Mobeye CM2410 User manual

USER MANUAL
Mobeye® CM2410
GSM fire alarm communicator
Accessory for Ei Electronics fire detector
SW version 5.n Incl. CM2400

CONTENT
1. General description 2
2. Getting started 3
2.1 Sign up in the Mobeye Internet Portal 3
2.2 Register the Mobeye SIM card 3
2.3 Insert the Mobeye SIM card 4
2.4 Insert the batteries 4
2.5 Enter the program mode 4
2.6 Activate the device 5
2.7 Configuration and synchronisation 5
2.8 How to use the Mobeye Internet Portal 6
2.9 Mount the GSM module housing to the ceiling 7
2.10 Connect the EI detector and close the cover 7
2.11 Perform a test 8
2.12 Confirmation of the alarm message 8
3. Combine other Ei detectors and a wireless network 9
3.1 combinations of Ei Electronics detectors 9
3.2 Several detectors in a wireless network 9
4. Use of external power supply 10
5. Possible settings 11
5.1 Installation code 11
5.2 Alarm Phone numbers 11
5.3 Call on/off 11
5.4 Test message 11
5.5 System reset 12
6. Status feedback 13

1
Attention! Very important
This user manual contains important guidelines for the installation and usage of the Mobeye®
device in combination with an Ei Electronics fire detector.
Please read the manual thoroughly before you start using the device. It contains vital
information on unit operation and installation. If you are installing this device the manual must
be given to the householder.
In case of damage caused by disregarding the guidelines, the warranty becomes void.
The user must regularly check the proper functioning of the device. The manufacturer cannot
be held liable for any damage or loss caused by any incorrect use or incorrect functioning of
the Mobeye® device.
Safety guidelines
• The permitted ambient temperature during operation may not be exceeded (not lower
than 0°C and not higher than 40°C).
• The device is intended for use in dry and clean places with a residential function.
• Protect the device from moisture, heat and water splashing.
• The guidelines for the battery usage must be regarded.
• Do not expose the device to strong vibrations.
• Do not let it fall from height.
• Do not use in an environment where any inflammable gases, vapors or dust are present
or could be present.
• Repair of the device may only be carried out by people, trained for Mobeye®repair.
• If the device must be repaired, only original replacement components may be used.
Use in accordance with the regulations
The purpose of this device in accordance with the regulations is sending messages and
making telephone calls after an alarm situation. Other uses are not permitted and may
invalidate the warranty.
Product and battery recycling
When disposing of this product, separate the product and the CR123 batteries from
other waste streams to ensure that it can be recycled in an environmentally sound
manner. For more information on collection and proper disposal, please contact your
local government office or the retailer where you purchased this product.

2
1. GENERAL DESCRIPTION
The Mobeye GSM fire alarm communicator CM2410 is a battery operated GSM
module used to send out an alarm after the input is triggered by a Ei Electronics
smoke or heat detector.
The Mobeye Smoke Detector CM2400 is a combination of the Ei Electronics
Ei605TYC and the Mobeye CM2410. For other combinations please see paragraph
3.1.
The default settings for standard use are:
- In case the input 1 of the alarm module is activated by the Ei Electronics fire detector,
the Mobeye GSM communicator (CM2410) sends an alarm message to the Mobeye
Internet Portal and calls the phone numbers programmed in by the user. The Portal
forwards the alarm as text message and/or e-mail.
- In case the batteries need to be replaced, the Mobeye GSM communicator (CM2410)
sends a ‘low battery’ message to the Mobeye Internet Portal. The portal forwards this
to the ‘service’ contacts.
Please refer to the manual of the Ei Electronics detector for installation instructions
and the description of the behaviour of the fire detector.
Chapter 5 describes how to influence the standard behaviour.
For use of the stand-alone Mobeye CM2410 -without the Mobeye
Internet Portal - please download the stand-alone manual from
www.mobeye.eu/EU/documentation/manuals.
Manuals in other languages can be found on the website.
Deutsch: www.mobeye.eu/de/dokumentation/anleitungen
Nederlands: www.mobeye.eu/nl/documentatie/handleidingen

3
2. GETTING STARTED
To get started with the Mobeye CM2410 at least the following steps need to be taken
in following order:
1. Sign up in the Mobeye Internet Portal
2. Activate the SIM card
3. Insert the Mobeye SIM card
4. Insert the batteries
5. Enter the program mode
6. Activate the device in the Mobeye Internet Portal
7. Program the settings Mount the GSM module housing to the ceiling
8. Connect the Ei Electronics detector and close the cover
9. Perform a test
These steps are further explained in this chapter.
2.1 SIGN UP IN THE MOBEYE INTERNET PORTAL
Go to www.mymobeye.eu
and sign up for a new account. Follow the
instructions on the screen.
You will receive an e-mail to confirm the new account. After confirmation login to the
portal.
If you do not receive this e-mail, check your spam box or ask Mobeye
(in[email protected]).
2.2 REGISTER THE MOBEYE SIM CARD
To activate the Mobeye SIM card in the Mobeye
Internet Portal, choose ‘activate new SIM card’.

4
Enter the SIM card number. This is the number written on the plastic SIM card. Only
take the last 8 digits of the last two lines (incl. number after space, do not type the
space).
The screen leads you through several pop-ups where you choose your device type
(search for “CM2410”) and select the type of contract (for instance “CM2410 SIM +
Portal Monitoring”).
At the moment you accept the price and terms, you confirm the subscription. You will
receive an invoice for the mentioned amount.
Before activating the device in the Mobeye Internet Portal, first prepare the unit (see
next paragraphs).
2.3 INSERT THE MOBEYE SIM CARD
Open the enclosure by removing the 4 screws and insert the Mobeye SIM card into the
module. Push the black cover slightly outward to open the holder and close it
afterwards. Make sure the SIM card is inserted before the batteries.
2.4 INSERT THE BATTERIES
Insert the two batteries (CR123) in the module. Use the +/- indication for the correct
placement. If you replace batteries the settings will not be deleted, since they are
stored in the device memory.
2.5 ENTER THE PROGRAM MODE
To activate the unit in the portal, the GSM module needs to be open and connected to
the network.
As soon as the batteries are placed, the Mobeye GSM communicator (CM2410)
switches to the program mode. First the GSM module establishes network connection.
During this time the LED flashes green and red. Within 10-30 seconds the connection
is established and the status LED starts flashing 1 sec. on/1 sec. off (or stays on
continuously in case the first telephone number has been configured).

5
To get back to the program mode, reinsert the batteries.
2.6 ACTIVATE THE DEVICE
When the Mobeye GSM
communicator (CM2410) is in initial
(factory) status and the batteries
are inserted (so the LED is flashing), you activate the device in the Mobeye Internet
Portal by clicking ‘Activate device’, which is written behind the registered SIM card.
The unit will receive a message from the portal and the data exchange is started. At
the first pop-up window you are asked to enter the installation code. Type the factory
code ‘1111’. The next screen will ask for a name and location of your device. These
fields can be changed later.
Once the activation is completed, the new device is visible in the device list.
By clicking the name, the detail page will be opened.
2.7 CONFIGURATION AND SYNCHRONISATION
The device settings can be programmed in the Mobeye Internet Portal. In this way you
prepare the settings, to be picked up by the device: since the Mobeye device is
leading in the communication between the portal and the device, the data
synchronisation is done after:
1)any message to the portal (e.g. alarm, test, low batteries)
2)reinserting the batteries

6
2.8 HOW TO USE THE MOBEYE INTERNET PORTAL
The device detail screen in the Mobeye Internet Portal shows several blocks:
Contacts
The contacts are the contact persons that will receive alarm and service notifications,
per SMS text message and/or e-mail. Service notification may be warnings about
missed keep-alive (test) messages and low battery voltage.
To add a contact, please first create the contact person in the (blue) tab Contact.
Note: the telephone numbers that will be dialed directly from the unit, are configured in
the Options.
Status
The status block displays several values, important information about the unit.
The GSM status tells the network strength in the last communication session. If the
values is lower than -95dB, please consider another location for the device).
If the ‘Synchronised’ status is ‘No’, new options are to be picked up by the device.
Device
Open the device details to change the name and location of the device. These are
copied into each SMS text message and e-mail and meant as identifier.
Message texts
In the message texts are the event texts in the SMS text message and e-mails. These
texts can be customized.
History
All historical events and logs are displayed in the history. Click ‘show’ all.
Options
The configuration options (settings) can be changed in the
Mobeye Internet Portal. Click ‘edit’ to change the settings.
Type the installation code (factory setting is ‘1111’) to open the pop-up.
Please see chapter 5 for the description of each setting.
After saving new settings, they need to be picked-up by the device, i.e. synchronised.
Please see 2.7 for more information about the synchronisation.

7
2.9 MOUNT THE GSM MODULE HOUSING TO THE CEILING
Mount the housing in which the module is fixed to the desired place to the ceiling,
using the plugs and screws which can be found inside the Ei Electronics box. Please
refer to the manual of the Ei Electronics detector for the ideal location and installation
method.
2.10 CONNECT THE EI DETECTOR AND CLOSE THE COVER
Remove the back cover from the Ei Electronics detector. The
GSM communicator (CM2410) will be used as back cover.
Press the green cabled connector to the pins of the Ei
Electronics detector. Next to the pins the text 1 2 is written.
Be sure that the (in most situations) grey connector in the Ei
Electronics detector was removed.
Hold the EI detector to prevent tension on the wires!
Bring the Ei Electronics detector and the back cover with GSM module to each other at
the correct position and turn the detector gently clockwise until it is closed and locked.
In the EI detector a red light will flash regularly.

8
2.11 PERFORM A TEST
After the previous steps, the GSM fire detector is operational.
In order to execute a test, press the TEST & HUSH (or TEST & STUMM) button of the
EI detector during a few seconds (this can take up to 5 seconds). The siren will sound
and the GSM module will establish network connection in order to send the SMS
messages and call the contact persons.
Note: make sure the cover is closed, so that the fire detector and the GSM module are
locked.
2.12 CONFIRMATION OF THE ALARM MESSAGE
When the system is triggered it will send alarm notifications. First the message to the
portal is sent, followed by the phone call directly from the unit. When you pick up the
phone, you will hear beeps. It is possible to confirm the phone call by answering the
phone and pressing any key. The other alarm numbers will not be called afterwards.

9
3. COMBINE OTHER EI DETECTORS AND A WIRELESS NETWORK
3.1 COMBINATIONS OF EI ELECTRONICS DETECTORS
The CM2410 can be applied in various combinations:
-A stand-alone GSM smoke or heat detector can be the combination of the Mobeye
CM2410 and the Ei605C, Ei605TYC, Ei603C or Ei603TYC (smoke or hear)
detector, or any other detector in the Ei600 and Ei650-series.
-If applied in a network of several detectors (cabled or using RF modules), the
detector with the CM2410 GSM module must be of the type Ei605C, Ei605TYC,
Ei603C or Ei603TYC. The other detectors in the network can be any detector in
the 600- and 650-series.
3.2 SEVERAL DETECTORS IN A WIRELESS NETWORK
Although the Ei Electronics fire detector is a stand-alone unit, it is also possible to form
a wireless network with several smoke and heat detectors. For this purpose each Ei
Electronics detector needs to be equipped with an RF module. This module can be
integrated in the Ei Electronics detector. Before the detectors are operational, the
detectors need to enrolled, in order to know each other.
Please refer to the Ei Electronics manuals for the steps to follow.

10
4. USE OF EXTERNAL POWER SUPPLY
Although the Mobeye CM2410 is designed to run on batteries, it is possible to use an
external power supply. In this mode the module is always in connection with the GSM
network and therefore always in program mode. In case the power fails, the batteries
take over the functioning and a message is sent via the portal. The module continues
operating albeit in the low power mode. This means the GSM module switches off and
only establishes network connection in case it needs to send out an alarm, test
message or low battery alert.
Connect the external power adapter (or any other
regulated 12VDC power supply) to the power input of
the connector (press on the green pins for connecting
the wires):
- V+ to “+”
- Ground (black lead) to “-“
If Mobeye accessory 10027 is used:
V+ is the black lead with white stripe.

11
5. POSSIBLE SETTINGS
The Mobeye CM2410 settings are prepared in the portal, in the "Options" block, and
then retrieved by the device during a synchronization session. The factory setting for
the security code is '1111'. All settings are saved and stored in the unit, even when the
unit is not powered or the batteries have been removed.
5.1 INSTALLATION CODE
For configuration activities the installation code of the Mobeye CM2410 must be used.
The initial (security) code is ‘1111’. The code can be changed in the options. Note: the
code is only visible when changing the settings.
5.2 ALARM PHONE NUMBERS
The Mobeye CM2410 is able to directly call to up to 5 phone numbers. These may be
different numbers than the (unlimited number of) contacts who will receive SMS text
messages and/or e-mails. It is not required to enter phone numbers.
5.3 CALL ON/OFF
Even if the alarm telephone numbers are set in the options, the calling process can be
suppressed. By turning off the CALL, the unit will only send the notification via the
Mobeye Internet Portal. The default value is set to ON.
5.4 TEST MESSAGE
The Mobeye CM2410 can send regular test messages (keep alive) to the Mobeye
Internet Portal, to ensure the proper functioning of the unit. The test message will also
be sent if the unit is disarmed. The Mobeye Internet Portal expects the test message
and checks the timely receipt. The monitoring of the test messages follow the
‘management by exception’ rule: only if the message was not received, the ‘service’
contacts will receive a notification.
The timing of the test message can be programmed. Since new settings (options) will
be synchronised after the test message, setting a specific time of the test message
can help the process of remote programming. Example: if you force a daily test

12
message at 17.30 hrs, you can prepare new settings and be sure they are loaded into
the device before the evening.
The interval between the test messages can be set between 0 days (no test message)
and 30 days. The default test interval is set to 7 (weekly test message).
5.5 SYSTEM RESET
To reset the Mobeye CM2410 to its factory settings two steps are necessary:
1. Reset the Mobeye CM2410
2. Delete the Mobeye CM2410 from the Mobeye Internet Portal
1. To reset the Mobeye CM2410 to its factory settings
1. Be sure the GSM module is in program mode (see chapter 2 step 5).
2. Send following SMS text message to the telephone number in the unit (without
CODE)
SMS command Reset: RESET
3. The green LED blinks 3x to indicate a successful command. In case of an
incorrect command the LED flashes 5x green.
After a successful reset, the LED will blink green to indicate that the module is not
configured. The security code is back to factory settings as well.
2. To delete the Mobeye CM2410 from the Mobeye Internet Portal
Delete the device from the Mobeye Internet Portal. The SIM card could be then reused
for another Mobeye device, or the same device can be connected again.
In the device list, click the name of the device to go to the details screen. Next choose
‘ Device’. Click ‘delete’ to delete the device and confirm the option.
The SIM card will be disconnected from the device and visible on the first screen.
After a successful reset, the status LED on the keypad will blink green to indicate that
the module is not configured. The security code is back to factory settings as well.

13
6. STATUS FEEDBACK
LED pattern
Status
Required action
Blinking green, 1 second
on / 1 second off
Module not configured
Configure at least one
telephone number.
1 green flash every 3
seconds
Module is switched on,
powered by batteries
No action required.
Green LED stays on
continuously
Module is switched on,
powered by an external
source
No action required.
Flashing red/ green
every second
Module establishes
network connection
Wait until the network
connection is established.
2 flashes red,
every 3 seconds
No GSM connection
Try the module at another
location.
3 flashes red,
every 3 seconds
No valid SIM card or
wrong PIN
SIM card failure.
Blinking 3 times green
Successful programming
action
No action required.
Blinking 5 times red
Faulty programming
action
Check SMS command.
4 red flashes
every 3 seconds
Low batteries
Replace both batteries.
Blinking green rapidly
Data exchange with
portal
No action required.

14

15
Technical specifications
GSM : Quad band EGSM,
850/900/1800/1900 MHz
Batteries : 2* CR123 (lithium)
Battery life in normal mode : >1 year
Power consumption low power : ca. 50 μA stand-by / max. ca. 500 mA
Ext. power connection : 12 VDC (+/- 2 VDC) / min. 500 mA (optional)
Power consumption 12V : ca. 50 mA stand-by / max. ca. 500 mA
Ambient temperature : 0 °C until +40 °C
This manual is published by Mobeye®.
All rights, the translation included are reserved. Any reproduction, either
photocopy, microfilm or saved in an automated data dictionary, only after written
approval of the Publisher. Reprinting, even in summary, is prohibited.
This user manual meets the technical requirements at the moment of printing.
Changes in technology and equipment are reserved.
© Copyright 2018 by Mobeye, version CM2410ENPORTAL180201

16
