Mobatime BU 192t User manual

© MOBATIME BE-800163.10
MOUNTING AND
INSTRUCTION MANUAL
Movements Models 192 / 192t
FU 192(t) ●BU 192(t) ●QU 192(t)

© MOBATIME 2 / 20 800163.10
Certification of the producer
Standards:
All movements of Series 192 have been developed and produced in
accordance with the EU-Standards 89 / 336 / EWG.
Applied Standards: EN 50081-1 EN 50082-2
References to the Instruction Manual
1. The information in this Instruction Manual can be changed at any time without previous
notice.
2. We do not answer for direct or indirect damages, which could occur when using this Manual.
3. Please read the instructions carefully and start the setting-up of the Series 192 only once you
have correctly understood all information for the installation and operation.
4. The installation must be carried out by skilled staff only.

© MOBATIME 3 / 20 800163.10
Content
1. INTRODUCTION, OVERVIEW............................................................................................................... 4
2. DIMENSIONS ......................................................................................................................................... 4
3. FIXING OF MOVEMENT ........................................................................................................................ 4
4. MOUNTING AND STARTING-UP.......................................................................................................... 5
4.1 STARTING-UP OF A COMPLETELY ASSEMBLED CLOCK WITH FU 192.......................................................... 5
4.2 MOUNTING OF HANDS AND STARTING-UP ................................................................................................ 5
4.2.1 Mounting of hands ....................................................................................................................... 5
4.2.2 Starting-up and check of the hand position ................................................................................. 5
4.2.3 Mounting of Power Supply........................................................................................................... 5
4.3 FUNCTION OF THE OPERATING KEY (FIG.5)............................................................................................. 6
4.3.1 FU / BU 192 (t) in normal operation............................................................................................. 6
4.4 REMOTE CONTROL BY MEANS OF EXTERNAL KEY (FIG.6)......................................................................... 6
5. SYNCHRONIZATION............................................................................................................................. 7
5.1 SYNCHRONIZATION BY ANTENNA AD 192 (DCF-77KHZ)......................................................................... 7
5.2 SYNCHRONIZATION BY ANTENNA AM 192 (WEST EUROPEAN TIME)......................................................... 7
5.3 SYNCHRONIZATION WITH AD 192 (DCF) IN THE TIME ZONES MEZ+1 OR MEZ-1...................................... 7
5.4 SYNCHRONIZATION BY MEANS OF INTERNAL OR EXTERNAL KEY ................................................................ 8
5.5 SYNCHRONIZATION OF THE BU 192 BY MEANS OF SERIAL TELEGRAMS OVER IF 494.................................. 8
5.5.1 Synchronization by local time ...................................................................................................... 8
5.5.2 Synchronization by UTC time ...................................................................................................... 8
5.6 CONCEPT FOR SENDING AND RECEIVING SERIAL TELEGRAMS ................................................................... 9
6. CASCADE ............................................................................................................................................ 10
6.1 STARTING-UP OF CASCADED MOVEMENTS............................................................................................. 10
6.2 MASTER MOVEMENT TIME SETTING WITH SERIAL TELEGRAMS................................................................. 10
7. SERIAL TELEGRAMS ......................................................................................................................... 11
7.1 STANDARD TIME TELEGRAM (IF 482) WITH LOCAL TIME ........................................................................ 11
7.2 TIME TELEGRAM WITH UTC TIME.......................................................................................................... 11
7.3 TIME TELEGRAM TRANSMITTED WITH LOCAL TIME (THROUGH OUT PLUG)................................................ 11
7.4 TELEGRAM WITH OFFSET TO UTC AND SEASON DATA (SU -WI)............................................................ 12
8. QUARTZ MOVEMENT QU 192............................................................................................................ 13
8.1 GENERAL FUNCTION DESCRIPTION QU 192.......................................................................................... 13
8.2 MANUAL STARTING-UP AND TIME SET................................................................................................... 13
8.3 STARTING-UP AND SYNCHRONIZATION WITH SERIAL TELEGRAMS............................................................ 13
8.4 STARTING-UP AND SYNCHRONIZATION BY PC ....................................................................................... 14
8.5 STARTING-UP AND SYNCHRONIZATION BY PALM.................................................................................... 15
9. DETAILED FUNCTION DESCRIPTION .............................................................................................. 16
9.1 CURRENT SAVING MODE OF THE MOVEMENT,CURRENT CONSUMPTION................................................... 16
9.2 CONCEPT FOR THE RADIO SIGNAL RECEPTION....................................................................................... 16
9.3 CHANGE OF TIME SOURCE.................................................................................................................... 17
10. PROBLEM REMOVAL......................................................................................................................... 17
11. CONNECTIONS ................................................................................................................................... 18
12. TECHNICAL DATA .............................................................................................................................. 19

© MOBATIME 4 / 20 800163.10
1. Introduction, Overview
Movements BU 192(t) FU 192(t) QU 192(t)
Type of movement Basic movement Radio movement Quartz movement
Components BU 192 BU 192 & Radio Antenna QU 192 (& IF 494)
Synchronization Button / serial DCF 77 Radio Antenna Quartz / button / serial
t Long shaft See Fig. 2 : 192t for illuminated clocks
Movements for self-setting indoor and outdoor clocks for dials up to 80 cm of diameter. Without
illumination series 192, with illumination series 192 t. Up to 3 slave movements can be connected
in cascade, Fig. 8, page 8.
2. Dimensions
192 192t
A 18.9 34.0
B 11.9 27.0
C 8.4 23.5
D --- 8.0
9
19
108
143
129.6
M12x1
86.6
35.7
35.7
A
B
C
6h8
4h8
D
Fig. 1
3. Fixing of Movement
The dial must be sufficiently stable. The
fixing hole must have a diameter of 12,3
mm. The movement must be fixed in
vertical position.
See Fig. 2 for the position of mounting
parts. The disc nut (7*) M12 x 1 has to be
tightened with a special wrench tool (Art.
No. 36761) and a torque wrench with a
torque of 4.5 Nm +/- 0.2 Nm..
Attention:
Using the movement 192t the ring nut (5),
and the compensation ring (6) must not be
removed..
192t
6
192
Fig. 2
Movement with short shaft (192): the rubber washer (3)
must not be located on movement case side.
The case can be bended and therefore block the
movement. Always use synthetic ring first (2).
1Movement 5Ring nut
2Synthetic ring 6Distance ring
3Rubber washer 7Disc nut
4Dial

© MOBATIME 5 / 20 800163.10
4. Mounting and Starting-up
4.1 Starting-up of a completely assembled clock with FU 192
Install the power supply as per Chapter 4.2.3.
At the foreseen clock place align the antenna and check the reception, see chapter 5.1 page 7.
4.2 Mounting of hands and Starting-up
4.2.1 Mounting of hands
The shafts of the hour and minute hands are positioned ex-work on the reference position (12
o’clock). The hands shall be carefully fixed and tightened on the shafts. Enough space must be
foreseen between the hands.
The position 12 o’clock must be checked on each movement after the mounting (chapter
4.2.2).
4.2.2 Starting-up and check of the hand position
Pull out the IN plug (the 12 o’clock position must be separately checked in case of cascade
connected movements).
Install the power supply as per chapter 4.2.3 The clock runs to 12 o’clock position
Position of hands OK?
If the hand position is wrong, carefully loosen the hands, adjust and tighten.
Check the 12 o’clock position again (initialising by a short interruption of the power supply).
Insert the IN plug (data connection)
Check the reception, see chapter 5 page 7.
Attention:
After a correct adjustment the hands must not be turned manually any more!
If the clock in the meantime has been once synchronized, the movement will behave as per
4.3.1.
4.2.3 Mounting of Power Supply
To open the battery box lift the cover with a screwdriver,
which is placed in the foreseen space, and press lightly
downwards (Fig. 3). Possible power supplies for this series of
movements:
Var.1: 1 Lithium battery 3.6V 27Ah 250394
Var.2: External power supply 230 VAC 201670
Var.3: 2 Monocells LR20 1.5V 33mm x 60mm
Fig. 3
Attention:
Please pay attention to the polarity of the power supply!
As soon as the movement is under power, the hands will start
moving.
Advice:
The electric contact can be improved through a slight
tightening of the synthetic screw.
The lithium battery and the mains part shall be connected by
using the corresponding connection wires.
LIT: B598 3000 0000
Var. 1
2x LR20 1.5V Batterie
Var. 3
Fig. 4

© MOBATIME 6 / 20 800163.10
4.3 Function of the operating key (Fig. 5)
4.3.1 FU / BU 192 (t) in normal operation
The clock has been synchronized once at least !
Key touch < 5s Switch on radio signal reception
Key touch > 5s Positioning onto reference position 12 o’clock
When the hands have been set on 12 o’clock with a key touch > 5s,
they remain in this position during 10 minutes and will then start running
autonomously to the correct time.
With a brief key touch the hands will run to correct time immediately.
If the clock has to be disassembled or the hands adjusted anew, it is
recommended to remove the power supply, after that the hands have
stopped at 12 o’clock.
This will prevent, that the hands suddenly will start running after 10
minutes.
If the movement never has been synchronized, it will behave as per
chapter 5.4, page 8.
LED
Fig. 5
4.4 Remote control by means of external key (Fig. 6)
The functions with external key are identical
with those of the internal operation key
(chapter 4.3.1 und 5.4 page 6).
The external key will be connected on the
plug position OUT. For the connection of the
plug see chapter 11, page 18.
An external key including 5 m cable is
available (KEY 192).
External Key
KEY 192:
5m Cabel
Fig. 6

© MOBATIME 7 / 20 800163.10
5. Synchronization
5.1 Synchronization by Antenna AD 192 (DCF-77kHz)
Check radio signal reception Orientation of the antenna:
The antenna should be oriented towards the site of the emitter
(Mainflingen near Frankfurt a.M. / Germany).
Check the reception quality by the side-positioned LED
(Fig. 5, page 6).
The LED should flash regularly in second pulses.
Activate reception by a brief key touch (Fig. 5, page 6).
At bad reception push the antenna backwards from the fixing
device and turn it round its own axle (Fig. 7). This will change
the orientation of about 40°.
Should the reception quality, in spite of the turning round the
own axle, not has improved much, the antenna can be optimally
placed and oriented by means of an extension cable CAB 192.
A weatherproof (IP54) antenna (AD 192.5) for outdoor use is
available for especially difficult cases.
OUT IN
Fig. 7
The radio signal reception is on as long as two valid telegrams are picked up. At good reception
conditions the movement should move to actual time after about 2 - 3 minutes.
For further information concerning the radio signal reception, see chapter 9.2 page 16.
The movement can also be set manually to correct time (chapter 5.4 page 8).
5.2 Synchronization by Antenna AM 192 (West European Time)
The movement can also be controlled by an antenna from MSF-Rugby 60kHz.
The emitting station is in Rugby, England. The same rules of reception as for DCF-antenna are
valid (chapter 5.1).
Important:
Before installation the movement must be coded for MSF operation.
A solder bridge underneath the OUT plug (Fig. 8, page 8) must be added.
In the MSF operation mode the solder bridges M+1 and M-1 have no influence.
5.3 Synchronization with AD 192 (DCF) in the time zones MEZ+1 or MEZ-1
The movement with the DCF-77 antenna (FU 192) can also be used in the time zones WEZ (West
European Zone) or EEZ (East European Zone), if the radio signals can be received in these zones
and if the daylight saving time (DST) change-over is the same as for MEZ.
Before starting-up the movement should be coded for the corresponding operation mode by means
of a soldering bridge (M+1: MEZ+1, M-1: MEZ-1) (Fig. 8 page 8).
Important:
Only one soldering bridge must be added, otherwise the correct function cannot be guaranteed.

© MOBATIME 8 / 20 800163.10
5.4 Synchronization by means of internal or external key
Valid for FU-, BU- and QU 192, as well as for movements in cascade connection:
Operation device: Internal key (Fig. 5, page 6), or external key (Fig. 6, page 6)
Condition: Movement(s) have not yet been synchronized through a external source.
This condition is also performed after an interruption of the power supply.
If the movement was synchronized before (FU-, BU 192) and the power supply
not interrupted, the reaction will be as per 4.3.1.
Key touch < 2s Forward motion of 1 minute or stop of forward motion
Key touch > 2s Forward motion of 1 hour LED is blinking slowly
Key touch > 5s Forward motion of 11 hours LED is blinking quickly
Each key touch sets the time on the beginning of a minute. So the time can be set within an
accuracy of ±1sec.
In case of movements in cascade connection all movements react at the same time with the key
touch of one of the movements. The external key can thus be plugged in the last movement.
5.5 Synchronization of the BU 192 by means of serial telegrams over IF 494
Instead of using an antenna, time can be read-in from a serial telegram. By means of an interface
IF 494 a serial telegram can be transmitted to the movements BU 192 or QU 192. The interface
connection (IN plug) is identical with the antenna connection (Fig. 7).
IF 494, connection possibilities, see page 18.
The synchronization time is about 3 sec. with telegrams sent every second. See chapter 8.3, page
13. Definition of the serial telegrams, see chapter 7, page 11.
5.5.1 Synchronization by local time
The movements BU 192 and QU 192 can be
synchronized by local time (Chapter 7.1,
page 11).
The external device must always transmit the
local time in serial telegrams, as the
movements BU / QU do not automatically
switch onto daylight saving time.
That means, that in this operation mode the
movements will always show the time
transmitted in the telegram.
IF 494
M+1
M-1 MSF
OPT
Fig. 8
5.5.2 Synchronization by UTC time
The movement QU 192 can also be synchronized by UTC time (chapter 7.2, page 11).
In this operation mode the movement will autonomously calculate the local time as per predefined
season data for MEZ (Middle European Zone). Should the QU 192 be used in another time zone,
the offset to UTC-time and season data must be programmed by means of a special serial
telegram (chapter 7.4, page 12).

© MOBATIME 9 / 20 800163.10
5.6 Concept for sending and receiving serial telegrams
After the starting-up the BU 192 waits in "Run" mode until the serial telegram arrives. When the
movement has received two telegrams with the correct time, it runs to the actual time. At each
minute change a telegram will be sent and received. In the second 3 the movement switches again
to current saving mode.
The memorized time information deviates in the seconds range or falls out:
If suddenly no telegram occurs between seconds 0 and 3, the movement remains in "Run" mode.
After 4 minutes the information from the time source will be deleted, the movement switches onto
current saving mode and continues to run un-synchronized on its own time base (quartz precision
BU192 50ppm).
When the serial telegram re-appears, the movement will be "waked up", takes over the time from
the telegram and runs normally again. Should no telegram occur any more, the movement will
activate the radio reception once every hour. If in the meantime an antenna was connected, the
time will be taken over from DCF.
After 7 days without time reception, the clock runs to 12 o’clock and stops running.
Duration of the time take-over:
The telegram will be transmitted every second:max. 3 sec.
The telegram will be transmitted every minute (e.g. save movement in cascade): max. 3 min.

© MOBATIME 10 / 20 800163.10
6. Cascade
Cascading means that a number of movements will be
connected in series.
Up to three slave movements BU192 can be connected to
one master movement (Fig. 9).
As master movement the following types can be used:
FU 192
QU 192
BU 192 with serial synchronization (over IF494)
The cascading is done by means of a cascade cable COM
192 (length 1m), enabling to synchronize 4 movements with
only one reference signal. After the starting-up the time
synchronization for all movements will follow in a few seconds
only. Should the time for the master movement change during
the normal operation, the time take-over for each connected
movement will take about 2 minutes, which means totally
about 8 minutes. This is also valid for the daylight saving time
change.
OUT INOUT IN
OUT IN
OUT IN
OUT IN
Fig. 9
6.1 Starting-up of cascaded movements
As master movement should be used a FU 192 with radio signal reception, a BU 192 or a QU 192
with serial synchronization:
Connecting of the power supply movements run to the reference position (12 o’clock).
Wait until the master movement has taken over the time.
The master movement has taken over the time:
Starts to run on correct time.
Starts to transmit serial telegrams over the OUT plug (chapter 7.3 page 11)
Some seconds later the slave movements start running to the time of the master movement.
As master movement should be used QU 192 with manual time setting:
Separate the first slave movement (IN plug) from the OUT plug of the QU 192.
Connect the power supply movements run to the reference position (12 o’clock).
Set the QU 192 to correct time by means of the internal or external key (chapter 5.4 page 8)
Connect first slave movement with QU 192 OUT plug.
After 3 minutes at the latest the slave movements start running to the time of the master
movement.
Remark:
In the cascaded movements all the internal keys are connected in parallel.
On the OUT plug of the last movement an additional external key can be connected.
Each key touch influences all the movements.
6.2 Master movement Time setting with serial telegrams
A BU 192 or a QU 192 requires at least 2 serial telegrams with valid time. That means, when the
same telegram will be transmitted several times, the movement will never take over the time. As
the time always continues to run, also he seconds and minutes must be incremented in the
telegram.
The date must be a valid value. It can, however, remain constant. (e.g. 01.01.01).
Attention:
After the time setting the QU 192 accepts no new time for about 3 minutes !

© MOBATIME 11 / 20 800163.10
7. Serial Telegrams
7.1 Standard Time Telegram (IF 482) with Local Time
Definition: Time telegram (ASCII), terminating at the designed second in the telegram:
9600 bit/s, 7 data bits, even parity, 1 stop bit. Jitter < 50 ms.
Format:
Byte Nr. Designation Sign HEX Code
1 Stat sign O 4F
2 Supervision 1) A or M 41 or 4D
3 Time-Season 3) W, S or L 57, 53 or 4C
4 Year tens 0 .. 9 30 .. 39
5 Year units 0 .. 9 30 .. 39
6 Month tens 0 or 1 31 or 31
7 Month units 0 .. 9 30 .. 39
8 Day tens 0 .. 3 30 .. 33
9 Day units 0 .. 9 30 .. 39
10 Monday .. Sunday 2) 1 .. 7 31 .. 37
11 Hours tens 0 .. 2 30 .. 32
12 Hours units 0 .. 9 30 .. 39
13 Minutes tens 0 .. 5 30 .. 35
14 Minutes units 0 .. 9 30 .. 39
15 Seconds tens 0 .. 5 30 .. 35
16 Seconds units 0 .. 9 30 .. 39
17 Telegram end CR 0D
1) 'A': Correct time code reception from the transmitter. 'M': No time signal has been received
during more than 12 hours (Time will be taken over at 'A' and 'M').
2) Weekday not evaluated by BU / QU 192.
3) Winter, Summer or Local time: Will be checked but not evaluated.
7.2 Time telegram with UTC Time
Definition: Time telegram (ASCII), terminating at the designed second in the telegram:
9600 bit/s, 7 data bits, even parity, 1 stop bit. Jitter < 50 ms.
Format:
Byte Nr. Designation Sign HEX Code
1 Start sign O 4F
2 Supervision 1) A or M 41 or 4D
3 UTC-time U 55
Bytes 4 – 17 same as standard telegram (IF482) (chapter 7.1).
7.3 Time telegram transmitted with local time (through OUT plug)
Definition: Time telegram (ASCII), terminating at the designed second in the telegram:
9600 bit/s, 7 data bits, even parity, 1 stop bit.
Format:
Byte Nr. Designation Sign HEX Code
1 Start sign O 4F
2 Supervision 1) A 41
3 Local time (displayed by the clock) L 4C
10 not used F 46
Bytes 4 – 9 and 11 – 17 same as standard telegram (IF482) (chapter 7.1).

© MOBATIME 12 / 20 800163.10
7.4 Telegram with Offset to UTC and Season Data (Su - Wi)
Definition: The telegram must be transmitted at least twice:
9600 bit/s, 7 data bits, even parity, 1 stop bit.
Format:
Byte Nr. Designation Sign HEX Code
1 Start sign O 4F
2 Identification season telegram S 53
3 1) Type of season – entry tens 0 30
4 Type of season – entry units 2 or 5 32 or 35
5 – 14 2) Daylight saving Time start date / time 0 .. 9, A .. F 30 .. 39, 41 .. 46
Daylight saving Time Offset, value ±120 min:
15 High Nibble 0 .. 9, A .. F 30 .. 39, 41 .. 46
16 Low Nibble 0 .. 9, A .. F 30 .. 39, 41 .. 46
17 – 26 2) Daylight saving Time end date / time 0 .. 9, A .. F 30 .. 39, 41 .. 46
Local Offset,value ±780 min:
27 High Byte, High Nibble 0 .. 9, A .. F 30 .. 39, 41 .. 46
28 High Byte, Low Nibble 0 .. 9, A .. F 30 .. 39, 41 .. 46
29 Low Byte, High Nibble 0 .. 9, A .. F 30 .. 39, 41 .. 46
30 Low Byte, Low Nibble 0 .. 9, A .. F 30 .. 39, 41 .. 46
31 End of telegram CR 0D
1) Following types of season entries are available (see below):
2: Season switch at determined day every year.
5: No season switch, just offset to UTC
2) Definition of summer time start and end date / time:
Legend:
WDM: 1 .. 4 = first .. fourth WD (weekday) of month (e.g. first Saturday in April)
1...31 = first ...thirty-first day of the month (e.g. 21. April)
-1 (FF) / -2 (FE) = last / last but one WD of month (e.g. last Sunday in March)
WD: Weekday: Monday = 1 … Sunday = 7 or Day = 0
Example for MEZ:
1 2 3/4 5/6 7/8 9/10 11..14 15/16 17/18 19/20 21/22 23..26 27..30 31
O S 02 03 FF 07 0078 3C 0A FF 07 00B4 003C 0D
3/4: Type 2 15/16: Season offset 60 min.
5/6: Month 03 -> March 17/18: Month 10 -> October
7/8: Hex FF = -1 -> last weekday of month 19/20: see 7/8
9/10: Weekday 7 -> Sunday 21/22: see 9/10
11..14:Hex 0078 = 120 -> 120 min. of day -> 02.00 23..26: Hex 00B4 = 180 min. -> 03.00
27..31:Offset to UTC 60 min.
5not used no sumtime not used i.e. 60 (MEZ)
Type(1B) SumTime begin Time/Date (5B) SumOffset (min) (1B) SumTime end Time/Date (5B) LocalOffset to UTC (min)(2B)
2i.e. 60 (MEZ) i.e. 60 (MEZ)month WDM WD min of day month WDM WD min of day
14B

© MOBATIME 13 / 20 800163.10
8. Quartz movement QU 192
8.1 General Function Description QU 192
The QU 192 reacts in certain situation different from the BU 192 and FU 192. For this reason a
special chapter in this manual has been dedicated to the QU 192.
The QU 192 is equipped with a temperature compensated quartz with high running accuracy:
Temperature range 0 – 40°: ± 2 ppm or ± 60 sec. per year.
Temperature range -30 – +70°: ± 7.5 ppm or ± 4 min. per year.
The movement can be set to correct time either manually (chapter 8.2) by means of a key (Chapter
5.4, page 8), or with serial telegrams from a PC or Palm using IF494. (Chapter 8.3 – 8.5).
8.2 Manual Starting-up and Time Set
The following procedure for the manual time setting is recommended:
Insert power supply Clock runs to 12 o’clock position.
Keep pressed key > 5s Clock starts advancing 11 hours LED blinks quickly.
About 10 minute steps before the actual time, stop the procedure by means of brief key touch.
Through brief key touch set clock hands to actual time step by step.
Wait until the reference clock shows the second 59 in the actual minute, then synchronize the
clock on the minute beginning by means of a last brief key touch.
Now the key should not be touched any more. Clock runs on exact time.
In case of manual time setting no automatic daylight saving time switch-over will follow, this can,
however, very easily be set by means of the operation key. (Chapter 5.4, page 8).
The setting should always start on second 59, as every key touch sets the second of the internal
clock to 0.
8.3 Starting-up and Synchronization with serial telegrams
The serial telegrams can contain either local time (Chapter 7.1, page 11) or UTC-time (Chapter
7.2, page 11). If the QU 192 is synchronized with local time, the functioning is the same as a BU
192.
With the setting of UTC-time, the movement runs in a mode, which will automatically execute the
daylight saving time change-over. As standard the programmed time zone is MEZ. Should another
time zone be required, it has to be set by means of the special season telegram (Chapter 7.4, page
12).
For the programming of the time zone and the UTC time a PC or a Palm can be used (Chapter 8.4
and 8.5 page 14 and following).
The following procedure for the starting-up with UTC time is recommended:
Insert power supply Clock runs to 12 o’clock position.
Should the MEZ-time zone not be required, send season telegram twice.
Transmit UTC-time with telegram every second until the hands start moving.
The serial connection can now be interrupted, as the movement continues to run on its own,
precise quartz.

© MOBATIME 14 / 20 800163.10
8.4 Starting-up and Synchronization by PC
If the standard time zone MEZ shall be applied, the next step can be overleaped.
Programming of time zone in a QU 192(t)
The diskette 'Timeset Utilities for QU192 with IF494' with Moser-Baer No. 201420 contains the
program Terminal.exe and the belonging QU192Sea.trm.
With a double click on Terminal.exe the terminal program will be started and with 'open file' the
configuration QU192Sea.trm can be charged (Fig. 10).
Some time zones and daylight saving time switch-over are here predefined as examples. They will
be sent through a click on the corresponding key in the lower bar.
Fig. 10
The examples can be changed or
complemented by opening the menu
'Settings – Function Keys' (Fig. 11).
The telegram to be transmitted can be
composed with the help of the description
in Chapter 7.4 and entered in the field
'Command'.
Attention:
The whole telegram will not be displayed.
The cursor can, however, be displaced
further to the right. At the end of the
telegram ^M must always appear.
Fig. 11
Setting of UTC time in a QU 192(t)
The diskette 'Timeset Utilities for QU192
with IF494' with Moser-Baer No. 201420
contains the program MobaSrc.exe.
After the starting-up the window here
beside will appear:
In order to be able to send UTC time to a
QU 192(t), at Time and at Saison 'UTC'
must be selected.
After a click on the 'Start' key the
telegram will be transmitted every second
(based on PC time). Fig. 12
If the PC is correctly connected with the IF 494 and this is plugged into the QU 192(t), the clock
starts running to the correct time after a few seconds.

© MOBATIME 15 / 20 800163.10
8.5 Starting-up and Synchronization by Palm
The diskette 'Timeset Utilities for QU192 with IF494' with
Moser-Baer Nr. 201420 contains the file 201247 Palm SW
for QU192.prc.
This file must be installed on a Palm. The Palm must be
connected to a PC (please pay attention to the description of
the Palm with its Software).
After the installation on the Palm, please start the application
'TimeStick'. After the start the window as per Fig. 13 will
appear.
By pressing on the arrow on the top to the left the window as
per Fig. 14 for selection of the time zones will appear. 51
time zones are available. After the selection the window will
close again.
By pressing the key 'Season Table' (Fig. 13) the selected
time zone will be transmitted to the movement through a
serial interface.
First check if the Palm system local time and season is set
correctly (see Fig. 13 first section). Otherwise refer to the
Palm system time setting view.
By pressing the key 'UTC' the actual Palm system UTC time
will be transmitted to the movement.
If the serial interface of the Palm is correctly connected to the
IF 494 (please pay attention to the Palm documentation) and
this is plugged to the QU 192(t), the clock starts running to
the correct time after a few seconds.
Fig. 13
Fig. 14

© MOBATIME 16 / 20 800163.10
9. Detailed Function Description
9.1 Current saving mode of the movement, current consumption
"Run" mode: Microprocessor active during time reception and control of the motor
Current saving mode: Microprocessor in repose mode
Starting-up:
After the insert of the power supply the movement remains in “Run” mode until the time is set
either manually (by operation key) or by a time signal.
When the time has been taken over, the movement switches to the current saving mode at the
next minute step at the latest normal operation.
Operation:
In operation the movement awakes for a short time at each second change and checks, if it must
remain in "Run" mode or if it can switch off again. At the same time the time will be adjusted.
In the second 59 the movement switches to the „Run“ mode, so that the minute step can follow
correctly on second 0. In second 2 (at serial reception second 3) the movement will return to the
current saving mode.
Average current consumption (measured over 24h):
Current saving mode < 10 A
"Run" mode < 3 mA
During motor step ca. 50 mA
Max. current during motor step and DCF-LED ca. 60 mA
FU 192, when reception quality is good ca. 280 A
BU 192 synchronized by serial telegram ca. 360 A
QU 192 time manually set ca. 260 A
9.2 Concept for the radio signal reception
The radio clock can receive time signals from the emitter DCF 77 in Mainflingen (D) up to a
distance of 1000 – 3000 km from the emitter (as per reception condition on installation site).
If an AM 192 antenna is used, the MSF 60 time signals from Rugby (GB) can be received. The
reception is only possible in parts of North and West Europe.
The radio clock receives the time signals through the antenna. The received time signals will be
evaluated by the receiver module (situated in the antenna case), demodulated, amplified and re-
transmitted as digital signals to the controller of the movement.
If the movement is once correctly adjusted by radio, it runs on its own 32 kHz quartz time base and
synchronizes itself once every hour (at minute 56 second 20) from the radio signal from the
emitter. In addition, twice every night the whole time information will be read in (01:56:20 and
02:56:20).
If the hourly synchronization cannot be executed within 45s because of interferences, the reception
will be switched off and after an hour a new attempt will follow.
If the complete time telegram cannot be received in the night within 5 min. because of
interferences, the receiver will be switched off and after an hour a new attempt will follow. This will
be repeated until 2 complete telegrams have been received, then it will commute to second
synchronization again.
After 7 days without time reception, the clock runs to 12 o’clock, stops and will remain there.
At each minute step an optic check of the hands position follows. If the 12 o’clock position will be
identified by the clock and the internal time base is not on 12 o’clock, the hands will automatically
be reset to the correct position in fast-running.
The daylight saving time changeover follows automatically.

© MOBATIME 17 / 20 800163.10
9.3 Change of time source
Possible changes of time sources:
1. Time source 2. Time source Duration until new synchronization
Radio reception Serial reception max. 1h
Serial reception Radio reception max. 1h, by key touch immediate
Manual time setting Radio reception max. 1h
Manual time setting Serial reception max. 1min.
10. Problem removal
Nr. Problems Solutions
1 All movements:
Clock shows suddenly wrong time
Hands are untied on axes
FU 192 / BU 192:
-Touch key > 5s. Clock runs to reference
position (12 o’clock)
-Check position of hands
-Brief touch on key for running to actual time
QU 192:
- Remove and re-insert power supply
- Clock runs to reference position (12 o’clock)
- Check position of hands
2 FU 192:
After more than one night not run on
actual time.
Bad reception conditions
(In metal or steal premises, near to
electrical devices as engines, TV, PCs or
fluorescent lamps)
- Turn antenna axial for 180°
- Extend cable by CAB 192 and mount
antenna remotely
- Use antenna AD 192.5 and mount it
outdoors
3 FU 192 / BU 192:
After a normal operation hands stand on
reference position.
Degrade of radio reception conditions.
Serial telegram missing.
After 7 days without radio reception hands
run on reference position.
FU 192:
- Turn antenna axial for 180°
- Extend cable by CAB 192 and mount
antenna remotely
- Use antenna AD 192.5 and mount it
outdoors
BU 192:
- Check LED on IF 494
- Check plug and connection to IF 494
- Check emitting unit to its functionality

© MOBATIME 18 / 20 800163.10
11. Connections
Plug IN
Antenna (Fig. 7, page 7): General occupation (IF 494)
1 nc 1 RxD
2 GND 2 GND
3 VCC Ant. 3 VCC
4 DCF in 4 DCF in
5 GND Ant. 5 GND Ant.
6 nc View from contact side 6 Remote key. View from contact side
Plug OUT
Key remote control (Fig. 6 page 6) General occupation
1 nc 1 TxD
2 Key 2 GND
3 nc 3 Res.
4 nc 4 nc
5 nc 5 nc
6 Key View from contact side 6 Key View from contact side
(nc: not connected) (nc: not connected)
IF494
Interface for the time setting and/or synchronization of the movements
BU192(t) or QU192(t) from a serial interface RS232 or RS422 with the
telegram IF 482.
Programming of the automatic daylight saving time change-over.
1 2 3
IF 494
LED
LED
Fig. 19
Synchronization and/or setting to actual time.
(Chapter 7.1 - 7.3, page 11)
Programming of the automatic daylight saving time
change-over (Chapter 7.4, page 12)
The LED confirms the data transmission with brief
flashing.
Mounting: Fig. 8, page 8
Dimensions ca. 34 x 20 x 15mm.
Data input plug IF 494:
A RS232 without external power supply
Connection to serial interface: 1: TxD 2: GND
B RS232 with external power supply
Connection to serial interface with galvanic
separated power source (6V – 12VDC) 1: TxD 2: GND
3: +6...12V 2: GND
C RS422 without external power supply
Connection to serial interface 1: TD - 2: TD +
D RS422 with external power supply
Connection to serial interface with external 1: TD - 2: TD +
galvanic separated power source (6 – 12VDC) 3: +6...12V 2: GND
4
2
5
3
Fig. 16
6
4
2
5
3
1
Fig. 15
6
4
2
5
3
1
Fig. 18
6
4
2
5
3
1
Fi
g
. 17
1 2 3
Fig. 20

© MOBATIME 19 / 20 800163.10
12. Technical Data
Models 192 / 192t - Description FU
192
FU
192t
BU
192
BU
192t
QU
192
QU
192t
Order Reference - Number 200 xxx 205 206 203 204 309 310
Operation DCF 77 (AD 192 adapted) / DCF 77 or MSF 60
time signal RS 232 / RS 422 for interface IF 494
temperature compensated Quartz with 60 sec./ year at
0 - 40°C or 4 min./ year at -30 - +70°
/ –
—
—
/ –
—
—
/
—
/
—
—
—
Type of reception DCF 77 Total reception with diagonal built-in antenna,
180° axial turnable, approx. 30V/m — — — —
Synchronization Synchronization every second: each hour
complete time take-over: at starting,
minimum. 2 x per night or by key touching
—
— — —
Control of hands position 1 x per 12 hours
Introduction to adjustment Connection to power supply / key touching
/
/
/ – / –
/ –
/ –
Setting times:
Starting position
Running time to reference pos.
Read-in of time telegram
Running time for new adjustment
Changes of daylight saving time
12.00 o’clock (ex-works)
6 minutes maximum
< 3 minutes (at perfect reception)
5 ... 12 minutes (at perfect reception)
5.5 minutes maximum
—
—
—
—
—
—
—
—
Setting of time, DST/ STD time
for QU 192 / QU 192t Touching key as per description — — — —
Power supply for in- and
outdoors
For indoor only
Life-span of batteries
1 x 3.6 V Lithium battery
power supply for 230 V/50 Hz, 3.6 VDC
2 x 1.5 V IEC LR 20 (Mono cells)
2 x 1.5 V LR 20 batteries approx. 3 years
Lithium battery with one clock approx. 6-7 years
rechargeable battery in power supply approx. 3-4 years
Actuation 1 motor for minute- and hour hands
Step frequency of minute hand
motor Normal operation mode: 1 step / min
Setting mode 2 steps / sec.
Dimensions of hands max. As per DIN 41092/3 for dial
up to 80 cm
Weight of hands max. Balanced min.-hand 140 g, hour-hand 110 g
Fixing Central nut M 12 x 1 mm
Operation and stocking
temperature -30°C up to +70°C
Dimensions of battery box
(Chapter 2, page 4) B 143 x H 149 x T 35 mm
B 143 x H 130 x T 35 mm
—
—
—
—
—
—
Colour Cream white RAL 9001
Weight without batteries gram 310 350 260 300 260 300
Radio reception indoors outdoors
Model Description Ex-works Extendable
by CAB 192
Ex-works Extension Reference No..
AD 192 DCF 77-Radio time signal receiver AD 192 4 / 8 m — 200208
AD 192.5 DCF 77-Radio time signal receiver AD 192.5
—
—
—
5 m 200330
AM 192 MSF 60-Radio time signal receiver AM 192 4 / 8 m — 200209
AM 192.5MSF 60-Radio time signal receiver AM 192.5
—
—
—
5 m 200331
Optional:
COM 192: Cascade cable with connectors (Length = 1 m) 200045
KEY 192: External key with 5 m cable and connectors 201373
Long-life Lithium battery, 3.6 V, 27 Ah Within a protected clock housing (IP 54) 250394
External power supply unit for 230 V/50 Hz, 3.6 VDC
(95 x 40 x 35mm) for in- and outdoor use 201670
IF 494: Interface plugable, with connection to serial interface
RS 232 or RS 422 200328
TIMESET Kit: Timeset Utilities for IF 494 for programming of
the time and season tables with QU 192 (BU 192). PC Software: 'MobaSrc.exe'
Palm Software: '201247 Palm SW for QU192.prc' 201420

© MOBATIME BE-800163.10
BÜRK MOBATIME GmbH
Postfach 3760, D-78026 VS-Schwenningen
Steinkirchring 46, D-78056 VS-Schwenningen
Tel. +49 7720 8535 0 / Fax +49 7720 8535 11
MOBATIME AG
Stettbachstrasse 5, CH-8600 Dübendorf
Tel. +41 44 802 75 75 / Fax +41 44 802 75 65
MOSER-BAER SA EXPORT DIVISION
19 ch. du Champ-des-Filles, CH-1228 Plan-les-Ouates
Tel. +41 22 884 96 11 / Fax + 41 22 884 96 90
MOSER-BAER AG
Spitalstrasse 7, CH-3454 Sumiswald
Tel. +41 34 432 46 46 / Fax +41 34 432 46 99
SALES SWITZERLAND
HEADQUARTERS / PRODUCTION SALES WORLDWIDE
SALES GERMANY, AUSTRIA
MOBATIME SA
En Budron H 20, CH-1052 Le Mont-sur-Lausanne
Tél. +41 21 654 33 50 / Fax +41 21 654 33 69
This manual suits for next models
8
Table of contents
