Moffat 350A4502P554 Original instructions

Top Load Models
Owner’s Manual &
Installation Instructions
Washer
350A4502P554 189D3768P001
Safety Instructions . . . . . . . . . . .2, 3
Operating Instructions
Control Panel . . . . . . . . . . . . . . . . . .4
Control Settings . . . . . . . . . . . . . . .5
Features . . . . . . . . . . . . . . . . . . . . . .5
Loading and Using
the Washer . . . . . . . . . . . . . . . . . . . 6
Installation Instructions . . . . .7-11
Troubleshooting Tips . . . . . .12–14
Consumer Support
Consumer Support . . . . . . . . . . . .18
Product Registration . . . . . . .15, 16
Warranty . . . . . . . . . . . . . . . . . . . . .17 La section française commence
à la page 19
Manuel d’utilisation
et instructions d’installation
Laveuse

2
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips
■Install or store where it will not be exposed to
temperatures below freezing or exposed to the
weather, which could cause permanent damage
and invalidate the warranty.
■
NOTE: This appliance must be properly
grounded, and electrical service to the washer
must conform with local codes and ordinances
and the latest edition of the National Electrical
Code, ANSI/NFPA 70.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, personal injury,
or loss of life.
WATER HEATER SAFETY
Under certain conditions, hydrogen gas may be produced in a water heater that has not been used
for two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by
turning on all hot water faucets and allowing them to run for several minutes. Do this before using any
electrical appliance which is connected to the hot water system. This simple procedure will allow any
built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or
appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions
before it is used. If you did not receive an Installation Instructions sheet, you can receive one by
visiting GEAppliances.ca, or by calling 1.800.361.3400.
Installation Instructions
The instructions in this manual and all other literature included with this washer are not meant to cover
every possible condition and situation that may occur. Good, safe practices and caution MUST be applied
when installing, operating, and maintaining any appliance.
ELECTRICAL REQUIREMENTS
CIRCUIT - Individual, properly polarized and grounded circuit, protected by a 15 Amperes circuit breaker or fuse.
POWER SUPPLY - 2-wire, with ground, 120 Volt, single phase, 60 Hz alternating current.
OUTLET RECEPTACLE - Properly grounded 3-prong receptacle to be located so the power supply cord is accessible when
the washer is in an installed position.
GROUNDING REQUIREMENTS
This appliance must be grounded. In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock. This appliance is equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in
accordance with local codes and ordinances.
DO NOT - modify the plug provided with the appliance.
DO NOT - cut off or alter the grounding prong on the power cord. If the plug will not
fit the outlet, have a proper outlet installed by a qualified electrician.
DO NOT - use an extension cord or adapter plug.
WARNING!
Improper connection of the equipment grounding conductor can result in a risk of
electrical shock. Check with a licensed electrician if you are in doubt as to whether the
appliance is properly grounded.

YOUR LAUNDRY AREA
■Keep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance is
used by or near children. Do not allow children
to play on, with or inside this or any other
appliance.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
3
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.
WHEN USING THE WASHER
■Never reach into washer while it is moving.
Wait until the machine has completely stopped
before opening the lid.
■Do not mix chlorine bleach with ammonia
or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a
toxic gas which may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted with
combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.) These substances give off
vapors that may ignite or explode. Do not add
these substances to the wash water. Do not use or
place these substances around your washer or
dryer during operation.
■The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
■To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the building’s
distribution panel by removing the fuse or
switching off the circuit breaker before
attempting any maintenance or cleaning.
NOTE: Turning the Cycle Selector Knob to an off position or
pressing PAUSE does NOT disconnect the appliance from
the power supply.
■Never attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled,
or has missing or broken parts, including a
damaged cord or plug.
WHEN NOT IN USE
■Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if
a break or rupture should occur. Check the
condition of the fill hoses; they should be
replaced every 5 years.
■Before discarding a washer, or removing it
from service, remove the washer lid to prevent
children from hiding inside.
■If the power cord is damaged or worn, it must be
replaced by a service technician or qualified
person to avoid hazard.
■Do not attempt to disassemble, repair or replace
any part of this appliance unless specifically
recommended in this Owner’s Manual, or in
published user-repair instructions that you
understand and have the skills to carry out.
Otherwise, this should be done by a qualified
technician.
■Do not tamper with controls.
■In order to plug and unplug your washer, hold
the cord by the plug. Never pull the power cord.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Installation Instructions

4
Understanding your washer
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips Installation Instructions
Lid Lock
Your washer has a security system that prevents opening the lid during the spin cycle. The lid lock prevents
anyone (especially children) from reaching into the washer while the basket is spinning. The lock will be
released approximately 2 minutes after the basket stops spinning.
About the control panel
Load Size
Loosely load clothes into the washer basket and select the appropriate load size. (For models that do not have a load size
selection knob, press the load size button repeatedly to switch between different water levels).
Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care label or instructions when
laundering.
(For models that do not have a temperature selection knob, the washer automatically selects the wash temperature according
to the selected cycle. Wash temperatures for each cycle are indicated on the control panel).
2
nd
Rinse Option (on some models)
When you use extra detergent or bleach to clean heavily soiled clothes, you may want to use the 2nd Rinse option. It provides a
second deep cold rinse (short: 3 mins; long: 6 mins).
Wash Cycle
The wash cycle controls the length of the washing process. Select the desired wash cycle and press the Start/Pause button to
begin. If you wish to change the wash program after the washer has begun operating, press the Start/Pause button in order to
stop the operation. Change to the desired wash program and press the Start/Pause button to start again. The wash cycle will
start from the beginning.
For some models, the Manual Mode button allows you to modify the wash program by selecting a specific cycle stage. After
selecting a wash program, press the Manual Mode button repeatedly to choose different program stages.
(For models that do not have the manual mode option, this button serves as the load size selector).
Cycle Indicator Lights
identify what stage the washer is in. If the indicator lights are blinking, the operation of the washer has been paused. To
resume operation press the Start/Pause button. During the spin cycle, the lid lock will be engaged, and will be shown on the
indicator lights. The lid lock will be released approximately 2 minutes after the spin cycle is completed.
Start/Pause
Press the Start/Pause button to begin the cycle. If you raise the lid or change the cycle, you will have to press the Start/Pause
button to resume the operation of your washer.
Your washer may not be exactly as shown.

The fabric softener dispenser automatically
releases liquid fabric softener at the proper
time during the cycle.
Do not stop the washer during the first spin.
This will cause the dispenser to empty
too soon.
NOTE: We recommend you clean the
dispenser periodically to prevent buildup.
Remove the dispenser from the top of the
agitator, soak it, and clean with a soft cloth.
To use, follow these steps:
Make sure dispenser is securely attached
to agitator.
Use only liquid fabric softener.
Pour into dispenser, using amount
recommended on package.
Never pour fabric softener directly on clothes.
It may stain them.
Add water to dispenser until it reaches
the maximum fill line.
5
The chart below will help you match the wash cycle setting with your clothing.
(Some models will not have all of the wash cycles described below).
HEAVY DUTY For heavy soiled items, household linens, work and play clothes.
WHITES Intense wash cycle designed for white clothes, as well as non-colourfast light colours.
COLOURS Wash cycle designed for colourfast garments or lightly soiled light-coloured clothes.
EASY CARE/ For wrinkle-free and permanent press items, and knits.
PERMA PRESS
DELICATE/ For lingerie and special-care fabrics with light to normal soil that require gentle wash action.
GENTLE WASH
SPEED CYCLE/ For lightly soiled items, or for quickly washing perspiration, stains, etc. out of clothes.
SHORT WASH
MIXED LOAD For mixed loads of cotton and synthetic fabrics.
SPIN ONLY The Spin Only cycle may be used to remove excess water from your clothes. This cycle may also be selected after a wash cycle
has completely finished to provide additional drying. If the tub still contains water when the spin cycle is selected, the washer
will drain first and then begin the spin cycle.
About the control settings.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
1
2
3
The Fabric Softener Dispenser (depending on model)
About washer features
Liquid Bleach Dispenser
The dispenser dilutes liquid chlorine bleach before it reaches into your wash load.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■ Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
■ Do not pour powdered bleach into bleach dispenser.
It is recommended that you pour diluted bleach directly into the dispenser 5 minutes
before the end of the wash stage, just before the rinse cycle.
■ Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing can produce a toxic gas which may cause death.
1
2
3

6
About washer features.
Always follow fabric manufacturer’s care label when laundering.
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates)
and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy).
Sorting Wash Loads
Add detergent and start the washer before adding
clothes so that the detergent can work effectively.
To avoid any risk of overflow, add clothes before
the washer has stopped filling.
Using too little or too much detergent is a
common cause of laundry problems.
You can use less detergent if you have soft water, a
smaller load or a lightly soiled load.
Proper Use of Detergent
Load dry items loosely, no higher than the top row
of holes in the washer basket. When loading wet
items, make sure you set the load/water level high
enough to allow the items to move freely. Water
level should just cover the clothes. To add items
after washer has started, lift the lid and submerge
additional items next to the agitator.
Do not overload the wash basket
■
Do not wrap long items like sheets or pants around
the agitator.
■ Do not wash fabrics containing flammable materials
(waxes, cleaning fluids, etc.).
■ Agitation will not start with the lid up.
Loading the Washer
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean
the basket, use a clean soft cloth dampened with
liquid detergent, then rinse. (Do not use harsh or
gritty cleaners.)
Fill Hoses: Hoses connecting washer to faucet
should be replaced every 5 years.
Exterior: Immediately wipe off any spills. Wipe with
damp cloth. Try not to hit surface with sharp
objects.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Care and Cleaning of the Washer
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips Installation Instructions

7
Installation Washer
Instructions
Read these instructions completely and carefully.
•IMPORTANT – Save these
instructions for local inspector’s use.
•IMPORTANT – Observe all
governing codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these instructions
for future reference.
•Skill level – Installation of this appliance requires
basic mechanical and electrical skills.
•Completion time – 1-3 hours.
•Proper installation is the responsibility of the
installer.
•Product failure due to improper installation is not
covered under the Warranty.
BEFORE YOU BEGIN
FOR YOUR SAFETY
WARNING
•This appliance must be properly grounded and
installed as described in these Installation
Instructions .
•Do not install or store appliance in an area where it
will be exposed to water/weather. See Location of
Your Washer section.
•NOTE: This appliance must be properly grounded,
and electrical service to the washer must conform
with local codes and ordinances and the latest
edition of the National Electrical Code,
ANSI/NFPA 70.
TOOLS REQUIRED FOR
WASHER INSTALLATION
Bubble level
Pliers
Phillips screwdriver
Flat-blade screwdriver
PARTS SUPPLIED
Water Hoses (2)
Cable Tie

8
Installation Instructions
Do Not Install the Washer
1. In an area exposed to dripping water or outside
weather conditions. The ambient temperature
should never be below 60°F (15.6°C) for proper
washer operation.
2. In an area where it will come in contact with
curtains or drapes.
3. On carpet. The floor MUST be a hard surface with
a maximum slope of 1/2” per foot (1.27 cm per
30 cm). To make sure the washer does not vibrate
or move, you may have to reinforce the floor.
WARNING: Recycle or destroy the
carton and plastic bags after the washer is
unpacked. Make materials inaccessible to
children. Children might use them for play.
Cartons covered with rugs, bedspreads, or plastic
sheets can become airtight chambers causing
suffocation.
Make sure you have removed all of the packaging
material from the top and bottom of the washer.
LOCATION OF YOUR WASHER
UNPACKING THE WASHER
Carton protector
Plastic bag
containing
installation
accessories
Corner protectors
Motor base
Cardboard base
DRAINAGE
A vertical standpipe with an internal diameter of 1-1/2”
(3.8 cm) is required. The standpipe height above the
floor must be:
Minimum height: 36” (91,4 cm)
Maximum height: 72” (182,9 cm)
Insert the drain hose into the standpipe and secure it
with the cable tie located inside the accessories bag.
The standpipe must be open to the atmosphere (there
must be an air gap around the drain hose).
CLEARANCES
If you are installing your washer in a closet or alcove,
you must consider additional clearances relative to the
dimensions of your washer, and provide proper
ventilation openings in the closet doors.
INSTALLATION REQUIREMENTS
36” (91.4 cm)
minimum
72” (182.9 cm)
maximum
Cable tie
0"
0"
3" (7,6 cm)
3" (7,6 cm)
52" (132 cm)
3"
(7,6 cm) 2" (5,1 cm)
(0 cm) (0 cm)
Closet door
Must be lowered or
equivalent and have at
least 120 in2(774 cm2)
open area.

9
Installation Instructions
Read these instructions completely and carefully.
CIRCUIT – Individual, properly polarized and
grounded 15-amp branch circuit fused with 15-amp
time-delay fuse or circuit breaker.
POWER SUPPLY – 2-wire, with ground, 120-volt,
single-phase, 60-Hz, Alternating Current.
OUTLET RECEPTACLE – Properly grounded
3-prong receptacle to be located so the power supply
cord is accessible when the washer is in an installed
position.
ELECTRICAL REQUIREMENTS
Hot and cold water faucets MUST be installed within
42”(107 cm) of your washer’s water inlet. The faucets
MUST be 3/4” (1.9 cm) garden hose-type so inlet
hoses can be connected. Water pressure MUST be
between 10 and 100 pounds per square inch. Your
water department can advise you of your water
pressure. The hot water temperature should be set to
deliver water at 120° to 140°F (48° to 60°C).
WATER SUPPLY REQUIREMENTS
WARNING: Improper connection of
the equipment grounding conductor can result in
a risk of electrical shock. Check with a licensed
electrician if you are in doubt as to whether the
appliance is properly grounded.
1. The washer MUST be grounded. In the event of
malfunction or breakdown, grounding will reduce
the risk of electrical shock by providing a path of
least resistance for electrical current.
2. Since your washer is equipped with a power supply
cord having an equipment-grounding conductor and
a grounding plug, the plug MUST be plugged into
an appropriate, copper-wired receptacle that is
properly installed and grounded in accordance with
all local codes and ordinances or in the absence of
local codes, with the National Electrical Codes,
ANSI/NFPA 70 (latest edition). If in doubt, call a
licensed electrician.
DO NOT cut off or alter the grounding prong on
the power supply cord. In situations where a two-slot
receptacle is present, it is the owner’s responsibility
to have a licensed electrician replace it with a
properly grounded three-prong grounding-type
receptacle.
GROUNDING REQUIREMENTS

10
Installation Instructions
1. Pull the drain hose out of the back panel of the
washer as shown. Insert the drain hose into the
standpipe and secure it with a cable tie. (Refer to
Drainage installation requirements).
2. Run some water from the hot and cold faucets to
flush the water lines and remove particles that might
clog up the water valve screens.
3. Remove the inlet hoses from the plastic bag and
ensure that the rubber washers in each end of the
inlet hoses is properly positioned.
4. Install the inlet hoses as shown. Ensure that the cold
water hose and hot water hose are connected to the
correct outlet of the water valve.
5. Tighten each connection by hand, then tighten
another 2/3 turn with pliers. Do not crossthread or
over-tighten these connections.
INSTALLING THE WASHER
Cold
Hot
Cold
water hose
Hot water
hose
6. Place the drain hose in a laundry tub or insert it into
the standpipe and secure it with a cable tie.
7. Carefully move the washer to its final location.
Gently rock the washer into position.
8. With the washer in its final position, place a level on
top of the washer. Adjust the four leveling legs up or
down to ensure the washer is resting firmly and
completely level. All 4 leveling legs must touch the
ground for the washer to maintain stability.
9. Plug the power cord into a grounded outlet.
NOTE: Check to be sure the power is off at a circuit
breaker/fuse box before plugging the power cord
into an outlet.
36” (91.4 cm)
minimum
72” (182.9 cm)
maximum
Cable tie
Check using a
bubble level

11
10.Turn on the power at a circuit breaker/fuse box.
11.Read the rest of this Owner’s Manual. It contains
valuable and helpful information that will save you
time and money.
12.Before starting the washer, check to make sure:
Main power is turned on.
The washer is plugged in.
The water faucets are turned on.
The unit is level and firmly supported on its
4 leveling legs.
The drain hose is properly tied up.
There are no leaks at the faucet, drain line or
washer.
13.Run the washer through a complete cycle. Check
for water leaks and proper operation.
14.Verify the lid lock engages during the spin cycle.
The lock will be released approximately 2 minutes
after the basket stops.
15.If your washer does not operate, please review the
Before You Call For Service section before calling for
service.
16.Place these instructions in a location near the
washer for future reference.
Installation Instructions

WATER Possible Causes What To Do
Too many suds Type of detergent •Switch to a lower sudsing detergent brand and follow instructions
on package.
Very soft water •Try less detergent.
Too much detergent •Measure your detergent carefully. Use less soap if you have soft water,
a smaller load or a lightly soiled load.
Water leaks Fill hoses or drain hose is •Make sure hose connections are tight at faucets and rubber washers are
improperly connected installed. Make sure end of drain hose is correctly inserted in and
secured to drain facility.
Household drain may be clogged •Check household plumbing. You may need to call a plumber.
Constant water pressure to the fill •Tighten hoses at the faucets and turn the water off after each use.
•Check condition of the fill hoses; they should be replaced every 5 years.
Using too much detergent in washer •Use less detergent. Use less soap if you have soft water, a smaller load or
a lightly soiled load.
Water temperature Cooler water temperatures provide •New laundry detergents have been formulated to work with cooler
seems incorrect improved energy efficiency water temperatures without affecting wash performance.
Control is not set properly •Check water temperature control and adjust.
Water supply is turned off or •Turn both hot and cold faucets fully on and make sure hoses are
improperly connected connected to correct faucets.
Water valve screens are stopped up •Turn off the water source and remove the water connection hoses from
the upper back of the washer. Use a brush or toothpick to clean the
screens in the machine. Reconnect the hoses and turn the water back on.
House water heater is not set •Make sure house water heater is delivering water at 120°F–140°F
properly (48°C–60°C).
Water won’t drain Drain hose is kinked or •Straighten drain hose and make sure washer is not sitting on it.
improperly connected •Top of drain outlet should be less than 8 ft (2.5 m) above floor.
Lid is not completely closed – •Close lid and reset cycle, to the beginning if necessary.
safety feature prevents agitation
and spinning when lid is up
OPERATION Possible Causes What To Do
Washer won’t operate Washer is unplugged •Make sure cord is plugged securely into a working outlet.
Water supply is turned off •Turn both hot and cold faucets fully on.
Controls are not set properly •Check controls.
Lid is not completely closed – •Close lid and reset cycle, to the beginning if necessary.
safety feature prevents agitation
and spinning when lid is up
Circuit breaker/fuse is •Check house circuit breakers/fuses. Replace fuses or reset breaker.
tripped/blown Washer should have separate outlet.
Electronics need to be reset •Unplug washer, wait 2 minutes, plug back in and press START.
START was not pressed •Press START.
Troubleshooting Tips
Save time and money! Review the charts on the following pages,
or visit GEAppliances.ca. You may not need to call for service.
Before you call for service…
12
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips Installation Instructions

13
OPERATION Possible Causes What To Do
Washer won’t spin Circuit breaker/fuse is •Check house circuit breaker/fuses. Replace fuses or reset breaker.
tripped/blown Washer should have separate outlet.
START was not pressed for •Press Start/Pause button.
spin only cycle
Lid is not completely closed – •Close lid and reset cycle, to the beginning if necessary.
safety feature prevents agitation
and spinning when lid is up
Washer won’t rinse Lid is not closed •Close lid and press Start/Pause button again.
Washer has not finished •Verify that the pump is draining the water. If so, wait for this stage to
draining the water, or has not complete.
stopped spinning
Lid won’t close A foreign object is blocking •Remove foreign object from lid locking system and return it to its
the lid locking system original position. Close lid gently without forcing it.
Lid won’t open During the spin cycle the lid •The lid lock will be released approximately 2 minutes after the spin
locking system will not allow cycle has completed, or after the Start/Pause button has been pressed.
the lid to be opened
PERFORMANCE Possible Causes What To Do
Clothes too wet Incorrect spin cycle selected •Make sure the spin cycle selected matches the load you are
washing. Some fabrics will feel wetter when rinsed with cold water.
Colored spots Incorrect use of fabric softener •Check fabric softener package for instructions and follow directions for
using dispenser.
•Pretreat stain and rewash.
Dye transfer •Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent •Use more detergent (especially with larger loads).
clothes Be sure to follow detergent manufacturer’s directions.
Hard water •Use a water conditioner like Calgon brand or install a water softener.
Water is not hot enough •Make sure water heater is delivering water at 120°F–140°F (48°C–60°C).
Washer is overloaded •Select load size to match clothes load.
Detergent is not dissolving •Add detergent as wash basket fills with water before you load clothes.
Dye transfer •Sort clothes by color. If fabric label states
wash separately, unstable
dyes may be indicated.
Lint or residue on Clothes are air or line dried •If you do not dry your clothes with a clothes dryer, your clothes may
clothes retain more lint.
Incorrect sorting •Separate lint producers from lint collectors.
Washing too long •Wash small loads for a shorter time than larger loads.
Detergent not dissolving •Add detergent as wash basket fills with water, before you load clothes.
•Try a liquid detergent.
•Use warmer water temperature.
Overloading •Load clothes no higher than the top row of holes in the washer basket.
•Make sure load size selected matches clothes load size.
Incorrect use of fabric softener •Check fabric softener package for instructions and follow directions
for using dispenser.
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation Instructions

14
PERFORMANCE (cont.) Possible Causes What To Do
Pilling Result of normal wear on •While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Snags, holes, tears, rips Pins, snaps, hooks, sharp •Fasten snaps, hooks, buttons and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets and
zippers and sharp objects sharp buttons.
left in pockets •Turn knits (which snag easily) inside out.
Undiluted chlorine bleach •Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes to
come in contact with undiluted bleach.
Chemicals like hair bleach •Rinse items that may have chemicals on them before
or dye, permanent wave washing.
solution
Wrinkling Improper sorting •Avoid mixing heavy items (like work clothes) with
light items (like blouses).
•Try a fabric softener.
Overloading or incorrect •Load your washer so clothes have enough room to move
water level freely with water covering all of the clothes.
Incorrect wash and •Match Cycle selection to the type of fabric you are washing
dry cycles (especially for easy care loads).
Repeated washing in •Wash in warm or cold water.
water that is too hot
NOISE Possible Causes What To Do
Washer is noisy Washer is uneven •To level the front of the washer, adjust the front leveling
legs by rotating the individual leg in the proper direction
for up or down. To level back of washer, lift back of
machine 4” (11 cm) and set down.
Washer load is •Press PAUSE to stop the washer, open the lid and
unbalanced redistribute the load evenly. Close the lid and press START.
Washer is sitting too close •Pull washer away from the wall; about 4” (11 cm)
to wall (causes knocking is needed.
during cycle)
Noise before Spin Cycle Normal sound of the washer •Your washer’s system generates an adjustment sound before
starting the spin cycle. This is normal.
Troubleshooting Tips
Before you call for service…
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips Installation Instructions

15
OWNERSHIP REGISTRATION
P.O. BOX 1780
MISSISSAUGA, ONTARIO
L4Y 4G1
(FOR CANADIAN CONSUMERS ONLY -
POUR RÉSIDENTS CANADIENS SEULEMENT)
Please place in envelope and mail to:
Veuillez mettre dans une enveloppe et envoyez à :
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation Instructions

16
CUT ALONG THIS LINE AND RETURN CARD – THANKS
DÉCOUPEZ ICI ET ENVOYEZ LA FICHE – MERCI
For Canadian
Customers
Pour les
consommateurs
canadiens
OWNERSHIP REGISTRATION CERTIFICATE – FICHE D’INSCRIPTION DU PROPRIÉTAIRE
Please register your product to enable us to contact you in
the remote event a safety notice is issued for this product
and to allow for efficient communication under the terms of
our warranty, should the need arise.
REGISTER ON-LINE: www.geappliances.ca
ENREGISTREMENT SUR INTERNET À : www.electromenagersge.ca
MAIL TO: P.O. BOX 1780, MISSISSAUGA
POSTEZ À : ONTARIO, L4Y 4G1
MR. / M MRS. / MME.
MISS/MLLE. MS.
FIRST NAME / PRÉNOM LAST NAME / NOM
STREET NO / N
O
RUE STREET NAME / RUE APT.NO/APP./RR#
CITY / VILLE
PROVINCE POSTAL CODE POSTAL
AREA CODE/
IND. RÉG.
TELEPHONE E-MAIL/COURRIEL
DID YOU PURCHASE A SERVICE CONTRACT FOR THIS APPLIANCE?
AVEZ-VOUS ACHETÉ UN CONTRAT DE SERVICE POUR CET APPAREIL ?
YES/OUI
NO/NON
IF YES/SI OUI : EXPIRATION
Y/A M D/J
NAME OF SELLING DEALER / NOM DU MARCHAND
INSTALLATION DATE / DATE D’INSTALLATION
Y/A M D/J
CORRESPONDENCE
ENGLISH
CORRESPONDANCE
FRANÇAIS
I do not wish to receive any promotional offers regarding this product.
Je ne désire pas recevoir d’offres promotionnelles concernant ce produit.
MODEL / MODÈLE
SERIAL / SÉRIE
Veuillez enregistrer votre produit afin de nous permettre de
communiquer avec vous si jamais un avis de sécurité concernant
ce produit était émis et de communiquer facilement avec vous en
vertu de votre garantie, si le besoin s’en fait sentir.
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips Installation Instructions

■Service trips to your home to teach you how to use
the product.
Read your Owner’s Manual. If you then have any questions
about operating the product, please contact your dealer or
our Consumer Affairs office at the address below.
Manager, Consumer Relations
Mabe Canada Inc.
1 Factory Lane, Suite 310
Moncton, N.B.
E1C 9M3
■Improper installation
If you have an installation problem, contact your dealer
or installer. You are responsible for providing adequate
electrical, exhausting and other connecting facilities.
■Replacement of house fuses or resetting of circuit
breakers.
■Failure of the product if it is misused, or used for other
than the intended purpose or used commercially.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Damage to finish not reported within 48 hours following
the delivery of the appliance.
■Product not accessible to provide required service.
For The Period Of: We will replace:
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this
From the date of the limited one-year warranty , we will also provide, free of charge, all labour and in-home service to
original purchase replace the defective part.
All warranty service provided by our Factory Service Centers, or an authorized technician.
For service, call 1.800.361.3400.
In-home service will be provided in areas deemed reasonable by Mabe.
Please have serial number and model number available when calling for service.
17
Washer Warranty.
What Is Not Covered:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within Canada.
In home warranty service will be provided in areas where it is available and deemed reasonable by Mabe to provide.
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation Instructions
EXCLUSION OF IMPLIED WARRANTIES - Your sole and exclusive remedy is product repair as provided in this Limited
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose, are
limited to one year or the shortest period allowed by law.
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
Warrantor: MABE CANADA INC.

Consumer Support. moffatappliances.ca
GE Appliances Website GEAppliances.ca
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a
day, any day of the year! For greater convenience and faster service, you can now download Owner’s
Manuals, order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of
ExpertsTM” your questions, and so much more...
Schedule Service 1.800.361.3400 or GEAppliances.ca
Expert GE repair service is only one step away from your door. Get on-line and schedule your service
at your convenience 24 hours any day of the year! Call 1.800.361.3400 during normal business hours.
Real Life Design Studio
GE supports the Universal Design concept---products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical
and mental abilities and impairments. For details of GE’s Universal Design applications, including
kitchen design ideas for people with disabilities, check out our Website today.
In Canada, contact: Manager, Consumer Relations, Mabe, Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Extended Warranties 1.888.261.2133 or GEAppliances.ca
Purchase a GEextended warranty and learn about special discounts that are available while your
warranty is still in effect. You can purchase it on-line anytime, or call 1.888.261.2133 during normal
business hours. GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories 1.800.661.1616 or GEAppliances.ca
Individuals qualified to service their own appliances can have parts or accessories sent directly to their
homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day
or by phone at 1.800.661.1616 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other
servicing generally should be referred to qualified service personnel. Caution must be
exercised, since improper servicing may cause unsafe operation.
Contact Us GEAppliances.ca
If you are not satisfied with the service you receive from GE, contact us on our Website with all the
details including your phone number, or write to:
Director, Consumer Relations, Mabe, Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Register Your Appliance GEAppliances.ca
Register your new appliance on-line----at your convenience! Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need
arise. You may also mail in the pre-printed registration card included in the packing material.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips Installation Instructions

19
nInstallez ou entreposez l’appareil à un endroit où il ne
sera exposé ni à des températures en-dessous du point
de congélation ni aux intempéries : l’appareil pourrait
subir des dommages permanents et la garantie serait
annulée.
n
REMARQUE : Cet appareil doit être correctement mis
à la terre et son alimentation électrique doit être
conforme à tous les codes et règlements en vigueur,
ainsi qu’à la dernière édition du Code national de
l’électricité, ANSI/NFPA 70.
CONSIGNES DE SÉCURITÉ IMPORTANTES.
LISEZ TOUTES LES INSTRUCTIONS AVANT D’UTILISER VOTRE APPAREIL.
AVERTISSEMENT! Pour votre sécurité et pour réduire les risques d’incendie, d’explosion, de choc électrique,
de dommages matériels, de blessures ou même d’accident mortel, vous devez vous
conformer aux instructions contenues dans ce manuel.
SÉCURITÉ – CHAUFFE-EAU
Dans certaines conditions, de l’hydrogène peut se former dans un chauffe-eau qui n’a pas été utilisé pendant
deux semaines ou plus. L’hydrogène présente des risques d’explosion dans ces circonstances.
Si l’eau chaude n’a pas été utilisée pendant 2 semaines ou plus, ouvrez tous les robinets d’eau chaude et laissez l’eau
couler pendant plusieurs minutes pour éviter tout dommage ou toute blessure. Faites de même avec tout appareil
électrique raccordé au circuit d’eau chaude. Ce simple procédé permet à l’hydrogène de s’échapper. Ce gaz étant
inflammable, ne fumez pas et n’utilisez pas d’appareil ou de flamme nue pendant cette opération.
INSTALLATION APPROPRIÉE
Cette laveuse doit être installée conformément aux instructions d’installation avant d’être utilisée.
Si vous n’avez pas reçu la feuille d’instructions d’installation, vous pouvez l’obtenir sur le site Web
www.electromenagersge.ca ou en appelant le 1-800-361-3400.
Les instructions contenues dans ce manuel et toute la documentation fournie avec cette laveuse ne couvrent pas la
totalité des conditions ou situations éventuelles. Vous DEVEZ utiliser des méthodes sûres et appropriées, et user de
prudence lorsque vous installez, utilisez et entretenez tout type d’électroménager.
ALIMENTATION ÉLECTRIQUE
CIRCUIT - Circuit individuel, correctement polarisé et mis à la terre, protégé par un disjoncteur ou un fusible de 15 A.
ALIMENTATION ÉLECTRIQUE - Courant alternatif monophasé, bifilaire, avec mise à la terre, de 120 V et 60 Hz.
PRISE DE COURANT - Prise à 3 alvéoles, correctement mise à la terre, située de manière à ce qu’il soit facile d’accéder au cordon
d’alimentation une fois la laveuse installée.
MISE À LA TERRE
Cet appareil doit être mis à la terre. En cas de dysfonctionnement ou de panne, la mise à la terre
diminue le risque de choc électrique. Cet appareil est équipé d’un cordon muni d’un conducteur
de terre et d’une fiche de mise à la terre. La fiche doit être branchée sur une prise appropriée,
correctement installée et mise à la terre conformément aux codes et règlements en vigueur.
NE MODIFIEZ PAS - la fiche fournie avec l’appareil.
NE COUPEZ OU NE MODIFIEZ PAS - la broche de mise à la terre du cordon d’alimentation. Si la
fiche ne rentre pas dans la prise, faites installer une prise appropriée par un électricien qualifié.
N’UTILISEZ PAS - de cordon prolongateur ou de fiche d’adaptation.
AVERTISSEMENT!
Un raccordement incorrect du conducteur de terre de l’équipement peut entraîner un risque de
choc électrique. Renseignez-vous auprès d’un électricien qualifié si vous avez des doutes
concernant la qualité de la mise à la terre de votre appareil.
Service à la clientèleDépannage
Utilisation
Sécurité Installation

VOTRE BUANDERIE
nVeillez à ce qu’il n’y ait aucun matériau combustible
(charpie, papiers, chiffons, produits chimiques, etc.)
sous et autour de vos appareils.
nSurveillez attentivement les enfants lorsque ceux-ci se
trouvent près de l’appareil ou qu’ils l’utilisent. Ne
permettez pas aux enfants de jouer sur, avec ou à
l’intérieur de cet appareil ou de tout autre appareil.
20
Cet appareil doit
uniquement être
utilisé aux fins
prévues et
décrites dans
ce manuel.
LORS DE L’UTILISATION DE LA LAVEUSE
nNe mettez jamais la main dans la laveuse lorsque
celle-ci est en mouvement. Attendez jusqu’à ce que
l’appareil soit complètement arrêté avant d’en ouvrir
le couvercle.
nNe mélangez pas d’agent chloré de blanchiment avec
de l’ammoniaque ou des produits acides tels que le
vinaigre et/ou l’antirouille. Le mélange de divers
produits chimiques peut produire un gaz toxique
mortel.
nNe lavez et ne séchez pas d’articles qui ont été
nettoyés, lavés, trempés ou tachés avec un produit
combustible ou explosif (cire, huile, peinture, essence,
dégraissant, solvant pour nettoyage à sec, kérosène,
etc.). Ces substances dégagent des vapeurs qui
pourraient s’enflammer ou provoquer une explosion.
N’ajoutez aucun de ces produits à l’eau de lavage.
N’utilisez et ne rangez aucun de ces produits autour de
votre laveuse ou sécheuse lorsque celle-ci fonctionne.
nLe lavage/séchage peut réduire l’aspect ignifuge des
tissus. Pour éviter cela, suivez attentivement les
instructions de lavage et de soin du fabricant du
vêtement.
nPour réduire le risque de choc électrique, débranchez
cet appareil ou coupez l’alimentation électrique de la
laveuse au niveau du tableau de distribution de votre
domicile en retirant le fusible ou en mettant le
disjoncteur en position d’arrêt avant d’effectuer tout
entretien ou toute réparation.
REMARQUE : Tourner le bouton de sélection de cycle pour le
mettre en position d’arrêt ou appuyer sur PAUSE NE
DÉCONNECTE PAS l’appareil de l’alimentation électrique.
nN’essayez jamais d’utiliser cet appareil s’il est
endommagé, fonctionne mal, s’il est partiellement
démonté ou si certaines de ses pièces manquent ou
sont cassées (y compris le cordon d’alimentation ou la
fiche).
EN CAS DE NON-UTILISATION
nFermez les robinets d’eau pour relâcher la pression au
niveau des tuyaux et des robinets, et pour réduire les
fuites en cas de tuyau cassé. Vérifiez l’état des tuyaux
de remplissage : ils doivent être remplacés tous les
5 ans.
nAvant de mettre une laveuse au rebut ou de la mettre
hors service, retirez le couvercle pour éviter que les
enfants ne se cachent à l’intérieur de l’appareil.
nSi le cordon d’alimentation est endommagé ou usé, il
doit être remplacé par un technicien ou une personne
qualifiés pour éviter tout danger.
nN’essayez pas de réparer ou remplacer toute pièce de
cet appareil, sauf si cela est spécifiquement
recommandé dans ce manuel ou dans des manuels
d’instructions de réparation pour l’utilisateur : vous
devez bien comprendre les instructions et avoir les
aptitudes nécessaires à la réalisation de ces réparations.
Dans le cas contraire, les réparations doivent être
effectuées par un technicien qualifié.
nN’altérez pas les commandes.
nPour brancher et débrancher votre laveuse, maintenez
le cordon au niveau de la fiche. Ne tirez jamais sur le
cordon d’alimentation.
LISEZ ET SUIVEZ ATTENTIVEMENT CES CONSIGNES DE SÉCURITÉ.
CONSERVEZ CES INSTRUCTIONS
Utilisation Sécurité
Service à la clientèle Dépannage Installation
