Technical data sheet for
ELECTRIC RANGE STATIC OVEN 900mm
RN8610E, RN8613E, RN8616E, RN8619E
Heavy-duty construction
2.4kW open radiant elements
Optional hot plate elements
300mm, 600mm and 600mm griddle plate
options
GN 2/1 6.5kW electric static oven
Drop down door
Stainless steel exterior
Easy clean
Easy service
Fully modular
Overall Construction
• Galvanized steel chassis
• Welded hob with 1.5mm 304 stainless steel bull nose
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel
with adjustable feet
Cooktop
• 2.4kW open radiant elements in heavy-duty welded element frames
• Vitreous enamelled element module and hob spill trays
• Hot plate elements with machine finished 8mm steel plate
(optional extra)
• 12mm thick mild steel griddle plates
• 2.5mm 304 stainless steel griddle splash guards
• Aluminised steel internal construction
Griddle sections are standard on RH side. Available on LH side or centre
to order.
Oven
• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 6.5kW heating elements
• Welded frame drop down door with heavy-duty spring hinge system
• 0.9mm 304 stainless steel door outer
• 1.0mm press formed vitreous enamelled door inner
• High density fibreglass insulated
• Stay cool stainless steel door handle with cast metal handle mounts
• Supplied with two chrome wire oven racks
Controls
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
Cooktop
• Radiant elements with energy regulator controls
• Hot plate elements with energy regulator controls
• 50-320˚C thermostat per 300mm griddle section
• Indicator lights for power and heating for each element control
Oven
• Separate temperature and top heat power regulation controls
• 50-320˚C thermostatic control
• Lo-Hi top heat control
• Indicator lights for power and heating
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Removable vitreous enamelled element module and hob spill trays
• Hinge up element and griddle sections
• Removable oven racking and sole plate
• Easy clean vitreous enamel oven and door inner
• Door hinge spring adjustable on unit (door outer removed)
• Door disengages for lift off removal and increased service access
• All parts front accessible from installed position
• Access to all parts from front of unit

Australia
Moffat Pty Limited
Victoria/Tasmania
740 Springvale Road
Mulgrave, Victoria 3170
Telephone [phone]
acsimile 03-9518 3833
[email protected]
New South Wales
Telephone [phone]
[email protected]
South Australia
Telephone [phone]
[email protected]
Queensland
Telephone [phone]
[email protected]
Western Australia
Telephone [phone]
[email protected]
New Zealand
Moffat Limited
Christchurch
Telephone [phone]
[email protected]
Auckland
Telephone [phone]
[email protected]
Australia
www.moffat.com.au
New Zealand
www.moffat.co.nz
ISO9001
All Waldorf products are designed and
manufactured by Moffat using the
internationally recognised ISO9001 quality
management system, co ering design,
manufacture and final inspection, ensuring
consistent high quality at all times.
ISO9001
Quality
Management
Standard
Designed and manufactured by
In line with policy to continually de elop and
impro e its products, Moffat Limited reser es
the right to change specifications and design
without notice.
Technical data sheet for
ELECTRIC RANGE STATIC OVEN 900mm
Specifications
Cooktop
2.4 kW Open Radiant elements
2.0 kW Hot Plate elements
3.6 kW Griddle elements
(per 300mm griddle section)
Oven
4.5kW bottom heat element
2.0kW top heat element
Electrical requirements
RN8610E 20.9 kW
RN8613E 19.7 kW
RN8616E 18.5 kW
RN8619E 17.3 kW
Electrical connection
20.9 kW max
400-415Vac, 50/60hz,3P+N+E
L 1 29.3A max
L2 29.3A max
L3 28.3A max
Griddle Plate
300mm Griddle cooking surface
292mm x 475mm, 1387cm2
600mm Griddle cooking surface
592mm x 475mm, 2812cm2
900mm Griddle cooking surface
892mm x 475mm, 4237cm2
Oven Dimensions
Width 665mm
Depth 650mm
Height 400mm
Rack size 650mm x 600mm
Rack positions 4
Electrical connection
69mm from RH side, 484mm from rear,
and 150mm from floor
Dimensions
Width 900mm
Depth805mm
Height 915mm
Incl. splashback 1130mm
Packing data
1.02m3
Width 940mm
Depth865mm
Height 1255mm
Options at extra cost
Hot plate elements
(replace individual open radiant elements)
Ribbed griddle plates
Joining caps
Castors
Plinth mounting
RN8610E, RN8613E, RN8616E, RN8619E
