Monaco 2008 LaPalma XL User manual

i
MONACO LiMited WArrANty - 2008
MONACO®MOTORHOME LIMITED WARRANTY
WHAT THE PERIOD OF COVERAGE IS:
This Limited Warranty provided by Monaco®(“Warrantor”) covers those
components, assemblies and systems of your new motorhome not excluded under the
section “What is Not Covered” and when sold by an authorized dealer, for twelve (12)
months from the original retail purchase date or the rst 24,000 miles of use, whichever
occurs rst. However, this Limited Warranty provided by Warrantor covers the steel or
aluminum frame structure, only, of the sidewalls (excluding slide outs), roof, and rear
and front walls for sixty (60) months from the original retail purchase date or the rst
50,000 miles of use, whichever occurs rst.
If you use your motorhome for any rental, commercial or business purposes
whatsoever, the Limited Warranty provided by Warrantor covers your new motorhome
when sold by an authorized dealer for ninety (90) days from the original retail purchase
date or the rst 24,000 miles of use, whichever occurs rst. In addition, the Limited
Warranty provided by Warrantor covers the steel or aluminum frame structure, only, of
the sidewalls (excluding slide outs), roof, and rear and front walls for twelve (12) months
from the original retail purchase date or the rst 24,000 miles of use, whichever occurs
rst. A conclusive presumption that your motorhome has been used for commercial
and/or business purposes arises if you have led a federal or state tax form claiming
any business tax benet related to your ownership of the motorhome. The above
Limited Warranty coverage applies to all owners, including subsequent owners, of the
motorhome. However, a subsequent owner must submit a warranty transfer form by
ling the form through an authorized Monaco dealer. A subsequent owner’s warranty
coverage period is the remaining balance of the warranty coverage period the prior owner
was entitled to under this Limited Warranty. Warranty transfer forms can be obtained by
contacting the Customer Relations Department. There is no charge for the transfer.
LIMITATIONAND DISCLAIMER OFIMPLIED WARRANTIES:
IMPLIED WARRANTIES, IFANY, ARISING BY WAY OF STATE LAW,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY
AND ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE TERM OFTHIS
LIMITED WARRANTYAND ARE LIMITED IN SCOPE OF COVERAGE
TO THOSE PORTIONS OFTHE MOTORHOME COVERED BYTHIS
LIMITED WARRANTY. WARRANTOR DISCLAIMS ALL IMPLIED AND
EXPRESS WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITYAND THE IMPLIED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE, ON COMPONENTS AND APPLIANCES
EXCLUDED FROM COVERAGE AS SET FORTH BELOW. There is no warranty
of any nature made by Warrantor beyond that contained in this Limited Warranty. No
person has authority to enlarge, amend or modify this Limited Warranty. The dealer is
not the Warrantor’s agent but is an independent entity. Warrantor is not responsible for
any undertaking, representation or warranty made by any dealer or other person beyond
those expressly set forth in this Limited Warranty. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.
WHAT THE WARRANTY COVERS:
Warrantor’s Limited Warranty covers defects in the manufacture of your motorhome
and defects in materials used to manufacture your motorhome. “Defect” means the
failure of the motorhome and/or the materials used to assemble the motorhome to
conform to Warrantor’s design and manufacturing specication and tolerances. Also
see the section “What the Warranty Does Not Cover” set out below.
WHAT WE WILLDO TO CORRECT PROBLEMS:
Warrantor’s sole and exclusive obligation is to repair and/or replace, at its option, any
covered defect if: (1) you notify Warrantor or one of its authorized servicing dealers of
the defect within the warranty coverage period and within ve (5) days of discovering
the defect; and (2) you deliver your Motorhome to Warrantor or Warrantor’s authorized
servicing dealer at your cost and expense. It is reasonable to expect some service items
to occur during the warranty period. The performance of warranty repairs shall not
extend the original warranty coverage period. Further, any performance of repairs after
the warranty coverage period has expired or any performance of repairs to component
parts and appliances that are excluded from coverage shall be considered “good will”
repairs, which shall not alter the express terms of this limited warranty. If the repair
or replacement remedy fails to successfully cure a defect after Warrantor received a
reasonable opportunity to cure the defect(s), your sole and exclusive remedy shall be
limited to Warrantor paying you the cost of having an independent third party perform
repair(s) to the defect(s).
Warrantor may use new and/or remanufactured parts and/or components of
substantially equal quality to complete any repair.
Defects and/or damage to interior and exterior surfaces, trim, upholstery and other
appearance items may occur at the factory during manufacture, during delivery of
the motorhome to the selling dealer or on the selling dealer’s lot. Normally, any such
defect or damage is detected and corrected at the factory or by the selling dealer during
the inspection process performed by the Warrantor and the selling dealer. If, however,
you discover any such defect or damage when you take delivery of the motorhome, you
must notify your dealer or Warrantor within ve days of the date of purchase to have
repairs performed to the defect at no cost to you as provided by this Limited Warranty.
If either three or more unsuccessful repair attempts have been made to correct any
covered defect that you believe substantially impairs the value, use or safety of your
motorhome, or repairs to any covered defect(s) which you believe substantially impairs
the value, use or safety of your motorhome have taken 30 or more days to complete,
you must, to the extent permitted by law, notify Warrantor directly in writing of the
failure to successfully repair the defect(s) so that Warrantor can become directly
involved in exercising a nal repair attempt for the purpose of performing a successful
repair to the identied defect(s).

ii
MONACO LiMited WArrANty - 2008
HOW TO GET SERVICE:
The “Acknowledgement of Receipt of Warranty/Production Information” form must
be returned to Warrantor promptly upon purchase to assure proper part replacement
and repair of your motorhome. Failure to return the “Acknowledgement of Receipt
of Warranty/Production Information” form will not affect your rights under the
Limited Warranty so long as you can furnish proof of purchase. For warranty service
simply contact one of Warrantor’s authorized service centers for an appointment, then
deliver your motorhome (at your expense) to the service center. If you need assistance
in locating an authorized warranty service facility, contact Warrantor’s Warranty
Department (1-877-466-6226). The mailing address is:
91320 Coburg Industrial Way
Coburg, Oregon 97408
In the event the motorhome is inoperative due to malfunction of a warranted part,
Warrantor will pay the cost of having the motorhome towed to the nearest authorized
repair facility provided you notify Warrantor prior to incurring the towing charges to
receive directions to the nearest repair facility.
Because Warrantor does not control the scheduling of service work by its authorized
servicing dealers, you may encounter some delay in scheduling and/or in the
completion of the repairs.
WHAT THE WARRANTY DOES NOT COVER:
This Limited Warranty does not cover: any motorhome sold or registered outside of
the United States or Canada; items which are added or changed after the motorhome
leaves Warrantor’s possession; items that are working as designed but which you
are unhappy with because of the design; normal wear and usage, such as fading or
discoloration of fabrics, or the effects of moisture inside the motorhome; defacing,
scratching, dents and chips on any surface or fabric of the motorhome, not caused by
Warrantor; owner maintenance, including by way of example wheel alignments and
resealing exterior sealant areas; the automotive chassis and power train, including, by
way of example the engine, drivetrain, steering and handling, braking, wheel balance,
mufer, tires, tubes, batteries and gauges; appliances and components covered by
their own manufacturer’s warranty including, by way of example the microwave,
refrigerator, ice maker, stove, oven, generator, roof air conditioners, hydraulic jacks,
VCR, television(s), water heater, furnace, stereo, radio, compact disc player, washer,
dryer, inverter and cellular phone; or aking, peeling and chips or other defects or
damage in or to the exterior or nish caused by rocks or other road hazards, the
environment including airborne pollutants, salt, tree sap and hail. Component part
and appliance manufacturers issue limited warranties covering those portions of the
motorhome not covered by the Limited Warranty issued by Warrantor. To learn more
on what specic component parts and appliances are excluded from the Limited
Warranty issued by Warrantor please contact your selling dealership or Warrantor
directly or review the warranty packet inside the Motorhome.
EVENTS DISCHARGING WARRANTOR FROM OBLIGATION UNDER
WARRANTY:
Misuse or neglect, accidents, unauthorized alteration, failure to provide reasonable
and necessary maintenance (see Owner’s Manual), damage caused by off road use,
collision, re, theft, vandalism, explosions, overloading in excess of rated capacities,
and odometer tampering shall discharge Warrantor from any express or implied
warranty obligation to repair any resulting defect.
DISCLAIMER OF CONSEQUENTIALAND INCIDENTAL DAMAGES:
THE ORIGINAL PURCHASER OF THE MOTORHOMEAND ANY PERSON
TO WHOM THE MOTORHOME IS TRANSFERRED,AND ANY PERSON
WHO IS AN INTENDED OR UNINTENDED USER OR BENEFICIARY OF
THE MOTORHOME, SHALLNOT BE ENTITLED TO RECOVER FROM
WARRANTOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES
RESULTING FROM ANY DEFECT IN THE MOTORHOME, INCLUDING
BY WAY OF EXAMPLE FUELAND TRANSPORTATION EXPENSES TO
DELIVER THE PRODUCT TO THE SERVICING DEALER, HOTEL ROOMS,
LOST WAGES AND MOISTURE DAMAGE SUCH AS MOLDAND MILDEW.
THE EXCLUSION OF CONSEQUENTIALAND INCIDENTAL DAMAGES
SHALL BE DEEMED INDEPENDENT OF, AND SHALL SURVIVE, ANY
FAILURE OFTHE ESSENTIAL PURPOSE OFANY LIMITED REMEDY. Some
states do not allow the exclusion or limitation of consequential or incidental damages,
so the above exclusions may not apply to you.
LEGAL REMEDIES:
THIS LIMITED WARRANTY DOES NOT “EXTEND TO FUTURE
PERFORMANCE”. ANYACTION TO ENFORCE THIS LIMITED
WARRANTY ORANY IMPLIED WARRANTIES SHALL NOT BE
COMMENCED MORE THAN 90 DAYS AFTER THE EXPIRATION OF THE
ONE YEAR WARRANTY COVERAGE PERIOD DESIGNATED ABOVE.
IFYOU USE YOUR MOTOR HOME FOR COMMERCIALOR BUSINESS
PURPOSES, ANYACTION TO ENFORCE THIS LIMITED WARRANTY
OR ANY IMPLIED WARRANTIES SHALL NOT BE COMMENCED MORE
THAN ONE YEAR AFTER THE EXPIRATION OF THE NINETY (90)
DAY WARRANTY COVERAGE PERIOD DESIGNATED ABOVE. THE
PERFORMANCE OF REPAIRS SHALL NOT SUSPEND THIS LIMITATIONS
PERIOD FROM EXPIRING. Some states do not allow the reduction in the statute of
limitations, so the above reduction in the statute of limitations may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
LARGER PRINT VERSION AVAILABLE WITHIN THE OWNER’S
MANUALAND UPON REQUESTADDRESSED TO YOUR SELLING DEALER
OR WARRANTOR’S WARRANTY DEPARTMENT. 111506

RoadmasteR Limited WaRRanty - 2008
iii
ROADMASTER®CHASSIS LIMITED WARRANTY
WHAT THE PERIOD OF COVERAGE IS:
This Limited Warranty provided by Roadmaster®(“Warrantor”) covers your
Roadmaster Chassis for thirty-six (36) months from the original retail purchase date
or the rst 50,000 miles of use, whichever occurs rst. If you use the Roadmaster
Chassis that your motorhome is mounted upon for any rental, commercial or business
purposes whatsoever, this Limited Warranty covers your new Roadmaster Chassis for
Ninety (90) days from the original retail purchase date or the rst 24,000 miles of use,
whichever occurs rst. A conclusive presumption that the Roadmaster Chassis has been
used for commercial and/or business purposes arises if you have led a federal or state
tax form claiming any business tax benet related to your ownership of the motorhome.
This Limited Warranty applies to all owners, including subsequent owners, of the
Roadmaster Chassis. However, a subsequent owner must submit a warranty transfer
form. A subsequent owner’s warranty coverage period is the remaining balance of the
warranty coverage period the prior owner was entitled to under this Limited Warranty.
Warranty transfer forms can be obtained by contacting the Customer Relations
Department. There is no charge for the transfer.
LIMITATIONAND DISCLAIMER OF IMPLIED WARRANTIES:
IMPLIED WARRANTIES, IFANY, ARISING BY WAY OF STATE LAW,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY
AND ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE TERM OF THIS
LIMITED WARRANTYAND ARE LIMITED IN SCOPE OFCOVERAGE
TO THOSE PORTIONS OF THE MOTORHOME COVERED BY THIS
LIMITED WARRANTY. WARRANTOR DISCLAIMS ALL IMPLIED AND
EXPRESS WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITYAND THE IMPLIED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE, ON COMPONENTS AND APPLIANCES
EXCLUDED FROM COVERAGEAS SET FORTH BELOW. There is no
warranty of any nature made by Warrantor beyond that contained in this Limited
Warranty. No person has authority to enlarge, amend or modify this Limited
Warranty. The dealer is not the Warrantor’s agent but is an independent entity.
Warrantor is not responsible for any undertaking, representation or warranty made by
any dealer or other person beyond those expressly set forth in this Limited Warranty.
Some states do not allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you.
WHAT THE WARRANTY COVERS:
Warrantor’s Limited Warranty covers defects in the manufacture of the
Roadmaster Chassis and defects in materials used to manufacture the Roadmaster
Chassis. “Defect” means the failure of the Roadmaster Chassis and/or the materials
used to assemble the Roadmaster Chassis to conform to Warrantor’s design and
manufacturing specication and tolerances. Also see the section “What the Warranty
Does Not Cover” set out below.
WHAT WE WILLDO TO CORRECT PROBLEMS:
Warrantor’s sole and exclusive obligation is to repair and/or replace, at its option, any
covered defect if: (1) you notify Warrantor or one of its authorized servicing dealers of
the defect within the warranty coverage period and within ve (5) days of discovering
the defect; and (2) you deliver your Roadmaster Chassis to Warrantor or Warrantor’s
authorized servicing dealer at your cost and expense. It is reasonable to expect some
service items to occur during the warranty period. The performance of warranty repairs
shall not extend the original warranty coverage period. Further, any performance of
repairs after the warranty coverage period has expired or any performance of repairs to
component parts and appliances that are excluded from coverage shall be considered
“good will” repairs, which shall not alter the express terms of this limited warranty.
If the repair or replacement remedy fails to successfully cure a defect after Warrantor
received a reasonable opportunity to cure the defect(s), your sole and exclusive remedy
shall be limited to Warrantor paying you the cost of having an independent third party
perform repair(s) to the defect(s). Warrantor may use new and/or remanufactured parts
and/or components of substantially equal quality to complete any repairs. Defects
and/or damage to interior and exterior surfaces, trim, upholstery and other appearance
items may occur at the factory during manufacture, during delivery of the motorhome
to the selling dealer or on the selling dealer’s lot. Normally, any such defect or
damage is detected and corrected at the factory or by the selling dealer during the
inspection process performed by the Warrantor and the selling dealer. If, however, you
discover any such defect or damage when you take delivery of the motorhome, you
must notify your dealer or Warrantor within ve days of the date of purchase to have
repairs performed to the defect at no cost to you as provided by this Limited Warranty.
If either three or more unsuccessful repair attempts have been made to correct any
covered defect that you believe substantially impairs the value, use or safety of your
motorhome, or repairs to any covered defect(s) which you believe substantially impairs
the value, use or safety of your motorhome have taken 30 or more days to complete,
you must, to the extent permitted by law, notify Warrantor directly in writing of the
failure to successfully repair the defect(s) so that Warrantor can become directly
involved in exercising a nal repair attempt for the purpose of performing a successful
repair to the identied defect(s).

RoadmasteR Limited WaRRanty - 2008
iv
HOW TO GET SERVICE:
For warranty service simply contact one of Warrantor’s authorized service centers
for an appointment, then deliver your Roadmaster Chassis (at your expense) to the
service center. If you need assistance in locating an authorized warranty service facility,
contact Warrantor’s Warranty Department (1-877-466-6226). The mailing address is:
91320 Coburg Industrial Way
Coburg, Oregon 97408
In the event the Roadmaster Chassis is inoperative due to malfunction of a warranted
part, Warrantor will pay the cost of having the motorhome towed to the nearest
authorized repair facility provided you notify Warrantor prior to incurring the towing
charges to receive directions to the nearest repair facility. Because Warrantor does not
control the scheduling of service work by its authorized servicing dealers, you may
encounter some delay in scheduling and/or in the completion of the repairs.
WHAT THE WARRANTY DOES NOT COVER:
This Limited Warranty does not cover: modications and alterations to the
Roadmaster Chassis by others; the motorhome that is mounted upon the Roadmaster
Chassis, including by way of example the motorhome manufacturer’s design,
manufacture, assembly and/or installation of the side walls, roof, windows, ooring,
electrical system, plumbing system, LP-Gas system, appliances and slide outs; items
that are working as designed but which you are unhappy with because of the design;
normal wear and usage; routine maintenance including by way of example wheel
alignments; component parts covered by their own manufacturer’s warranty, including
by way of example the engine, radiator, transmission, tires, tubes, batteries, exhaust
system and the emission control systems; and, aking, peeling rusting and chips or
other defects or damage in or to the frame and frame cross members caused by rocks
or other road hazards and the environment including airborne pollutants and salt.
Component part manufacturers issue limited warranties covering those portions of the
Roadmaster Chassis not covered by the Limited Warranty issued by Warrantor. To learn
more on what specic component parts are excluded from the Limited Warranty issued
by Warrantor please contact your selling dealership or Warrantor directly or review the
warranty packet inside the Motorhome.
EVENTS DISCHARGING WARRANTOR FROM OBLIGATION UNDER
WARRANTY:
Misuse or neglect, accidents, unauthorized alteration, failure to provide reasonable
and necessary maintenance (see Owner’s Manual), damage caused by off road use,
collision, re, theft, vandalism, explosions, overloading in excess of rated capacities,
and odometer tampering shall discharge Warrantor from any express or implied
warranty obligation to repair any resulting defect.
DISCLAIMER OF CONSEQUENTIALAND INCIDENTAL DAMAGES:
THE ORIGINAL PURCHASER OF THE ROADMASTER CHASSIS
AND ANY PERSON TO WHOM THE ROADMASTER CHASSIS IS
TRANSFERRED, AND ANY PERSON WHO IS AN INTENDED OR
UNINTENDED USER OR BENEFICIARY OF THE ROADMASTER CHASSIS,
SHALL NOT BE ENTITLED TO RECOVER FROM WARRANTOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES RESULTING FROM
ANY DEFECT IN THE ROADMASTER CHASSIS, INCLUDING BY WAY
OF EXAMPLE FUELAND TRANSPORTATION EXPENSES TO DELIVER
THE PRODUCT TO THE SERVICING DEALER, HOTEL ROOMS, LOST
WAGES AND WATER DAMAGE. THE EXCLUSION OFCONSEQUENTIAL
AND INCIDENTAL DAMAGES SHALL BE DEEMED INDEPENDENT OF,
AND SHALL SURVIVE, ANY FAILURE OF THE ESSENTIAL PURPOSE OF
ANY LIMITED REMEDY. Some states do not allow the exclusion or limitation of
consequential or incidental damages, so the above exclusions may not apply to you.
LEGAL REMEDIES:
THIS LIMITED WARRANTY DOES NOT “EXTEND TO FUTURE
PERFORMANCE.” ANYACTION TO ENFORCE THIS LIMITED
WARRANTY ORANY IMPLIED WARRANTIES SHALL NOT BE
COMMENCED MORE THAN NINETY (90) DAYS AFTER THE EXPIRATION
OF THE THIRTY-SIX (36) MONTH WARRANTY COVERAGE PERIOD
DESIGNATEDABOVE. IFYOU USE YOUR MOTORHOME FOR
COMMERCIAL OR BUSINESS PURPOSES, ANYACTION TO ENFORCE
THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTIES SHALL NOT
BE COMMENCED MORE THAN ONE YEAR AFTER THE EXPIRATION OF
THE NINETY (90) DAY WARRANTY COVERAGE PERIOD DESIGNATED
ABOVE. THE PERFORMANCE OF REPAIRS SHALL NOT SUSPEND
THIS LIMITATIONS PERIOD FROM EXPIRING. Some states do not allow
the reduction in the statute of limitations, so the above reduction in the statute of
limitations may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
LARGER PRINT VERSION AVAILABLE WITHIN THE OWNERS MANUAL
AND UPON REQUESTADDRESSED TO YOUR SELLING DEALER OR
WARRANTOR’S WARRANTY DEPARTMENT.
012507

2008 LaPalma XL
SECTION 1 - GENERAL INFORMATION ............................ 3
SECTION 2 - DRIVING & SAFETY .................................. 13
SECTION 3 - EXTERIOR & INTERIOR CARE ................... 49
SECTION 4 - APPLIANCES............................................ 75
SECTION 5 - EQUIPMENT............................................. 99
SECTION 6 - WATER SYSTEMS ................................... 125
SECTION 7 - LP-GAS SYSTEMS ................................... 141
SECTION 8 - ELECTRICAL SYSTEMS – HOUSE ............ 151
SECTION 9 - ELECTRICAL SYSTEMS – CHASSIS .......... 169
SECTION 10 - CHASSIS INFORMATION ...................... 185
INDEX ......................................................................223

The information contained in this document is intended to reect standard and optional
equipment included in a typically equipped model at the time of delivery to the initial retail
owner. Your actual unit may vary from this document as a result of optional equipment that
is not generally offered on this model. In the case that you are not the initial retail owner
of the unit, this document will not reect modications that may have been performed by
previous owners.
©Copyright Monaco Coach Corporation. All rights reserved. All other trademarks or
registered trademarks are property of their respective holders. Brand name products of
other companies mentioned in this manual are not endorsed by the manufacturer of the
motorhome.
Product information and specications are shown herein as of the time of printing.
The motorhome manufacturer reserves the right to change product specications,
designs and standard equipment without notice and without incurring obligation.
07124 ATG

2008 LaPalma XL
GENERAL INFORMATION — SECTION 1
Warranty InformatIon fIle ............................................................. 4
reportIng Safety DefectS................................................................ 4
Safety termS....................................................................................... 4
gloSSary of termS ............................................................................ 5
oWner’S manual Survey: lapalma Xl DIeSel 2008....................... 9
lImIteD Warranty tranSfer applIcatIon/
change of oWner InformatIon...................................................... 11

GENERAL INFORMATION — 1
42008 LAPALMA XL
Warranty InformatIon fIle
In addition to this Owner’s Manual you will
nd a Warranty Information File in your unit.
This le contains valuable documents about your
motorhome systems and equipment. Many of the
component manufacturer warranty registration
cards can be found in the box. They will need to
be lled out and mailed. Be sure you read and
understand all the information in this le to help
you safely operate, maintain and troubleshoot
those items.
Additional Information:
Changes, additions and supplemental
information in the form of Manual Addendums
and “Tech Tips” can be obtained by visiting our
Web Site at www.monaco-online.com. Select
one of the products from the product lineup. Go
to the Service menu. A submenu will appear.
It may also be helpful to browse the “Tech
Tips” menu for the other product lines. The tips
may not completely apply to your particular
model, but information contained therein can be
useful.
reportIng Safety DefectS
If you believe that your motorhome has a
defect which could cause a crash or could
cause injury or death, you should immediately
inform the National Highway Trafc Safety
Administration (NHTSA) in addition to
notifying Monaco Coach. If NHTSA receives
similar complaints, it may open an investigation,
and if it nds that a safety defect exists in a
group of motorhomes, it may order a recall or
remedy campaign. However, NHTSA cannot
become involved in individual problems between
you, your dealer or Monaco Coach. To contact
NHTSA you may call the Auto Safety Hot line
toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153) (or 1-202-366-0123 in the Washington
D.C. area), visit their websites at www.nhtsa.
gov or www.safercar.gov, or write to:
NHTSA
U.S. Department of Transportation
400 Seventh Street S.W.
Washington, DC 20590
Safety termS
Many of the safety terms are personal safety
instructions. Denitions for the terms are listed
below. It is important to thoroughly read and
understand the safety instructions displayed
throughout the manual. Failure to comply with
specic instructions may result in personal injury
or death. Many instructions are required by
National Safety Associations.
WARNING:
Warnings contain information regarding
personal safety and/or pertaining to potential
extensive or permanent damage to the
motorhome or its components by means of
hazards or improper use.
CAUTION:
Cautions pertain to potential damage to the
motorhome and/or its components.
POISON:
A warning or caution pertaining to safety
and/or use of a poisonous substance or
harmful chemical.
NOTE:
Information and reminders concerning
proper operation of the motorhome and/or its
components.
INSPECTION:
Inspection of the motorhome and/or
its components is required. Additional
instruction may follow.
LUBE:
Lubrication, or addition of a lubricant
product, to the motorhome and/or a specied
component or part is required. Additional
instruction may follow.
ASSEMBLE or REPAIR:
Assembly, disassembly or installation of
a component or part, and/or repair to the
motorhome may be required. Assistance of
Technical Support or Technician may be
necessary.
INFORMATION:
References to additional information
regarding operation of the motorhome and/or
its components found in additional sources,
other than the Owner’s Manual. Also refers
to the WARRANTY INFORMATION FILE,
found within the Warranty Information Box
in the motorhome.

5
2008 LAPALMA XL
GENERAL INFORMATION — 1
TIP:
Tips contain information, helpful hints
and/or suggestion for ease of operation of the
motorhome or its components.
gloSSary of termS
AC Electricity - Alternating current also
known as household power.
Air Compressor - Pumps air to and builds
pressure in an air system.
Air Dryer - Cools, lters and dries the air
delivered by compressor.
Air Governor - Controls the operation of
the air compressor by constantly monitoring
air pressure in the supply tank of the air
system. The air governor initiates the unload
cycle when the cut-out pressure is reached.
The air governor also controls the air dryer
by sending a signal (at the beginning of the
compressor unload cycle) to the control port
of the air dryer, initiating the purge cycle.
When this air signal is removed by the
governor (at the beginning of the compressor
load cycle) the purge valve closes and the
drying cycle begins.
Alternating Current (AC) - A current
that varies periodically in magnitude
and direction. A battery does not deliver
alternating current. Also referred to as
shore power, utility power, inverter power,
generator power, etc.
Ampere (Amp) - The unit of measure
of electron ow rate of current through a
circuit.
Ampere-hour (Amp-hr. AH) - A unit of
measure for a battery electrical storage
capacity, obtained by multiplying the current
in amperes by the time in hours of discharge.
Example: A battery which delivers 5
amperes for 20 hours, delivers 5 amperes
times 20 hours, or 100 Amp-Hr. of capacity.
ANSI - American National Standards
Institute.
ASTM - American Society for Testing and
Materials.
Black Water - Term associated with the
sewage holding tank. The toilet drains
directly into this tank.
CCA - Cold Cranking Amperage is the
amount of current a battery can deliver for
30 seconds at 0° F without dropping below a
specied voltage, usually 10.5 Volts DC.
Chassis Battery - Powers chassis 12 Volt
accessories and starts engine.
Circuit - An electric circuit is the path of
an electric current. A closed circuit has a
complete path. An open circuit has a broken
or disconnected path.
City Water - A term associated with
the water supply that you hook-up to at
campgrounds. It is called city water because
water is pulled from a central source (like in
a city) and not the fresh water tank.
Compressor Load Cycle - The time during
which the compressor is building pressure in
an air system.
Compressor Unload Cycle - The time
during which the air compressor is idling
and is not building air pressure in an air
system.
Curbside - This refers to the side of the
motorhome which faces the curb when it
is parked. Often called the door side or
passenger side.
Current - The rate of ow of electricity
or the movement rate of electrons along a
conductor. It is comparable to the ow of
a stream of water. The unit of measure for
current is ampere.
Cut-In Pressure - The pressure level in the
air system supply tank which triggers the
compressor load cycle.
Cut-Out Pressure - The pressure level in
the air system supply tank which triggers the
compressor unload cycle.
Cycle - In a battery, one discharge plus one
recharge equals one cycle.

GENERAL INFORMATION — 1
62008 LAPALMA XL
Desiccant - A granular substance that has a
high afnity for water and is used to retain
moisture from the air stream owing through
the air dryer cartridge.
Direct Current (DC) - Power that is
stored in a battery bank or supplied by
photovoltaics, alternator, chargers and DC
generators. Direct current is also known as
battery power. Current only ows one way.
Drain Trap - This is a curve that is in all
drains. Water is trapped in the curve and this
creates a barrier so tank odors cannot escape
through the drain.
Dry Camping - Camping in the motorhome
when there is no city water hook-up or shore
power. In other words, using only the water
and power that is in the motorhome and not
from another source.
Drying Cycle - The time during which the
air dryer cools, lters and removes moisture
from the air delivered by the air compressor.
The drying cycle begins and ends the same
as the compressor load cycle.
Dump Station - A site where the waste
(grey) and sewage (black) tanks can be
drained. In most states it is illegal to drain
waste tanks anywhere other than at a dump
station.
Dump Valve - Another name for the
T-handle valve used to drain the sewage
(black) and waste (grey) tanks.
Escape (Egress) Window - The formal
name for the emergency window located in
the rear of the motorhome. Egress windows
can be easily identied by red handles.
Full Hook-Up Site - A campground that has
city water, shore power and sewer hook-ups
or connections available.
Grey Water - Term associated with the
waste water holding tank. Water from the
sink drains, the shower and the washer-dryer
(if equipped) go into this tank.
House Battery - Powers 12 Volt DC lights
and accessories inside motorhome.
LED (Light Emitting Diode) - Indicator
light.
Low Point Drain - The lowest point in the
plumbing. These drains must be closed when
lling the water tank.
OEM - Term for Original Equipment
Manufacturer.
OHM - A unit for measuring electrical
resistances.
Ohm’s Law - Expresses the relationship
between Volt (E), amperes (I) in an
electrical circuit with resistance (R). It can
be expressed as follows: E = IR. If any two
of the three values are known, the third
value can be calculated by using the above
formula.
Potentiometer - A device for measuring
an unknown potential difference or
electromotive force.
Pounds Per Square Inch Gauge (psig) -
Pressure measured with respect to that of the
atmosphere. This is a pressure gauge reading
in which the gauge is adjusted to read zero at
the surrounding atmospheric pressure. It is
commonly called gauge pressure.
Purge - The initial blast of air
(decompression) from the air dryer purge
valve at the beginning of the air compressor.
Purge Cycle - The time during which the air
dryer is undergoing purge and regeneration.
This cycle starts at the beginning of the
compressor unload cycle and normally ends
well before the beginning of the compressor
load cycle.
Regeneration - The mild backow of air
through the air dryer and out the purge valve
that begins immediately after the purge
and lasts normally 10 to 15 seconds. This
backow of air, from the air system and
through the air dryer, removes moisture from
the desiccant cartridge and prepares the air
dryer for the next compressor load cycle.
Roadside - This refers to the side of the
motorhome which faces the road when it is
parked. Often called the off-door side or the
driver side.

7
2008 LAPALMA XL
GENERAL INFORMATION — 1
SCA - Term for Supplemental Coolant
Additive. Chemical added to coolant for
diesel engines to help prevent cylinder liner
pitting and internal corrosion.
Shore Line - This is the electrical cord
which runs from the motorhome to the
campground 120/240 Volt AC electrical
supply.
Stinger - An arm attachment on a tow truck
that is used to lift the motorhome slightly for
towing.
VIM - Vehicle Interface Module.
Volt - The unit of measure for electric
potential.
Watt - The unit for measuring electrical
power, i.e. the rate of doing work, in moving
electrons by or against an electric potential.
Wet Cell Battery - A type of battery that
uses liquid as an electrolyte. This type
of battery requires periodic maintenance
to clean the connections and check the
electrolyte level.

OWNER’S MANUAL SURVEY: LaPalma XL 2008
Your suggestions are very important to us and we are continually
striving to improve the quality of our manuals. After becoming familiar
with your new recreational vehicle and the accompanying manual,
please take the time to answer the following questions. When you are
nished please return the survey via mail to our Technical Publications
Department, or you may fax the survey to: [phone] Attention:
Technical Publications Department. Feel free to attach an additional
page if you desire.
1. Is this your rst recreational vehicle? YES / NO (circle one)
2. If no, what was your previous recreational vehicle brand/model?______
______________________________________________________________
______________________________________________________________
3. Was the overall appearance and lay-out of this manual what you
expected to see in your new recreational vehicle?
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
4. Was the information within this manual helpful in acquainting you with
your new recreational vehicle? If not please address any area(s) we need
to expand or improve on.
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
5. Were the operating instructions clearly written, and were you able to
follow the steps without any difculty?
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
6. Is there any additional information you would like to see incorporated
within the owner’s manual?
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
NAME: ________________________________________________
PHONE: (_____________)________________________________
ADDRESS:__________________________________________________
___________________________________________________________
___________________________________________________________
SERIAL # ____________________________________________________
TEAR OFF PAGE AND MAIL TO:
TECHNICAL PUBLICATIONS PLT. 17
MONACO COACH CORPORATION
91320 COBURG INDUSTRIAL WAY
COBURG, OR 97408

LIMITED WARRANTY TRANSFER APPLICATION/CHANGE OF OWNER INFORMATION
Mail to:
Monaco Coach Corporation
Warranty Transfer
91320 Coburg Industrial Way
Coburg, OR 97408
Please read terms and representations below before signing.
Submitted By:
Name:
Address:
City: State: Zip:
Phone: ( )
Limited Warranty Transfer
Address Change
By your signature(s) on face side of this form, and in order to induce
Monaco Coach Corporation to transfer its Limited Warranty, you represent
the following:
1. That you have received and read a copy of the Limited Warranty.
2. You understand that the unit is to be used only for family camping and cross
country travel on improved roads.
3. All information provided by you on face side of this form is true and correct.
4. You understand that you are purchasing a pre-owned recreational vehicle
and Monaco Coach Corporation does not make any representation as to its
present condition.
TEAR OFF PAGE AND MAIL TO:
WARRANTYTRANSFER, MONACO COACH CORPORATION,
91320 COBURG INDUSTRIAL WAY
COBURG, OR 97408
A. Current Owner Information:
First Name Initial Last Name
–
Vehicle Identication Number Unit # (15 digits) (6 digits) Model/Year
B. New Owner Information, Transfer Coverage To:
First Name Initial Last Name
( )
Phone Number Street Address City State Zip
Date of Transfer (If Applicable) Odometer Reading at Transfer (If Applicable)
C. Signatures:
(New) Owner’s Signature Date Selling Dealer’s Signature (If Applicable) Date
Terms & Representations

DrIvIng & Safety.............................................. 14
Inspections ..................................................... 14
Familiarize Yourself.......................................... 14
Mirror Adjust................................................... 14
Safety Seat Belts............................................. 15
DrIvIng tIpS ...................................................... 16
trIp preparatIon ............................................. 19
hItch .................................................................. 20
Using the Rear Receiver .................................. 20
Tow Plug Connection....................................... 22
rear vISIon SyStem......................................... 22
Features.......................................................... 23
BackIng up a motorhome............................... 23
Set-up proceDureS.......................................... 24
Dry campIng ..................................................... 25
BreakIng camp ................................................. 26
emergency roaDSIDe proceDureS .............. 28
In Case of Flat Tire .......................................... 28
Dead Chassis Battery...................................... 28
toWIng proceDureS ........................................ 30
tIreS ................................................................... 30
Importance of Air Pressure.............................. 31
Tire Pressure Inflation Guideline....................... 31
Tire Chart - Goodyear...................................... 32
Inspecting & Pressure ..................................... 33
Air Pressure Checklist ..................................... 34
Tire Support When Leveling ............................ 34
Tire Vibration................................................... 34
Tire Rotation ................................................... 35
Tread .............................................................. 35
Storage of Tires - Long Term ........................... 35
Wheel mountIng .............................................. 35
WeIghIng the motorhome..............................36
Weight Terms.................................................. 36
Weight Label................................................... 38
Four Corner Weighing (Example) ..................... 39
Cargo Carrying Capacity Flowchart ................. 41
Weighing Procedure Worksheet ....................... 42
Weight Record Sheet....................................... 43
Smoke Detector............................................... 44
Operation ........................................................ 44
Testing............................................................ 44
Maintenance ................................................... 44
Troubleshooting .............................................. 44
carBon monoXIDe Detector .......................... 44
Operation ........................................................ 45
Alarm.............................................................. 46
Testing............................................................ 46
Cleaning & Maintenance.................................. 46
fIre eXtInguISher ............................................ 47
eScape (egreSS) WInDoW ...............................48
2008 LaPalma XL
Driving & Safety — Section 2

DRIVING & SAFETY — 2
14 2008 LAPALMA XL
DrIvIng & Safety
Section Two contains information on driving
tips, emergency situations, towing, safety
devices, weighing the motorhome and tires.
NOTE:
The motorhome has an electronic
data recording device that may record
information about direction, road speed,
engine speed, brake application, steering
attitude or other vehicle operating data.
Data recording devices can be present
in engines, transmissions, ABS (Antilock
Brake Systems) or other systems
affiliated with operation of the vehicle.
Information from data recording devices
can be examined in case of an accident.
Contact the component manufacturer to
learn more about these devices.
Inspections
Differences between a passenger automobile
and a motorhome are signicant. Always be
aware of these differences when traveling.
The key to safely operating a motorhome is
inspection. Undetected problems could cause
problems on the road and may result in lost time
and increased repair costs. Several states require
a special license endorsement and motorhome
inspection prior to registration. Know and
observe the laws of the states in which you will
be traveling. Laws may vary from state to state.
A systematic inspection conducted prior to
moving the motorhome can help ensure nothing
is overlooked and will assist in familiarizing the
owner with the motorhome. Prior to moving the
motorhome perform a general inspection.
Examine the condition of the motorhome and
the surrounding area. Look high and low when
walking around the motorhome.
Familiarize Yourself
Because the location of the driver’s seat in
the motorhome is higher and farther to the left
than most vehicles, a different perspective of
the roadway is created. Rely on the outside
mirrors to line up with the center of the road
and to check conditions behind the motorhome.
The dashboard may include more gauges and
controls than are normally found in passenger
automobiles. Become familiar with these gauges
and their indications before starting out.
Mirror Adjust
Adjust the mirrors prior to
starting out. Have an assistant
help to simplify the mirror
adjustment process.
MirrorAdjusting:
Tools needed: Allen
wrench, at blade
screwdriver and socket
wrench.
Adjust the driver seat to the travel
position.
Remove plug at the bottom of the arm.



Use the socket wrench to loosen the bolt
located at the base of the arm. (See point
A on the drawing.)
Adjust the mirror for a clear side view of
the coach.
Tighten the bolt once the proper
adjustment is made.
Reinstall the plug.
To adjust the “head” of the mirror, loosen
the set screws located below the mirror
shown as point B. Adjust the head of the
mirror to the left or right.
Manually adjust the bottom section of the
mirror.
Tighten set screws once the proper
adjustment is made.
Repeat procedure for passenger side
mirror.
NOTE:
Use the mirror adjust switch located on
the driver’s console to fine tune upper
mirror.








031210e
080378
Mirror Adjust
Switch on
Driver’s
Console

15
2008 LAPALMA XL
DRIVING & SAFETY — 2
Safety Seat Belts
All occupants must be furnished with and
use seat belts while the motorhome is moving.
The driver’s seat, and all other seats designed
to carry passengers while the motorhome is in
motion, are equipped with safety seat belts. DO
NOT occupy beds or seats that are not equipped
with a safety belt while the motorhome is in
motion. The driver’s seat must be locked in the
forward facing position while motorhome is in
motion. DO NOT use a seat belt on more than
one person.
To fasten the seat belt, pull the belt out of the
retractors and insert the tab into the buckle; a
click will sound when the tab locks into the
buckle. Seat belt lengths automatically adjust to
your size and sitting position. DO NOT route
belts over armrest or under arm.
WARNING:
Safety belts are supplied at affixed
seating positions. DO NOT occupy seats
not equipped with safety belts while the
motorhome is in motion. Seat belts must
only be used on permanently mounted
seats. DO NOT use a single seat belt on
more than one person. Pilot and Co-
pilot seats must be locked in a forward
facing position with seat belts fastened
while the motorhome is in motion. DO
NOT rotate the seat while in transit.
WARNING:
Only forward facing booth dinette seats
equipped with seat belts are designed
for occupancy while the motorhome is in
motion.
GENERAL CHILD SEAT USE INFORMATION *
Always refer to the child seat and vehicle manufacturers’ instructions for proper use and
installation instructions.
Age/Weight Seat Type/Seat Position Usage Tips
Infants
Birth to at least 1 year and at
least 20 lbs. Infant-Only Seat/rear-facing (or )
Convertible Seat/used rear
facing
▪ Never use in a front seat where an air bag
is present.
▪ Tightly install child seat in rear seat,
facing the rear.
▪ Child seat should recline at approximately
a 45° angle.
▪ Harness straps/slots at or below
shoulder level (lower set of slots for most
convertible child safety seats).
▪ Harness straps snug on child; harness
clip at armpit level.
Less than 1 year/20 to 35 lbs. Convertible Seat/used
rear facing (select one
recommended for heavier
infants)
Children may remain in their
rear-facing seats as long as they
haven’t exceeded the height or
weight requirements.
Seats should be secured to the
vehicle by the safety belts or by
the LATCH system.
Preschoolers/Toddlers
1 to 4 years/at least 20 lbs. to
approx. 40 lbs.
Children may remain in their
forward-facing seats as long as
they haven’t exceeded the height
or weight requirements.
Convertible Seat/forward-
facing or forward facing only
(or)
Combination Seat with
Harness
Seats should be secured to the
vehicle by the safety belts or by
the LATCH system.
▪ Tightly install child seat, facing forward.
▪ Harness straps/slots at or above child’s
shoulders (usually top set of slots for
convertible child safety seats).
▪ Harness straps snug on child; harness
clip at armpit level.
Young Children
4 to at least 8 years/unless
they are 4’ 9” (57”) tall. Belt-Positioning Booster No back or High Back Belt-
Positioning Booster.
NEVER use with lap-only belts
— belt-positioning boosters
are always used with lap and
shoulder belts.
▪ Booster used with adult lap and shoulder
belt in rear seat.
▪ Shoulder belt should rest snugly across
chest, rests on shoulder; and should
NEVER be placed under the arm or
behind the back.
▪ Lap-belt should rest low, across the
lap/upper thigh area — not across the
stomach.
Stay informed about child safety seat recalls; be sure to ll out the registration card that comes with new child seats.
The motorhome manufacturer is not the author of this chart. The information in this chart is reprinted from the National
Highway Trafc Safety Administration’s web site. Visit NHTSA’s website at www.nhtsa.gov for the most recent and up to
date information.

DRIVING & SAFETY — 2
16 2008 LAPALMA XL
The child safety seat can be positioned in two
places in the motorhome: the front passenger
(co-pilot) seat and forward facing permanently
mounted booth dinette seat.
WARNING:
DO NOT transport children unrestrained.
Infants must be placed in approved
safety seats - small children must be
restrained in child safety seats. DO NOT
use a single seat belt on more than one
child. Failure to comply with these rules
can lead to injury or death.
NOTE:
Individual states and Canadian
provinces may have laws that can exceed
the requirements as described in this
section. It is your responsibility to know
and comply with the laws in the state or
province in which you travel.
WARNING:
Because many styles of safety and booster
seats are available, refer to the safety
seat manufacturer’s manual forproper
installation and how to properly install
and secure the safety or booster seat.
NOTE:
Use of a safety or booster seat in the
front seat may be prohibited in some
states and Canadian provinces.
Seat Belt Care:
Keep the belt clean and dry. Clean with mild
soap and lukewarm water. DO NOT clean seat
belts with bleach, dye or abrasive cleansers
that may weaken the belt material. Periodically
inspect belts for cuts, frays or loose parts, and
replace damaged parts. DO NOT disassemble
or modify the system. Replace the seat belt
assembly after a severe impact, even when
damage is not obvious.
DrIvIng tIpS
The motorhome is a complex
vehicle that requires increased
driving awareness because of its
size and various components.
Due to the motorhome length
the turning radius will be
much wider than that of a
standard automobile. Always pay close attention
to the perimeter of the motorhome including
front, sides, rear, roof and undercarriage. Ensure
the surrounding area is clear of obstacles. Utilize
the driving mirrors to observe trafc conditions
as well as the motorhome exterior including
tires, bay doors, blind spots, etc. Use a push-pull
method of steering, with both hands parallel on
the steering wheel.
The motorhome is also heavier than an
automobile and has a higher center of gravity.
These factors affect the reaction time of the
motorhome. Swerving and sharp turning,
especially performed at high speeds, could result
in loss of control of the motorhome. Keep the
size of the motorhome in mind and drive with
extra caution to avoid situations which might
require quick momentum changes. Increase
reaction time by paying attention to trafc and
road conditions 12 to 15 seconds ahead of the
motorhome’s position.
The motorhome will travel safely and
comfortably at highway speed limits. However,
it takes more time to reach highway speed.
When passing another vehicle, allow extra time
and space to complete the pass due to the added
length of the motorhome.
When descending a long hill, manually shift
to a lower gear and begin the descent at a slow
speed. DO NOT allow the motorhome to gain
momentum before trying to slow down. Use the
exhaust brake in conjunction with the service
brakes to help maintain a slow, safe descent.
The transmission and engine will help control
downhill speed and can extend the service life of
the brake lining.
Distance required to stop the motorhome is
greater than an automobile. Practice stopping
away from trafc to get the feel of distance
required to stop the motorhome.
Adjusting to road, weather and terrain
conditions is necessary to keep the motorhome
under control. Pay attention to road signs
that advise of local road hazards and driving
conditions. DO NOT operate the motorhome
when road, weather and terrain conditions
seem unsafe.
Keep the windshield clear of humidity in the
form of water or ice. Start the motorhome
and turn on the dash defrost and the overhead
blowers to help remove moisture from inside
the windshield. It may also be necessary to
use a clean cloth to wipe away moisture. Keep
windshield wipers in good working order at all
times. DO NOT operate the motorhome if the
windshield is not clear.
downhill.eps
