1
MODECOM
Quick Installation Guide
MC-106USB
WLAN USB Adapter

2
Package Contents
The MODECOM MC-106 USB package includes the following.
Wireless USB
Adapter
Quick Installation
Guide
AUTORUN CD
MODECOM MC-106 USB Overview
Wireless USB Adapter has the USB interface and LED below.
Interface
USB Interface: Connect the USB Interface to a USB port on your computer.
LED Description
LED: The LED stays lighted to indicate WLAN link established and active.
Wireless USB Adapter Installation
The following instructions will guide you to through the process of installing
the Wireless USB Adapter.
GB
MC-106USB
WLAN USB Adapter

3
Windows Vista/XP/2000/ME/98SE
Step 1:
The following illustrations of installation procedures are from Windows Vista.
And these procedures are all similar to the operating procedures on Windows
98SE/ME/2000 and XP.
As Windows starts it will detect that new hardware has been added, and start
the "Found New Hardware Wizard “. Click on“Cancel “.
Step 2:
Please insert the AUTORUN CD into your CD-ROM drive.
The CD should auto-start, displaying the following window. If it does not start,
click on Start – Run and type in CD:\autorun.exe (where CD is the drive letter
of your CD-ROM drive.) Click "Driver Installation".

4
Step 3: (For Vista User only)
For Security reasons VISTA requires the installer program to have administra-
tor privileges so the new policy called “User Account Control“ has been intro-
duced in Windows VISTA. If UAC is enabled Windows pops up a window “User
Account Control“ Windows need your permission to continue. User needs to
Click “Continue“ to proceed with the installation.
Step 4:
Click “Next“.

5
Step 5:
Click “Next“.
Step 6:
Click “Install“.

6
Step 7:
For Windows 2000/XP and Vista User, just click“ Finish “.
For Windows 98SE and ME User, you will need to restart the computer.
Making a Basic Wireless Network Con-
nection
For Windows XP/Vista users, your native Windows XP/Vista wireless support
(Wireless Zero Conguration Service) has been disabled by default.
Infrastructure mode
An Infrastructure Mode network contains at least one wireless client and one
wireless AP or router. This client connects to Internet or intranet by communi-
cating with this wireless AP or router.
Step 1:
Double click the icon on your desktop to start the utility or in the task
bar.

7
Step 2:
Click the“ Available Network“ button to scan available access points.

8
Step 3:
Double click on the SSID of AP that you are going to connect to and create pro-
le that you are connecting to an open (Encryption is None) wireless network
for example the SSID is ssid3915.
Step 4:
Click the“ OK“.

9
Step 5:
Click the“ OK“.
Step 6:
Now you are ready to use the Wireless Network to Internet or intranet.

10
Note: This example is an open wireless network. If you are going to connect to
a Wireless adapter with security protection, you will have to congure the en-
cryption settings in this prole to be corresponding to the other wireless adapt-
er. Please click on the “ Network Authentication “ drop-down list to select an
authentication method, and then select a “ Data encryption “ type. Fill in each
required blanks and click “ OK “.
Environment protection:
This symbol on our product nameplates proves its compatibility
with the EU Directive2002/96 concerning proper disposal of
waste electric and electronic equipment (WEEE). By using the ap-
propriate disposal systems you prevent the potential negative
consequences of wrong product take-back that can pose risks to
the environment and human health. The symbol indicates that this product
must not be disposed of with your other waste. You must hand it over to a des-
ignated collection point for the recycling of electrical and electronic equipment
