MMF POS 2261998USBA1-XX Guide

USB Interface /USB-HUB Combo Interface Instruction manual / User Guide
Approved Date of Revision 5/1/2010 Doc. Instruction Manual
P/N: 531911900
USBInterface/USB-HUBComboInterface
If you have purchased a USB-HUB Combo, proceed by always connecting the standard USB interface which serves as
the cash drawer’s connectivity first. For both types of interfaces, please follow these steps:
GETTINGSTARTED:
Select Cash Drawer Number
The MMO POS USB Interface Board is factory defaulted to recognize the first cash drawer to be
installed as drawer number zero (0), see Figure 1.0 Dip-Switch Position (Default Setting). If user
decides to assign another drawer number, please follow the pin configuration illustrated in SWITCH
SETTINGS Table 1.0 or label attached to the interface for correct pin orientation. MMF recommends
selecting cash drawer number one (1) as your option.
Connect the Power Supply (12VDC / .8 Amp)
Plug the small plug tip to the interface power port in the back of the cash drawer interface as illustrated in
Figure 1. Plug the power adapter end into a 120 Volt AC Recepticle.
Always connect the power supply before the USB Cable. LED#2 (GREEN) and LED#5 (RED) should be ON
at this time, refer to Table 2.0 for reference.
Connect USB Cable
Plug the T ype B connector e nd to the U SB Po rt o f the i nterface a s i llustrated i n F igure 1 a nd the T ype A
Connector to the USB port of the Host Computer. ALL the LED except LED#4 (GREEN) should be ON at this
time. Refer to Table 2.0 for LED State.
Test Functionality of Interface
Follow the steps detailed below for ‘USB Test Utility Installation’.
Install OPOS Drivers
Follow the steps detailed below for ‘MMF OPOS Drivers Installation’.
NOTE: Do not assign two (2) USB interface cash drawers within the same system with the same cash drawer number.
FIGURE1.0
TABLE1.0
SWITCH
SETTINGS
DRAWER
0
1
2
3
4
5
6
7
DIP-SWITCH
SW1
ON OFF ON OFF ON OFF ON
OFF
SW2
ON ON OFF OFF ON ON OFF
OFF
SW3
ON ON ON ON OFF OFF OFF
OFF
SW4
RESERVED
Note: OFF is when pins are facing down (↓). ON is when pins are facing up (↑).
LEDS
DIP-SWITCHPOSITION
DefaultSetting: Drawer0
PowerPort
Connect12VDC
PowerSupply
Here
USBPort
Portof CashDrawer
Interface
ConnectTypeB
ConnectorofUSB
cableHere
1
2
3
4
5
This light should not be ON at
any time
USB Interface
P/N#2261998USBA1-XX:
USB Interface KIT (Includes Power
Supplies & USB Host Cables)
P/N# 641-2575-00:
Cash Drawer Power Supply (12V dc)
P/N# 641-25BX-00:
USB Host Cable
USB-HUB Combo Interface
(A combination of our standard USB
Interface and a 4-Port HUB)
P/N# 2261998USBA1-XX:
USB-HUB Interface KIT (Includes Power
Supplies & USB Host Cables)
P/N# 641-2575-00:
Cash Drawer Power Supply (12V dc)
P/N# 641-25CE-00:
USB Hub Power Supply (5V dc)
P/N# 641-25BX-00:
USB Host Cable

USB Interface /USB-HUB Combo Interface Instruction manual / User Guide
Approved Date of Revision 5/1/2010 Doc. Instruction Manual
P/N: 531911900
TABLE2.0
LED
NAME
COLOR
STATE
ON
OFF
Solid
Intermittent
LED-1
Red
USB Cable Connected
No USB Cable
LED-2
Green
Cash Drawer Closed
USB
Communication
Transmit
Cash Drawer Open
LED-3
Yellow
Solenoid in position and
ready to kick drawer open
Solenoid kicked
drawer open
LED-4
Green
Port Powered-
Not Recommended
1st:Plug USB Cable
2nd:Plug Power Adapter
Adapter Powered
1st:Plug P
ower Adapter
2nd:Plug USB Cable
LED-5
Red
Power Supply Connected
No Power Supply
FIGURE1.1
A CD with the utility drivers and test utility (See Figure 1.1) is included
with the cash drawer. The drivers and test could also be found by logging
on to:
USBTESTUTILITYINSTALLATION
http://www.mmfpos.com/drivers
Download the MMF USB Driver and Test Utility file from the
website by opening the zipped file or insert CD.
» Open folder named “MMF USB_Setup”
» Click on the “Setup.exe” Icon
» Click on “Run”
» Follow through the automatic setup
» After download is completed, go to “Start” Menu
» Go to “All Programs”
» Select the “MMF Cash Drawer Company USB CRDemo”
program
Click Status, a result letter character (O/C/N) should appear in the result box under the cash drawer number
given to the unit by setting the dip switch (Step 1-Getting Started)
Make sure cash drawer is closed and the letter ‘C’ appears in the result box.
Click ‘Kick’ to open the cash drawer, the letter ‘O’ should now appear in the result box.
Repeat if necessary.
LEGEND
Action Result under Assigned Drawer #
Present N
Closed C
Opened O
NOTE 1
Port Powered:
Draws power
from the
computer,
which will not
provide
enough power
to operate cash
drawer’s latch
mechanism.
NOTE 2:
Adapter
Powered:
Draws power
from the
provided
power supply
adapter.
See
Note 1

USB Interface /USB-HUB Combo Interface Instruction manual / User Guide
Approved Date of Revision 5/1/2010 Doc. Instruction Manual
P/N: 531911900
MMFOPOSDRIVERV1.9INSTALLATION
Install MMF OPOS Driver V1.11, available under: http://www.mmfpos.com/drivers
STEP1
 The user installing the MMO POS software and configuring the cash drawer devices on Windows 2000 and Windows XP is
required to have Administrator Rights. Once the software is installed, all users with normal rights can use it.
If using CD, open the file named MMF OPOS 1.11
STEP2
To install the driver run the file: Setup.exe.
The program will ask you to unzip, click Unzip.
» After download is completed, go to “Start” Menu
» Go to “All Programs”
» Select the “MMF Cash Drawer” program
» Select the “Configure and Test” program
STEP3
Open the “Configure and Test”
FIGURE1.2
program and click on “Configure Device”.
(See Figure 1.2)
To configure drawer - click on “Add new
drawer”. A window will appear asking
you to enter a name for your cash
drawer, name it Cash_Drawer#1 (See
NOTE). Select the option of “USB
Interface with Statistics” as the Cash
Drawer Interface (See Figure 1.3) and
click “OK” to save settings.
STEP4
NOTE: The name Cash_Drawer#1 is
case and character sensitive. Please
type it exactly as shown
FIGURE1.3
NOTE: NOTE: The name
Cash_Drawer#1 is case and
character sensitive.

USB Interface /USB-HUB Combo Interface Instruction manual / User Guide
Approved Date of Revision 5/1/2010 Doc. Instruction Manual
P/N: 531911900
0
STEP5
To test drawer - Click on
FIGURE1.4
“Initialize OPOS Drawer 1”
then, click on “Open OPOS
Drawer 1” (See Figure 1.4
the following message will be
displayed:
Click “OK” to the above message and then
STEP6
manually close the cash drawer.
When the drawer is completely closed the
following message will be displayed:
Click on “Un-initialize OPOS Drawer 1” and the test is complete. Repeat only if necessary.
STEP7
Make sure the power supply adapter was connected before the USB cable and that LED#4 (GREEN)
is OFF.
TROBLESHOOTINGTIPS
Check Dipswitch Setting correlate to the name of the cash drawer. If you decide to change dipswitch
settings, disconnect the power cable and USB cable from the interface, change dipswitch pins and
reconnect all the cables per the steps detailed in the ‘Getting Started’ Section on page one of this
manual.
If installing the OPOS drivers, when adding a new drawer, make sure you selected “USB Interface
with Statistics” as the Interface type.
If installing the OPOS drivers, make sure that under
‘USB Properties’ the number in the dropdown is the
same as the number selected for the drawer on the
dipswitch.
Switch to another USB port in the computer, if necessary.

USB Interface /USB-HUB Combo Interface Instruction manual / User Guide
Approved Date of Revision 5/1/2010 Doc. Instruction Manual
P/N: 531911900
USB4–PORTHUBSET-UP
Determine if the 5V power supply will be necessary (Self or Bus
Powered) according to the type of peripherals that will connect to
it.
STEP1
Self Powered Peripherals: Devices which have their own power
supply adapter, and just need the USB connectivity as a
communication medium. Such devices will not need the hub to
be powered by the 5V power supply provided.
Bus Powered Peripherals: Devices which do not have their own power supply adapter and will need 5V or less to
operate. Such devices will need the hub to be powered by the 5V power supply provided.
If not sure, connect the power supply anyway. Plug the small plug tip to the hub power port in the back of the cash
drawer interface as illustrated in Figure 1.5. Plug the power adapter end into a 120 Volt AC Recepticle.
Connect the host cable to the host computer as illustrated in Figure 1.5.
STEP2
Connect the peripherals to any of the 4 ports available.
STEP3
NO Drivers or Software necessary for the USB 4-Port Hub
4-
PORT USB HUB FEATURES:
Compliant with USB Specification 2.0 / 1.1
Supports Data Rate: 1.5/12/480 Mbps
4 Downstream Ports
Support split transaction to handle full speed and low speed transaction at downstream
facing ports when Hub controller is working at high-speed mode.
One Transaction Translator per hub and supports four (4) concurrent non-periodic
transactions.
Self or Bus-Powered
Self Power Mode (With Power Supply)
-Connects up to four (4) devices (Any USB Peripheral Device)
-500mA per each USB downstream port – Type A Connectors
Bus Powered Mode (No Power Supply)
-Connects up to four (4) self-powered or low- powered devices
-100mA per each USB downstream port – Type A Connectors
-Only self powered hubs may be connected to hub
Supports Over-Current detection and individual power control
Supports “non-removable” attribution on individual port
System Requirements:
Windows 98/SE/2000/ME/XP/Vista
MAC OS 8.6.1 or above (USB1.1)
Host Cable-
Connect to
Computer
5V Power Jack for
4-Port USB HUB
Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, MMF Cash Drawer, declare that the product:
USB Interface to which this declaration relates:
Complies with Part 15 of the FCC Rules
This Class ‘A’ Digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe ‘A’ est conforme à la norme
NMB-003 du Canada.
CE Declaration
Complies with the EMC Directive 89/336/EEC Standard EN55022 (2006), EN55024(1998), EN61000-3-2(1995), EN61000-3-3(2006)
