntable
You need to install the turntable before you can use it.
1. Take the accessories out of the packing case and check that the accessories are in complete
and good condition.
#
Accessory
Quantity
1
RCA cable
1 pcs
2
Power cable
1 pcs
3
Counterweight
1 pcs
4
45 RPM adapter
1 pcs
5
Turntable mat
1 pcs
6
Two belts
1 pcs（installed)
7
User guide
2. Install the metal platter (the belt is preinstalled on the bottom of the metal platter) and a
turntable mat on the metal platter.
3. Attach and adjust the counterweight.
4. Carefully remover the tape. Too much force will damage the cover and stylus.

Installing the platter and turntable mat
Note: The belt is preinstalled on the bottom of the metal platter.
1. Make sure that the belt is not twisted, then use your thumb to stretch the belt until it
reaches the round hole in the platter.
Note: Make sure that you place the belt on the metal track and not on be section with teeth.
2. Still holding the belt, flip the platter over, then insert the platter onto the spindle in the
center of your turntable.
3. Align the round hole in the platter with the pulley and use your finger to hook the belt onto
the pulley.
4. Place the turntable mat on the platter.
Note: When you want to take out the platter from the turntable, remove the mat first, then grasp
the platter and pull it upward. This is especially important if you are shipping your turntable
to prevent the platter from shaking.

Attaching and adjusting the counterweight
The counterweight on the tone arm adjusts the needle pressure. If the pressure is too much,
sound is distorted. If the pressure is too little, track skipping happens more frequently.
1. Hold the counterweight with the black number ring on the counterweight towards you, and
then slightly push the counterweight into the end of tone arm. When you hear the second
click from the pogo pin on the tone arm, the counterweight has been installed correctly.
2. Remove the stylus cover.
3. Set the Anti-Skating control to 0 (zero).
4. Release the lock catch, push the tone arm lifter forward so that the tone arm leaves the base,
then push the tone arm left to the position above the turntable.
CAUTION: Make sure that the needle does not contact any part of your turntable.

5. Turn the counterweight so that the tone arm is horizontal. You can move the counterweight
forward or backward on the tone arm.
6. Hold the metal counterweight at the back of the tone arm.
7. Hold the metal counterweight to keep it from moving, and then carefully rotate the front
black number ring so that 0 is in the 12 o'clock position.
Note: Do not turn the metal counterweight. The black number ring turns separately.

8. Hold both the metal counterweight and black number ring together. Rotate them
counter-clockwise one full circle, then set the ring to 0 so that 0 on the dial is in the 12
o’clock position. This will set the tone arm to 2.0 grams of downward force (the
recommended tracking weight) for this needle.
Using your turntable
Plug one end of the power cord into the AC power jack on the back of the turntable, and then
plug the other end into a power outlet.
1. We strongly recommended that you operate your turntable only from the type of power
source indicated on the marking label.
2. To prevent interference, avoid bundling the audio signal cables together with the AC power
cord.
3. The top cover helps prevent dust from settling on your turntable. We recommend that you
use the top cover when you’re playing records or when you’re not using your turntable.
Playing a record
1. Gently open the dust cover.
Note: Be careful not to pinch your finger when opening or closing the dust cover.
2. Place a vinyl record on the turntable.
Note: When playing a 45 RPM record, use the included 45 RPM adapter if required.
3. Select the appropriate speed by turning the RPM selector switch to 33 or 45.
4. Remove the tone arm-rest lock catch to release the tone arm.
5. Push the tone arm lifter forward to raise the tone arm.
6. Gently push the tone arm to the left over the turntable.
7. Push the tone arm lifter backward to lower the tone arm so that the stylus touches the
record and starts to play.
8. To pause or stop playing, push the tone arm lifter forward to raise the tone arm.

Note: When the end of the record is reached, the tone arm and rotation stop.
9. When playing is completed, push the tone arm lifter forward to raise the tone arm, and
then move the arm back to the tone arm rest. Push the tone arm lifter down to lower the
tone arm.
Notes:
•Closing the top cover helps prevent dust from settling on the turntable.
•Always relock the tone arm clip before transporting your turntable.
•Do not place anything on top of the turntable cover, especially while playing a record.
Listening to music using Bluetooth speakers
1. Turn the switch to your record type, 33 or 45.
2. Put your Bluetooth speaker in pairing mode.
Note: Make sure that Bluetooth is off on any devices in the vicinity that will automatically
connect to your speaker.
3. On the turntable, press and hold the Bluetooth pairing button for two seconds to turn the
Bluetooth transmitter on. While searching, the Bluetooth indicator flashers red and blue.
When connected successfully, the Bluetooth indicator lights solid, and your turntable
sounds a tone.
Notes:
•If your turntable fails to connect with your speaker, the Bluetooth indicator lights red.
Press the Bluetooth pairing button one more time to reconnect with your Bluetooth
speaker.
•The effective distance between your Bluetooth device and your turntable is 33 ft. (10 m).
•Make sure that you remove any obstacle between your Bluetooth speaker and your
turntable to make sure that the sound is clear.
4. To turn off the Bluetooth, press and hold the Bluetooth pairing button for 2 seconds until the
status indicator turns off.
5. To reset Bluetooth, press the Bluetooth pairing button five times continuously until the
status indicator turns purple.
Note: After reset, it is recommended to press the Bluetooth pairing button to turn off
Bluetooth transmission. And then switch the RPM selector switch to OFF and restart the
turntable.

Listening to music through the Line out jacks
1. Plug the red and white connectors on the included RCA cable into the Line out jack on the
back of your turntable, red to red and white to white.
2. Plug the other end of the cable into your speakers, red to right speaker and white to left
speaker.
3. Toggle the PRE-AMP ON/OFF switch to select the output mode.
Connected external device
Switch position
Device with PHONO input
OFF
Device without PHONO input
ON
Note:
1. Improper setting of PRE-AMP ON/OFF switch will lead to no sound or explosive sound.
2. Adjust the volume of the external speaker when using the RCA cable.
USB Recording operation
To properly record your vinyl to MP3 via computer, use the included USB Output Cable and
Instructional CD Software. Connect one end of the USB cable to the turntable (USB jack on the
back of the unit) and the other end into your computer. Then connect the AC power cord to the
turntable.
To install and use the software on your computer, select the proper Mac or PC install files, then
follow the prompts provided on the Instructional CD.
For the most up to date manuals, software, instructional details, troubleshooting or other
downloadable content, please go to http://audacityteam.org
Replacing the stylus
The stylus should last about 300 hours under normal use. However, it is recommended that the
stylus be replaced as soon as you notice a change in sound quality. Prolonged use of a worn-out
stylus may damage the record.
1. Turn the RPM selector switch to OFF to turn off the power.
2. Remove the stylus by pulling it downward and forward at the same time.
3. Insert the new stylus upwards into the slot under the head, then push upward until the tip
locks into place.

CAUTIONS:
1. Do not remove or bend the stylus.
2. Do not touch the needle to avoid injury your hand.
3. Keep out of reach of children.
Adjusting the anti-skating control
When a record is playing, a small inward force (might cause skating) pull the tone arm towards
the center of the record. To counteract this inward force, you can adjust the anti-skating control
to apply an outward force (anti-skating).
Normally you should set anti-skating compensation to its minimum setting. If the turntable is
experiencing excessive skipping while nearing the center spindle, try increasing the anti-skating.
Start by adding an increment of 1, and then test its performance. If needed, you can increase and
test by one increment at a time.
Notes:
1. When you adjust the Anti-Skating knob, leave the tone arm and balance weight alone to
prevent damaging the stylus needle.
2. If a record can’t playback entire tracks, we recommend you reset the anti-skating control to
0 (zero).
3. In case of substantial use of back-cueing, scratching, or reverse-direction operation, you
may prefer to use less, or no, anti-skate compensation.
Enjoying your sound experience
Needle pressure impacts your sound experience and is controlled by the counterweight. You can
adjust it to fit your personal preference. Reduce it to bring out rich bass in your music selections
or increase it to bring out higher frequencies. See Attaching and adjusting the counterweight.
Note:
After adjusting the counterweight, you may need to adjust the anti-skating force. See Adjusting
the anti-skating control.

Specification:
GENERAL
Power Requirements AC 120-240V ~ 50/60 Hz
Power Consumption 5 W
Dimensions (W x H x D) 42.8cm x 13.5cm x 36.8cm. (approx.)
BLUETOOTH TRANSMIT
Bluetooth Version Bluetooth V5.1
Bluetooth Profiles A2DP, AVRCP
Bluetooth Frequency range 2.402GHz-2.480GHz
Operating Distance 10 meters (33 ft.)
Maximum RF Power ＜5dBm
RECORD PLAYER section
Motor DC servo motor
Drive System Belt Drive
Speeds 33-1/3 rpm, 45 rpm,
Wow Flutter Less than 0.25% (WTD)
S/N Ratio 55 dB
Cartridge Type Moving Magnetic Cartridge
RCA OUT 200-280 mV (5 cm/sec at 1 KHz-10dB)
Phono out 3-4mv ((5 cm/sec at 1 KHz-10dB)
USB
Type USB series B connector
Full-speed USB 2.0 full speed
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Mitchell Acoustics is under license. Other trademarks and trade names
are those of their respective owners.

Troubleshooting
Check this list for a possible trouble shooting solutions before calling for service.
General
PROBLEM
SOLUTION
My turntable doesn’t
turn on.
• Make sure that the power cord is connected to your turntable and
a working power outlet.
I don’t hear sound from
the speakers.
• Increase the volume on the external speaker.
• If you are using the RCA jacks, make sure that the RCA cable is
connected correctly and securely.
The sound is noisy.
• Turn off appliances (like a TV) near your turntable.
• Move your turntable farther away from nearby appliances.
My turntable is on, but
doesn’t respond.
• Remove the power cord and all power supply devices, wait one
minute, then plug your turntable back into the power outlet.
PHONO Player
PROBLEM
SOLUTION
The sound is noisy
when
I use my turntable for a
period of time.
• Replace the stylus.
A record doesn’t fit on
the spindle.
• Make sure that the record is a 33 or 45 RPM record. Your turntable
doesn’t play 78 RPM records
Bluetooth
PROBLEM
SOLUTION
My turntable won’t pair
with a Bluetooth
device.
• Press and hold the Bluetooth pairing button for two seconds to
make sure that your turntable is switched to transmitting mode.
• Make sure that your Bluetooth speaker is turn on and in Bluetooth
mode. See the instructions that came with your Bluetooth speaker.
• Move your Bluetooth speaker closer to your turntable.
Bluetooth pairing
failed.
• Make sure that your Bluetooth speaker is not connected to another
Bluetooth device. If it is connected to another device, turn off the
device or delete the Bluetooth connection name from your speaker's
list of devices.
• Make sure that your Bluetooth speaker uses BQB-certified receive.
Bluetooth can’t
reconnect
• Press the Bluetooth pairing button five times continuously until the
status indicator turns purple To reset Bluetooth and then restart
pairing normally.
