Mitox 260B User manual

Operator’s Manual
user manual, maintenance instructions and spare parts
260B Blower / 280BV Blower Vacuum
www.mitoxgm.co.uk
Read this manual carefully before operating the machine
Original Instructions Version July 12

260B Blower / 280BV Blower Vacuum
2
Original Instructions Version July 12
Component Location
1. Ignition Switch ON-OFF toggle switch. Switch to ON before starting. Switch to OFF to stop engine
2. Spark Plug Provides spark to ignite 2-stroke fuel mixture
3. Air Cleaner Replaceable air lter
4. Fuel Tank Contains fuel and fuel lter
5. Fuel Cap Seals fuel inside fuel tank
6. Recoil Starter Pull to start engine
7. Muer Controls exhause emissions and noise
8. Choke To assist cold starting. Fully extend to close choke. Push in to open choke.
9. Primer Bulb Draws fuel from fuel tank and purges air from the carburetor prior to starting.
10. Blower Pipes Two parts lock together to form air discharge pipe.
11. Throttle Lever Pull to increase engine speed.
12. Vacuum Tube Two parts lock together to form air intake pipe. Vacuums in debris to be shredded.
13. Vacuum Elbow Discharges shredded materials into collection bag.
14. Collection Bag Collects shredded materials with zip to empty.
15. Side Cover Must be closed when in blower mode.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.

260B Blower / 280BV Blower Vacuum
3
Original Instructions Version July 12
PRODUCT DESCRIPTION
This Blower/Vacuum is a 2 stroke fast running power tool and is designed to be used in
a domestic application for vacuuming leaves and cut lawn. It can be easily converted
into a blower.
Important
The information contained in this manual describes machines available at the time of production. While
every attempt has been made to give you the very latest information about your BV280, there may be
some dierences between your machine and what is described here .We reserve the right to make changes
in production without prior notice, and without obligation to make alterations to machines previously
manufactured.
Before using this product, consult local regulations concerning noise restrictions and hours of operation.
• ThisproducthasbeendesignedtobeusedasaBlower/Vacuumpowertoolasdescribed 
previously and it should never be used for any other purpose; doing so could result in unforeseen
accidents and injuries occurring. Only approved Mitox accessories should be used with this
product.
• ThisBlow/Vacisequippedwithextremelysharpblades,alwayswearsturdygloveswhenhandling
the blades and t the safety guards when not in use.
• WhenusingtheBlow/Vac,gripthehandlesrmlywithbothhands,placeyourfeetslightlyapart
so your weight is distributed evenly across both legs, and always maintain a steady even posture
while working. Do not use on ladders or if the ground surface is slippery or uneven.
Work Clothing and Safety Equipment
When using the product, you should wear proper clothing and protective equipment:
• Helmet
• Protectiongogglesorfaceprotector
• Earprotectors
• Thickworkgloves
• Non-slipsoleworkboots
• Whenusingyourblower,alwayswearstrong,durable,workclothing;shirtsshouldbelong-
sleeved and trousers should be full-length. No loose clothing / ties or jewellery.
• Dustmask

260B Blower / 280BV Blower Vacuum
4
Original Instructions Version July 12
Warnings in the Manual
This manual contains special “attention statements”surrounded by boxes and preceded
by the triangular Attention Symbol:
Additional attention statements that are not preceded by the Attention Symbol are:
A statement preceded by the word“IMPORTANT” is one that possesses special
signicance.
Astatementproceededbytheword“NOTE”containsinformationthatishandytoknow
and may make your job easier.
Read and follow this manual. Failure to do so could result in serious
injury.
Wear eye and hearing protection at all times during the operation of
this machine
DO not operate this machine if you are tired, ill
or under the inuences of alcohol, drugs, or Medicine.
IMPORTANT
!
NOTE

260B Blower / 280BV Blower Vacuum
5
Original Instructions Version July 12
Product Description
The operational procedures described in this manual are intended to help you get the
most from your machine and also to protect you and others from harm. These procedures
are general guidelines only,
and are not intended to replace any safety rules/laws that may be in force in your area.
Ifyouhaveanyquestionsregardingyourblower/vacuum,orifyoudonotunderstand
something in this manual, your dealer will be glad to assist you.
Specications
Model………………………………………………………………………………BV280
Dimensions(L×W×H)…………………………………………………845×340×350(mm)
EngineType ………………………………2 cycle air cools gas engine, vertical cylinder
Bore&Stroke…………………………………………………………………..34×28(mm)
Displacement…………………………………………………………………26cc
Fuel………………………………………………………………Gasoline/oilmixture25:1
Carburetor……………………………………….Walbro diaphragm-typewithprimerpump
Ignition…………………..………………………All transistor electronic ignition system
Spark plug……………………………………L9T(LD)
Starting……………………………………………………………………….Recoil starter
Stopping………………………………………………………………..Grounding
FuelTank Capacity………………………………………………………………….0.65liter
Exhaustsystem………………………………………………lowdB;spark-arrestormuer
Air Cleaner Type………………………………………………………………….Semi-wet
Weight(dry;withvacuumtubes)………………………………………………………6.3kg
Vibration values……………………………………………………………………≤10m/s
Soundpowervalues……………..………………………………………………≤105dB(A)

260B Blower / 280BV Blower Vacuum
6
Original Instructions Version July 12
Assembling the Vacuum
1.FittheVacuumelbowtubeoverthe
blower discharge port, aligning the
channels in the tube over the locking pin.
2. Twist the Vacuum elbow tube to engage
the locking pin as illustrated.
3.Lockthetubeinplaceusing1xM5x10
screw.
1.
2.
3.
Open the side cover using the
thumbscrew.

260B Blower / 280BV Blower Vacuum
7
Original Instructions Version July 12
Fit the upper vacuum tube over the
vacuum intake port, aligning the channels
in the tube over the locking pin.
Twist the upper vacuum tube to engage
the locking pin as illustrated.
Attach the lower vacuum tube to the
upper vacuum tube using the same
method.
Fit the collection bag over the Vacuum
elbow tube using the velcro fastener.

260B Blower / 280BV Blower Vacuum
8
Original Instructions Version July 12
Assembling the Blower
Fit the straight blower tube over the
blower discharge port, aligning the
channels in the tube over the locking pin.
Twist the straight blower tube tube to
engage the locking pin as illustrated. Lock
thetubeinplaceusing1xM5x10screw.

260B Blower / 280BV Blower Vacuum
9
Original Instructions Version July 12
Important
Blower tube installation aects both blower Balance and performance! The tube and
Nozzle are correctly installed when the label “TOP” is visible to the operator during normal
operation.
Fit the tapered blower tube over the
straight blower tube, aligning the channels
in the tube over the locking pins.
Twist the tapered blower tube tube to
engage the locking pins as illustrated.
Note the tapered discharge chute is
marked with a TOP side.

260B Blower / 280BV Blower Vacuum
10
Original Instructions Version July 12
Two-Stroke Fuel
Fuel is very ammable. Do not smoke or bring any ame or sparks near fuel.
Always stop the engine and allow it to cool before refuelling.
Refueloutdoorsonbareground,restartengineatleast5mawayfromtherefuellingstop.
The engine is lubricated by oil mixed into petrol. Prepare a mixture of unleaded petrol and semi-synthetic
two-strokeoilthatmeetsthespecicationsof:APITC,ISO-L-EGC,JASOFC(LowSmoke)oil.
Recommended mixing ratio is 25:1.
FUEL WITH NO OIL (RAW PETROL) will cause severe damage to the engine which is not covered by
manufacturer’s warranty.
Usefresh,unleadedpetrol(95RON)andsemi-syntheticoilspeciallymadeforhighperformancetwo-stroke
engines.Mixinaratioof25partspetrolto1partofoil.
By using two-stroke oil specially made for two-stroke engines you will reduce the formation of ash and
carbondepositsonthesparkplug,piston,exhaustmuerandcylinderaswellasreducingemissionsof
harmful exhaust gases.
OilFOR4-CYCLEENGINESshouldnotbeusedastwo-strokelubricationoilasitcancausefoulingofthespark
plug, exhaust port blocking, piston ring sticking and other internal engine damage.

260B Blower / 280BV Blower Vacuum
11
Original Instructions Version July 12
Fuel Storage
Mixed two-stroke fuel which has been left unused for a period of one month or more may damage
the carburettor and result in the engine failing to start or operate correctly.
When storing the grass trimmer for a period of more than one month, empty the fuel tank, and
run the engine to empty the carburettor of fuel.
Two stroke fuel can cause deterioration of rubber and/or plastic components during prolonged
storage.
Itisimportanttoonlyusegoodquality,freshfuelmix.

260B Blower / 280BV Blower Vacuum
12
Original Instructions Version July 12
Fuelling
Shake the fuel container to thoroughly mix the two-
stroke oil and petrol.
Clean dirt from around the fuel cap before
removing.
Pour two-stroke fuel into the fuel tank with a
ltered funnel, up to 80% of the fuel tanks capacity.
Replace the fuel cap and tighten securely. Spilled
fuel must be wiped away from the blower before
starting the engine.
Moveatleast5mawayfromtherefuellingareabeforerestartingtheengine.
When relling the tank, always turn o the engine and allow it to cool down. Take a careful look around
to make sure that there are no sparks or open ames anywhere nearby before refuelling.

260B Blower / 280BV Blower Vacuum
13
Original Instructions Version July 12
Starting the Machine

260B Blower / 280BV Blower Vacuum
14
Original Instructions Version July 12
IMPORTANT !
A two-position “ON-OFF” switch located on the left of the machine handle grip controls the engine ignition.
Cold Engine Starting Procedure
1.2.
3. SettheignitionswitchtotheONposition.
4. Slowlypulltherecoilstarterhandleuntilengagementofthepawlswiththeywheelisfelt.
5. Whileholdingtheunit,pulloutthestarterropermlyuntilengineres(indicatedbya‘cough’
 fromtheengine).
6. Pushthechokerodbackin(chokeisopen).
7. Pull the starter rope until the engine starts.
8. Allow the engine to warm up before use.
Prime the fuel system by repeatedly
depressing the fuel primer bulb
until no air bubbles are visible in
the fuel discharge line.
ColdEngineOnly.Chokethe
engine by pulling the choke
control to the fully extended
position(chokeisclosed).

260B Blower / 280BV Blower Vacuum
15
Original Instructions Version July 12
Hot Engine Starting Procedure
Set the ignition switch to the ON position .
Pull the starter rope until the engine starts.
Iftheenginedoesnotstartafter5pulls,usethecoldstartprocedure.
Overchoking
Should the engine become ooded due to overchoking, turn the ignition switch o, unscrew the spark plug,
wipe it dry or replace.
Stopping the Engine
Set the engine to idling by releasing the throttle lever.
Set the ignition switch to the o position OFF.
If the engine fails to stop, set the choke lever to the closed position to stall the engine; do not use the
machine until the ignition switch is repaired.

260B Blower / 280BV Blower Vacuum
16
Original Instructions Version July 12
Adjusting the Engine Idle Speed
1. Starttheenginebyfollowingthe
procedures described on the preceding
pages.
2. Run the engine at idle speed until
 operatingtemperatureisreached(2-3
 minutes).
3. Useascrewdrivertoadjusttheengine
 idlespeedto2300-2500r/min.
Turn the idle screw clockwise to increase engine
idle speed.
Turn the idle screw counterclockwise to decrease
engine idle speed.
IMPORTANT !
Machinetubesandintakecovermustbeinstalledwhileadjustingengineidle!Engineidlespeedwillalsobe
aected if either the intake cover or machine tubes are blocked, damaged or incorrectly installed!
IMPORTANT !
If the engine continues to run with the ignition switch in the“OFF” position, stop the engine by pulling the
choke control out to the fully closed position.
Acleanandunrestrictedairowisessentialtoyourmachine’sengineperformanceanddurability!Before
attemptinganycarburetoradjustments,inspectandcleantheengineaircleanerasdescribedonpage11of
this manual.

260B Blower / 280BV Blower Vacuum
17
Original Instructions Version July 12
Using the Machine
As a general rule, try to operate your machine at the lowest throttle setting necessary to get the job done:
•Uselowthrottlesettingswhenclearinglightweightmaterialsfromaroundlawnsorshrubbery.
•Usemediumtohigherthrottlesettingstomovelightweightgrassorleavesfromparkinglotsorwalkways.
•Usefullthrottlewhenmovingheavyloadssuchasdirtorsnow.
Safe operation
(1)Machinenoiseincreasesathigherthrottlesettings!Alwaysusethelowestthrottlesettingrequiredtoget
the job done!
(2)Neveroperatetheblowerwhenvisibilityispoor.
(3)Alwaysweareyeprotectionsuchasfaceshieldorgoggleswhileoperatingthismachine.
(4)Wearadustmasktoreducetheriskofinhalationinjuries.
(5)Wearclose-ttingclothingtoprotectyourlegsandarms.
(6)Wearhearingprotectionwhenoperatingthismachine.
(7)Neveroperatetheblowerifanycomponentpartsaredamaged,loose,ormissing.

260B Blower / 280BV Blower Vacuum
18
Original Instructions Version July 12
Using the Vacuum
Always be aware of the strength and direction of
stream. Never direct the blower discharge stream
toward people or animals.
Using the Blower
Always be aware of the strength and direction of
stream. Never direct the blower discharge stream
toward people or animals.

260B Blower / 280BV Blower Vacuum
19
Original Instructions Version July 12
Routine Maintenance
Daily Maintenance
Remove dirt and debris from the blower exterior.
Inspect the engine, tank, and hoses for possible fuel leaks, and repair as necessary.
Inspect the engine cooling ns for accumulations of dirt or debris, and clean
as necessary.
Inspect the entire machine for damage, loose or missing components or fastenings, and repair as necessary.
Every 10 Hours Use (MOREFREQUENTLYINDUSTYCONDITIONS)
     1.Loosentheaircleanercoverretainingscrew,and
remove the cover and lter element.
2. Inspect the element. If the element is distorted or
damaged, replace it with a new one.
     3.Washtheelementincleanfuel,andsqueezeor
blow dry. Wash the air cleaner cover in clean fuel,
and wipe or blow dry.
     4.Installtheelementandcover,andthentighten
the cover retaining screw.

260B Blower / 280BV Blower Vacuum
20
Original Instructions Version July 12
Every 10/15 Hours Use
     1.Usethesparkplugwrenchtoremovethespark
     plug(turncounter-clockwisetoremove).
2. Clean and adjust the spark plug gap to
0.6~0.7mm. Replace any damaged or visibly worn
     plugwithachampionRCJ6Yorequivalent.
     3.Installthesparkplugnger-tightinthecylinder
head, and then tighten it rmly with the spark plug
     wrench.Ifatorquewrenchisavailable,torquethe
     sparkplugto148-165inchpounds.
Every 50 Hours Use (MOREFREQUENTLYIFYOUNOTEREDUCEDPERFORMANCE)
     INSPECTIONInspecttheentiremachineand
tubes for damage, including loose or missing
components, and repair as necessary.
SPARK PLUG Replace the spark plug with a
     championL9T(LD),gappedto(0.6~0.7)mm.
     FUELFILTERUseawirehooktoextractthefuellter
from inside the fuel tank, and then remove and
wash the lter element in clean fuel.
Before reinstalling the lter, inspect the condition
of the fuel line. If damage or deterioration is noted,
the vacuum should be removed from service until
it can be inspected by a trained service technician.
COOLINGSYSTEMRemovetheenginecover(asdescribedunder“SparkArrestor”),anduseawoodorplastic
scraper and a soft brush to remove dirt and debris from the cylinder ns and crankcase.
