Moffat Turbochef C3 User manual

ExtErior ConstruCtion
n430 stainless steel front, top, sides and back
n4" (102 mm) adjustable legs
nPowder coated handle
nCool to the touch pull down door with microwave seal
intErior ConstruCtion
nFully insulated and sealed cook chamber
n304 stainless steel liner with large radius corners
n304 stainless steel removable grease collection pan
standard FEaturEs
nIntegral recirculating catalytic converter system for UL listed
ventless operation (UL KNLZ)
nVariable speed High H recirculating
impingement airflow system
nForced vertical recirculated impingement hot air system
nBottom-launched microwave system
nSmart Menu System capable of storing up to 128 receipes
nBuilt-in self-diagnostics for monitoring oven
components and performance
nStackable design (requires stacking kit)
nIncludes plug and cord (5 ft.)
nCatalytic Converter eliminates flavor transfer between foods,
reduces emissions/qualifies for ventless operation
nCeramic cooking platter
PErForManCE
n The C3 roasts, browns, and
carmelizes a wide variety of foods
up to 10x faster and at a quality that
meets or exceeds traditional cooking
£°ÊÜiÀÊÌÀ
Ó°Ê«}i`ÊÀÊ
ΰÊVÀÜ>ÛiÊÕÀÃÌÃ
{°Ê«}iiÌÊi>ÌiÀ
x°Ê>Ì>ÞÌVÊÛiÀÌiÀ
Ó
x
£
{
1. Blower Motor
2. Impinged Air
3. Microwave Bursts
4. Impingement Heater
5. Catalytic Converter
*This product conforms to the ventilation recommendations set forth by NFPA96 using EPA202 test method.
C3
thE C3
Accelerating the World of CookingTM

C3
PLUG
29” (736 mm)
21.5”
(546 mm)
21.5”
(546 mm)
29.5” (749 mm)
11.5” (292 mm)
25.5”
(648 mm)
Australia
www.moffat.com.au
New Zealand
www.moffat.co.nz
Australia
Moffat Pty Limited
Victoria/Tasmania
740 Springvale Road
Mulgrave, Victoria 3170
Telephone [phone]
Facsimile 03-9518 3833
Email [email protected]
www.moffat.com.au
New South Wales
Telephone [phone]
Email [email protected]
South Australia
Telephone [phone]
Email [email protected]
Queensland
Telephone [phone]
Email [email protected]
Western Australia
Telephone [phone]
Email [email protected]
New Zealand
Moffat Limited
Christchurch
Telephone [phone]
Email [email protected]
www.moffat.co.nz
Auckland
Telephone [phone]
Email [email protected]
Accelerating the World of CookingTM
ELECTRICAL SPECIFICATIONS
EUROPE/ASIA/PACIFIC/AUSTRALIA
C3/C Multi Model (3 Phase, TC3-0602-1w)
Phase 3 Phase
Voltage 380-415 VAC
Frequency 50 or 60 Hz
Current 16 amp
Cord 5 Wire (inc. ground), 1.5m;
H07RN-F
Plug IEC 309, 5 pin, 32 amp,(red)
Max Imput 7.4 kW
Microwave Power In 2 kW
C3/C Multi Model
Phase 3 Phase
Voltage 230 VAC
Frequency 50 Hz
Current 30 amp
Cord 4 Wire (inc. ground)
Plug IEC 309, 4 pin, 32 amp, (blue)
Max Imput 7.4 kW
DIMENSIONS
Single Units
Height 21.5” (546 mm)
on legs 25.5” (648 mm)
Width 29” (736 mm)
Depth 29.5” (749 mm)
with handle 32.25” (819 mm)
Weight 255 lbs. (116 kg)
Stacked Units
(Stacking Kit Required)
Height 43” (1092 mm)
Width 29” (737 mm)
Depth 29.5” (749 mm)
with handle 32.25” (819 mm)
Weight 510 lbs. (231 kg)
Cook Chamber
Height 7.1” (180 mm)
Width 17.8” (452 mm)
Depth 14.5” (368 mm)
Volume 1.1 cu. ft. (31 liters)
Wall Clearance
Top/Sides 2” (51 mm)
NEMA
6-30
IEC 309, 5-pin,
16 amp
IEC 309, 3-pin,
32 amp
IEC 309, 4-pin, 32
amp for C3
IEC 309, 4-pin,
32 amp
All ED Ovens
*All C3 multi-phase ovens can be field configured to allow single to
3 Phase operation.
**TurboChef recommends installing a type D circuit breaker for all installations.
