Mitchell uStreamTT1 User manual

Belt-Drive Bluetooth Turntable
User Guide

Important Safety Instruction
1. Read these instructions – All the safety and operating instructions should be read before this
product is operated.
2. Keep these instructions – The safety and operating instructions should be retained for future
reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water or
moisture – for example, in a wet basement or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
12. Unplug the apparatus during lightning storms or when unused for long periods of
time.
13. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
14.
- This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
a. Warning: To reduce the risk of electric shock, do not remove cover (or back) as there
are no user-serviceable parts inside. Refer servicing to qualified personnel.
b. The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the appliance.
15. This equipment is a Class II or double insulated electrical appliance. It has been designed
in such a way that it does not require a safety connection to electrical earth.
16. The mains plug is used as disconnect device, the disconnect device shall remain readily
operable.
17. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and that no objects

filled with liquids, such as vases, shall not be placed on apparatus.
18. The use of the equipment in moderate climate.
19. WARNING: Please refer the information on exterior bottom enclosure for electrical and safety
information before installing or operating the apparatus.
20. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-
cloths, curtains etc.
21. No naked flame sources, such as lighted candles, should be placed on the apparatus.
22. Do not install this equipment in a confined space such as a book case or similar unit.
23. The symbol with Indication AC voltage.
24. Correct Disposal of this product. This marking indicates that this product should not be
disposed with other household wastes throughout the EU.
-To prevent possible harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of material resources.
-To return your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for environmental safe
recycling.

Precautions
Safety Information-caution:
1. In order to shut off power to this product completely, unplug the power cord from the wall outlet. Be sure
to unplug the unit if you do not intend to use it for an extended period of time, such as during a vacation.
2. Use of controls, adjustments and performance of procedures other than those specified herein may result in
hazardous radiation exposure.
3. To prevent electric shock, match wide blade of plug to wide slot, fully insert.
4. If this product is experience problems during operation, contact qualified service centers, and do not use the
product in defective states.
Safety Precautions
WARNING:
To reduce the risk of fire or electric shoc k, do no t expose this app liance to rain or moisture.
CAUTION:
Use of controls or adjustments or performance of procedures other than those specified may result
in hazardous radiation exposures.
CAUTION
RISK OF ELECTRIC SHOCKS - DO NOT OPEN!
To reduce the risk of electric shock, do not remove cover or back.
No user serviceable parts inside. Refer servicing to qualified service personnel.
The light flash with arrowhead symbol, within an equilateral triangle, is intended to alert
user to the presence of non-insulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert user to the
presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
(See markings on the back of the unit.)

Before Use
1. Choose unit installation location carefully. Avoid placing it in direct sunlight or close to a source of heat.
Also avoid locations subject to vibrations and excessive dust, cold or moisture. Keep away from sources
that hum, such as transformers or motors.
2. Do not open the cabinet as this may result in damage to the circuitry or electrical shock. If a foreign object
should get into the set, contact Customer Service.
3. Be sure not to handle record with dirty fingers. Never play a record that has a crack on the surface.
4. When removing the power plug from the wall outlet, always pull directly on the plug, never pull the cord.
5. To protect the stylus, don’t forget to put on the white protective needle cover after use.
6. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Use a clean, dry
cloth.
7. In order to shut off the power to this product completely, unplug the power cord from the wall outlet. Be
sure to unplug the unit if you do not intend to use it for an extended period of time, such as a vacation.
8. Keep this manual in a safe place for future reference.

Product Overview
Top view
#
ITEM
DESCRIPTION
1
Turntable
Aluminum alloy turntable.
2
Spindle
Place a record onto the spindle to play.
3
Counterweight
Turn to adjust the needle pressure.
4
Anti-skate control
Turn to adjust the inward tracking forces that occur with
certain pick-up when the stylus nears the center of the
record.
5
Tone arm lifter
Push forward and pull back to raise and lower tone arm.
6
Tone arm rest holder
Place the tone arm on this holder when not in use.
7
Tone arm
Holds the stylus that produces sound from the record.
8
Bluetooth pairing
button
Press to open Bluetooth transmitting. The white Bluetooth
indicator slowly flash. Wait for 5 seconds, press again to
start Bluetooth pairing. Your turntable pairs to audio
devices (such as Bluetooth speakers, headphones, and
receivers). The white Bluetooth indicator quickly flash.
When the turntable paired with a Bluetooth speaker, the
white indicator lights solid.
9
RPM selector switch
Turn to select the record type (33 or 45) or OFF to turn off
your turntable.(The default OFF)
10
Status indicator
Bluetooth standby: white light slowly flash
Bluetooth pairing: red and white light quickly flash.
Bluetooth paired: white light solid.
Bluetooth pairing failed: red light solid.
11
Stylus
Generates sound from a playing record.

Rear view
#
ITEM
DESCRIPTION
1
Line out jack
Plug the included RCA cable into this jack. Make sure red to red
and white to white.
2
PRE-AMP ON/OFF
switch
Ensure pre-amp switch is switched to “ON” for “LINE IN”
connection. For “PHONO ON” connection pre-am switch would
be switched to “OFF”. Improper setting of PRE-AMP switch will
lead to no sound or explosive sound.
3
AC power jack
Plug the AC power cord into this jack and into a power outlet.
Setting up your turntable
You need to install the turntable before you can use it.
1. Take the accessories out of the packing case and check that the accessories are in complete
and good condition.
#
Accessory
Quantity
1
RCA cable
1 pcs
2
Power cable
1 pcs
3
Counterweight
1 pcs
4
45 RPM adapter
1 pcs
5
Turntable mat
1 pcs
6
Two belts
2 pcs (one installed and
one spare)
7
User guide
2. Install the metal platter (the belt is preinstalled on the bottom of the metal platter) and a
turntable mat on the metal platter.
3. Install dust cover.
4. Attach and adjust the counterweight.
5. Carefully remover the tape. Too much force will damage the cover and stylus.

Installing the platter and turntable mat
1. Make sure that the belt is not twisted, then use your thumb to stretch the belt until it reaches
the round hole in the platter.
2. Still holding the belt, flip the platter over, then insert the platter onto the spindle in the center
of your turntable.
Note: The belt is preinstalled on the bottom of the metal platter.
Note: Make sure that you place the belt on the metal track and not on be section with teeth.

3. Align the round hole in the platter with the pulley and use your finger to hook the belt onto
the pulley.
4. Place the turntable mat on the platter.
Install dust cover
1. Insert the dust cover hinges into the hinge bases on the back panel of the unit.
2. Hold the dust cover and insert it into the hinges.
Note: When you want to take out the platter from the turntable, remove the mat first, then
grasp the platter and pull it upward. This is especially important if you are shipping your
turntable to prevent the platter from shaking.
Note: To remove the dust cover, grasp the two sides of the dust cover and
slowly lift upward to remove the dust cover together with hinges.

Attaching and adjusting the counterweight
The counterweight on the tone arm adjusts the needle pressure. If the pressure is too much,
sound is distorted. If the pressure is too little, track skipping happens more frequently.
1. Hold the counterweight with the black number ring on the counterweight towards you, and
then slightly push the counterweight into the end of tone arm. When you hear the second
click from the pogo pin on the tone arm, the counterweight has been installed correctly.
2. Remove the stylus cover.

3. Set the Anti-Skating control to 0 (zero).
4. Release the lock catch, push the tone arm lifter forward so that the tone arm leaves the
base, then push the tone arm left to the position above the turntable.
5. Turn the counterweight so that the tone arm is horizontal. You can move the counterweight
forward or backward on the tone arm.
CAUTION: Make sure that the needle does not contact any part of your
turntable.

6. Hold the metal counterweight at the back of the tone arm.
7. Hold the metal counterweight to keep it from moving, and then carefully rotate the front
black number ring so that 0 is in the 12 o'clock position.
8. Hold both the metal counterweight and black number ring together. Rotate them counter-
clockwise one full circle, then set the ring to 0.5 so that 0.5 on the dial is in the 12 o’clock
position. This set the tone are to 3.5 ± .5 grams of downward force (the recommended
tracking weight) for this needle.
Note: Do not turn the metal counterweight. The black number ring turns
separately.

Using your turntable
Plug one end of the power cord into the AC power jack on the back of the turntable, and then
plug the other end into a power outlet.
Playing a record
1. Gently open the dust cover.
2. Place a vinyl record on the turntable.
3. Select the appropriate speed by turning the RPM selector switch to 33 or 45.
4. Remove the tone arm-rest lock catch to release the tone arm.
5. Push the tone arm lifter forward to raise the tone arm.
6. Gently push the tone arm to the left over the turntable.
7. Push the tone arm lifter backward to lower the tone arm so that the stylus touches the
record and starts to play.
8. To pause or stop playing, push the tone arm lifter forward to raise the tone arm.
9. When playing is completed, push the tone arm lifter forward to raise the tone arm, and
then move the arm back to the tone arm rest. Push the tone arm lifter down to lower the
tone arm.
Listening to music using Mitchell Acoustics uStream Bluetooth speakers
Note:
1. We strongly recommended that you operate your turntable only from the type of
power source indicated on the marking label.
2. To prevent interference, avoid bundling the audio signal cables together with the AC
power cord.
3. The top cover helps prevent dust from settling on your turntable. We recommend that
you use the top cover when you’re playing records or when you’re not using your
turntable.
Note: Be careful not to pinch your finger when opening or closing the dust cover.
Note: When playing a 45 RPM record, use the included 45 RPM adapter.
Note: When the end of the record is reached, the tone arm and rotation stop.
Notes:
1. Closing the top cover helps prevent dust from settling on the turntable.
2. Always relock the tone arm clip before transporting your turntable.
3. Do not place anything on top of the turntable cover, especially while playing a record.

1. Turn the switch to your record type, 33 or 45.
2. Put your Bluetooth speaker in pairing mode by making sure no other device is connected via
Bluetooth..
3. On the turntable, press and hold the (Bluetooth pairing) button for two seconds to turn the
Bluetooth transmitter on. White Bluetooth indicator light blinks slowly.
4. Wait for 5 seconds, press the Bluetooth button again to search for your Bluetooth speaker.
While searching, the Bluetooth indicator will flash quickly.
When connected successfully, the Bluetooth indicator lights solid.
5. To reset Bluetooth, press and hold the button for 10 seconds until the status indicator lights
turn off.
Listening to music through the Line out jacks
1. Plug the red and white connectors on the included RCA cable into the Line out jack on the
back of your turntable, red to red and white to white.
2. Plug the other end of the cable into your speakers, red to right speaker and white to left
speaker.
Note: Make sure that Bluetooth is off on any devices in the vicinity that will automatically
connect to your speaker.
Notes:
2. The effective distance between your Bluetooth device and your turntable is 33 ft.
(10m).
3. Make sure that you remove any obstacle between your Bluetooth speaker and your
turntable to make sure that the sound is clear.

3. Toggle the PRE-AMP ON/OFF switch to select the output mode.
Connected device
Switch position
Device with PHONO input
OFF
Device without PHONE input
ON
Replacing the stylus
The stylus should last about 300 hours under normal use. However, it is recommended that the
stylus be replaced as soon as you notice a change in sound quality. Prolonged use of a worn-out
stylus may damage the record.
1. Turn the RPM selector switch to OFF to turn off the power.
2. Remove the stylus by pulling it downward and forward at the same time.
3. Insert the new stylus upwards into the slot under the head, then push upward until the tip
locks into place.
Note:
1. Improper setting of PRE-AMP ON/OFF switch will lead to no sound or explosive sound.
2. Adjust the volume of the external speaker when using the RCA cable.

Adjusting the anti-skating control
When a record is playing, a small inward force (might cause skating) pull the tone arm towards
the center of the record. To counteract this inward force, you can adjust the anti-skating
control to apply an outward force (anti-skating).
Normally you should set anti-skating compensation to its minimum setting. If the turntable is
experiencing excessive skipping while nearing the center spindle, try increasing the anti-skating.
Start by adding an increment of 1, and then test its performance. If needed, you can increase
and test by one increment at a time.
Enjoying your sound experience
Needle pressure impacts your sound experience and is controlled by the counterweight. You
can adjust it to fit your personal preference. Reduce it to bring out rich bass in your music
selections or increase it to bring out higher frequencies. See Attaching and adjusting the
counterweight.
CAUTIONS:
1. Do not remove or bend the stylus.
2. Do not touch the needle to avoid injury your hand.
3. Keep out of reach of children.
Notes:
1. When you adjust the Anti-Skating knob, leave the tone arm and balance weight alone to
prevent damaging the stylus needle.
2. If a record can’t playback entire tracks, we recommend you reset the anti-skating control
to 0 (zero).
3. In case of substantial use of back-cueing, scratching, or reverse-direction operation, you
may prefer to use less, or no, anti-skate compensation.
Note:
After adjusting the counterweight, you may need to adjust the anti-skating force. See
Adjusting the anti-skating control.

Specification:
GENERAL
Power Requirements ..……………………………………. AC 230 V ~ 50 Hz
Power Consumption……………………………………….. 5 W
Dimensions (W x H x D)…………………………………… 43.9cm x 35.5cm x 13.4cm (approx.)
BLUETOOTH TRANSMIT
Bluetooth Version…………………………………………… Bluetooth V4.2
Bluetooth Profiles…………………………………………… A2DP, AVRCP
Bluetooth Frequency range…………………………….. 2.402GHz-2.480GHz
Operating Distance…………………………………………. 10 meters (33 ft.)
RECORD PLAYER section
Motor……………………………………………………………… DC servo motor
Drive System…………………………………………………… Belt Drive
Speeds……………………………………………………………. 33-1/3 rpm, 45 rpm,
Wow Flutter …………………………………………………… Less than 0.25% (WTD)
S/N Ratio………………………………………………………… 55 dB
Cartridge Type………….…………………………….………. Moving Magnetic Cartridge
RCA OUT…………………………………………………………. 200-280 mV (5 cm/sec at 1 KHz-10dB)
Phono out……………….…………………….……………….. 3-4mv ((5 cm/sec at 1 KHz-10dB)

Mitchell Acoustics Limited
Clover Top Office, Nup End, Old Knebworth, Hertfordshire SG3 6QJ UNITED KINGDOM TEL: [phone]
Unit 1105-06, 11/F, 106, How Ming Street, Kwun Tong, Kowloon, Hong Kong. Tel: [phone]
HONG KONG TEL: [phone]
Company registered in the United Kingdom number: 11438199
DECLARATION OF CONFORMITY
Mitchell Acoustics as manufacturer certifies that the following designated product
Mitchell Acoustics uStream TT1 Vinyl Turntable
Is in full conformity with
ErP Directive
2009/125/EC
Commission Regulation: (EC) No. 1275/2008 (EU) No. 801/2013
Test Standard EN 50564:2011
RoHS
directive 2011/65/EU and the amendment directive (EU) 2015/863
EMC
ETSI EN 301 489-1 V2.2.3 (2019-11) (Draft) ETSI EN 301 489-17 V3.2.4 (2020-09),
EN55032:2015+A1:2020, EN 55035:2017+A11:2020, EN IEC 61000-3-
2:2019+A1:2021 and EN 61000-3-3:2013+A2:2021, ETSI EN 300 328 V2.2.2 (2019-07), EN
62479:2010, EN 50663:2017
The designated products were subject to sample testing for which
RED (Radio Equipment Directive) 2014/53/EU
EN 55032:2015+A1:2020, EN 55035:2017+A11:2020, EN IEC 61000-3-2:2019+A1:2021, EN
61000-3-3:2013+A2:2021, ETSI EN 301 489-1 V2.2.3 (2019-11), ETSI EN 301 489-17 V3.2.4 (2020-
09), ETSI EN 300 328 V2.2.2 (2019-07), EN 62479:2010, EN 50663:2017, EN IEC 62368-
1:2020+A11:2020
STC (Dongguan) Company Limited
68 Fumin Nan Road, Dalang, Dongguan, Guangdong, China. Zip Code: 523770
issued test reports numbered:
DM22080081, DM22080082, DM22080083, DM22080084, DE22080123
And therefore the products comply with the essential
requirements and the provisions of the EU Directives.
RoHs
Mitchell Acoustics has a policy of appointing independent 3rd party specialists to advise on manufacturing to ensure that
manufacturing partners comply with product material content testing; seeking confirmation from suppliers that materials
meet the RoHs standards, and have remedial and replacement programs are in place, and that manufacturers have
procedures in place for identifying, segregating and replacing compliant from non-compliant materials
The declaration is the sole responsibility of the manufacturer / importer.
The reports are held on file at :-
Mitchell Acoustics Limited
Turner House, 9-10 Mill Lane, Alton, Hampshire GU34 2QG UNITED KINGDOM
Date: 15th Sept 2022 Signed: Paul Mitchell - Director

Troubleshooting guide
In case of trouble with the unit, please look through below and see if you can solve the problem
by yourself before calling your dealer.
Problem
Solution
My turntable doesn’t turn on
• Make sure that the power cord is connected to your
turntable and a working power outlet.
My turntable is working, but I
can’t hear the record playing.
• The device does not have a built-in speaker. Make sure your
turntable is connected to an external audio device (using
Bluetooth connection or RCA cable connection).
I don’t hear sound from the
speakers.
• Increase the volume on the external device.
• If you are using the RCA jacks, make sure that the RCA cable
is connected correctly and securely.
The sound is noisy.
• Turn off appliances (like a TV) near your turntable.
• Move your turntable farther away from nearby appliances.
My turntable is on, but doesn’t
respond.
• Remove the power cord and all power supply devices, wait
one minute, and then plug your turntable back into the power
outlet.
The sound is noisy when I use
my turntable for a period of
time.
• Replace the stylus.
A record doesn’t fit on the
spindle.
• Make sure that the record is a 33 or 45 RPM record. Your
turntable doesn’t play 78 RPM records.
• If you playing a 45 RPM record, use the included 45 RPM
adapter.
My turntable won’t pair with a
Bluetooth speaker.
• Press and hold the (Bluetooth pairing) button for two
seconds to make sure that your turntable is switched to
transmitting mode.
• Make sure that your Bluetooth speaker is turn on and in
Bluetooth pairing mode. See the instructions that came with
your Bluetooth speaker.
• Move your Bluetooth speaker closer to your turntable.
Bluetooth pairing failed.
• Make sure that your Bluetooth speaker is not connected to
another Bluetooth device. If it is connected to another device,
turn off the device or delete the Bluetooth connection name
from your speaker's list of devices.
• Make sure that your Bluetooth speaker uses BQB-certified
receive.
Bluetooth can’t
reconnect
• Press and hold the (Bluetooth pairing) button for 10 seconds,
turn your turntable off, then turn it back on and restart pairing
normally.
There is no sound after a
successful Bluetooth
connection.
• Ensure the record is playing properly. The stylus is working.
• Check that the volume switch on the paired Bluetooth
speaker is on and adjust to the appropriate volume.
