Moduspace MAX Series User manual

MAX Series
MAX70/70plus/150/150plus

Quick overview of aluminum frame
Front Frame
Side frame back bar
Joints uses M5x20mm (3/4”) bolts x 32 and washers x 32

*Note
If you have adjoining displays, please DO NOT insert Rubber slots on the back of the front frame and
Side frame bar before assembly of displays.

Horizontal bracket
Horizontal bracket
screws (Shorter)
Horizontal bracket
nuts
Cleaning cloth
Allen wrench for display
Vertical bracket
screws
Vertical bracket
Footpad
Allen wrench
for vertical
bracket
Safety screw
Washer for display’s screws
Display frame screws (Longer)

*Orientation of Front frame
Centre screw hole upward
Lips facing outward
*Rubber slot facing up
Insert rubber slot if you are
installing the sidepanel.
*The rubber slot facing inward, opposite of the
front frame lips

Side panel
Side panel

Top panel

Side frame Back Bar
bar
Side frame Back Bar
bar
*Do not tighten the bolts

*Leave at least a 5mm or ¼” gap

*Flip the display 180 degrees
Back panel
