MobileDemand xTablet T1180 User manual

1
User Manual
xTablet T1180
1501 Boyson Square Drive – Suite 101 Hiawatha, Iowa 52233 | PH: 319.363.4121 | RuggedTabletPC.com

xTablet T1180
2
User Manual
xTablet T1180
Contents
Copyright and Trademark Notice 3
FCC Information 4
IC Statements 5
Safety Instructions 6
Introduction 8
Product Overview 9
Specications 12
Power Supply 13
AC Adapter 13
Battery 14
VIEW
VIEW
VIEW
VIEW
VIEW
VIEW
VIEW
VIEW
VIEW
VIEW

xTablet T1180
3
Copyright and Trademarks Notice
All marks and names mentioned may be trademarks of their respective owners. No warranty as to accu-
racy or completeness is expressed or implied. We reserves the right to make changes to this document
without prior notice.
Revision History
►Version: 1.0
►Date: 09, 2019

xTablet T1180
4
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and radiates radio frequency
energy, and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
►Reorient or relocate the receiving antenna.
►Increase the separation between the equipment and receiver.
►Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
►Consult the dealer or an experienced radio TV technician for help.
NOTE
►The changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
►Shield interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
►This device may not cause harmful interference.
►This device must accept any interference received, including interference that may cause undesired operation.
FCC/IC RF Radiation Exposure and SAR Statements
The xTablet T1180 has been tested for body-worn Specic Absorption Rate (SAR) compliance. The FCC/IC has established de-
tailed SAR requirements and has established that these requirements. This model meets the applicable government require-
ments for exposure to radio frequency waves. The highest reported SAR level for usage near the body (0mm) is 0.99 W/kg,
and for the simultaneous transmission is 1.56W/kg.

xTablet T1180
5
IC Statements
This device complies with Industry Canada RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploita-
tion est autorisée aux deux conditions suivantes:
1. il ne doit pas produire de brouillage et
2. l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est
susceptible de compromettre le fomctionnement du dispositif.
►This Class B digital apparatus complies with Canadian ICES-003.
►Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
CE Conformity
This device is in compliance with the essential safety requirements and other relevant provisions
set out in the European Directive.
Battery Regulations
European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted house-
hold waste. Please use the public collection system to return, recycle, or treat them in compliance with the
local regulations.
Taiwan: For better environmental protection, waste batteries should be collected separately for recycling or
special disposal.
California, USA: The button cell battery may contain perchlorate material and requires special handling
when recycled or disposed of in California.
For further information please visit: http://www.dtsc.ca.gov/hazardouswaste/perchlorate/
Safety Guideline for Using Lithium Battery
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recom-
mended by the equipment manufacturer. Discard used batteries according to manufacturer’s instructions.
WEEE Statement
European Union: Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment,
Directive 2002/96/EC, which takes eect on August 13, 2005, products of “electrical and electronic equip-
ment” cannot be discarded as municipal waste anymore and manufacturers of covered electronic equip-
ment will be obligated to take back such products at the end of their useful life.

xTablet T1180
6
Read the safety instructions carefully and thoroughly. All cautions and warnings on the equipment or
user’s manual should be noted.
Keep this equipment away from humidity and high temperature.
The openings on the enclosure are used for air convection to prevent the equipment from overheating.
Do not cover the openings.
• Do not leave the equipment in an unconditioned environment with a storage temperature
above 60ºC (140ºF) or below -20ºC (-4ºF), which may damage the equipment.
• This unit should be operation under maximum ambient temperature of
50ºC (120ºF) or under 60ºC (140ºF) for light loading applications.
Followings are requirements of battery storage:
1. If the storage duration is within 3 months, please remain the temperature at -20º ~45ºC ;
If the storage duration is above 3 months but within 1 year, please remain the temperature
at 23º± 2ºC.
2. The battery capacity should remain at 30 ± 5%.
3. The storage humidity should remain at 65 ± 25%RH.
4. The battery charging temperature should be 10º ~45ºC , the discharging temperature should
be -20º ~60ºC.
5. For the maximum battery discharging performance, please remain the storage temperature at 25ºC.
Make sure the power voltage is within safety range and has been adjusted properly to the value of
100~240V before connecting the equipment to the power outlet.
• Always unplug the AC power cord before installing any add-on card or module to the equipment.
• Always disconnect the AC power cord or uninstall the battery pack or switch o the wall socket if the
equipment would be left unused for a certain time to achieve zero energy consumption.
Place the power cord in a way that people are unlikely to step on it. Do not place anything on top of the
power cord.
Safety Instructions

xTablet T1180
7
Always keep the strong magnetic or electrical objects away from the tablet.
Never pour liquid into the opening that could damage the equipment or cause an electrical shock.
If any of the following situations arises, get the equipment checked by a service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment has not worked well or you can not get it work according to User’s Manual.
• The equipment was dropped and damaged.
• The equipment has obvious signs of breakage.
Green Product Features
• Reduced energy consumption during use and stand-by
• Limited use of substances harmful to the environment and health
• Easily dismantled and recycled
• Reduced use of natural resources by encouraging recycling
• Extended product lifetime through easy upgrades
• Reduced solid waste production through take-back policy
Environmental Policy
• The product has been designed to enable proper reuse of parts and recycling and should not be
thrown away at its end of life.
• Users should contact the local authorized point of collection for recycling and disposing of their
end-of-life products.

xTablet T1180
8
Introduction
Congratulations on the purchase of MobileDemand’s xTablet®T1180. Designed and tested to meet our
exacting standards ensures dependability and customer satisfaction.
Refer to this manual to guide you through the basic functions and features.
Unpacking
Unpack the shipping carton and check all items carefully. If any item is damaged or missing contact your local dealer
immediately. Please keep the box and packing materials in the event you need to ship the unit. The package should
contain the following items:
• XTablet T1180
• AC/DC adapter and AC power cord
• String (optional)
• Hand strap (optional)
• Brief case handle (optional)
• Stylus (optional)
• Stylus holder (optional)
• Quick Start Manual(optional)

xTablet T1180
9
Product Overview
1 2 3
4
5
1. Status LED
Power
• Green OFF: Power o(S5)/Hibernation(S4)/charging
• Green ON: Power on(S0) while not charging
• Flashing Green: Standby(S0iX)/Sleep(S3)
while not charging
Battery
• Orange OFF: Battery is fully charged or not charging
• Orange ON: Battery is charging while system ON and OFF
• Blinking Orange (1Hz): Battery is charging while system
Standby(S0iX)/Sleep(S3)
• Blinking Orange (4Hz): Battery error.
2. Light Sensor
3. Front Camera
4. Internal Microphone
5. Touch Screen

xTablet T1180
10
1. Volume
2. Power
3. Barcode Scanner (optional)
4. Headphone Jack
1. Boss Holes
2. Dock Connector
1. RJ-45 Connector
2. USB 3.0 Port
3. Reset Hole
4. DC-in Jack
5. USB 3.0 Port
6. Micro HDMI Port
1
1
2
2 1
3 4
1 2 3 4 5 6

xTablet T1180
11
1
2
3
4
5
6
7 8 9
1. Battery Latch
2. LTE Card Slot (optional)
3. Speaker
4. Finger Print Reader (optional)
5. Battery Status Button
6. Battery Status LED
7. F1 Function - Default Barcode Scanner function. (optional)
8. Backup Battery Slot
9. Rear Camera

xTablet T1180
12
DIMENSIONS 11.16” W x 7.56“ H x .87” D
2.64 lb. (1.2kg) - base cong
DISPLAY 10.1” sunlight viewable
WUXGA 1920W x 1200H IPS; 550 NITS
10-point multi-touch capacitive screen.
Supports stylus, glove and wet-touch mode
CPU Intel® Core™ i5-8200Y;
1.30-3.9GHz
MEMORY 8GB LPDDR3 - standard
16GB LPDDR3 - optional
STORAGE 256GB M.2 SSD
512GB M.2 SSD
O/S Windows 10 Professional 64-bit
RUGGEDIZED MIL-STD 810G (5’ drop)
Sealing IP65 (dust and water)
Screen Protector Oleophobic, scratch-resistant glass
Operating Temp 14° F to +122° F (-10° C to +50° C)
Storage Temp -4° F to +140° F (-20° C to +60° C)
Operating Humidity 95% non-condensing
CAMERA Front - 2MP
Rear - 8MP AF with ash
OPTIONAL 3D CAMERA
Model Intel® RealSense™ D415 Camera
I/O PORTS USB Type A 3.0 (2)
HDMI Type D (Micro)
3.5mm Aux
Power - DC Barrel Jack
Standard SIM Card Slot (2FF)
MicroSD Slot
RJ45 Gigabit Ethernet Port
AUDIO Intel® HD audio,
built-in digital microphone
2 microphone array
2 integrated speakers
SCANNER Optional: High performance
Honeywell N6703 2D
barcode scanner
BUTTONS Barcode scan; Function
Power; Volume +/-
SENSORS 9 Axis MEMS
Gravity Acceleration
E-Compass
Gyroscope
Ambient light
Proximity
BATTERY
SYSTEM
3.7V, 10,800mAh, 40Wh
up to 10Hr battery life¹
Hot swappable
WIRELESS/NETWORK
WLAN Wi-Fi 802.11a/b/g/n/ac
Intel® (AC 9260 M.2 2X2)
Bluetooth 5.0
GPS Ublox NEO-M8N
4G LTE Optional Sierra Wireless EM7565
(North America/EMEA)
SECURITY
TPM 2.0 Firmware
NFC Optional contactless NFC module for reading/writing
NDEF (NFC Data Exchange Format) formatted tags
ISO 15693 and 14443 A/B compliant if formatted
according to NDEF format
AGENCY APPR FCC-CE-IC
¹Battery life varies signicantly depending on settings, app usage, and other factors
²Only compliant with ISO 15693 and 14443 A/B if tags are formatted according to NDEF formatting standard
Specications
The specications listed here is for reference only, and may change without notice.
VIEW

xTablet T1180
13
Getting Started
Power Supply
This section provides basic safety precautions when using an AC/DC adapter and battery.
AC/DC Adapter
Ensure the xTablet T1180 is connected to an AC power source via the AC adapter before turning it on for
the rst time. If the xTablet automatically shuts down due to low battery power, it is likely to cause system
failure. Below are some Dos and Don’ts for an AC/DC adapter.
►Dos
• Use the adapter that shipped with xTablet T1180 only.
• Always be aware of heat coming from the AC/DC adapter while in use.
• Unplug the AC power cord before disassembly the notebook.
►Don’ts
• Never cover an adapter that is in use as it can generate heat.
• Never leave the power cord plugged in after powering o the system.
1. Take up the interchangeable plug and look for the groove on the interchangeable plug which can be used for locking
on the AC/DC adapter. Then align the groove of the interchangeable plug on the tenon of the AC/DC adapter with
correct orientation. Next, rotate the interchangeable plug 90 degrees clockwise until it is xed on the AC/DC adapter.
2. Plug the DC end of the AC/DC adapter into the DC-in jack of the Tablet PC.
3. Then plug the AC/DC adapter into the power outlet.
4. When remove, please follow the steps 3 2 1.
(NOTE:The interchangeable plug may vary depending on countries or regions.)

xTablet T1180
14
Battery
This Tablet is equipped with a built-in high-capacity Lithium-ion Polymer battery pack.
The rechargeable Lithium-ion Polymer battery pack is an internal power source.
The battery pack may be damaged if users attempt to disassemble the battery pack. The limited warran-
ty will be voided if the battery pack is disassembled by non-authorized technicians. Please follow your
local laws and regulations to recycle the Tablet and the built-in battery pack.
►Conserving Battery Power
Ecient battery power is critical to maintain normal operation. If battery power is not managed well, the saved data and cus-
tomized settings may be lost.
To optimize battery life and avoid sudden power loss, read the tips below:
• Suspend system operation if the system will be idle for a while or shorten the suspend time period.
• Turn o the system if you won’t be using it for a period of time.
• Disable unnecessary settings or remove idle peripherals.
• Connect an AC/DC adapter to the system whenever possible.
►Charging the Battery Pack
The built-in battery pack can be recharged when the Tablet is connected to the AC power. Please pay attention to the follow-
ing tips before recharging the battery:
• You can use the system, suspend system operation or shut down and turn o the system without interrupting the
charging process.
• The built-in battery pack uses Lithium-ion Polymer battery cells that have no “memory eect.” It is unnecessary to dis-
charge the battery before recharging. However, to optimize the life of battery, we suggest that consuming the battery
power completely once a month is necessary.
• The actual charging time will be determined by the applications in use.
(NOTE:Please do not charge battery in temperature below 0º or above 45ºC , it may cause safety issue.)
