i-PRO Amber8s User manual
1. TECHNICALCHARACTERISTICSOFTHEcellularAmber8s
TheModelAmber8shasthefollowingtechnicalspecifications.
Processor
Processor architecture ARM Cortex-A7
Processor family MT
K
Processor frequency 1.3GHz
Processor model MT6580M
Number of processor cores 4 core
Memory
Internal memory 16GB+8Gb
Internal memory type LPDDR3
Display
Screen diagonal 5.5”
Touch screen
Aspect ratio 18：
9
Screen resolution 960*480 pixels
LED backlight
Touch technology Two-touch
Touch screen type Capacitive
Audio
Built-in speakers
Built-in microphone
Ports And Interfaces
Headphones 3.5 mm
Micro-USB 2.0 ports quantity one
Headphone output
Weight and measurements
Height 9.6 mm
Width 71.4 mm
Weight 157.8g
Depth 150.29mm
Energy Control
AC adapter output current 1A
AC adapter output voltage 5 V
Connection
2 G bands
3G bands
4G bands
Supported 2G bands 850,900,1800,1900 MHZ
Supported 3G bands
Supported 4G bands
850,1900 MHZ
/
Bluetooth
Dual SIM support
Wi-Fi standard Wi-Fi (802.11bgn)
2G standards GSM
3G standards WCDMA
4G standars
Bluetooth version /
4.0
Storage Media
Internal storage capacity 16 GB
Integrated reading card
Compatible memory cards MicroSD (TransFlash)
Storage unit Flash
Photographic camera
Frontal camera
Rear camera
Integrated flash
Video recording
Front camera resolution (numeric) 2 MP
Rear camera resolution (numeric) 5 MP+0.3MP
Flash type LED
PackagingContents
AC adapter included
Include skeyboard
User manual
Messenger service
Email
Battery
Battery capacity 2700 mAh
Battery technology Lithium
Battery voltage 3.8 V
PhoneFeatures
Speaker
Caller ID
voicecall
Video call
Design
Product color Black
Form factor Board
Type of device smart phone
Performance
Assisted GPS (A-GPS) function
software
Platform Android
Installed perating system Android GO
Media Formats
Supported audio formats APE, FLAC, MP3, WAV, WMA
Supported image formats BMP, GIF, JPEG XR, PNG, TIF
Supported video formats AVI, H.264, MKV, MPEG1, MPEG2,
RM, RMVB
Phone Overview
Get Started
Install the USIM/SIM Install the memory card
Remove the back cover Mount/Demount the battery
Basic Operations
Switch on
Touch and hold the Power button until the phone switches on.
Note: If you have enabled USIM/SIM locking in the Settings menu, enter the
correct PIN number upon power-on before you use the phone.
Caution: Three consecutive attempts of entering an incorrect PIN will lock the
SIM card. If it is locked, use a PUK provided by the operator to unlock it.
Switch off
Touch and hold the “Power button” until the Phone Options screen displays.
Tap " Power off ” to switch off the phone.
Unlock
Short press the “Power button” light up the screen, according to the clues of
the screen interface can be unlocked.
Touchscreen Usage
Use your fingers to perform operations directly on icons, buttons, and the on-
screen keypad.
Tap/Touch/Click
Tap the icon of an App to start it.
Touch & Hold
Touch and hold an item to display a pop-up menu of options. For example, go
to Address Book, touch and hold a contact on the Address Book page, and a
menu of options pops up.
Drag
Tap an item on the screen and drag it to another place.
Slide/Sweep
To sweep vertically or horizontally across the screen, you can view apps,
pictures, and webpages in a convenient manner.
Scroll
Similar to sweeping, but faster.
Pinch
Put two fingers on the screen to pinch in or out an item, such as a webpage or
picture.
Home Screen
1. Status bar: allows you to view status icons and notices, such as signal,
battery, current time and data service.
2. Notification bar: On the Home screen, tap the status bar and drag it down
to display the notification bar. Tap this bar. Then you can view the notices.
Touch the return button to switch back to the previous page.
3. App icon: Tap an app to open it.
4. Main menu: Drag it up to enter the app main menu.
Phone Settings
To display the Settings menu, tap the Settings icon directly.
1.SIM card: In the Settings menu, select WLAN to configure your radio
network，choose SIM Card. You can then manage your SIM cards on the pop-up
page.
2. Network: In the Settings menu, select WLAN to configure your radio
network; or select Traffic usage to View the details of usage; or select
Mobile Network configure data services of your phone
3. Sound: In the Settings menu, choose Sound. The allows you to set the
volume, enable/disable vibration during ringing, and select ringtones for
incoming calls and alarm clock, as well as enable/disable keypad touch
sound effect, touch alert tone, and screen lock tone
4. Display: allows you to configure the brightness, wallpaper, automatic
device rotation, sleep duration, and font size.
5. Security: In the Settings menu, choose Security. The Security page allows
you to set the screen locking mode and USIM/SIM locking mode.
6. Application and notification: In the Settings menu, choose Apps. Then you
can view or manage your apps.
Note: Disable or unload certain apps if available space is less than 100MB.
7. Message: On the Message page, tap the Menu button and choose Settings,
you can open and close message send prompt sound, you can enable/disable
Message report obtain，view SMS in SIM.
8. Call: To display the Call Settings page, choose Settings on the Call page.
Move/Uninstall apps
1. Access the App main menu from the Home screen. On the ALLApp page, tap
and hold an app to be put on the Home screen, and drag it left or right to
locate it at a proper place. In this way, a desktop app is created.
2. On the All App page, tap and hold an app, and drag it to Uninstall on the
desktop. In this way, the app is removed from the phone.
Note: You are not allowed to uninstall basic apps of the phone.
3. On the All App page, tap and hold an app, Then select the application
information，In this way details about the app is displayed.
Call
This phone allows you to make or answer a call, initiate an emergency call,
and launch a multi-party call.
On the bottom left of the Home screen, tap the Dial-up icon. The Dial-up page
is displayed. Enter a phone number and choose between card 1 and card 2 to
make the call. When you enter the number, the phone will automatically
search among all contacts a number that best matches the entered numerals,
to facilitate your operation.
During a call, tap Add a Call, and this call automatically switches to Silent
mode. Enter the number of another contact, tap Dial-up, and the previous
call automatically switches to On-hold mode. After the second call is
answered, tap Join. In this way, a teleconference is established to achieve a
multi-party talk.
Note: You need to subscribe to this service from your carrier before you use it.
You are also allowed to initiate a call by selecting a phone number from the
list of contacts or the Message page.
Contacts
Tap Contacts to open it. The Contacts page offers management functions. It
allows you to view the list of contacts and related details, make a call or send
an SMS to a certain contact, and share the contact.
Contact import: On the Contacts page, tap the setting button, and choose
Import/Export to select a mode for importing or exporting a contact.
Add a contact: On the lower right of the Contacts page, tap the Add button to
add a contact to your phone or USIM/SIM. Enter the name and number, and
tap Finish. In this way, a contact is created.
Contact list: On the Contacts page, tap the image of a contact. Details about
the contact is displayed. This allows you to quickly make a call or send an SMS
to the contact.
Search contact: On the Contacts page, tab Search, and enter related
information about a certain contact to search it among the list of contacts.
Message
Tab Message on the desktop. Then you can create and send an SMS or MMS.
New message: Tap the Add icon on the upper right of the Message page. The
message creating page is displayed. Enter the name or phone number of the
target contact into the Recipient bar. The phone will automatically search
among the list of contacts for one that best matches the entered info. (You
can also select the contact from the list of contacts or groups.)
Input method: Tap the text editing zone to invoke the keypad. Long press the
space bar to switch your input method.
Send: After an SMS is complete, tap Send and choose between card 1 and card
2 for sending the SMS.
Browser
Tap Browser to open it. The Browser page allows you to access and manage
WAP and WWW webpages.
During a browse, tap the Menu button, choose Bookmark to display the
Bookmark list. In addition, tapping the Menu button helps save the webpage
that you are viewing to the Bookmark.
Tap the Menu button during a webpage browse: also allows you to share the
webpage, search on the webpage, and view history records.
Add a webpage bookmark to desktop: On the Bookmark page, tap and hold a
bookmark, and choose “Add shortcut to the Home screen”. In this way, you
can add frequently used webpages to the desktop for future access.
Browser settings: Tap the Menu button and choose Settings. The Browser
Settings page allows you to configure the browser as desired, such as common
content settings and privacy & security settings. Advanced settings allows for
resetting to default settings.
E-mail
Tap E-mail to open it. The E-mail page is display. On this page, you can send
and receive an e-mail via the phone.
For the first time you use this function, enter your e-mail account and
password to set up an account. You can also set more accounts for ease of
uniform management of all mails.
Gallery
Gallery saves and manages all pictures obtained via the camera, Internet, and
the MMS received.
On the Home screen, tap Gallery to open it. The Gallery page is displayed. It
supports management of all pictures.
Open a picture and then click the share button at the top. In this way, the
picture is shared via the Bluetooth, message, and mail.
Clock
Tap Clock to open it. The Clock page is displayed.
Set clock: Tap the alarm clock on the upper left. The Alarm Clock page is
displayed.
Add clock: On the Alarm clock page, tap “+” on the top to add an alarm. Edit
the alarm time and tap Finish. When editing the alarm time, select Hour
before Minute. For example, in the 12-hour format, select 8 as the hour and 0
as the minute, and select a.m.
Multimedia Function
The phone also supports many multimedia functions, such as camera, music,
and recorder. Tap any icon of theirs to open any one of them.
Manage File
This function allows you to copy, paste, share and delete a file stored on the
SD card or other memory cards.
Search
On the Home screen, Tap Google, and enter keywords. In this way, you can
search for a webpage, app, contact, and music. The result will be displayed
below the search bar.
Voice Search
In the network-connected state, tab Voice Search, and speak to the
microphone what you want to search, such as weather and other information.
Play Store
This store allows you to download the latest Android apps, games, music,
movies, TV programs, books, and magazines to your phone.
Troubleshooting
To save time and avoid unnecessary cost, please conduct the following checks
before contacting our after-sale personnel:
1. Unable to turn on the phone: Check whether you have tapped and hold
the Power button for over two seconds. Check whether the battery is in good
contact. If not, remove the battery, reinstall it, and turn on the phone again.
Check whether the battery runs out. If yes, charge it.
2. Poor signal: It is possibly because of where you are, for example, on the
basement or near a high-rise, that deteriorates the reachability of radio
waves. Please move to someplace with better signal reachability.
3. Echo or noise: The network trunk line of certain carriers may be in poor
quality. Please tap the hang-up icon and redial, so that you may switch to
another trunk line with better quality.
4. Unable to charge the battery: Your battery may fail. Please contact the
dealer.
5.SIM card error: The metal surface of the SIM card is dirty. Rub the metal
contact terminals with a clean dry cloth.
The SIM card is not installed properly. Install it again as specified in the user
manual.
The SIM card breaks down. Contact the network service provider.
6. Unable to enter anything into Phone Book: This is possible because that
your phone book memory is full. Please delete needless data from Contacts.
to try to correct the i
and on, the user is encouraged
ticular installation. If this equipment
does cause har
rdance with the instructions, may cause
to operate the eq
s authority
undesir
eived, including interference that may cause
s when used with an accessory designated for this
limit establishe
that it does not exceed the exposure
although the SAR is determined at the high
FCC Warning
Specific Absorption Rate (SAR) information SAR tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands,
est certified power level, the actual SAR level of the
phone while operating can be well below the maximum value, in general, the closer you are to a wireless base station antenna, the lower the power output.
Before a new model phone is a available for sale to the public, it must be tested and certified to the FCC
d by the FCC, Tests for each phone are performed in positions and locations (e.g. at the ear and worn on the body)as required by the FCC.
For body worn operation, this mobile phone has been tested and meets the FCC RF exposure guideline
product or when used with an accessory that contains no metal and that positions the handset a minimum of 10mm from the body.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference rec
ed operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’ uipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in acco
rference to radio communications. However, there is no guarantee that interference will not occur in a par
mful interference to radio or television reception, which can be determined by turning the equipment off
nterference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
harmful inte
Other i-PRO Cell Phone manuals
