Modern Forms FH-W1803-44L-BZ User manual

Axis 44 Flush
Installation Instructions
works with the
Google Assistant

FH-W1803-44
Axis Flush Instructions2
Please read and
save these instructions
before installation
DO NOT RETURN TO STORE

FH-W1803-44 Axis Flush Instructions 3
For all questions about your ceiling fan please read all included
instructions, installation procedures, troubleshooting guidelines
and warranty information before starting installation.
For missing parts or general inquiries call our trained technical staff at:
1-866-810-6615 option 0
MON-FRI 8AM-8PM EST
Email: [e-mail]
Or live chat at modernforms.com
For fast service have the following information below when you call:
1. Model Name and Number
2. Part Number and Part Description
3. Date Of Purchase and Purchase Location
1-866-810-6615 option 1
MON-FRI 8AM-8PM EST
Email: [e-mail]
General Inquiries
Fan Support

FH-W1803-44
Axis Flush Instructions4
For operation, maintenance, and troubleshooting information,
visit http://modernforms.com/fan-support/
To reduce the risk of electric shock, ensure electricity has been turned off at the circuit breaker
before beginning. All wiring must be in accordance with the National Electrical Code “ANSI/NFPA
70” and local electrical codes. Electrical installation should be performed by a licensed electrician.
The fan must be mounted with a minimum of 7 ft. (2.1m) clearance from the trailing edge of
the fan blades to the floor and a minimum of 1.5 ft (0.5m) from the edge of the fan blades to the
surrounding walls. Never place objects in the path of the fan blades. To avoid personal injury or
damage to the fan and other items, please be cautious when working around or cleaning the fan.
To avoid electrical shock or damage to the motor or finish, do not use water or chemicals
when cleaning the fan or fan blades. A dry cloth or lightly dampened cloth will be suitable
for most cleaning.
After making electrical connections, spliced conductors should be turned upward and pushed
carefully up into the outlet box. The wires should be spread apart with the grounded conductor and
the equipment-grounding conductor on one side of the outlet box, and the ungrounded conductor
on the other side of the outlet box.
All set screws must be checked and re-tightened
where necessary before installation.
Safety Rules

FH-W1803-44 Axis Flush Instructions 5
WARNING:Do not install or use your fan if any part(s) is/are damaged or missing. This product
is designed for use only with the supplied parts and/or accessories designated for use with this
product by Modern Forms . Substitution of parts or accessories not designated for use with this
product by Modern Forms could result in personal injury or property damage and will void the
warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
WARNING:To reduce the risk of electric shock, this fan must
be installed and operated with the supplied wall control, or controlled from the Modern Forms app
or Wi-Fi Touch Panel Wall Control (not included).
WARNING:Do not use power tools to assemble or install your fan. Using power tools can result in
improper assembly which can lead to noise or fan damage,personal injury or property damage.
WARNING:To reduce the risk of personal injury, do not bend the blade arms when installing the
brackets, balancing the blades or cleaning the fan.
WARNING: Do not insert foreign objects between rotating fan blades.
WARNING:Do not operate fan unless fan blades are in place. Noise and fan damage can occur
WARNING:This appliance is not intended for use by young children without supervision.
WARNING: To reduce the risk of fire, electric shock, personal injury or damage to the fan or other
items, the outlet box and support structure must be securely mounted and capable of reliably
supporting a minimum of 35 Ibs (15.9 kg). Use only UL/cUL listed outlet boxes marked “FOR FAN
SUPPORT.” Use only the screws and washers provided with the outlet box.
CAUTION:Before assembling your fan, refer to the “Making the Electrical Connections“
section. If you feel you do not have enough wiring knowledge or experience, have your fan
installed by a licensed electrician.
NOTE:Before servicing or cleaning the fan, switch power off at the circuit breaker.

FH-W1803-44
Axis Flush Instructions6
Get Smart...
Integrates
seamlessly with:
devices you already own
works with the
Google Assistant
Get Smart...
Integrates
seamlessly with:
devices you already own
works with the
Google Assistant
Premium smart
features:
Accessories:
DC
MOTOR
complement high quality materials
personalize your experience
Quiet, reliable, and up to 70%
more ecient than AC fans
Wi-Fi and Bluetooth enabled
for exible control
Bluetooth Wall Control
Dims light to 1% | ON/OFF
6 fan speeds | Sold separately
F-WCBT-WT White
Bluetooth Remote Control
Dims light to 1% | ON/OFF
6 fan speeds
F-RCBT-WT White
Wet Location-listed to the strictest
UL/cUL safety regulations. Finished
and rated for interior and exterior use

FH-W1803-44 Axis Flush Instructions 7
Contents
Tools Required
1. Mounting Options 10
2. Installing the Mounting Bracket 10
3. Hanging the Fan 12
4. Attaching the Fan Blades 14
5. Making the Electrical Connections 14-16
6. Installing the Optional Wall Control 18
7. Finishing the Installation 20
8. Installing the Adapter Plate 20
9. Installing the LED Luminaire Module/Cover 22
10. Controlling the Fan 24
11. Reset 26
12. Breeze Mode 26
13. Application 26
14. Accessories 28
15. Troubleshooting 29-32

FH-W1803-44
Axis Flush Instructions8
Package Contents
7. Glass Shade
RPL-F1803-GLA
8. Luminaire Cover
RPL-FH1803-COVER-**
9. Control Receiver
w/Hardware
F-R3-1803-0**
10. Remote w/Wall Cradle
F-RCBT-WT
Hardware Bag
RPL-AXISFLUSH-PART
1. Blade Set of 3
RPL-F1803-**-BD-**
2. Hanger Plate
RPL-F1803-HGR
3. Trim Ring - Decorative
RPL-FH1803-TRIM**
4. Motor Assembly
5. Adapter Plate
6. LED Module
F4IN-120V-R1-30
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
** denotes finish code of fan/blade sweep
of fan
AMachine Screws (2)
Spring Washers (2)
Flat Washers (2)
BWood Screw (1)
Spring Washer (1)
Flat Washer (1)
CWire Nuts (8)
DScrew with Fiber Washers (10)

FH-W1803-44 Axis Flush Instructions 9
10
4
9
8
7
5
6
3
2
1
IMPORTANT: Please make note
of the MAC ID on the
receiver and keep it in a
safe place.
MACID
Hanging Weight: 13 lbs

FH-W1803-44
Axis Flush Instructions10
1. Mounting Options
CAUTION: To prevent electrical shock, ensure electricity has been
turned off at the circuit breaker before beginning.
If there isn’t an existing UL/cUL listed outlet box, please refer to the
following instructions. Secure the outlet box directly to the building
structure. Use appropriate fasteners and building materials. The outlet
box and support structure must be able to fully support the moving
weight of the fan (at least 35 lbs/15.9 kg). Do not use plastic outlet
boxes. Use only UL/cUL listed outlet boxes marked
“FOR FAN SUPPORT.”
Secure the outlet box directly to the building structure.
Figures 1-1C are examples of different ways to mount the outlet box.
NOTE: To hang your fan where there is an existing fixture but no
ceiling joist, you may need an installation hanger bar.
1. Disconnect power to the fan location at the breaker. A licensed
electrician must install the fan.
2. There are four screws on top of the motor assembly. Remove two
that are on the opposite of each other and save for the Finishing
the Installation section. Loosen remaining two.
3. Pass the 120-volt supply wires through the center hole in the
ceiling mounting bracket as shown (Fig. 2).
4. Secure the hanger plate to the ceiling outlet box with the screws
and washers provided (Fig. 2).
REMEMBER to turn off power at the breaker.
Follow the steps below to hang your fan properly:
2. Installing the Mounting Bracket

FH-W1803-44 Axis Flush Instructions 11
1
1A 1B
2
2
1
2
2
3
1. Support Brace
2. Outlet Box
3. Joist

FH-W1803-44
Axis Flush Instructions12
3. Hanging the Fan
REMEMBER to turn off power at the breaker.
Follow the steps below to hang your fan properly:
Disconnect power at the breaker to the fan location.
Check your outlet box to make sure it has a proper Hot, Neutral,
and Ground. If not, you will need to consult with a licensed
electrician to install a new cUL/UL outlet box (Fig. 3).
1. Remove 1 of 2 screws from the bottom of mounting bracket
and save for use in the Finishing the Installation section. Loosen
the other screw (Fig. 3).
2. Pass the 120-volt supply wires through the center hole
in the ceiling mounting bracket as shown in (Fig. 3A).
3. Secure the mounting bracket to the ceiling outlet box with
the screws and washers provided with your fan.
Use A hardware.
4. Lift motor assembly and hang it on the hook of mounting bracket
using one of the screw holes (Fig. 3B).
5. Secure the safety cable to the building structure using spring
washer, flat washer, and wood screw provided (Fig. 3B).
Use B hardware.
NOTE: Safety cable is required for all installations in Canada. Safety
cable is required for ceiling fan and light combinations over 35 lbs. in
both flush and downrod models in the United States.

FH-W1803-44 Axis Flush Instructions 13
Follow the steps below to connect the fan to your household wiring. Use the plastic wire nuts with your fan.
Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections.
3 3A
3B 3C
1. Screws
2. Top Assembly
A A
B B
4
4
3
3
2
2
1
1
DO NOT SCALE DRAWING
UPWARD MOUNTING BRACKET
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:5
WEIGHT:
REV
DWG. NO.
B
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
1
2
1. Wood Screw
2. Safety Cable
3. Trim Ring
4. Top Assembly
2
1
3
4
1. 120V Wires
2. cUL Listed Electrical Box
3. Mounting Plate
4. Mounting Screws
(supplied with outlet box)
1
23
4
1. cUL Listed Electrical Box
2. Mounting Screws
(outlet box mounting screws
not included)
3. 120V Wires
2
3
1
To Switch A
A
B
(HOT)
(Neutral)
(HOT)/
Switch
(No Neutral)
(Ground)
*Bare or Green
(Ground)
*Bare or Green
To Switch

FH-W1803-44
Axis Flush Instructions14
1. Insert the blade through the slot in the housing. Align the holes
in the blade with the fan motor assembly holes and secure with
blade attachment screw with lock washers (Fig. 4).
Use C hardware.
2. Repeat this procedure with the remaining blades.
4. Attaching the Fan Blades
5. Making the Electrical Connections
WARNING: Installation of this fan requires that a three-conductor
cable (including ground and neutral wires) which should run between
ceiling and wall outlet box.
WARNING: Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire nuts,
except for the ground wire. Use electrical tape as needed.
Before inserting and wiring the receiver - make note of the MAC ID on
the receiver.
Insert the receiver into the motor assembly with the flat side of the
receiver facing the ceiling (Fig. 5).

FH-W1803-44 Axis Flush Instructions 15
4
1. Screws with
Rubber Washers
2. Slot
3. Top Assembly
1
3
2
5
1
3
2
1. Motor Assembly
2. Receiver
3. Trim Ring

FH-W1803-44
Axis Flush Instructions16
5. Making the Electrical Connections
Motor to Receiver & Receiver to house supply wires (Fig. 5A).
1. Connect the motor assembly ground wire, mounting bracket
ground wire and receiver ground wire to the ground wire in
outlet box.
WARNING: Failure to connect ground wires could result in
poor fan control functionality.
2. Connect the red wire from the fan to the red wire marked
“TO MOTOR” from the receiver.
3. Connect the grey wire from the fan to the grey wire marked
“TO MOTOR” from the receiver.
4. Connect the yellow wire from the fan to the yellow wire marked
“TO MOTOR” from the receiver.
5. Connect the white wire from the fan to the white wire marked
“FOR LIGHT” from the receiver.
6. Connect the black wire from the fan to the blue wire marked
“FOR LIGHT” from the receiver.
7. Connect the black (hot) wire from the ceiling to the black wire
marked “AC in L” from the receiver.
8. Connect the white (neutral) wire from the ceiling to the white
wire marked “AC in N” from the receiver.

FH-W1803-44 Axis Flush Instructions 17
Follow the steps above to connect the fan to your household wiring. Use the plastic wire nuts with your fan.
Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections.
5A
Black(Hot)
can be RED from Switch leg
Black(Line in H)
RED(to Motor)
GREEN(Ground)
BLUE (to Light)
BLUE (for Light)
GREEN(GND Must Use)
GREEN(Hanger Assembly Ground)
RED(to Motor)
GREY(to Motor)
WHITE(Neutral)
WHITE(to Light)
WHITE(Neutral)
GREY(to Motor)
YELLOW(to Motor)
WHITE(Line in N)
YELLOW(to Motor)
Outlet
Box
Receiver
HARDWARE USED:
D- Wire Nuts

FH-W1803-44
Axis Flush Instructions18
6. Installing the Optional Wall Control
NOTE: A Bluetooth wall control accessory can be purchased separately.
1. Connect the green wire marked “GROUND” from the wall
control to the copper wire from the wall outlet box that
feeds back to the circuit breaker – important for proper
fan function (Fig. 6).
2. Connect the black wire marked “LINE IN” from the wall control to
the black LINE VOLTAGE wire from the wall outlet box that feeds
back to the circuit breaker (Fig. 6).
3. Connect the red wire from the wall control to the black wire from
the wall outlet box that feeds up to the fan (Fig. 6).
4. Connect the white wire from the wall control to the white
(neutral) wire from the wall outlet box (Fig. 6).
5. Carefully tuck the wire connections inside the outlet box.
Secure the wall control with the two (2) wall control screws
provided (Fig. 6A).
6. Attach the wall mounting plate over the wall switch and secure
with the two (2) wall mounting plate screws provided (Fig. 6A).
7. Fasten the wall plate to the wall mounting plate (Fig. 6A).
6
Wall Switch WiresHouse Wires
(Hot In)
(Neutral)
(Ground)
(Hot out to Fan)
Fan Switch leg
(Copper/Ground)
(Neutral)
(Hot)
to Fan
From Breaker
* Home Wiring may vary

FH-W1803-44 Axis Flush Instructions 19
6A
Multi-location wiring
1 2 3
54
1. Wall Outlet
2. Wall Control
3. Wall Mounting Plate
4. Mounting Plate Screws
5. Wall Plate
Individually pair each of the wall controls with the fan
receiver using the pairing instruction. See page 22.
Line/Hot
Red
Green (Green or Bare)
Wallcontroller 1 Wallcontroller 2 Wallcontroller 3
If Applicable
FAN
Neutral/White
Wall Control 1 Wall Control 2 Wall Control 3

FH-W1803-44
Axis Flush Instructions20
7. Finishing the Installation
1. Secure all wire connections with supplied wire ties to assist in canopy
installation.
2. Tuck connections neatly into ceiling outlet box.
3. Remove the motor from the hook on the mounting bracket. Slide the
motor up to the mounting bracket and place the key hole on the motor
over the screw of the mounting bracket (Fig. 7).
4. Turn motor until it locks in place at the narrow section of the
key holes.
NOTE: Make sure the receiver sits flat and does not interfere with
the hook.
5. Align the circular hole on canopy with the remaining hole on the
mounting bracket. Secure by tightening the two screws previously
loosened and the two screws previously removed.
6. Raise up trim ring and line up the 4 tabs with the 4 grooves on the
mounting bracket. Once lined up, slide the trim ring and secure it to
the canopy until snug.
1. Remove one of the three mounting plate screws from the
mounting ring and loosen the other two screws (do not remove).
2. Place the key holes in the mounting plate over the two screws
previously loosened from the mounting ring. Turn the mounting
plate until the adapter plate locks in place at the narrow section
of the key holes (Fig. 8).
3. Tighten the two mounting ring screws previously loosened and
the one previously removed to secure adapter plate.
8. Installing the Adapter Plate
