Moffat MNSR1070 User manual

Washers
Safety Information . . .3, 4
Operating Instructions
Control Panels and
Settings . . . . . . . . . . . .5, 6
Features . . . . . . . . . . . . . .7
Loading and Using
the Washer . . . . . . . . .8–11
Stain Guide . . . . . . .10, 11
Troubleshooting Tips
Before You Call
For Service . . . . . . . .12–14
Customer Service
Service Telephone
Numbers . . . . . . . . . . . .16
Warranty . . . . . . . . . . . .15
175D1807P453 49-90186 08-03 JR
MNSR1070
MNXR1070
MNXRP080
Owner’s Manual

IMPORTANT!
Staple sales slip or cancelled check here.
Proof of the original purchase date is needed to obtain service under the warranty.
2
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
A Service Partnership.
FOR YOUR RECORDS
Write the model and serial numbers here:
#
#
You can find them in the upper right corner on the back of your washer.
READ THIS MANUAL
Inside you will find many helpful hints on how to use and maintain your washer properly. Just a little
preventive care on your part can save you a great deal of time and money over the life of your washer.
IF YOU NEED SERVICE
You’ll find many answers to common problems in the Before You Call For Service section. If you review our
chart of Troubleshooting Tips first, you may not need to call for service at all.
If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer
service numbers is included in the back section. Or call 1.800.361.3400.

■Install or store where it will not be exposed to
temperatures below freezing or exposed to
the weather.
■Properly ground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, personal injury, or loss of life.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
3
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for
two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by
turning on all hot water faucets and allowing them to run for several minutes. Do this before using any
electrical appliance which is connected to the hot water system. This simple procedure will allow any
built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or
appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions
before it is used. If you did not receive an Installation Instructions sheet, you can receive one by calling,
toll-free 1.800.361.3400.
■Keep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance is
used by or near children. Do not allow children
to play on, with, or inside this or any other
appliance.
YOUR LAUNDRY AREA

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
4
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
■Never reach into washer while it is moving.
Wait until the machine has completely stopped
before opening the lid.
■Do not mix chlorine bleach with ammonia or
acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a
toxic gas which may cause death.
■Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or spotted with
combustible or explosive substances (such as wax,
oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.). These substances give off
vapors that may ignite or explode. Do not add
these substances to the wash water. Do not use or
place these substances around your washer or
dryer during operation.
■ The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
■To minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the household
distribution panel by removing the fuse or
switching off the circuit breaker before
attempting any maintenance or cleaning.
NOTE: Turning the Cycle Selector knob to an
off position does NOT disconnect the appliance
from the power supply.
■N ever attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled,
or has missing or broken parts, including a
damaged cord or plug.
WHEN USING THE WASHER
■Turn off water faucets to relieve pressure on
hoses and valves and to minimize leakage if
a break or rupture should occur. Check the
condition of the fill hoses; they should be
replaced every 5 years.
■Before discarding a washer, or removing it
from service, remove the washer lid to prevent
children from hiding inside.
■Do not attempt to repair or replace any part of
this appliance unless specifically recommended
in this Owner’s Manual, or in published user-
repair instructions that you understand and
have the skills to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
SAVE THESE INSTRUCTIONS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

Find your washer control panel.
You can locate your model number behind the top edge of the control panel.
Model MNSR1070
1
5
3
Model MNXR1070
1 3
Model MNXRP080
1 3
2

Load Size
Loosely load clothes no higher than the top row of holes in the washer basket. The water level should
just cover the clothes. Adjust the load size accordingly.
Temperature (on some models)
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care
label or instructions when laundering. Follow the water temperature guide on the washer lid.
Wash Cycle
The wash cycle controls the length of the washing process. On some models, the wash cycle also
controls the wash temperature. You can choose a cooler wash temperature no matter what color
of fabric you are washing. Always follow the instruction on the fabric care label when laundering.
The chart below will help you match the wash cycle setting with your clothing.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
EASY CARE/ For wrinkle-free and permanent press items, and knits.
PERMA PRESS
KNITS Specially designed for normally soiled knits.
CASUALS For wrinkle-free and permanent press items, and knits. Provides agitate/pause cycles to clean your
items.
SUPER/EXTRA For heavily soiled and heavy-duty fabrics. This cycle provides a longer agitation.
3
2
1
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
6
About the control settings.

The Agitator Cap or Fabric Softener Dispenser (depending on model)
The agitator cap fits into the top of the
agitator. If it accidentally comes off, simply
put it back on.
The fabric softener dispenser automatically
releases liquid fabric softener at the proper
time during the cycle.
Do not stop the washer during the first spin.
This will cause the dispenser to empty
too soon.
To use, follow these steps:
Make sure dispenser is securely
attached to agitator.
Use only liquid fabric softener.
Pour into dispenser, using amount
recommended on package.
Never pour fabric softener directly on clothes.
It may stain them.
Add water to dispenser until it reaches
the maximum fill line.
3
2
1
Do not pour anything into the agitator if
the agitator cap or dispenser is removed.
Liquid Bleach Dispenser (on some models)
The dispenser dilutes liquid chlorine bleach before it reaches your wash load.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■ Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
■Do not pour powdered bleach into bleach dispenser.
Before starting the washer, pour measured amount of bleach directly into bleach
dispenser. Avoid splashing or over-filling dispenser. If you prefer to use powdered
bleach, add it into the wash basket with your detergent.
■Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover. Mixing can
produce a toxic gas which may cause death.
3
2
1
Cleaning the Fabric Softener Dispenser (on some models)
Remove the dispenser from the top of the agitator.
Separate the dispenser cup from the cover by grasping the top and pushing down on
the inside of the cup with your fingers. Dispenser cup will pop free from the cover.
To clean the dispenser, soak both the dispenser cup and the dispenser cover in the
following solution:
■1 US gallon (3.8 liters) warm water
■ 1/4 cup (60 ml) heavy duty liquid detergent
■1 cup (240 ml) bleach
If necessary, loosen build-up with a clean, soft cloth after soaking. Do not use a stiff
brush; you may roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser back on the agitator.
5
4
3
2
1
Separate for cleaning.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
7
About washer features.
NOTE: Not all features are available on all washer models.

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Loading and using the washer.
Always follow fabric manufacturer’s care label when laundering.
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates),
and whether the fabric produces lint (terry cloth,
chenille), or collects lint (velveteen, corduroy).
Sorting Wash Loads
8
Add detergent as the wash basket fills with water,
before you load clothes. Using too much detergent
can be a common cause of laundry problems.
Today’s detergents are formulated to be effective
without highly visible sudsing. Be sure to carefully
read and follow manufacturer’s recommendations
for how much detergent to use in your wash.
You can use less detergent if you have soft water,
a smaller load, or a lightly soiled load.
Proper Use of Detergent
Load dry items loosely, no higher than the top row
of holes in the washer basket. When loading wet
items make sure you set the load/water level high
enough to allow the items to move freely. Water
level should just cover the clothes. To add items
after washer has started, push in Cycle Dial and
submerge additional items next to the agitator.
Close the lid and pull Cycle Dial out to restart.
■Do not wrap long items like sheets and pants around
the agitator.
■Do not wash fabrics containing flammable materials
(waxes, cleaning fluids, etc.).
■Water will fill and pump out of the washer and the
timer will advance with the lid up, but as a safety
precaution the washer will not agitate or spin.
Loading the Washer

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Machine
wash
cycle Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Hand wash Do not wash Do not wring
Water
temperature Hot
(50°C/120°F)
Warm
(40°C/105°F)
Cold/cool
(30°C/85°F)
Tumble
dry
Dry Normal Permanent Press/
wrinkle resistant
Gentle/
delicate Do not tumble dry
Do not dry
(used with
do not wash)
Heat
setting
High Medium Low No heat/air
Special
instructions Line dry/
hang to dry Drip dry Dry flat In the shade
Bleach
symbols Any bleach
(when needed) Only non-chlorine bleach
(when needed)
Do not bleach
WASH LABELS
DRY LABELS
BLEACH LABELS
9
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean the
basket use a clean soft cloth dampened with liquid
detergent, then rinse. (Do not use harsh or gritty
cleaners.)
Fill Hoses: Hoses connecting washer to faucet
should be replaced every 5 years.
Exterior: Immediately wipe off any spills. Wipe
with damp cloth. Try not to hit surface with
sharp objects.
Moving and Storage: Ask the service technician to
remove water from drain pump and hoses. Do not
store the washer where it will be exposed to the
weather. For information on how to keep the tub
stationary when moving the washer write to:
Manager, Consumer Relations, Camco Inc.,
1 Factory Lane, Suite 310, Moncton, N.B. E1C 9M3.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Care and Cleaning of the Washer
Below are fabric care label “symbols” that affect the clothing you will be laundering.
Fabric Care Labels

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
STAIN White and Bleachable Fabrics Other Washable Fabrics
Adhesives Rub with ice or immerse in •Same as white and bleachable fabrics.
(chewing gum, etc.) very cold water. Use dull tool
to carefully scrape off as much
adhesive or gum as possible.
Rub the stain with undiluted
liquid detergent. Rinse well,
then wash as usual.
Antiperspirants, Apply undiluted liquid detergent. •Same as white and bleachable fabrics except use
deodorants Rinse. If stain remains, use the non-chlorine bleach.
Bleach Solution; launder.
Blood Soak in cold water, then launder •Sponge or soak in cool water, then launder.
in warm water. If stain remains,
use the Bleach Solution; launder.
Chocolate, cream, Soak in cold water. Use the •Same as white and bleachable fabrics except use
ice cream and milk Bleach Solution; launder. non-chlorine bleach.
Coffee and tea Without cream: Use the Bleach •Sponge with warm water. If stain remains, apply warm
Solution; launder. glycerine (available at drug stores), let stand 30 minutes
and rinse well. Wash as usual.
With cream: Soak in cold water,
then use the Bleach Solution;
launder.
Cosmetics, crayon Use the Bleach Solution; •Rub the stain with undiluted liquid detergent.
launder. Rinse well, then wash as usual.
The invisible stain When They Become Visible:
•Rub the stain with undiluted liquid detergent.
•Let stand 30 minutes.
•Rewash using the hottest water that is safe for the fabric.
Preventing These Stains:
•Increase the amount of detergent used.
•Increase water temperature.
•Wash synthetics often.
Foods on synthetic clothes may
cause stains which are virtually
invisible when you put the
clothes in the washer. If these
stains are not completely
removed in the wash, they may
pick up dirt from other clothes
in the washer and appear after
the clothes are dried.
Loading and using the washer.
Always follow fabric manufacturer’s care label when laundering.
10
Bleach Solution: To remove stains on white or bleachable
fabrics, try soaking the stained area in a container for five
minutes in the following solution and then launder in
the washer:
■1 US gallon (3.8 liters) cool water
■1/4 cup (60 ml) chlorine bleach
Removing Specific Stains

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
STAIN (cont.) White and Bleachable Fabrics Other Washable Fabrics
Grass, mildew, scorch Apply undiluted liquid detergent; •Sponge with warm water. Apply undiluted liquid
launder. (Treat mildew spots detergent; launder. Bleach with non-chlorine bleach;
while they are fresh, before mold launder. Old mildew cannot be removed. Scorch can
has a chance to weaken fabric.) seldom be removed.
If either type stain remains,
use the Bleach Solution; launder.
(Severe scorch stains can seldom
be removed.)
Ink, ballpoint Fresh stains: Place stain face •Same as white and bleachable fabrics except launder
down on an absorbent towel using non-chlorine bleach.
and use a spray cleaner.
Rinse well, then wash as usual.
Old stains: Use the Bleach
Solution; launder.
Juices, wine, Soak stain in cool water. •Sponge with warm water. Bleach remaining stain with
food coloring If stain remains, use the non-chlorine bleach.
Bleach Solution; launder.
Perspiration Apply undiluted liquid detergent •Launder in warm water. Rinse well. Bleach with
and launder in warm water. non-chlorine bleach.
If color has changed you may
be able to restore it by treating
with ammonia or vinegar.
WARNING:
Do not mix chlorine bleach with
ammonia or acids such as vinegar
and/or rust remover. Mixing can
produce a toxic gas which may
cause death.
11

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
WATER Possible Causes What To Do
Too many suds Type of detergent •Switch to a lower sudsing detergent brand and follow
instructions on package.
Very soft water •Try less detergent.
Too much detergent. •Measure your detergent carefully. Use less soap if you
have soft water, a smaller load, or a lightly soiled load.
Water leaks Fill hoses or drain hose is •Make sure hose connections are tight at faucets and
improperly connected rubber washers are installed. Make sure end of drain
hose is correctly inserted in and secured to drain facility.
Household drain may •Check household plumbing. You may need to call a
be clogged plumber.
Constant water pressure •Tighten hoses at the faucets and turn the water off after
to the fill hoses at the each use.
water source •Check condition of the fill hoses; they should be
replaced every 5 years.
Using too much detergent •Use less detergent. Use less soap if you have soft water,
in washer a smaller load, or a lightly soiled load.
Water temperature Cooler water temperatures •New laundry detergents have been formulated to work
seems incorrect provide improved energy with cooler water temperatures without affecting wash
efficiency performance.
Control is not set properly •Check water temperature control (on some models) or
Cycle knob and adjust.
Water supply is turned off •Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and disconnect the water fill
stopped up hoses from the upper back of the washer. Use a brush or
toothpick to clean the screens in the machine. Reconnect
the hoses and turn the water back on.
House water heater is •Make sure house water heater is delivering water
not set properly at 120°F.–140°F.(48°C.–60°C.).
Water won’t drain Drain hose is kinked or •Straighten drain hose and make sure washer is not
improperly connected sitting on it.
•Top of drain outlet should be less than 8 ft. (2.5 m)
above floor.
Before you call for service…
12

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
PERFORMANCE Possible Causes What To Do
Colored spots Incorrect use of fabric •Check fabric softener package for instructions and
softener follow directions for using dispenser.
•Pretreat stain and rewash.
Dye transfer •Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent •Use more detergent (especially with larger loads).
clothes Be sure to follow detergent manufacturer’s directions.
Hard water •Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough •Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded •Select load size to match clothes load.
Detergent is not dissolving •Add detergent as wash basket fills with water before
you load clothes.
Dye transfer •Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried •If you do not dry your clothes with a clothes dryer,
clothes your clothes may retain more lint.
Incorrect sorting •Separate lint producers from lint collectors.
Washing too long •Wash small loads for a shorter time than larger loads.
Detergent not dissolving •Add detergent as wash basket fills with water, before you
load clothes.
•Try a liquid detergent.
•Use warmer water temperature.
Overloading •Load clothes no higher than the top row of holes in the
washer basket.
•Make sure load size selected matches clothes load size.
Incorrect use of fabric softener •Check fabric softener package for instructions and
follow directions for using dispenser.
OPERATION Possible Causes What To Do
Washer pauses during The washer normally pauses
wash cycle between washing steps
Washer pauses during This is normal •The washer may pause during the spin cycle to remove
spin cycle soapy water more efficiently.
Washer won’t operate Washer is unplugged •Make sure cord is plugged securely into a working outlet.
Water supply is turned off •Turn both hot and cold faucets fully on.
Controls are not set •Check controls and make sure Cycle knob is pulled out
properly to ON position.
Lid is open—safety feature •Close lid and reset cycle, to the beginning if necessary.
prevents agitation and spinning
when lid is up
Circuit breaker/fuse is •Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
13

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
OTHER Possible Causes What To Do
Labels on the exterior Occasionally the adhesive •Use a hair dryer set at the lowest heat setting, directing
of the washer will not used on the labels does the air at the label for a short amount of time. This will
peel off cleanly not release cleanly release the adhesive easily, without damaging the surface
of the washer.
NOISE Possible Causes What To Do
Washer is noisy Washer is uneven •To level the front of the washer, adjust the front leveling
legs by rotating the individual leg in the proper direction
for up or down. To level back of washer, lift back of
machine 4″(11 cm) and set down.
Washer load is unbalanced •Push the Cycle knob in to stop the washer, open the lid
and redistribute the load evenly. Close the lid and restart.
Shipping rod is still assembled •To remove shipping rod from washer, pull yellow tag and
in unit attached rod from the bottom right hand side of washer.
Washer is sitting too close to wall • Pull washer away from the wall; about 4″(11 cm)
causes knocking during cycle) is needed.
PERFORMANCE (cont.) Possible Causes What To Do
Pilling Result of normal wear on •While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Snags, holes, tears, rips Pins, snaps, hooks, sharp •Fasten snaps, hooks, buttons, and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets
zippers, and sharp objects and sharp buttons.
left in pockets •Turn knits (which snag easily) inside out.
Undiluted chlorine bleach •Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes
to come in contact with undiluted bleach.
Chemicals like hair bleach •Rinse items that may have chemicals on them before
or dye, permanent wave washing.
solution
Wrinkling Improper sorting •Avoid mixing heavy items (like work clothes) with
light items (like blouses).
•Try a fabric softener.
Overloading or incorrect •Load your washer so clothes have enough room
water level to move freely with water covering all of the clothes.
Incorrect wash and •Match Cycle selection to the type of fabric you are
dry cycles washing (especially for easy care loads).
Repeated washing in •Wash in warm or cold water.
water that is too hot
Before you call for service…
14

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
All warranty service provided by our Factory Service Centers or an authorized technician.
For service, call 1.800.361.3400.
What Is Not Covered:
■Service trips to your home to teach you how to use
the product.
Read your Owner’s Manual. If you then have any questions
about operating the product, please contact your dealer
or our Consumer Affairs office at the address below.
Manager, Consumer Relations
Camco Inc.
1 Factory Lane, Suite 310
Moncton, N.B.
E1C 9M3
■Improper installation.
If you have an installation problem, contact your
dealer or installer. You are responsible for providing
adequate electrical, exhausting and other connecting
facilities.
■ Replacement of house fuses or resetting of circuit
breakers.
■Failure of the product if it is misused, or used for
other than the intended purpose or used
commercially.
■ Damage to product caused by accident, fire, floods or
acts of God.
■ Damage to finish not reported within 48 hours
following the delivery of the appliance.
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
Warrantor: CAMCO INC.
Washer Warranty.
15
For The Period Of: We Will Replace:
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this
From the date of the full one-year warranty, we will also provide, free of charge, all labor and in-home service to replace
original purchase the defective part.
Five Years The transmission, if it should fail due to a defect in materials or workmanship. We will also replace
From the date of the the washer lid or cover, if they should rust under normal operating conditions. During this
original purchase additional four-year limited warranty, you will be responsible for any labor or in-home service costs.
Ten Years The washer basket and washer tub, if any of these parts should fail due to a defect in materials or
From the date of the workmanship. During this additional nine-year limited warranty, you will be responsible for any
original purchase labor or in-home service costs.

Schedule Service 1.800.361.3400
Repair service is close to you.
To arrange service for your Moffat appliance, all you have to do is call.
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted).
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be
referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.
You will find the nearest Camco Service Center number in the yellow pages of your phone book. Or, call us at
1.888.261.3055.
Contact Us
If you are not satisfied with the service you have received:
First of all, communicate with the people who repaired your appliance.
Then, if you are still not satisfied, send all information including telephone number to:
Director, Consumer Relations, Camco, Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Printed in the United States
Consumer Support.
16
