Mixtelematics MVR1204 Manual

MVR1204
Hardware Installation Guide

1 | P a g e
Table of Contents
1Introduction .................................................................................................................................................................................. 2
2. Hardware Installation ................................................................................................................................................................... 3
2.1 Connecting the MVR1204 unit to the FM unit...........................................................................................................................3
2.2 Connecting the Microphone to the MVR1204 unit....................................................................................................................3
2.3 Positioning the Microphone in the Vehicle................................................................................................................................4
2.4 Connecting the Camera to the MVR1204 unit..........................................................................................................................4
2.5 Positioning the Camera in the vehicle......................................................................................................................................5
2.5.1 Camera installation in a Truck........................................................................................................................................ 5
2.5.2 Camera Installation in a Light Vehicle............................................................................................................................. 5
2.6 Connecting Optional External Cameras to the MVR1204 unit..................................................................................................6
3. Verifying the installation.............................................................................................................................................................. 7
3.1.1 Verifying the camera installation..................................................................................................................................... 7
3.1.2 Verifying the microphone installation.............................................................................................................................. 7
3.1.3 Status LEDs on the MVR1204 unit................................................................................................................................. 8
4. Appendix A - Technical Specifications ....................................................................................................................................... 9
5. Appendix B - Certification and Conformity................................................................................................................................12

2 | P a g e
1 Introduction
Welcome to the MVR1204 Software Installation Guide. The MVR1204 is a H.264
Mobile Video Recorder. The MVR1204 includes an internal 3G modem to
automatically upload recorded video clips to MiX Telematics tracking software.
Video events are triggered and controlled by the FM on-board computer and are
recorded on an event basis and associated and stored with driver violations
and detailed trip information. Customers are able to remotely monitor the
vehicle performance and retrospectively download a high resolution video of a
specific event or incident.

3 | P a g e
2. Hardware Installation
The MVR1204 should be installed by a suitably qualified person. This manual assumes that the MVR has
already been fitted with a SIM card and that the software configuration was done to set the APN and server
IP address.
2.1 Connecting the MVR1204 unit to the FM unit
Figure 2
1. Connect the MVR1204 to the serial port S1 or S3 on an FM 3xxx by plugging the connecters into
the second and third slot from the left of the MVR1204.(Ports A and B as displayed on figure 2)
2. Then plug the DB9 connector into the S1 or S3 port a FM 300 Serial Harness (440FT0165) or FM300
Twin Serial Harness (440FT0276).
3. Connect the Red wire to a permanent power (battery) on the Vehicle (12V or 24V)
4. Connect the Green wire to Positive drive on the Twin Serial Harness (Red)
5. Connect the Black wire to ground. The brown wire (ground) of the Twin Serial Harness S3
connector should be tied to the same ground connection.
6. Optional external cameras (camera 3 and camera 4) can be connected on Port E and Port F as
shown in figure 2 above.
2.2 Connecting the Microphone to the MVR1204 unit
The microphone is connected to a cable that plugs directly into the MVR1204 unit.
Figure 3
1. Plug the connector, at the end of the microphone cable, into the audio port (Port E as displayed in
figure 3)

4 | P a g e
2.3 Positioning the Microphone in the Vehicle
1. Place the microphone inside the cab on the center panel closest to the driver’s side (please see image
below).
2. Ensure that the microphone is positioned as far away from the windscreen as possible as this has an
effect on the audio quality
3. Secure the microphone using the double sided tape provided
Secure microphone in this area
2.4 Connecting the Camera to the MVR1204 unit
The cameras have an integrated cable that plugs directly into the MVR1204 unit.
1. Camera 1 is the camera facing towards the road –connect the cable marked with a yellow tag to the
port marked as camera “1” on the unit (Port C in figure 1)
2. Camera 2 is the camera, with the LEDs around it, facing inside the cab –connect the unmarked
cable to the port marked as camera “2” on the unit (Port D in figure 1)
3. The optional external cameras are identical and each provides its own power, therefore they can be
plugged into port E or Port F in figure 2
Notes:
1. The MVR1204 must be connected to the S1 or S3 port of the FM3306 / 3316 / 3507i / 3517i / 3607i / 3617i /
3707i / 3717i via a FM 300 Serial Harness (440FT0165) or FM300 Twin Serial Harness (440FT0276)
2. Tracers are not supported.

5 | P a g e
2.5 Positioning the Camera in the vehicle
Please Note: Ensure that the windscreen surface is clean and dry before attaching
the camera to the windscreen. Use the alcohol swipe in the box to clean the
position on the windscreen where the camera will be mounted.
2.5.1 Camera installation in a Truck
Install the camera inside the cab, the camera should be placed against the windscreen. The position of the
camera should be one of the following:
1. Place the camera inside against the windscreen in the centre of the windscreen as close to the
bottom of the windscreen. If it is not possible to install in the centre, position the camera on the
driver side of the centre position.
2. For an optimum view, install the camera behind the path of the windscreen wiper.
3. The camera facing inside should always be higher than the dashboard to provide the best view of
the driver and co-driver. Ensure that the camera view facing outside is not blocked by a grid.
4. Ensure that the camera does not block or prevent automatic sun visors to be lowered all the way
down to the dashboard.
5. The cable should be routed along a safe path away from high voltage ignition lines sources of
mechanical damage etc. Cables should be safely secured.
2.5.2 Camera Installation in a Light Vehicle
Install the camera inside the vehicle, the camera should be placed against the windscreen. The position of
the camera should be following:
1. Install the camera, against the windscreen just below the rearview mirror.
2. For an optimum view, install the camera behind the path of the windscreen wiper.
3. The camera facing inside should always be higher than the dashboard to provide the best view of
the driver and co-driver. Ensure that the camera view facing outside is not blocked by a grid.
4. The cable should be routed along a safe path away from high voltage ignition lines sources of
mechanical damage etc. Cables should be safely secured.

6 | P a g e
2.6 Connecting Optional External Cameras to the MVR1204 unit
The optional external cameras plugs directly into the MVR1204 unit, but extension harnesses are available if
the install point if further than 5 meters away from the MVR1204 unit
Step
Part Number
Description
1
440FT0621
Each Camera has a 5 m
extension cable that plugs
directly into the MVR 1204.
Camera 3 on Port E
Camera 4 on Port F
2
440FT0813 (5m)
440FT0814 (10m)
440FT0815 (20m)
If the Installation point is
further than 5m from the
MVR1204, use one or
more of the extension
cables to cover the
complete distance.
3
440FT0621
to
440FT0814
Unplug the waterproof
connector (about 5 cm
behind camera) and plug
the two ends of the
extension cable into the
two connectors (one leads
to the camera and one
leads to the MVR1204)

7 | P a g e
4
440FT0621
Install the Camera.
Use the straight bracket if
you can access the panel
from behind, otherwise use
the L-bracket.
Use the MiX Vision Installation Utility to ensure the camera is orientated correctly (dot facing to the top of the
picture). Loosen the screws on the side of the camera to adjust the ball until the camera is 100% horizontally
aligned and facing the correct view. Tighten the screws in order to lock the camera into position.
3. Verifying the installation
3.1.1 Verifying the camera installation
1. Connect an Ethernet cable from the MVR1204 unit to the laptop
2. Open the MiX Vision utility
3. Click on Refresh
4. A unit serial number "MVR1204 xxxxx" should appear in the device list
5. Select the device
6. Click on Camera 1 to verify that camera 1 is facing the road and that alignment is correct
7. Click on Camera 2 to verify that camera 2 is facing into cab and that alignment is correct
8. Fit the end-caps to cover up the screws in order to resist any tampering with the camera angles
9. If the optional external Cameras (3 and 4) are installed, click on Camera 3 and Camera 4 to verify
that they are facing the correct view and that the alignment is correct.
3.1.2 Verifying the microphone installation
1. Connect an Ethernet cable from the MVR1204 unit to the laptop
2. Open the MiX Vision utility
3. Click on Refresh
4. A unit serial number "MVR1204 xxxxx" should appear in the device list
5. Select the device
6. Click on Camera 2 (in-cab) and ensure that the audio quality is clear.

8 | P a g e
3.1.3 Status LEDs on the MVR1204 unit
LED
LED Status
Operating Status
Camera 1- 4
Solid Green
Camera plugged in and active
100ms on / 1s off
Camera not plugged in or inactive
Power
Solid Red
Ignition is on and MVR has booted and has received at
least 1 watchdog ping from the FM unit.
Flashes Red every 10 s
Ignition is off and MVR is in shutdown mode
Flashes Red every 4s
Ignition is on and unit has booted –but has no
communication with the FM unit or are still booting up
SD Card
Flashes Green
Unit is writing to the SD card
SYNC
Permanently Off
Power Down Mode / Charge only Mode
500ms on / 500ms off
Limited network service: No SIM card inserted or no PIN
entered, or network search in progress or ongoing user
authentication or network login in progress
10ms on / 3990ms off
Idle Mode: The mobile is registered to the GSM
network(monitoring control channels and user
interactions) No call is in progress and no data transfer
10ms on / 1990ms off
Packet switched data transfer is in progress
UMTS data transfer is in progress
Permanently on
Connected to remote party or exchange of parameters
while setting up or disconnecting a call

9 | P a g e
4. Appendix A - Technical Specifications
General Information
Communication
GPRS and 3GPP based messaging
Internal GSM (With external antennae)
Over-the-air firmware downloads
Automatic, over-the-air unit configuration on power-up
32GB of storage for tacho data and for data logging during coverage loss
Events
Triggered by FM Events (Information or Detailed)
Exception-based rules
Power
Power harness with 1 x 3A fuse
Low power modes
Voltage and temperature monitoring
Optional
2 Cameras
Communication
GSM/GPRS/EDGE quad-band
UMTS/HSPA+ Five band
850/900/1800/1900 MHz
800/850/900/1900/2100 MHz
Output power
Class 4 : 2W
Class 1 : 1W
Class E2 : 0.5W
Class 3 : 0.25W
Data Support
GPRS packet data, 3GPP Release 4,6,7
Comprehensive I/O
Camera Inputs
4 x PAL/NTSC Video Inputs with status LED's.
Serial Interfaces
1 x RS232 Serial Port
Status LEDs
Camera Status, Power and GSM status
Audio
Mic Inputs
1x Mic input with option to provide limited power
External Microphone
Model - MC308-S3.5
Omnidirectional - built in pre-amplifier
Power backup

10 | P a g e
Super cap backup to facilitate safe shutdown and ensure no video loss in a power loss event.
Electrical Specification
Operating Voltage
11-32 VDC
Power Consumption (Typical)
Ignition Off: 23mW@12V 140mW@24V
Ignition On : 3W (idle)
Physical Specifications
Dimensions
145x107x28 (w x l x h)
Weight
185g
Environmental Specifications
Operating temperature
0° to +65° C
Storage temperature
-40° to +80° C
Humidity
95% R.H. @ 70° C non-condensing
Connectors, SIM Access
Cellular Antenna
External 2m cable
Power Interface
4 Way Molex MiniFit Connector
Host Interface
6 Way Molex MicroFit Connector
Cameras
4 Way Molex MicroFit Connector
Audio
4 Way Molex MicroFit Connector
SIM Access
Internal, from front panel
Mounting
Internal Cameras: Adhesive Mounting Bracket
External Cameras: Straight and L-Brackets
Main Unit: Screws, Tie wrap
Camera Specifications (standard, road and in-cab)
Imaging Device
1/3" SONY Color CCD
Horizontal Resolution
420 TV Lines
Minimum Illumination
0.5(day)/0.01(night) Lux
Operation Temperature
-10℃~ + 50℃, RH 95% Max
Storage Temperature
- 20℃~ + 60℃, RH 95% Max

11 | P a g e
Operating Voltage
9 VDC
Power Consumption - Road facing
800 mW
Power Consumption - Cab facing
(IR)
1060 mW
IP Rating
IP54
Camera Specifications (optional, external)
Imaging Device
1/3” Color CMOS
Horizontal Resolution
480TVL
Minimum Illumination
0.01 lux
Operation Temperature
-15℃~ + 70℃
Storage Temperature
-20℃~ + 70℃
Operating Voltage
9.5 VDC (Power sourced from main unit)
Power Consumption
1440 mW
IP Rating
IP67
Video Standards
Video Compression
H.264
Resolution
Up to 352x288
Frame rate
4 fps as default - Up to 10fps per channel

12 | P a g e
5. Appendix B - Certification and Conformity
Manufacturer:
Cathexis Technologies (Pty) Ltd
259 Montpelier Road
Morningside
4001
Cathexis is the manufacturer and OEM supplier of the Mix Telematics branded product called MiX Vision
Product Name
Model Number
Version
Part Number
Mix Vision
MVR1204 H 3G IR Kit
V3
440FT0793
Application of Council Directives
1999/5/EC, R&TTE Directive
2004/108/EC, Electromagnetic Compatibility
2002/95/EC, Restriction of Hazardous Substances
Region
Type
Directive/Legislation
Identifier
Test Standards Applied to Verify
Product
European
Union
CE
R&TTE Directive 1999/5/EC:
Directive of the European Parliament and of
the council of 9 March 1999 on radio
equipment and telecommunications
terminal equipment and the mutual
recognition of their conformity
RoHS (2002/95/EC):
Directive of the European Parliament and of
the Council of 27 January 2003 on the
restriction of the use of certain hazardous
substances in electrical and electronic
equipment
IEC 60950-1:2005 + A1: 2012/ SANS
60950-1:2010 IT Equipment Safety
EN301 489-1:V1.9.2:2011-09 EMC for
Radio Equipment and Services
EN301 489-7:V1.3.1:2005-11 Specific
conditions for mobile and portable radio
and ancillary equipment of digital cellular
radio telecommunications systems (GSM
and DCS)
EN301 511 V9.0.2:2003 and 3GPP TS
51.010-1 V12.2.0: 2014 GSM Radiated
Spurious Emissions
USA
FCC
FCC CFR 47 Part 15B: 2014 on Conducted and
Radiated Emissions
RF Exposure Levels as described in the
ICNIRP and FCC CFR 47 § 1.1310 Guidelines
at 20 cm, point of investigation
It contains
GSM Module
“PHS8-P”
with: FCC
Identifier
QIPPHS8-P
PTCRB
NAPRD.03 V5.8 Overview of PCS Type
certification review board Mobile Equipment
Type
Certification and IMEI control
PCS Type Certification Review board (PTCRB)
PTCRB listed
ETSI EN 301 908-1 V6.2.1: 2011
NAPRD.03 V5.16:2013-06
3GPP TS 34.124 V9.2.0:2010
PTCRB PPMD V2.10:2012-06
GCF CC V3.51.1:2013-07
