USER MANUAL
Thermostat Heating/Cooling
AR HK 4010 K

16
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Congratulations on your purchase
of this high-quality product. Func-
tionality and design are combined in
the series of Thermostats. Each Ther-
mostat is a perfect match for indivi-
dual room decoration and through
precise heat control enables a room
climate that completely meets your
individual needs.
It is our natural endeavor and goal
to produce products for customers
to enjoy with satisfaction in the ye-
ars to come.
Our products are used worldwide
and meet the future market require-
ments in this branch through ability,
design, and functionality.
Dear Customer
Introduction....................................17
Product Description ...................17
Product Description ...................18
Product Includes.........................18
Safety..............................................19
Safety Instructions .....................19
Installation......................................20
Installation .................................20
De-Installation............................20
Operation Guidelines.....................21
Temperature Selector ................21
Temperature Range Limitors.....21
Switch Ball..................................22
Indicator Symbol ICE CRYSTAL ..22
Indicator Symbol MOON ...........22
Energy Saving Mode..................23
Blocking „Cooling“ mode .........24
Replacement of Fuse .................24
Electrical Installation .................25
Technical Data ................................26
Dimensions (mm) .......................26
Functional Overview..................26
Technical Data............................27
Content

17
ENG
DEU
FRA
ITA
SPA
NLD
RUS
The Thermostat Heating/Cooling is room-thermostat working with Pulse Width
Modulation (PWM) to control thermoelectric Actuators. This enhanced way of
control enables a perfect and precise temperature regulation of heating/coo-
ling systems.
The desired room temperature is adjustable in ¼ degree steps. A switch ball
selects the operating mode to turn ON, OFF or set to AUTOMATIC the energy
saving mode (HEATING: Temperature Setback / COOLING: Temperature Setup) .
For the connection and installation of the room thermostat the Mounting Base
AS 1000 is used. It is possible to attach the Thermostat on the Mounting Base at
any time after the construction phase. A separate installation manual with a
detailed clamp connection is delivered with the Mounting Base AS 1000.
Introduction
Product Description

18
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Latch: to lock Thermostat to Mounting Base
Energy Saving Mode: defined temperature setback of 2 K to 6 K
(HEATING)
defined temperature setup of 2 K to 6 K
(COOLING)
Temperature Selector: to set desired room temperature
Switch Ball: Selection of operational mode
(Energy Saving Mode [ON/OFF/AUTOMATIC])
Product Description
Product Includes
Thermostat Heating/Cooling
(1 pcs.)
User Manual
(1 pcs.)

19
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Intended use
In the design variant Heating/Cooling Comfort, the thermostat is an
electronic room temperature thermostat for the electric readjust-
ment of water-bearing heating and cooling systems. In this scope,
this system may only be used for the control of thermal actuators.
The manufacturer cannot be held liable for improper use.
Authorised specialists
The electrical installations must be performed according to the
current VDE regulations as well as according to the regulations of
your local electric power utility company. These instructions require
special knowledge corresponding to an officially acknowledged
degree in one of the following professions:
- Electrical Equipment Installer or Electronics Engineer
- Systems Mechanic for sanitary, heating and air condition
technology
according to the profession designations officially announced in
the Federal Republic of Germany, as well as according to compara-
ble professions within the European Community Law.
Sources of danger
Thermostats must be disconnected from the electric supply before
opening them. Only use a dry and solvent-free, soft cloth for clea-
ning.
Emergency
De-energise the entire single room regulation system.
Safety Instructions
Safety

20
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Installation
De-Installation
123
45 6
123
Installation

21
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Temperature Selector
Operation Guidelines
























Selector for desired temperature with „soft click“
notches. The desired room temperature is adjustable
in 1/4 degree steps.Temperature scale in °C.
Temperature Range Limitors

22
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Switch Ball
Energy saving mode „ON“. Independently of
external signals, the temperature setback is
activated manually and the temperature is
reduced/increased by 2-6 K.
Energy saving mode „OFF“. No temperature
setback / setup in this mode.
The thermostate works in normal mode.
Energy saving mode „AUTOMATIC“. Depending on the signal from a HKmo-
dul or a timer ,the energy saving mode is turned on resp. turned off.
(ON: connected to L1)
Indicator Symbol ICE CRYSTAL
The symbol ICE CRYSTAL illuminates when the
mode COOLING is active. The Change-Over input is
connected through an external contact with L1
or the thermostat receives the signal COOLING.
through the setback channel of a Basis HKmodule.
When using a HK-module the CO-Output is not
inquired.
Indicator Symbol MOON
MOON illuminates, if temperature setback is
activated.

23
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Energy Saving Mode
The selectable tempera-
ture setback resp. setup
can be adjusted between
2 K to 6 K of the set
desired temperature. If
the energy saving mode
(temperature setup) is
activated in the COO-
LING mode, the desired
temperature is raised.
Energy is saved.
 
�

Beneath the tempera-
ture selector is selector
for energy saving mode
(temperature
setback / setup) is
located.


 












Setting of temperature
setback or setup.

24
ENG
DEU
FRA
ITA
SPA
NLD
RUS
Blocking „Cooling“ mode
Only in conjunction with Basis and HK-
Modul 4000! Link L1 and Input Change-
Over using a 4-lead wire.



Mounting Base
(bottom side)
Replacement of Fuse
The replacement of the
fuse can be done by
yourself. It is possible
that a defect fuse is the
cause for a major mal-
function of your system,
which can be only be
fixed by an authorized
and qualified specialist.


 






