Mojawa MOJO1 User manual

MOJO1
User Guide

Components
Micphone 1
Micphone 2
Alula Clip
LED Indicator
1
Volume+/Power Button
Volume- Button
Multi-Function Button
Charging Port
Quick Start
1. Power on:
Press and hold the Power button for 2 seconds.
2. Pairing:
Press and hold the Power button for 4 seconds to enter the pairing mode. On
your phone, tap to search for the Bluetooth device named “MOJO1” to connect.
2

How to Wear Identify the left and the right of the headphones
by the Volume button and the LED indicator
should be on the right side. Wear the head-
phones by putting it in the back of your head
and make it rmly seat on your ears.
3
Volume- Button
Volume+ / Power Button
4

Power On
Press and hold the Power button for 2 seconds until it says “Power On”
Power Off
Volume Up/Down
Click Vol+/ Vol-. A tone will sound whenever click the button and there
will be a special tone when the volume is set to the maximum.
Multi-function Button
Multi-function Button
5
Function Action
Play/Pause music Click 1x
Skip to the next track Click 2x
Back to the previous track Click 3x
Answer a call Click 1x
Decline an incoming call Press and hold the button for 2
seconds
Cancel an outgoing call Click 1x
Hang up a call Click 1x
6
Press and hold the Power button for 2 seconds until the tone is heard
and release the Power button then it will say “Power Off and the
indicator flashes red for 1 second then off.
”

Continue to talk with A and decline B
Hang up on the call from A and an-
swer B
Click the Function button twice
to hang up on the current call
with A and answer the incom-
ing call from B.
Put A on hold and answer B
While talking on the call with
A, click the Function button
once to answer the incoming
call from B.
Voice assistant Press and hold the button for 2
seconds.
Switch between your phone and
headphones for talk
Click the button twice on the
call.
7
About Charging
Charge the headphones with the included magnetic charging cable. The indi-
then charge the headphones.
8
While talking to A, press and
hold the Function buttonfor 2
seconds to decline the incoming
call from B

Bluetooth Connection
With the headphones powered off, press and hold the
Power button for 4 seconds to enter the pairing mode.
The red and blue indicators flash
On your phone, tap to search for the Bluetooth device
named “MOJO1”.
The headphones say “Power On” and “Pairing”, and
alternately until the headphones say “Source
Connect automatically With the headphones (with a pairing history) powered
off, press and hold the Power button for 2 seconds
to reconnect the last-connected Bluetooth-enabled
device. The headphones say “Power On” and “Source
Disconnect Disable Bluetooth on the phone for disconnection
from the headphones. The headphones say “Source
twice slowly.
Turn on Bluetooth With Bluetooth disabled, press and hold the Power
button and the Function button simultaneously for
2 seconds for reconnecting through Bluetooth. The
headphones say “Source Connected”.
9
Turn off Bluetooth When Bluetooth connection is established, press and
hold the Power button and the Functionbutton simul-
taneously for 2 seconds for disconnection of Bluetooth.
The headphones say “Source Disconnected”.
Unpair Use the phone to cancel the pair with the headphones.
The headphones say “Source Disconnected Pairing”
erable again.
Reconnect automat-
ically
With the headphones powered on,
1. When the headphones have been paired with the
phone, move the headphones outside the Bluetooth
range for disconnection;
2. When the headphones are moved back within the
Bluetooth range within 10 minutes, the headphones
automatically resume the connection with the last
connected phone (if the headphones have been
paired with several devices, the headphones automat-
ically reconnect the last connected Bluetooth-enabled
phone), say “Source Connected”, and resume the
fore the last disconnection.
10
Disconnected
and become discov
status be
Connected
Connected

Model: MOJO1 Speaker:Bone conduction
speaker
Frequency response: 2.4GHz Bluetooth range: 10 m
Microphone sensitivity: -36dB Bluetooth version : Bluetooth 5.0
Bluetooth protocol: A2DP 1.3, HFP (Hands- Endurance: Up to 8 hours
Battery type: Li-polymer battery Charging time: <=80 minutes
Standby time: The product will power off
automatically when it is not connected for
3 minutes.
Power supply:5V 500mA
Weight: 34g(with Alula) Warranty period: 1 year
Charging voltage: 5±0.25 V Ingress protection rating: IP67
Speaker impedance: 8.0 ohm±20% Battery capacity: 150mAh
Bluetooth frequency range: 2.402-2.480 GHz Bluetooth output power: >=3dBm
11
Flashes blue for 1 second Power on
Flashes red for 1 second Power off
Flashes blue slowly Connectable
Flashes red and blue 3 times every second Ready to pair
Flashes blue for 1 second Connected
Incoming call
LED Indicator
12

When the battery level is lower than 30%, the indicator
ashes red at an interval of 1 second.
When the battery level is between 30% and 80%, the
indicator ashes green at an interval of 1 second.
When the battery level is between 80% and 100%, the
indicator ashes blue at an interval of 1 second.
When the battery is fully charged, all indicators turn
solid blue simultaneously.
Charging
The indicator ashes red for 0.05 seconds every 10 sec-
onds for two times.
Low battery
The indicator ashes red for 0.5 seconds and then off
for 0.5 seconds, repeating for three times.
Reset to factory default
settings
13
Storage and Maintenance
The headphones should be stored in a cool and dry place. It should be used at the
ambient temperature between 5°F (-15°C) and 131°F (55°C) and charged at the am-
bient temperature between 32°F(0°C) and 104°F(40°C). The lifespan of the battery
may be reduced when it is operated in extreme environment where it is too cold,
hot or damp.
When left unused for a long time, the headphones must be recharged before use.
The headphones may be cleaned regularly, but the microphone may not be ushed
or immersed, otherwise, its performance may be affected.
Clean the headphones with a soft and dry cloth.
Please do not charge the headphones immediately after sports as any residual sweat
at the charging port may damage the circuit of the headphones.
A dry charging port helps to reduce the damage risk of your headphones during
charging.
14

Important Safety Instructions
Use manufacturer-designated accessories and supplies only.
Warning/Caution
• The headphones should be kept out of the reach of children and pets to avoid swal-
lowing it in accident. There is a Li-polymer battery in the headphones, which can
potentially cause a hazard. If the part is swallowed, seek medical care immediately.
The unused headphones should be kept out of the reach of children and pets.
• Do NOT use the headphones at a high volume for an extended period.
– To avoid hearing damage, use the headphones at a comfortable, moderate
volume level. Your hearing may be damaged and the sound may also be dis-
torted at a super high volume.
– Turn the volume down on the headphones before placing it in your ears, then
turn the volume up gradually until you reach a comfortable listening level.
• Use caution and follow applicable laws regarding the use of phone and head
phones if using the headphones for phone calls while driving. Some jurisdictions
the headphones for any other purposes while driving.
15
• When you need to use the headphones while engaging in an activity needing con
struction site or railroad, please beware of your safety and follow relevant laws regard
ing the use of headphones.
• This product contains small parts which may be a choking hazard. It is not suitable
for children under age 3.
• This product contains magnetic material. Consult your physician on whether this
might affect your implantable medical device.
• Do not make unauthorized alterations to this product.
• Use this product only with an agency approved power supply that meets local reg-
ulatory requirements (e.g., UL, CSA, VDE, CCC).
• Do NOT expose products containing batteries to excessive heat (e.g. from storage in
16

•
• Do not charge this product during thunder and lightning.
•
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc.
Apple, the Apple logo, iPad, iPhone, and iPod are trademarks of Apple Inc., registered in
the U.S. and other countries/regions. App Store is a service mark of Apple Inc. Use of the
-
-
veloper to meet Apple performance standards. Apple is not responsible for the opera-
tion of this product or its compliance with safety and regulatory standards. Please note
that the use of this accessory with an Apple product may affect wireless performance.
Android, Google Play, and the Google Play logo are trademarks of Google LLC.
17
Optional Accessories
Earplugs
When traveling by plane or train, you may use ear earplugs to block out back-
ground noise and enjoy better bone conduction sound.
Adjustable clip
Alula clip is suitable for different adjustable clips for varying grip.
Safety Reminder: When you wear the headphones with an Alula in a dark en-
Alula, which will serve as a reminder to warn the driver to pay attention to
safety driving.
Reset to factory default settings
Press and hold the Power button and Function button simultaneously for
4 seconds.
The headphones will be reset. All the pairing history will be deleted and the
volume is reset to the initial value, 8.
18
