Mode Machines Micro Mode Series User manual
1/ 6
F-106
Juno Filter
(Micro Mode Series)
User Manual
November 2012
2/ 6
Contents
F-106 Juno Filter
1. Knobs, buttons & LED
2. Product description
3. Downloads
4. Social Media
!
1. Knobs ,buttons & LED
3/ 6
Synthesizer Section
F-106 Juno Filter
2. Product description
Thank you for your purchase of the MODE MACHINES F-106 "Juno-Filter". This is an
analog device based on some of the original circuitry of the famous Juno 106."
You can use the F-106 to modulate audio signals and also connect external devices using
the CV inputs to control the functions of the unit.
KNOBS:
""""""""""""""
•CUTOFF: will adjust the cutoff of the lowpass filter
•RESONANCE: will adjust the resonance (feedback) of the filter
•VCA: will adjust the audio output level
SWITCHES:
•24dB / 12dB: will select the filter type , 24 or 12dB/OCT
•SELF OSC: will enable self-oscillation
•POWER: turns unit on/off
Connections:
•AUDIO OUT: audio output 6.35mm mono jack
•AUDIO IN: audio input 6.35mm mono jack
•FREQ–CV: input for cutoff (0 – 5V) 3.5mm mono jack
•RESO–CV: input for resonance (0 – 5V) 3.5mm mono jack
•VCA–CV: input for VCA (0 – 5V) 3.5mm mono jack
•POWER: 12 to 20VDC input. + on center pin.
•Power consumption: <100mA @ 12VDC
•Audio:"~30Hz to >15KHz
4/ 6
Control Panel
F-106 Juno Filter
3. Downloads
5/ 6
Downloads
F-106 Juno Filter
Dear customer,
we have provided an extensive offer of free data to download on our website. Here you
can find all pictures and documents of the required products.
Product-related you can find all instructions to the respective products also in other
languages. These are provided as a PDF file free of charge to download.
We are happy to offer you any time an extensive service.
If there are any questions for a product or a question including the manual you please
send us an e-mail. We are happy to help you!
4. Social Media
www.modemachines.com
www.facebook.com/mode machines
www.twitter.com/mode machines
www.flickr.com/photos/modemachines
www.myspace.com/modemachines
www.modemachines.tumblr.com
www.youtube.com/modemachinesofficial
