ModaFlame GF301600BK User manual

1
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
Pavilion Tabletop Firepit Bio Ethanol Fireplace
User Manual
Model: GF301600BK (BLACK)
GF301600W (WHITE)

2
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
Included in delivery (Parts List):
A. Fireplace body 1pc
B. Tempered Glass 4pcs
C. Round Burner 1pc
D. Control tool 1pc
E. Ring 1pc
F. Instruction manual and safety instructions.
Assembly Instructions:
1. Unpack the fireplace and accessories. Check the content for
completeness and any damage incurred in transit. Keep children away
from the packing.
2. The fireplace must only be installed on a solid surface of non-flammable
material
3. Place the fireplace body on a stable surface.
4. Place the ring into the burner( optional)
Caution: Please read the instruction manual of the burner and ring
carefully.
5. Place the burner into the burning chamber of the fireplace body.
6. Insert the glass into the intended slot
7. Assemble the control tool
WARNING: Always maintain a safe distance of at least 1 meter (40in)
from the fireplace when the flame is lit.

3
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
OPERATION INSTRUCTIONS
Step 1: Open the cover of the burner reservoir completely using the control
tool. Fill the burner with the ethanol, pay attention at the “Max” line.
CAUTION: Spilled ethanol must be removed with an absorbent tissue and
cleaned with water to prevent ignition outside the burner reservoir.
Spilled ethanol may lead to matt stains on parquet flooring.
Fuel must be kept in safe distance (min. 1 m/40 inch) to the fireplace. Do not
place fuel in front of the fireplace.
Step 2: Light the ethanol with stick-lighter. Keep a safe distance to the burner.
CAUTION: Fuel will burn low at first. Please allow 15 minutes to reach the
optimum temperature and flame height. Opening or closing the sliding cover
on the burner with the puller can adjust the flame.

4
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
Extinguish ：
CAUTION: Never extinguish the flame with water!
Let the fuel burn out completely if possible. This prevents ethanol left in the
burner and deflagration when reigniting.
If you wish to extinguish the flame before the fuel has completely burned
out. Please use the controlling tool to fully close the sliding cover of the
burner and wait until the flame is extinguished. Wait approximately 20
minutes until the burner has reached room temperature. Only then dispose
of the remaining fuel.
In case the flame is not extinguished immediately. Please close the cover
and wait approximate10-15 minutes to allow the flame to cool down.
Repeat the above instructions until the flame is fully extinguished.
It is urgently recommended that you keep a Class B fire extinguisher at
hand close to the device in case of fire.

5
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
Refill：
CAUTION: Never pour fuel into the burning flame.
WARNING：Allow the burner to cool down for at least 15 minutes before
refilling. Never refill the burner when the fireplace is operating or still hot.
SAFETY INSTRUCTION
When burning Moda Flame Premium Ethanol Fuel, water-vapor and
carbon dioxide are produced.
Never leave an open fire unattended at any time!
In a house of typical construction, that is, one that is not of unusually tight
construction due to heavy insulation and tight seals against air infiltration,
an adequate supply of air for combustion and ventilation is provided
through infiltration. The fireplace should not be used in a small room where
less than 5.7m3 (200ft3) of air space is provided for each 1000 Btu per
hour of fireplace (considering the maximum burner adjustment). Do not
use the fireplace in a bathroom, a room where sleeping accommodation is
provided or any other small room.
CAUTION: Item gets hot while in operation. Do not touch the fireplace
while burning. Please allow at least 15 minutes to cool down before
touching the product after flame is extinguished.
CAUTION: Risk of burns. Do not operate the ethanol fireplace without the

6
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
guard or grille or screen completely attached.
Never pour fuel into an open flame or into the burner reservoir unless it has
cooled down for at least 15 minutes after used.
Do not place any flammable material within 1 meter/ 40 inches around the
fireplace. A safety distance of at least 2 meters/80 inches should be kept
from any window or curtain. Do not burn under over hanging items.
CAUTION: Do not smoke while handling the fuel.
Avoid airflow in the room where the fireplace is operated.
WARNING:
ⅰRisk of Explosion
a.Never use any fuel other than Moda Flame Premium Ethanol Fuel. Never
use gasoline.
b.Never use the appliance in areas where flammable vapors or gas may be
present.
c.Never store or transport the fuel in other than a metal or plastic container
that is acceptable for use with the specified fuel in accordance with the
Consumer Chemicals and Containers Regulations 2001 and is the
original container for the specified fuel.
d.Never store fuel in the living space or in the same location as the
appliance.
ⅱ.Due to high surface temperatures, keep children, clothing, and furniture
away.
ⅲ.Do not use the appliance to heat or boil water or use as a cooking
appliance.
ⅳ.Do not use in a room with Oxygen tanks in use. Do not use the
appliance in a bathroom, a room where sleeping accommodation is
provided or any other small room.
ⅴ.Do not operate without installing the protective screens, grilles, or

7
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
guards.
ⅵ.THIS APPLIANCE HAS NOT BEEN TESTED FOR USE WITH DOORS.
TO REDUCE THE RISK OF FIRE OR INJURY, DO NOT INSTALL
DOORS.
ⅶ. Risk of Indoor Air Pollution - Use ethanol fireplace only in well-ventilated
areas and with doors of adjacent room open. Do not obstruct air flow to the
fuel holder box by piling logs over the fuel holding box, but only around it
and do not obstruct the fuel holder box in any other way or with any other
material. People with breathing problems should consult a physician before
using the ethanol fireplace.
WARNING: THIS APPLIANCE HAS NOT BEEN TESTED WITH AN
UNVENTED GAS LOG SET. TO REDUCE RISK OF FIRE OR INJURY,
DO NOT INSTALL AN UNVENTED GAS LOG SET INTO THIS
APPLIANCE."
CLEANING INSTRUCTION:
After each use, the burner surfaces must be cleaned regularly. Use warm
water and washing-up liquid. If the burner is not cleaned after each use,
bad odors can occur.
Check the sliding cover of burner for warp or damage before each use.
After several uses, the stainless steel burner may discolor depending on
the type of ethanol fuel you use. Rub the burner with a sponge to restore
the original shine of the stainless steel. Marks can be best removed with a
soft cloth and a mixture of lukewarm water and a small amount of cleaning
liquid (ph-neutral). We recommend cleaning the stainless steel items
regularly to prevent contamination.
CAUTION: Never use chemical, steel-wool or scrubbing sponges eight.
These can scratch the surface. The manufacturer cannot be held

8
Moda Flame Pavilion Tabletop Firepit Bio Ethanol Fireplace ©
Instruction Manual
responsible for any damages resulting out of false use and/ or cleaning of
the products.
Warranty:
Our fireplaces are guaranteed 1 year, parts and labor. Warranty begins on the
date of purchase.
Warranty will be applied on presentation of a dated cash receipt and is strictly
limited to factory service repair of the piece or pieces that are found to be
defective. Installations costs will not be reimbursed in any case as damages
for any reason whatsoever. Manufacturer will not be held responsible for any
incidental or consequential defects, on goods or individuals.
The warranty will not be applied if devices have been subjected to abnormal
use or if used under other conditions of use than the ones they were intended
for.
The warranty will not apply in case of deterioration or accident due to
negligence, damages caused by failing to maintain and service the device or
resulting from an alteration of material.
Moda Flame
Tel: [phone]
Email: [email protected]
Website: www.MODAFLAME.com
