Moffat Turbofan SEL150CX User manual

Specification Information
Installation Information
Model No.: SEL150CX
50.5kW
Client to provide the following connections:
Oven requires direct wiring from switchboard. Note: element wattage may vary by 5%
Water connection ½” BSP
Drainage connection ½” copper drain pipe
Power: 3P + N + E, 400 - 415V, 50 Hz
(48kW heating 2.5kW motors)
Connections: ½” BSP water supply connection and ½” copper drain located at rear of oven
Dimensions: Width:1650mm
Depth: 1720mm (includes canopy)
Height: 2700mm (includes canopy)
Weight: 850kg
Note: Oven supply does not include canopies and flues as required by relevant authorities.
Bends or offsets in the flue restrict gas velocity and must be allowed for when designing
the flue height and diameter which will be dependent on the building and local
conditions.
A flue connection is required and is not included in the contract.
Exhaust flue - 200mm in dia (canopy models), 100mm dia (non canopy models)
Clearance: 50mm clearance is required at back and sides of unit
Minimum 2900mm ceiling height
Floor: A concrete or tile surface is preferred.
The floor area is to be flat to within 3mm over whole floor area.
Access: Oven is supplied partially assembled to be fully erected on site.
Largest piece if partially assembled 2130mm H x 1650mm W x 1220mm D
Largest piece if unassembled 2130mm H x 1650mm W x 660mm D
TECHNICAL SPECIFICATIONS
TURBOFAN 150 (Electric)
