Momax 2 Healthy User manual

2 Healthy MAX
IoT Air Purifying Dehumidifier
AP11S
INSTRUCTION MANUAL
IoT 智能 2-in-1 空氣淨化抽濕機
使用說明 / 使用說明
IoT 智能 2-in-1 空氣淨化除濕機
N2

Product Information p.2 - 29
產品資料 p.30 - 52
產品資料 p.53 - 75
1

IoT Air Purifying & Dehumidifier (AP11S)
• Purifies air with H11 HEPA, Activated carbon filters and Antibacterial
Coating.
• Works with low-temperature dehumidification up to 5°C.
• Smart control with MOMAX Smart APP and trigger automation
based on environment.
• Dehumidification up to 12L per day.
Introduction Quick Start Guide
1. Download ‘MOMAX Smart’ APP
Download “MOMAX Smart” from iOS App Store, Android Google
Play Store or other platforms.
2. Register
Register an account and log in using your mobile number or email
address.
3. Wireless Pairing
Click “+”, then tap “MOMAX Smart Air Purifying & Dehumidifier” to
add device.
Press and hold the Timer button for about 5 seconds until you hear a
beep sound and the Wifi indicator rapidly blink. Tap “Confirm indicator
rapidly blink”. Then, tap ‘Next’ to proceed.
• This product cannot be paired directly through the Bluetooth list of the mobile
phone.
• The pairing process may take 2 minutes, please do not perform other operation.
4. Successfully connected
Once the connection is completed, you can edit the name of the Air
Purifying Dehumidifier.
Before Using
1. Please make sure the electric power supply of your region meets the
product’s requirement.
2. An independent 13A switch must be used for this product.
3. Make sure there are no broken parts of the power cord and the
product.
4. This product cannot replace daily air ventilation and dust collection.
5. Do not insert your fingers or objects into the air outlet or the air inlet to
prevent physical injury or malfunctioning of the appliance.
2 3

1
2
3
4
5
6
7
8
Find “AP11S” in MOMAX’s channel
helpdesk.momaxsmart.com
Get step-by-step setup and support.
Watch the latest video tutorial to learn to setup and operate your AP11S.
Keep up to date with the latest updates.
Product Overview
1. Control Panel
2. Portable Handle
3. Body
4. Wheels
5. Air Inlet Cover
6. Air Purifying Filter
7. Water Tank
8. Drainage Hole
4 5

Control Panel LED Control
Touch
Control
LED
Display
1
2
3
4
5
6 7 8
1. Wi-Fi Indictor
2. Relative Humidity Display
3. Child Lock Indictor
4. Water Tank Full Indictor
5. Power Indicator
6. Relative Humidity Indicator
7. Timer Indicator
8. Windspeed Indicator
Power Button
Humidity Setting Button
Timer Button
Fan Speed/ Child Lock Button
6 7

Function
Power Button
• Touch the button to control the device power on/off.
• Once the machine is turned on, the power indicator will
turn on.
Humidity Setting Button
• Touch the button to set the target environmental
humidity between 40%, 60%, 80% and Cont.
(Continuous dehumidification).
Timer Button
• Touch the button to set the timer of 2H, 4H and 8H.
• Long press the timer button to enter pairing mode.
Fan Speed/ Child Lock Button
• Touch the button to set the fan speed of the machine
between High (H), Low (L) and Sleep.
• Long press 3 seconds to activate or cancel child lock
function.
Relative Humidity Display
• Display the ambient humidity value of the machine.
Child Lock Indicator
• Display when Child lock is on, all buttons are locked.
Water Tank Full Indicator
• When the water tank is full, the indicator is on and the
machine will stop.
Air Quality Indicator:
After the machine is powered on for 30s, it will be in the reservation
state. At this time, the color lights at the bottom of the control panel
will gradually change for 30s (in the order of blue, cyan, green, yellow,
orange, red and purple).
Air quality control results are as follows:
• The ambient light turns blue when the air quality is good.
• The ambient light turns yellow when the air quality is normal.
• The ambient light turns red when the air quality is poor.
When the machine is in sleep mode, the full-color lights go out and the
machine enters sleep mode.
Dehumidification Humidity Setting:
When the relative humidity setting is switched, the corresponding relative
humidity indicator will be turned on, and the machine will dehumidify
according to the set relative humidity value (40%, 60%, 80%, Cont).
8 9

Safety Features
Continuous Drainage:
When the machine needs to drain continuously, use a proper flexible
rubber pipe (not included in this product) to connect to the drainage hole
to the hole at the back of device. Water will not be stored in the water tank
when the machine is running on continuous drainage.
• Extend the continuous drainage pipe from the continuous drainage
outlet into the machine, and then insert the pipe from the tank port into
the drainage hole.
• When using continuous drainage, the pipe should be placed flat on the
ground. Any part of the pipe should not be folded or warped, and the
outlet end of the pipe should not extend below the liquid level of other
containers.
Water Tank Full Automatic Protection:
• When the machine is working, if the tank is full, the compressor and the
fan motor will stop working, and the tank full indicator will be on.
• Take out the tank and pour out the water.
• Put the tank back, and the machine will restart according to the state
before the tank is full (Dehumidification will not start until 3 mins later).
Filter Replacement Reminder:
• When the whole machine has been running for 2,200hr in total, the
power indicator will flash at the frequency of 1s/time, reminding that
the filter needs to be replaced. If the filter has been replaced, you can
long press the power button to reset.
Maintenance
Ensure the machine is unplugged before maintenance.
Cleaning:
Wipe the tank and the body with a soft. (Do not use corrosive detergents.)
Clean the filter with a vacuum cleaner every 2 weeks to ensure a good
dehumidification effect.
10 11

Specification
This page records the main topics of safety precautions to prevent
personal injury or property loss of users and others. Please read them
carefully and observe the precautions recorded here.
1. Do not operate this machine with wet hands, or flush the dehumidifier
directly with water, or place this machine near the water source.
2. Do not put your hands into the air outlet or the inside of it; Do not
place heavy weights at the air outlet of this machine or sit directly at
the air outlet.
3. Do not throw or place any objects into the dehumidifier.
4. Do not put flammable and explosive gases in the place where the
dehumidifier is used, and please keep this machine away from any
heat source.
5. It is forbidden to turn off the machine directly through the power
switch; and when the machine is not in use in a long term, please turn
off the power switch.
6. In case of anything untoward (e.g., the machine gives off burning
smell), the machine must be stopped from running with the power
supply cut off.
7. The power supply must be cut off during thunderstorms.
8. It is forbidden to replace the power cord without authorization, or
connect the power cord midway or use it in parallel with other high-
power electrical appliances.
9. It is forbidden to disassemble, modify, repair or clean internal devices
without authorization.
10. When cleaning the machine, please stop it and turn off the power
switch.
11. The appliance is for indoor use only.
12. Do not use the unit on a socket under repairs or not installed properly
Safety Precautions
Model No. : AP11S
Rated Voltage : AC 220~240V, 50Hz
Rated Power : 158W
Maximum Power : 205W
Filter Type : HEPA H11 Filter With Activated Carbon &
Anti-Bacterial Technology
Effective Area : Up to 24m² (Ceiling Height 2.3m)
CADR : Approx. 55.8m³/Hr
Water tank Volume : 3.2L
Humidity Setting : 40%, 60%, 80%, Cont
Dehumidification Capacity : 12L/Day (30°C, RH80%),
6.9L/Day (27°C, RH60%)
Work Temperature : 5°C – 35°C
Noise Level : <45dB
Maximum Refrigerant Charge : R290/45g
Allowable Working Pressure : 4.52MPa (Maximum)
Discharge Pressure : 2.6MPa (Maximum)
Wireless Frequency : 2.4GHz
Size : 295 x 295 x 560mm
Weight : 12kg ± 100g
Contains
1.2 Healthy MAX IoT Air Purifying Dehumidifier
2.HEPA Filter With Activated Carbon & Anti-Bacterial Technology (1pc)
3.Wheels (4pcs)
4.Instruction Manual And Warranty Card
12 13

13. Do not use the unit, follow these precautions:
A: Near to source of fire.
B: An area where oil is likely to splash.
C: An area exposed to direct sunlight.
D: An area where water is likely to splash.
E: Near a bath, a laundry, a shower or a swimming pool.
14. Never insert your fingers, rods into the air outlet. Take special care to
warn children of these dangers.
15. Keep the unit upward while transport and storage, for the
compressor locates properly.
16. Children should be supervised to ensure that they do not play with
the appliance.
17. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
18. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
19. The appliance shall be installed in accordance with national wiring
regulations.
20. Details of type and rating of fuses : T, 250V AC,6.3A.
21. Recycling.
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product
was purchased. They can take this product for environmentally safe
recycling.
22. Contact authorized service technician for repair or maintenance of
this unit.
23. Do not pull, deform. or modify the power supply cord or immerse
it in water. Pulling or misuse of the power supply cord can result in
damage to the unit and cause electrical shock.
24. Compliance with national gas regulations shall be observed.
25. Keep ventilation openings clear of obstruction.
26. Any person who is involved with working on or breaking into a
refrigerant circuit should hold a current valid certificate from an
industry-accredited assessment authority, which authorizes their
competence to handle refrigerants safely in accordance with an
industry recognized assessment specification.
27. Servicing shall only be performed as recommended by the
equipment manufacturer. Maintenance and repair requiring the
assistance of other skilled personnel shall be carried out under
the supervision of the person competent in the use of flammable
refrigerants.
28. Do not operate or stop the unit by inserting or pulling out Die power
plug, it may cause electric shock or fire due to heat generation.
29. Unplug the unit if strange sounds, smell, or smoke comes from it.
30. Do not lean the machine against obstacles or walls.
31. Please keep a distance of more than 20cm from the machine to its
rear and to its left and right, and a distance of more that 50cm from
the machine to its top and to its front.
14 15

Notes:
1. If any parts damage, please contact the dealer or a designated repair
shop.
2. In case of any damage, please turn off the air switch, disconnect the
power supply, and contact the dealer or a designated repair shop;
3. In any case, the power cord shall be firmly grounded.
4. To avoid the possibility of danger, if power cord is damaged, please
turn off the air switch and disconnect the power supply. It must be
replaced from the dealer or a designated repair.
Checks to the area
Prior to beginning work on systems containing flammable refrigerants,
safety checks are necessary to ensure that the risk of ignition is minimized.
For repair to the refrigerating system, the following precautions shall be
complied with prior to conducting work on the system.
a) Work procedure
Work shall be undertaken under a controlled procedure so as to
minimize the risk of a flammable gas or vapour being present while the
work is being performed.
b) General work area
All maintenance staff and others working in the local area shall be
instructed on the nature of work being carried out. Work in confined
spaces shall be avoided. The area around the workspace shall be
sectioned off. Ensure that the conditions within the area have been
made safe by control of flammable material.
c) Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector
prior to and during work, to ensure the technician is aware of potentially
flammable atmospheres.
Ensure that the leak detection equipment being used is suitable for use
with flammable refrigerants, i.e. non-sparking, adequately sealed or
intrinsically safe.
d) Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or
any associated parts, appropriate fire extinguishing equipment shall
be available at hand.
Have a dry powder or CO2 fire extinguisher adjacent to the charging
area.
16 17

e) No ignition sources
No person carrying out work in relation to a refrigeration system
which involvesexposing any pipe work that contains or has contained
flammable refrigerant shall use any sources of ignition in such a
manner that it may lead to the risk of fire or explosion.
All possible ignition sources, including cigarette smoking, should be kept
sufficiently far away from the site of installation, repairing, removing
and disposal, during which flammable refrigerant can possibly be
released to the surrounding space.
Prior to work taking place, the area around the equipment is to be
surveyed to make sure that there are no flammable hazards or ignition
risks. No Smoking signs shall be displayed.
f) Ventilated area
Ensure that the area is in the open or that it is adequately ventilated
before breaking into the system or conducting any hot work. A degree
of ventilation shall continue during the period that the work is carried
out. The ventilation should safely disperse any released refrigerant and
preferably expel it externally into the atmosphere.
g) Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit
for the purpose and to the correct specification. At all times the
manufacturer’s maintenance and service guidelines shall be followed.
If in doubt consult the manufacturer’s technical department for
assistance. The following checks shall be applied to installations using
flammable refrigerants:
The charge size is in accordance with the room size within which the
refrigerant containing parts are installed; The ventilation machinery
and outlets are operating adequately and are not obstructed; If an
indirect refrigerating circuit is being used, the secondary circuit shall
be checked for the presence of refrigerant; Marking to the equipment
continues to be visible and legible.
Markings and signs that are illegible shall be corrected; Refrigeration
pipe or components are installed in a position where they are unlikely
to be exposed to any substance which may corrode refrigerant
containing components, unless the components are constructed
of materials which are inherently resistant to being corroded or are
suitably protected against being so corroded.
h) Checks to electrical devices
Repair and maintenance to electrical components shall include
initial safety checks and component inspection procedures. If a fault
exists that could compromise safety, then no electrical supply shall
be connected to the circuit until it is satisfactorily dealt with. If the
fault cannot be corrected immediately but it is necessary to continue
operation, an adequate temporary solution shall be used.
This shall be reported to the owner of the equipment so all parties
are advised. Initial safety checks shall include: That capacitors are
discharged: this shall be done in a safe manner to avoid possibility
of sparking; That there no live electrical components and wiring are
exposed while charging, recovering or purging the system; That there
is continuity of earth bonding.
Repairs to sealed components
a) During repairs to sealed components, all electrical supplies shall be
disconnected from the equipment being worked upon prior to any
removal of sealed covers, etc. If it is absolutely necessary to have an
electrical supply to equipment during servicing, then a permanently
operating form of leak detection shall be located at the most critical
point to warn of a potentially hazardous situation.
b) Particular attention shall be paid to the following to ensure that by
working on electrical components, the casing is not altered in such a
way that the level of protection is affected. This shall include damage
to cables, excessive number of connections, terminals not made to
original specification, damage to seals, incorrect fitting of glands, etc.
18 19

Ensure that apparatus is mounted securely. Ensure that seals or
sealing materials have not degraded such that they no longer serve
the purpose of preventing the ingress of flammable atmospheres.
Replacement parts shall be in accordance with the manufacturer’s
specifications.
The use of silicon sealant may inhibit the effectiveness of some types of
leak detection equipment. Intrinsically safe components do not have to
be isolated prior to working on them.
1. Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance loads to the
circuit without ensuring that this will not exceed the permissible voltage
and current permitted for the equipment in use. Intrinsically safe
components are the only types that can be worked on while live in the
presence of a flammable atmosphere. The test apparatus shall be at
the correct rating. Replace components only with parts specified by
the manufacturer. Other parts may result in the ignition of refrigerant
in the atmosphere from a leak.
2. Cabling
Check that cabling will not be subject to wear, corrosion, excessive
pressure, vibration, sharp edges or any other adverse environmental
effects. The check shall also take into account the effects of aging or
continual vibration from sources such as compressors or fans.
3. Detection of flammable refrigerants
Under no circumstances shall potential sources of ignition be used in
the searching for or detection of refrigerant leaks. A halide torch (or
any other detector using a naked flame) shall not be used.
4. Leak detection methods
The following leak detection methods are deemed acceptable for
systems containing flammable refrigerants.
Electronic leak detectors shall be used to detect flammable
refrigerants, but the sensitivity may not be adequate, or may need re-
calibration. (Detection equipment shall be calibrated in a refrigerant-
free area).
Ensure that the detector is not a potential source of ignition and is
suitable for the refrigerant usedleak detection equipment shall be set
at a percentage of the LFL of the refrigerant and shall be calibrated to
the refrigerant employed and the appropriate percentage of gas (25
% maximum) is confirmed.
Leak detection fluids are suitable for use with most refrigerants but the
use of detergents containing chlorine shall be avoided as the chlorine
may react with the refrigerant and corrode the copper pipe-work.
If a leak is suspected, all naked flames shall be removed/ extinguished.
If a leakage of refrigerant is found which requires brazing, all of the
refrigerant shall be recovered from the system, or isolated (by means
of shut off valves) in a part of the system remote from the leak.
Oxygen free nitrogen (OFN) shall then be purged through the system
both before and during the brazing process.
5. Removal and evacuation
When breaking into the refrigerant circuit to make repairs or for any
other purpose conventional procedures shall be used.
However, it is important that best practice is followed since flammability
is a consideration.
The following procedure shall be adhered to:
• Remove refrigerant;
• Purge the circuit with inert gas;
• Evacuate;
• Purge again with inert gas;
• Open the circuit by cutting or brazing.
20 21

The refrigerant charge shall be recovered into the correct recovery
cylinders.
The system shall be flushed with OFN to render the unit safe.
This process may need to be repeated several times.
Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking the vacuum in the system with
OFN and continuing to fill until the working pressure is achieved, then
venting to atmosphere, and finally pulling down to a vacuum.
This process shall be repeated until no refrigerant is within the system.
When the final OFN charge is used, the system shall be vented down
to atmospheric pressure to enable work to take place.
This operation is absolutely vital if brazing operations on the pipe-work
are to take place.
Ensure that the outlet for the vacuum pump is not close to any ignition
sources and there is ventilation available.
6. Charging procedures
In addition to conventional charging procedures, the following
requirements shall be followed.
Ensure that contamination of different refrigerants does not occur
when using charging equipment. Hoses or lines shall be as short as
possible to minimise the amount of refrigerant contained in them.
Cylinders shall be kept upright.
Ensure that the refrigeration system is earthed prior to charging the
system with refrigerant. Label the system when charging is complete
(if not already).
Extreme care shall be taken not to overfill the refrigeration system. P
rior to recharging the system it shall be pressure tested with OFN.
The system shall be leak tested on completion of charging but prior to
commissioning. A follow up leak test shall be carried out prior to leaving
the site.
7. Decommissioning
Before carrying out this procedure, it is essential that the technician
is completely familiar with the equipment and all its detail. It is
recommended good practice that all refrigerants are recovered safely.
Prior to the task being carried out, an oil and refrigerant sample
shall be taken in case analysis is required prior to re-use of reclaimed
refrigerant. It is essential that electrical power is available before the
task is commenced.
a) Become familiar with the equipment and its operation.
b) Isolate system electrically.
c) Before attempting the procedure ensure that:
• Mechanical handling equipment is available, if required, for
handling refrigerant cylinders;
• All personal protective equipment is available and being used
correctly;
• The recovery process is supervised at all times by a competent
person;
• Recovery equipment and cylinders conform to the appropriate
standards.
d) Pump down refrigerant system, if possible.
e) If a vacuum is not possible, make a manifold so that refrigerant can
be removed from various parts of the system.
f) Make sure that cylinder is situated on the scales before recovery
takes place.
g) Start the recovery machine and operate in accordance with
manufacturer’s instructions.
h) Do not overfill cylinders. (No more than 80 % volume liquid charge).
22 23

i) Do not exceed the maximum working pressure of the cylinder, even
temporarily.
j) When the cylinders have been filled correctly and the process
completed, make sure that the cylinders and the equipment
are removed from site promptly and all isolation valves on the
equipment are closed off.
k) Recovered refrigerant shall not be charged into another
refrigeration system unless it has been cleaned and checked.
8. Labelling
Equipment shall be labelled stating that it has been de-commissioned
and emptied of refrigerant. The label shall be dated and signed.
Ensure that there are labels on the equipment stating the equipment
contains flammable refrigerant.
9. Recovery
When removing refrigerant from a system, either for servicing
or decommissioning, it is recommended good practice that all
refrigerants are removed safely.
When transferring refrigerant into cylinders, ensure that only
appropriate refrigerant recovery cylinders are employed. Ensure that
the correct number of cylinders for holding the total system charge is
available. All cylinders to be used are designated for the recovered
refrigerant and labelled for that refrigerant (i.e. special cylinders for
the recovery of refrigerant). Cylinders shall be complete with pressure
relief valve and associated shut-off valves in good working order.
Empty recovery cylinders are evacuated and, if possible, cooled before
recovery occurs.
The recovery equipment shall be in good working order with a set of
instructions concerning the equipment that is at hand and shall be
suitable for the recovery of flammable refrigerants. In addition, a set
of calibrated weighing scales shall be available and in good working
order. Hoses shall be complete with leak-free disconnect couplings and
in good condition.
Before using the recovery machine, check that it is in satisfactory
working order, has been properly maintained and that any associated
electrical components are sealed to prevent ignition in the event of a
refrigerant release.
Consult manufacturer if in doubt.
The recovered refrigerant shall be returned to the refrigerant supplier
in the correct recovery cylinder, and the relevant Waste Transfer Note
arranged. Do not mix refrigerants in recovery units and especially not in
cylinders. If compressors or compressor oils are to be removed, ensure
that they have been evacuated to an acceptable level to make certain
that flammable refrigerant does not remain within the lubricant.
The evacuation process shall be carried out prior to returning the
compressor to the suppliers. Only electric heating to the compressor
body shall be employed to accelerate this process. When oil is drained
from a system, it shall be carried out safely.
24 25

• Please recycle or dispose of the packaging material for product in an
environmentally responsible manner.
• Never store or ship the air conditioner upside down or sideways to avoid
damage to the compressor.
• Dispose of this appliance in accordance with Federal and Local
regulations. Refrigerants must be evacuated before disposal.
• Risk of Fire or Explosion. This unit contains flammable
• Refrigerant. Additional safety precautions must be followed.
• Do not use means to accelerate the defrosting process or to clean,
other than those recommended by the manufacturer.
• The appliance shall be stored in a room without continuously operating
ignition sources (for example: open flames, an operating gas appliance
or an operating electric heater.
• Do not pierce or bum refrigerant tubing. Be aware that refrigerants
may not contain odor.
• Keep ventilation openings clear of obstruction.
• When handling, installing, and operating the appliance, care should be
taken to avoid damage to the refrigerant tubing.
• Do not drill holes in the unit.
• Maintenance, cleaning and service should only be performed by
technicians properly trained and qualified in the use of flammable
refrigerants.
• Dispose of air conditioner in accordance with Federal and Local
Regulations. Flammable refrigerants require special disposal
procedures. Contact your local authorities for the environmentally safe
disposal of your air conditioner.
Storage And Disposing Of The Unit
Transport of equipment containing flammable refrigerants.
Attention is drawn to the fact that additional transportation regulations
may exist with respect to equipment containing flammable gas. The
maximum number of pieces of equipment or the configuration of the
equipment, permitted to be transported together will be determined by
the applicable transport regulations.
Marking of equipment using signs.
Signs for similar appliances used in a work area generally are addressed
by local regulations and give the minimum requirements for the provision
of safety and/or health signs for a work location.
All required signs are to be maintained and employers should ensure
that employees receive suitable and sufficient instruction and training on
the meaning of appropriate safety signs and the actions that need to be
taken in connection with these signs.
The effectiveness of signs should not be diminished by too many signs
being placed together.
Any pictograms used should be as simple as possible and contain only
essential details.
Disposal of equipment using flammable refrigerants.
See national regulations.
Storage of equipment/appliances
The storage of equipment should be in accordance with the
manufacturer’s instructions.
Storage of packed (unsold) equipment
Storage package protection should be constructed such that mechanical
damage to the equipment inside the package will not cause a leak of the
refrigerant charge.
The maximum number of pieces of equipment permitted to be stored
together will be determined by local regulations.
Transportation, marking and storage for units that
employ flammable refrigerants.
26 27

Please reference Mobile Apps content: Before accepting the Agreement,
you are supposed to thoroughly read all the contents of the Agreement,
and fully understand its terms, especially restrictive clauses or exceptions
and Privacy Notice. Restrictive clauses or exceptions are bold or
highlighted in other forms to catch your attention. In case of any doubt
about the terms of the Agreement, please contact the relevant business
department of Tuya. You are not allowed to use the service before
you have read and accepted all the terms of the Agreement, relevant
agreements, and rules, etc. Once you select “agree and submit the
Agreement” (see registration page for detailed wordings) and complete
the registration procedure, or you use the service in any form, it will be
deemed that you have read and agreed with the restriction of the
Agreement and rules above. In case of any breach of the Agreement,
Tuya has the right to unilaterally restrict, suspend or terminate the service
for you, and has the right to investigate your relevant responsibilities.
Service Agreement of
Smart Mobile Application Platform
1. Do not place the product as household waste;
2. Please dispose of discarded electronic products properly according to
local regulations;
3. MOMAX encourages you to participate in the electronic recycling
program.
Disposal of Electronic Products
1. For any defect, in the judgment of our technician, caused under
normal use, we are responsible for repairing free of charge 12 months
commencing from the date of purchase at the discretion of our
company;
2. A valid warranty card and original purchase invoice must be presented
upon request of warranty service;
3. This warranty card shall not apply to the product if:
(a) It is consumable part(s), such as Filter, or;
(b) it has explicitly modified or repaired in any way by persons other
than technicians of this company, or;
(c) it has been damaged through misuse, malicious acts, negligence,
the inflow of any liquid, or;
(d) losses or damages are caused by force majeure or natural
disasters.
4. No alteration to this warranty card will be allowed;
5. The warranty terms and conditions are subject to change without prior
notice;
6. Please retain your proof of purchase for warranty service;
7. Please consult the dealer about the product compatibility with your
cell phone/ PDA before purchase. Product specifications are subject
to change without prior notice;
8. Please visit www.momax.net for the latest product information.
Warranty Conditions
28 29

簡介
IoT 智能2-in-1空氣淨化抽濕機 (AP11S)
•通過H11HEPA，活性碳濾網及抗菌塗層淨化空氣。
•環境溫度低至5度仍能有效抽濕
•通過MOMAXSmartAPP進行遙距控制，並可根據環境觸發自動化。
•每天最多抽濕量可達12L
搜尋 “AP11S” in helpdesk.momaxsmart.com
獲取有關設定和支援。
觀看最新的視頻教學，學習設置和操作您的 AP11S。
隨時了解最新資訊。
使用之前
1. 請確保你所在地區的電源供應符合產品需求。
2. 本產品必需使用獨立13A電源插座。
3. 確保電源線和產品沒有破損。
4. 本產品不能代替日常通風，日常除塵。
5. 請勿將手指或其他物體插入出風口或入氣口，以免造成人身傷害或設備
故障。
快速入門指南
1. 下載“MOMAX Smart”應用程式
在iOS或Android或任何平台上下載“MOMAXSmart”應用程式。
2. 註冊
註冊一個帳戶，然後使用您的手機號碼或電子郵件地址登錄。
3. 無線配對
按“+”（添加設備），選取“MOMAX 智能2-in-1空氣淨化抽濕機”以
添加設備。
打開設備，按住定時鍵約5秒直到聽到一聲提示聲及看到Wifi提示燈在快
閃。按＂確定提示燈正在快閃＂，再按＂下一步＂。
•不能透過手機的藍牙清單直接配對本產品。
•搜索過程可能需要兩分鐘。請在此期間不要執行任何操作。
4. 成功連接
如果配對成功，你會在應用程式中看到本產品的圖標。你可以修改此
AP11S的名稱。確保您的設備已連接，結果將發送到手機的應用程式。
30 31

1
2
3
4
5
6
7
8
產品總覽
1. 控制面板
2. 手提把手
3. 機身
4. 輪子
5. 空氣淨化濾網蓋
6. 濾網
7. 水箱
8. 排水口
控制鍵
LED
顯示器
控制面板
電源開關鍵
濕度設定鍵
定時鍵
風速鍵/童鎖鍵
32 33

1
2
3
4
5
6 7 8
LED 顯示器
1. Wi-Fi指示燈
2. 相對濕度顯示
3. 童鎖指示燈
4. 水滿指示燈
5. 電源指示燈
6. 濕度指示燈
7. 定時指示燈
8. 風速指示燈
功能
電源開關鍵
•控制設備開機/關機
•當設備開機後，電源指示燈會亮起來
濕度設定鍵
•設定環境的目標濕度，可設為40%,60%,80%或連續抽濕
定時鍵
•設定機器定時關機時間，可設為2H,4H或8H
•長按定時鍵進入配網模式
風速鍵/童鎖鍵
•設定機器的風速，可設為高風，低風和睡眠模式
•長按3秒可開啟和關閉童鎖功能
相對濕度顯示
•顯示機器附近的環境相對濕度值
童鎖指示燈
•童鎖模式下會亮起，所有按鍵會被鎖定
水滿指示燈
•當水箱滿的時候，指示燈會亮起，而機器會停止運作
34 35

空氣質量指示燈：
設備開機後會有約30秒的預備狀態，此時控制面板底部的顏色燈會漸變 (順序為
藍青綠黃橙紅紫)
空氣質量對照如下：
•空氣質量良好時，燈光顯示為藍色。
•空氣質量正常時，燈光顯示為黃色
•空氣質量差時，燈光顯示為紅色。
當機器進入睡眠模式時，全部燈光會關閉。
抽濕濕度設定：
當按下濕度設定鍵時，其相應的濕度指示燈會亮起，而機器亦會根據設定的
濕度值(40%,60%,80%,連續抽濕)來進行抽濕工作，將環境濕度降至設定值。
連續排水：
當機器需要連續排水時，用一根合適的軟膠管通過進水箱的孔位連接到排水孔
上。當機器連續排水運行時，水箱不會盛水。
• 將連續排水管從連續排水口伸到機器內部，然後從水箱口處將排水管插到排
水孔。
• 連續排水時，排水管需平放於地面。排水管的任何部位不可有折疊和上翹的
情況，以及排水管的出口端不能放入其他容器的水平面下。
36 37
