MITECH MICRO 8 User manual

MICRO 8
MINIATURIZED DIGITAL MICROWAVE BARRIER
200 m RANGE
WITH PLANAR ANTENNA
Installation and user manual
MADE IN ITALY

MICRO 8 Installation and user manual Page 2 of 24
Index
Introduction
and warnings
Page 3
Components
Page 4
•
Wall installation ……………………………………………………………………………………………………………………. 5
•
Wall installation with MICRO BOX …………………………………………………………………………………………. 6
•
Pole installation …………………………………………………………………………………………………………………….. 7
•
Pole installation with MICRO BOX ………………………………………………………………………………………….. 8
•
Horizontal and vertical orientation ………………………………………………………………………………………… 9
Microwave
device Pages
from 10 to 20
Notes
Pages
from 22 to 23
•
Introduction …………………………………………………………………………………………………………………………… 10
•
Features and non-detection zones …………………………………………………………………………………………. 10
•
Receiver board (RX ) …………………………………………………………………………………………………………….... 11
Description of dip switch and terminal board
•
Transmitter board (TX ) …………………………………………………………………………………………………………… 12
Description of dip switch and terminal board
•
Installation ……………………………………………………………………………………………………………………………… 13
•
Manual configuration by dip-switch ……………………………………………………………………………………….. 13
RX module - signal sensitivity setting
RX module - setting of the signal attenuation time
TX module - setting of 4dB transmission signal attenuation
•
Control through software (RS485) …………………………………………………………………………………………… 15
Description of columns and parameters modification
Columns READ - WRITE - REAL TIME
Connection options via RS485-USB adapter
Warnings
Page 20
Product
photos
Page 21
Mounting
options Pages
from 5 to 9

MICRO 8 Installation and user manual Page 3 of 24
Introduction
and warnings
INTRODUCTION
MICRO 8 is the state of the art miniaturized
microwave barrier and represents an absolute
innovation on the market.
Micro 8 has a diameter of only 8 cm and a very
narrow lobe aperture.
The microwave device has a high degree of
reliability and consists of a transmitting and a
receiving unit.
The technology adopted is the planar of a new
generation and military derivation,
with ultra-compact dimensions due to the
absence of the cumbersome antenna dish.
The presence of an intruder is detected using
a system of high-frequency electromagnetic
waves.
MICRO 8 is suitable for industrial, residential,
and commercial areas, prisons, military
settlements and in general in all applications
where it is also necessary to protect large
areas.
WARNINGS
•Use shielded cables.
•Power the device using the 13.8 Vdc
stabilised voltage only.
•The installation should be performed by
qualified personnel.
•MITECH is not responsible for damages
and / or barrier malfunctions
caused by incorrect installation
and / or improper use.
MICRO 8

MICRO 8 Installation and user manual Page 4 of 24
Components
0 0 0 0
MITECH MW-E485
CLOSING CAP
POLYCARBONATE
COVER
MAIN SUPPORT BRACKET WITH CABLE PASSAGE PROTECTION
(ALSO USABLE WITH MICRO BOX AND MICRO PL ACCESSORIES)
COVER CAP SCREW TAMPER
RX or TX
ANTENNA
RS485 MODULE
WITH BUZZER
BOX FOR WALL OR POLE
MOUNTING
CABLE GLAND
MICRO BOXMICRO PL
POLE MOUNTING
BRACKET
TO USE
WITH MICRO BOX
(Dimensions 100x100x50 mm)

MICRO 8 Installation and user manual Page 5 of 24
Mounting
options
Wall
installation
1.
Place the main bracket at a height between 80 and 90 cm from the ground, and drill four
holes with a 5 mm drill bit (figure 1). Make sure that the wall cable exit hole is aligned
with that of the bracket.
2.
Fix the bracket using the screws and plugs (figure 2).
3.
Screw the flanged M16 nut and tighten it with a 16 mm wrench (figure 2).
4.
Insert the following components (figures 3 and 4):
- the main structure where the RX or TX antenna is connected
- the serrated washer
- the M16 nut tightening it with a 16 mm wrench
5. Insert the cables and make the connections (see pages 11 and 12).
Note: the tamper signal can be taken by connecting it directly to the microswitch, or by
connecting the microswitch to the TAMPER IN input of the antenna and then picking up
the signal from the TAMPER OUT output.
6.
Align the antennas (see installation procedure on pages 13 and 14).
7.
Insert the following components (figure 5):
- polycarbonate cover
- closing cap by tightening it with the M4 screw
- Screw cover cap
Figure 1 Figure 2 Figure 3 Figure 4 Figure 5

MICRO 8 Installation and user manual Page 6 of 24
Wall installation with MICRO BOX
1.
Position the base of the MICRO BOX on the wall where you want to install the barrier
(height between 80 and 90 cm from the ground) and make four holes with a 5 mm tip
(figure 1).
2.
Fix the base to the wall using the four screws, plugs and washers supplied (figure 2). If the
supplied cable gland is not used, make a hole in the base of the MICRO BOX verifying that
the hole is in line with that of the wall cable outlet (figure 1). If not, make a hole in one of
the four sides of the base and fix the PG8 (figure 2).
3.
Drill a hole in the center of the MICRO BOX cover using the template provided (figure 3).
4.
Insert the cables into the base and into the MICRO BOX cover, into the main bracket and
close using the four supplied screws (figure 4).
5.
Follow the procedure already indicated in the pole installation from point 3 (see page 5).
Figure 1 Figure 2 Figure 3 Figure 4
Figure 6 Figure 7
Figure 5

MICRO 8 Installation and user manual Page 7 of 24
Pole
installation
1. Position the main bracket at a height between 80 and 90 cm from the ground and make
a hole in the pole, maximum diameter 10/12 mm (figure 1).
2.
Position the MICRO PL bracket at the back of the pole and use the four M4x70 screws
and the supplied washers to fix the two brackets (figures 1 and 2). Make sure that the
pole cable exit hole is aligned with that of the bracket.
3.
Screw the flanged M16 nut and tighten it with a 16 mm wrench (figure 2).
4.
Insert the following components (figures 3 and 4):
- the main structure where the RX or TX antenna is connected
- the serrated washer
- the M16 nut tightening it with a 16 mm wrench
5. Insert the cables and make the connections (see pages 11 and 12).
Note: the tamper signal can be taken by connecting it directly to the microswitch, or by
connecting the microswitch to the TAMPER IN input of the antenna and then picking up
the signal from the TAMPER OUT output.
6.
Align the antennas (see installation procedure on pages 13 and 14).
7.
Insert the following components (figure 5):
- polycarbonate cover
- closing cap by tightening it with the M4 screw
- Screw cover cap
Figure 1 Figure 2 Figure 3 Figure 4 Figure 5

MICRO 8 Installation and user manual Page 8 of 24
Pole installation with MICRO BOX
Figure 1
1. Make a hole in the pole at a height of 80/90 cm from the ground in case you do not use the
cable gland supplied (figure 1), otherwise make a hole in one of the four sides of the base
of the MICRO BOX and fix the PG8 (figure 2).
2. Position the MICRO PL bracket at the back of the pole and using the four M4x70 screws and
the supplied washers fix the MICRO PL bracket to the base of the MICRO BOX
(figures 3 and 4).
3.
Drill a hole in the center of the MICRO BOX cover using the template provided (figure 5).
4.
Insert the cables into the base and into the MICRO BOX cover, into the main bracket and
close using the four supplied screws (figure 6).
5.
Follow the procedure already indicated in the pole installation from point 3 (see page 7).
Figure 2 Figure 3 Figure 4 Figure 5
Figure 6 Figure 7 Figure 8 Figure 9 Figure 10

Horizontal
and vertical adjustment
Horizontal
adjustment
180°
HORIZONTAL ADJUSTMENT
Vertical
adjustment
It is possible to orient the antenna vertically by adjusting the four fixing screws up to a
maximum of 5
°.
MICRO 8 Installation and user manual Page 9 of 24
FRONT VIEW SIDE VIEW 1 LATERAL VIEW 2
5° DOWNWARD
ADJUSTMENT
LATERAL VIEW 3
5° UPWARD
ADJUSTMENT

MICRO 8 Installation and user manual Page 10 of 24
The microwave device consists of two TX and RX units to be positioned at opposite ends of the
protected area. The TX unit emits electromagnetic waves in the direction of the RX unit that
receives them, processes them and translates them into an electrical signal that is analyzed.
The intruder who crosses the detection area (ZR) causes a change in the signal. The intensity and
type of signal depend on the following factors,
size and mass of the intruder who crosses the ZR,
speed and time of crossing the ZR, conformation and soil conditions
Techinical
features
Maximum
range
200 m
Detection
speed
from
0,1 to 10,0 m/s
Power
supply
from
12 to 36 Vdc
Consumption
module
TX 70 mA - module RX 110 mA
Recovery time after alarm notification
10
s
Duration
of the report
5 s
Operating
frequency
from 24.000 to 24.250 GHz (K band)
Selectable
frequencies
By
dip-switch: 16 - by software: 250
Maximum lobe height
2,5 m
Maximum
lobe aperture
50 m range: 0,6 m at 25 m
100 m range: 1,2 m at 50 m
200 m range: 2,4 m at 100 m
Installation height
From 80 to 90 cm from the ground
Standard compliance
EN 50131
-1 and CEI 79-3
ROhs
compliance
2011/65/UE
Protection class
IP
65
Warranty
3 years
3,0 m
20 cm
2,0 m
50 cm
1,0 m
70 cm
90 cm
Non
-detection zones
Microwave device

MICRO 8 Installation and user manual Page 11 of 24
Receiver
board (RX )
LED
RX ANTENNA
DIP SWITCH
FREQ
0
ON
1 2
0
ON
0
ON
0
ON
1 2 1 2 1 2
SENS
LEVEL SENS TIME
ABS
CNF
S/A
LED
ON
TAMPER
IN TAMPER OUT 0 A B
RS485 GND VIN
ALARM WARN
TERMINAL BLOCK
Dip
-switch description :
FREQ:
frequency setting
SENS LEVEL:
signal attenuation level setting
SENS TIME:
signal attenuation duration setting
ABS:
detection mode setting (PARAMETER NOT TO CHANGE)
CNF:
activation of configuration mode
S/A:
activation of the RS485 module for software management
LED:
led activation
Terminal
board description:
TAMPER IN:
tamper input
TAMPER OUT:
tamper output
0 A B:
RS485
ALARM:
alarm output
WARN:
anti-masking output
GND
: 0 V
VIN:
+12 Vdc
TERM
BUZZER
MODULE RS485
WITH BUZZER

MICRO 8 Installation and user manual Page 12 of 24
Transmitter
board (TX)
LED
TX ANTENNA
FREQ
0
ON
1 2 0
ON
1 2
SENS
LEVEL SENS TIME
ABS
CNF
S/A
LED
ON
TAMPER
IN TAMPER OUT 0 A B
RS485 GND VIN
ALARM WARN
0
ON
1 2
Dip
-switch description:
FREQ:
frequency setting
SENS LEVEL:
attenuation of the 4 dB transmission level
ABS:
not used
CNF:
activation of configuration mode
S/A:
activation of the RS485 module for software management
LED:
led activation
Terminal
board description:
TAMPER IN:
tamper input
TAMPER OUT:
tamper output
0 A B:
RS485
ALARM:
fault output
WARN:
not used
GND
: 0 V
VIN:
+12 Vdc
TERMINAL BLOCK
DIP SWITCH
MODULE RS485
TERM
BUZZER

MICRO 8 Installation and user manual Page 13 of 24
Introduction
The MITECH antennas can be managed manually via the dip
-switches on both the RX and
TX modules or by using the MITECH Radar Barrier configuration proprietary program.
IMPORTANT: the modules always keep the last saved configuration in memory even in
the event of a power failure.
Installation
As standard the dip
-switches on the RX and TX modules are programmed as follows:
1.
Position the CNF dip-switch of the RX and TX module in ON mode. In this condition the led will
start to flash for a few seconds, confirming the input in configuration mode (on the TX module
the red led will remain lit, see paragraph TX Module - setting the transmission level attenuation
by 4dB on page ...).
2.
Defining the working frequency by programming the FREQ dip-switches of both modules,
the programming of the dip-switches of the RX module must be the same as that of the TX
module. If you do not want to change the frequency go directly to point 3.
3.
Orient the RX module towards the TX module in order to obtain the greater intensity of the
green RX led and the greater speed of the buzzer signal (to activate the buzzer act on the
BUZZER jumper). The turning on of the red led and the lower speed of the buzzer signal, mean
that you are moving away from the optimal position.
If necessary also act on the orientation of the TX module.
4.
At the end of the alignment if you want to keep the led on, program the led dip-switches in ON
mode on both modules.
5.
If you do not want to change other parameters and then exit the configuration mode, program
the CNF dip-switch in OFF mode on both modules, avoiding interrupting the signal and moving
the antennas.
RX MODULE
FREQ SENS LEVEL SENS TIME ABS CNF S/A LED
OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF ON OFF
TX MODULE
FREQ SENS LEVEL ABS CNF S/A LED
OFF OFF OFF OFF OFF OFF OFF OFF ON OFF
Manual control
Put in use
TX RX
RX
TX
TX
RX
YES YES NO

MICRO 8 Installation and user manual Page 14 of 24
By using the SENS LEVEL dip
-switches on the RX board , you can set the signal attenuation level.
Procedure:
1.
Enter the configuration mode (CNF in ON) and wait for the led to stop flashing.
2.
Program the two dip-switches following the combinations indicated in the following table:
3.
Exit the configuration mode by programming the CNF dip-switch in OFF mode, avoiding
interrupting the signal and moving the antenna.
RX board
- signal attenuation level setting
DIP 1 DIP 2
OFF OFF Minimal Sensitivity (-5db)
ON OFF (-3,8 db)
OFF ON (-2,5 db)
ON ON Maximum Sensitivity (-1,5db)
By using the SENS TIME dip
-switches on the RX board , it is possible to set the duration of the signal
attenuation.
Procedure:
1.
Enter the configuration mode (CNF in ON) and wait for the led to stop flashing.
2.
Program the two dip-switches following the combinations indicated in the following table:
3.
Exit the configuration mode by programming the CNF dip-switch in OFF mode, avoiding
interrupting the signal and moving the antenna.
RX board
- duration setting of signal attenuation
DIP 1 DIP 2
OFF OFF 50 mS
ON OFF 150 mS
OFF ON 250 mS
ON ON 350 mS
TX board
- 4dB transmission level attenuation setting
By using the SENS LEVEL dip
-switches on the TX board , the signal transmission level can be
attenuated by 4
dB.
Procedure:
1.
Enter the configuration mode (CNF in ON) and wait for the led to stop flashing.
2.
Program the two dip-switches in ON mode (the red led will switch off).
3.
Exit the configuration mode by programming the CNF dip-switch in OFF mode, avoiding
interrupting the signal and moving the antenna.
IMPORTANT
It is only possible to enter the configuration mode once to program the dip-switches.
In manual control mode it is not possible to make changes using the software.

MICRO 8 Installation and user manual Page 15 of 24
Procedure:
1.
Program the S/A dip-switches of the RX and TX modules in OFF mode.
2.
IMPORTANT: the CNF dip-switches of both modules must be programmed in OFF mode.
Connect the antennas (see Connection options - RS485-USB adapter).
3.
Select the MITECH radar barrier configuration program and wait a few seconds.
4.
- Select Com Ports and select the serial port on which the RS485 adapter is connected.
-
Select the communication speed according to the converter model used (standard 19200 bps).
- Select the Open Port command, wait a few seconds and then the SCAN key.
After about 16 seconds all the antennas connected to the serial port will be displayed
(see Figure 1, example of a pair of antennas connected to COM7).
MIRS485 module
- MITECH radar barrier configuration program start
Com Ports Baud rate Open Port SCAN
Figure 1
The MITECH Radar Barrier Configuration program allows, via the RS485 serial connection, the maximum
and simultaneous management of 16 pairs of antennas, using only one COM port.
In case it is necessary to manage more than 16 pairs of antennas, more COM ports must be used.

MICRO 8 Installation and user manual Page 16 of 24
Description of columns and modification of parameters
COLUMN ID
Displays the 485 serial addresses that can be controlled from a single COM.
The values entered in this column cannot be changed.
TX AND RX FREQ COLUMN
Displaying the frequency of the TX antenna and the RX antenna (range from 0 to 249 Hz) for each
connected module, 16 frequencies are set as standard.
For correct operation, the two TX and RX antennas must have the same frequency.
The program updates the values even if one of the two frequencies is changed. For example, by
changing only the freq. TX, the program also changes the freq. RX and vice versa.
To change the frequency place the mouse on the cell of the address you want to change (TX or RX)
and click once (figure 1).
Wait for the control window to open (figure 2) and enter a value between 0 and 249 and click OK
(figure 3).
In this phase the new value set on the TX
Freq and RX Freq cells will be displayed.
To save the modification, click with the mouse on the red cell of the address you are configuring
(figure 4).
TX LEVEL COLUMN
Displays the 4dB attenuation of the transmission signal for each address.
To activate or deactivate this parameter, position the mouse on the TX Level cell that you want to
modify and click once (figure 1). Wait for the activation of the curtain control (figure 2), click a second
time and select one of the two values 0
db or + 4db (figure 3).
With the value 0
db the signal is attenuated by 4 dB.
To save the modification, click with the mouse on the red cell of the address you are configuring
(figure 4).
Figure 1 Figure 2 Figure 3 Figure 4
Figure 1 Figure 2 Figure 3 Figure 4

MICRO 8 Installation and user manual Page 17 of 24
TX AND RX COLUMN LEDS ENABLED
They show the status of the green and red led on the TX and RX antennas.
To change the on / off condition, place the mouse on the led box whose status you want to change
(figure 1) and click once (figure 2).
The flag in the box indicates the led are lit.
To save the modification, click with the mouse on the red cell of the address you are configuring
(figure 4).
RX LEVEL COLUMN
Displays the level of the RX signal.
The values entered in this column cannot be changed.
INTRUDER SPEED COLUMN
Displays the time (in
mS) of the duration of the attenuation of the alarm signal.
To change this parameter, place the mouse on the cell of the address you want to modify and click once
(figure 1).
Wait for the control window to open (figure 2) and enter a value between 20 and 350, then click OK
(figure 3).
To save the modification, click with the mouse on the red cell of the address you are configuring
(figure 4).
COLUMN ALARM OFFSET
Displays the level (in dB) of attenuation of the alarm signal.
To change this parameter, place the mouse on the cell of the address you wish to modify and click once
(figure 1). Wait for the control window to open (figure 2) and enter a value between
-20 and -1, then
click OK (figure 3).
To save the modification, click with the mouse on the red cell of the address you are configuring
(figure 4).
Figure 1 Figure 2 Figure 3
Figure 1 Figure 2 Figure 3 Figure 4
Figure 1 Figure 2 Figure 4
Figure 3

MICRO 8 Installation and user manual Page 18 of 24
ALARM LEVEL COLUMN
Displays the level of the alarm signal.
The values entered in this column cannot be changed.
COLUMN ALARM DISABLED
Displays the status of the alarm output (ALARM terminal RX output).
To change the activation or deactivation condition, position the mouse on the panel of the output
whose status you want to change (figure 1), then click once (figure 2).
The flag in the box indicates that the output is not active (figure 2).
To save the modification, click with the mouse on the red cell of the address you are configuring
(figure 4).
MODE COLUMN
Displays the default detection mode.
This parameter cannot be changed.
Figure 1 Figure 2 Figure 3
READ
–WRITE –REAL TIME COLUMNS
READ COLUMN
Reading / enabling column for changes.
Instructions: click with the mouse on the green box of the address you want to read / modify.
WRITE COLUMN
Column for writing / editing parameters.
Instructions: Once the changes have been made to an address, click on the corresponding red box
with the mouse.
REAL TIME COLUMN
Activation of the real
-time display panel of the signal level for each pair of antennas. Function to be
used during the installation phase to verify, according to the parameters assigned, the signal level.
IMPORTANT: once the display panel is activated, the configuration table is automatically inhibited
and parameters can no longer be changed. To reactivate the commands, click on the Pause button.
Pause

MICRO 8 Installation and user manual Page 19 of 24
Option 1
Connection
options - RS485-USB adapter
MODULE
IMPORTANT
For all connections it is necessary to respect the following connection diagram:
A with A - B with B
MODULE
RS485 RS485
USB
PC
TERM TERM
Option 2
USB
PC
MODULE
RS485
TERM
MODULE
RS485
TERM
IMPORTANT
In the first and last modules connected,
insert the TERM jumper
IMPORTANT
Using an adapter with
120 Ohm fixed termination
(measurable value between pins A - B)
insert the TERM jumper
in the last connected module.
Using a terminated adapter
selectable set the value of 120 Ohm
and insert the TERM jumper
in the last connected module.
Using an adapter without termination,
insert a resistor
from 120 Ohm between pins A - B
and insert the TERM jumper
in the last connected module.

MICRO 8 Installation and user manual Page 20 of 24
Warnings
1. When preparing the device and during its use, observe the current technical safety standards
for electrical installations.
2. For standard installations recommended by the manufacturer with antennas positioned at
80/90 cm from the ground, the maximum height of the snowpack or grass must not exceed
the limit of 30 cm beyond which the device may not report any movement / intrusion to its
indoor.
3. Avoid creating interference due to incorrect pointing of multiple TX antennas towards the
same RX antenna.
4. Use shielded cables.
5. Supply the device with a stabilized voltage of 13.8
Vdc.
6. Installation must be carried out by qualified personnel.
7. MITECH is not responsible for damages and / or malfunctions of the barriers caused by
incorrect installation and / or improper use of the same.
