Monaco Camelot 2007 User manual

2007 MONACO LIMITED WARRANTY
i
MONACO MOTORHOME LIMITED WARRANTY
WHAT THE PERIOD OF COVERAGE IS:
This Limited Warranty provided by Monaco®(“Warrantor”) covers those components,
assemblies and systems of your new motorhome not excluded under the section “What
is Not Covered” and when sold by an authorized dealer, for twelve (12) months from
the original retail purchase date or the rst 24,000 miles of use, whichever occurs rst.
However, this Limited Warranty provided by Warrantor covers the steel or aluminum
frame structure, only, of the sidewalls (excluding slide outs), roof, and rear and front
walls for sixty (60) months from the original retail purchase date or the rst 50,000
miles of use, whichever occurs rst.
If you use your motorhome for any rental, commercial or business purposes
whatsoever, the Limited Warranty provided by Warrantor covers your new motorhome
when sold by an authorized dealer for ninety (90) days from the original retail purchase
date or the rst 24,000 miles of use, whichever occurs rst. In addition, the Limited
Warranty provided by Warrantor covers the steel or aluminum frame structure, only,
of the sidewalls (excluding slide outs), roof, and rear and front walls for twelve (12)
months from the original retail purchase date or the rst 24,000 miles of use, whichever
occurs rst. A conclusive presumption that your motorhome has been used for
commercial and/or business purposes arises if you have led a federal or state tax form
claiming any business tax benet related to your ownership of the motorhome.
The above Limited Warranty coverage applies to all owners, including subsequent
owners, of the motorhome. However, a subsequent owner must submit a warranty transfer
form by ling the form through an authorized Monaco dealer. A subsequent owner’s
warranty coverage period is the remaining balance of the warranty coverage period the prior
owner was entitled to under this Limited Warranty. Warranty transfer forms can be obtained
by contacting the Customer Relations Department. There is no charge for the transfer.
LIMITATION AND DISCLAIMER OF IMPLIED WARRANTIES:
IMPLIED WARRANTIES, IF ANY, ARISING BY WAY OF STATE LAW,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND ANY
IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE TERM OF THIS LIMITED WARRANTY
AND ARE LIMITED IN SCOPE OF COVERAGE TO THOSE PORTIONS
OF THE MOTORHOME COVERED BY THIS LIMITED WARRANTY.
WARRANTOR DISCLAIMS ALL IMPLIED AND EXPRESS WARRANTIES,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND
THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE,
ON COMPONENTS AND APPLIANCES EXCLUDED FROM COVERAGE
AS SET FORTH BELOW. There is no warranty of any nature made by Warrantor
beyond that contained in this Limited Warranty. No person has authority to enlarge,
amend or modify this Limited Warranty. The dealer is not the Warrantor’s agent but is
an independent entity. Warrantor is not responsible for any undertaking, representation
or warranty made by any dealer or other person beyond those expressly set forth in
this Limited Warranty. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
WHAT THE WARRANTY COVERS:
Warrantor’s Limited Warranty covers defects in the manufacture of your motorhome
and defects in materials used to manufacture your motorhome. “Defect” means the
failure of the motorhome and/or the materials used to assemble the motorhome to
conform to Warrantor’s design and manufacturing specication and tolerances. Also
see the section “What the Warranty Does Not Cover” set out below.
WHAT WE WILL DO TO CORRECT PROBLEMS:
Warrantor’s sole and exclusive obligation is to repair and/or replace, at its option, any
covered defect if: (1) you notify Warrantor or one of its authorized servicing dealers of
the defect within the warranty coverage period and within ve (5) days of discovering
the defect; and (2) you deliver your Motorhome to Warrantor or Warrantor’s authorized
servicing dealer at your cost and expense. It is reasonable to expect some service items
to occur during the warranty period. The performance of warranty repairs shall not
extend the original warranty coverage period. Further, any performance of repairs after
the warranty coverage period has expired or any performance of repairs to component
parts and appliances that are excluded from coverage shall be considered “good will”
repairs, which shall not alter the express terms of this limited warranty. If the repair
or replacement remedy fails to successfully cure a defect after Warrantor received a
reasonable opportunity to cure the defect(s), your sole and exclusive remedy shall be
limited to Warrantor paying you the cost of having an independent third party perform
repair(s) to the defect(s).
Warrantor may use new and/or remanufactured parts and/or components of
substantially equal quality to complete any repair.
Defects and/or damage to interior and exterior surfaces, trim, upholstery and other
appearance items may occur at the factory during manufacture, during delivery of
the motorhome to the selling dealer or on the selling dealer’s lot. Normally, any such
defect or damage is detected and corrected at the factory or by the selling dealer during
the inspection process performed by the Warrantor and the selling dealer. If, however,
you discover any such defect or damage when you take delivery of the motorhome, you
must notify your dealer or Warrantor within ve days of the date of purchase to have
repairs performed to the defect at no cost to you as provided by this Limited Warranty.
If either three or more unsuccessful repair attempts have been made to correct any
covered defect that you believe substantially impairs the value, use or safety of your
motorhome, or repairs to any covered defect(s) which you believe substantially impairs
the value, use or safety of your motorhome have taken 30 or more days to complete,
you must, to the extent permitted by law, notify Warrantor directly in writing of the
failure to successfully repair the defect(s) so that Warrantor can become directly
involved in exercising a nal repair attempt for the purpose of performing a successful
repair to the identied defect(s).

2007 MONACO LIMITED WARRANTY
ii
HOW TO GET SERVICE:
The “Acknowledgement of Receipt of Warranty/Production Information” form must
be returned to Warrantor promptly upon purchase to assure proper part replacement
and repair of your motorhome. Failure to return the “Acknowledgement of Receipt
of Warranty/Production Information” form will not affect your rights under the
Limited Warranty so long as you can furnish proof of purchase. For warranty service
simply contact one of Warrantor’s authorized service centers for an appointment, then
deliver your motorhome (at your expense) to the service center. If you need assistance
in locating an authorized warranty service facility, contact Warrantor’s Warranty
Department (1-877-466-6226). The mailing address is:
91320 Coburg Industrial Way
Coburg, Oregon 97408
In the event the motorhome is inoperative due to malfunction of a warranted part,
Warrantor will pay the cost of having the motorhome towed to the nearest authorized
repair facility provided you notify Warrantor prior to incurring the towing charges to
receive directions to the nearest repair facility.
Because Warrantor does not control the scheduling of service work by its authorized
servicing dealers, you may encounter some delay in scheduling and/or in the
completion of the repairs.
WHAT THE WARRANTY DOES NOT COVER:
This Limited Warranty does not cover: any motorhome sold or registered outside of
the United States or Canada; items which are added or changed after the motorhome
leaves Warrantor’s possession; items that are working as designed but which you
are unhappy with because of the design; normal wear and usage, such as fading or
discoloration of fabrics, or the effects of moisture inside the motorhome; defacing,
scratching, dents and chips on any surface or fabric of the motorhome, not caused by
Warrantor; owner maintenance, including by way of example wheel alignments and
resealing exterior sealant areas; the automotive chassis and power train, including, by
way of example the engine, drivetrain, steering and handling, braking, wheel balance,
mufer, tires, tubes, batteries and gauges; appliances and components covered by
their own manufacturer’s warranty including, by way of example the microwave,
refrigerator, ice maker, stove, oven, generator, roof air conditioners, hydraulic jacks,
VCR, television(s), water heater, furnace, stereo, radio, compact disc player, washer,
dryer, inverter and cellular phone; or aking, peeling and chips or other defects or
damage in or to the exterior or nish caused by rocks or other road hazards, the
environment including airborne pollutants, salt, tree sap and hail. Component part
and appliance manufacturers issue limited warranties covering those portions of the
motorhome not covered by the Limited Warranty issued by Warrantor. To learn more
on what specic component parts and appliances are excluded from the Limited
Warranty issued by Warrantor please contact your selling dealership or Warrantor
directly or review the warranty packet inside the Motorhome.
EVENTS DISCHARGING WARRANTOR FROM OBLIGATION UNDER
WARRANTY:
Misuse or neglect, accidents, unauthorized alteration, failure to provide reasonable
and necessary maintenance (see Owner’s Manual), damage caused by off road use,
collision, re, theft, vandalism, explosions, overloading in excess of rated capacities,
and odometer tampering shall discharge Warrantor from any express or implied
warranty obligation to repair any resulting defect.
DISCLAIMER OF CONSEQUENTIAL AND INCIDENTAL DAMAGES:
THE ORIGINAL PURCHASER OF THE MOTORHOME AND ANY PERSON
TO WHOM THE MOTORHOME IS TRANSFERRED, AND ANY PERSON
WHO IS AN INTENDED OR UNINTENDED USER OR BENEFICIARY OF
THE MOTORHOME, SHALL NOT BE ENTITLED TO RECOVER FROM
WARRANTOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES
RESULTING FROM ANY DEFECT IN THE MOTORHOME, INCLUDING BY
WAY OF EXAMPLE FUEL AND TRANSPORTATION EXPENSES TO DELIVER
THE PRODUCT TO THE SERVICING DEALER, HOTEL ROOMS, LOST
WAGES AND MOISTURE DAMAGE SUCH AS MOLD AND MILDEW. THE
EXCLUSION OF CONSEQUENTIALAND INCIDENTAL DAMAGES SHALL
BE DEEMED INDEPENDENT OF, AND SHALL SURVIVE, ANY FAILURE OF
THE ESSENTIAL PURPOSE OF ANY LIMITED REMEDY. Some states do not
allow the exclusion or limitation of consequential or incidental damages, so the above
exclusions may not apply to you.
LEGAL REMEDIES:
THIS LIMITED WARRANTY DOES NOT “EXTEND TO FUTURE
PERFORMANCE.” ANY ACTION TO ENFORCE THIS LIMITED WARRANTY
OR ANY IMPLIED WARRANTIES SHALL NOT BE COMMENCED MORE
THAN ONE YEAR AFTER THE EXPIRATION OF THE ONE YEAR
WARRANTY COVERAGE PERIOD DESIGNATED ABOVE. IF YOU USE
YOUR MOTOR HOME FOR COMMERCIAL OR BUSINESS PURPOSES,
ANY ACTION TO ENFORCE THIS LIMITED WARRANTY OR ANY IMPLIED
WARRANTIES SHALL NOT BE COMMENCED MORE THAN ONE YEAR
AFTER THE EXPIRATION OF THE NINETY (90) DAY WARRANTY
COVERAGE PERIOD DESIGNATED ABOVE. THE PERFORMANCE OF
REPAIRS SHALL NOT SUSPEND THIS LIMITATIONS PERIOD FROM
EXPIRING. Some states do not allow the reduction in the statute of limitations, so the
above reduction in the statute of limitations may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
LARGER PRINT VERSION AVAILABLE WITHIN THE OWNER’S MANUAL
AND UPON REQUEST ADDRESSED TO YOUR SELLING DEALER OR
WARRANTOR’S WARRANTY DEPARTMENT.
110505

iii
RoadmasteR Limited WaRRanty - 2007
ROADMASTER CHASSIS LIMITED WARRANTY
WHAT THE PERIOD OF COVERAGE IS:
This Limited Warranty provided by Roadmaster® (“Warrantor”) covers your
Roadmaster Chassis for thirty-six (36) months from the original retail purchase date or
the rst 36,000 miles of use, whichever occurs rst.
If you use the Roadmaster Chassis that your motorhome is mounted upon for any
rental, commercial or business purposes whatsoever, this Limited Warranty covers your
new Roadmaster Chassis for Ninety (90) days from the original retail purchase date or
the rst 24,000 miles of use, whichever occurs rst. A conclusive presumption that the
Roadmaster Chassis has been used for commercial and/or business purposes arises if
you have led a federal or state tax form claiming any business tax benet related to
your ownership of the motorhome.
This Limited Warranty applies to all owners, including subsequent owners, of the
Roadmaster Chassis. However, a subsequent owner must submit a warranty transfer
form. A subsequent owner’s warranty coverage period is the remaining balance of the
warranty coverage period the prior owner was entitled to under this Limited Warranty.
Warranty transfer forms can be obtained by contacting the Customer Relations
Department. There is no charge for the transfer.
LIMITATION AND DISCLAIMER OF IMPLIED WARRANTIES:
IMPLIED WARRANTIES, IF ANY, ARISING BY WAY OF STATE LAW,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND ANY
IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE TERM OF THIS LIMITED WARRANTY
AND ARE LIMITED IN SCOPE OF COVERAGE TO THOSE PORTIONS
OF THE MOTORHOME COVERED BY THIS LIMITED WARRANTY.
WARRANTOR DISCLAIMS ALL IMPLIED AND EXPRESS WARRANTIES,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND
THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE,
ON COMPONENTS AND APPLIANCES EXCLUDED FROM COVERAGE
AS SET FORTH BELOW. There is no warranty of any nature made by Warrantor
beyond that contained in this Limited Warranty. No person has authority to enlarge,
amend or modify this Limited Warranty. The dealer is not the Warrantor’s agent but is
an independent entity. Warrantor is not responsible for any undertaking, representation
or warranty made by any dealer or other person beyond those expressly set forth in
this Limited Warranty. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you
WHAT THE WARRANTY COVERS:
Warrantor’s Limited Warranty covers defects in the manufacture of the Roadmaster
Chassis and defects in materials used to manufacture the Roadmaster Chassis. “Defect”
means the failure of the Roadmaster Chassis and/or the materials used to assemble the
Roadmaster Chassis to conform to Warrantor’s design and manufacturing specication
and tolerances. Also see the section “What the Warranty Does Not Cover” set out below.
WHAT WE WILL DO TO CORRECT PROBLEMS:
Warrantor’s sole and exclusive obligation is to repair and/or replace, at its option, any
covered defect if: (1) you notify Warrantor or one of its authorized servicing dealers of
the defect within the warranty coverage period and within ve (5) days of discovering
the defect; and (2) you deliver your Roadmaster Chassis to Warrantor or Warrantor’s
authorized servicing dealer at your cost and expense. It is reasonable to expect some
service items to occur during the warranty period. The performance of warranty repairs
shall not extend the original warranty coverage period. Further, any performance of
repairs after the warranty coverage period has expired or any performance of repairs to
component parts and appliances that are excluded from coverage shall be considered
“good will” repairs, which shall not alter the express terms of this limited warranty.
If the repair or replacement remedy fails to successfully cure a defect after Warrantor
received a reasonable opportunity to cure the defect(s), your sole and exclusive remedy
shall be limited to Warrantor paying you the cost of having an independent third party
perform repair(s) to the defect(s).
Warrantor may use new and/or remanufactured parts and/or components of
substantially equal quality to complete any repairs.
Defects and/or damage to interior and exterior surfaces, trim, upholstery and other
appearance items may occur at the factory during manufacture, during delivery of
the motorhome to the selling dealer or on the selling dealer’s lot. Normally, any such
defect or damage is detected and corrected at the factory or by the selling dealer during
the inspection process performed by the Warrantor and the selling dealer. If, however,
you discover any such defect or damage when you take delivery of the motorhome, you
must notify your dealer or Warrantor within ve days of the date of purchase to have
repairs performed to the defect at no cost to you as provided by this Limited Warranty.
If either three or more unsuccessful repair attempts have been made to correct any
covered defect that you believe substantially impairs the value, use or safety of your
motorhome, or repairs to any covered defect(s) which you believe substantially impairs
the value, use or safety of your motorhome have taken 30 or more days to complete,
you must, to the extent permitted by law, notify Warrantor directly in writing of the
failure to successfully repair the defect(s) so that Warrantor can become directly
involved in exercising a nal repair attempt for the purpose of performing a successful
repair to the identied defect(s).

iv
RoadmasteR Limited WaRRanty - 2007
HOW TO GET SERVICE:
For warranty service simply contact one of Warrantor’s authorized service centers for
an appointment, then deliver your Roadmaster Chassis (at your expense) to the service
center. If you need assistance in locating an authorized warranty service facility, contact
Warrantor’s Warranty Department (1-877-466-6226). The mailing address is:
91320 Coburg Industrial Way
Coburg, Oregon 97408
In the event the Roadmaster Chassis is inoperative due to malfunction of a warranted
part, Warrantor will pay the cost of having the motorhome towed to the nearest
authorized repair facility provided you notify Warrantor prior to incurring the towing
charges to receive directions to the nearest repair facility. Because Warrantor does not
control the scheduling of service work by its authorized servicing dealers, you may
encounter some delay in scheduling and/or in the completion of the repairs.
WHAT THE WARRANTY DOES NOT COVER:
This Limited Warranty does not cover: modications and alterations to the
Roadmaster Chassis by others; the motorhome that is mounted upon the Roadmaster
Chassis, including by way of example the motorhome manufacturer’s design,
manufacture, assembly and/or installation of the side walls, roof, windows, ooring,
electrical system, plumbing system, LP-Gas system, appliances and slide outs; items
that are working as designed but which you are unhappy with because of the design;
normal wear and usage; routine maintenance including by way of example wheel
alignments; component parts covered by their own manufacturer’s warranty, including
by way of example the engine, radiator, transmission, tires, tubes, batteries, exhaust
system and the emission control systems; and, aking, peeling rusting and chips or
other defects or damage in or to the frame and frame cross members caused by rocks
or other road hazards and the environment including airborne pollutants and salt.
Component part manufacturers issue limited warranties covering those portions of the
Roadmaster Chassis not covered by the Limited Warranty issued by Warrantor. To learn
more on what specic component parts are excluded from the Limited Warranty issued
by Warrantor please contact your selling dealership or Warrantor directly or review the
warranty packet inside the Motorhome.
EVENTS DISCHARGING WARRANTOR FROM OBLIGATION UNDER
WARRANTY:
Misuse or neglect, accidents, unauthorized alteration, failure to provide reasonable
and necessary maintenance (see Owner’s Manual), damage caused by off road use,
collision, re, theft, vandalism, explosions, overloading in excess of rated capacities,
and odometer tampering shall discharge Warrantor from any express or implied
warranty obligation to repair any resulting defect.
DISCLAIMER OF CONSEQUENTIAL AND INCIDENTAL DAMAGES:
THE ORIGINAL PURCHASER OF THE ROADMASTER CHASSIS AND
ANY PERSON TO WHOM THE ROADMASTER CHASSIS IS TRANSFERRED,
AND ANY PERSON WHO IS AN INTENDED OR UNINTENDED USER
OR BENEFICIARY OF THE ROADMASTER CHASSIS, SHALL NOT BE
ENTITLED TO RECOVER FROM WARRANTOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES RESULTING FROM ANY DEFECT IN THE
ROADMASTER CHASSIS, INCLUDING BY WAY OF EXAMPLE FUEL
AND TRANSPORTATION EXPENSES TO DELIVER THE PRODUCT TO
THE SERVICING DEALER, HOTEL ROOMS, LOST WAGES AND WATER
DAMAGE. THE EXCLUSION OF CONSEQUENTIALAND INCIDENTAL
DAMAGES SHALL BE DEEMED INDEPENDENT OF, AND SHALL SURVIVE,
ANY FAILURE OF THE ESSENTIAL PURPOSE OF ANY LIMITED REMEDY.
Some states do not allow the exclusion or limitation of consequential or incidental
damages, so the above exclusions may not apply to you.
LEGAL REMEDIES:
THIS LIMITED WARRANTY DOES NOT “EXTEND TO FUTURE
PERFORMANCE”. ANY ACTION TO ENFORCE THIS LIMITED WARRANTY
OR ANY IMPLIED WARRANTIES SHALL NOT BE COMMENCED MORE
THAN ONE YEAR AFTER THE EXPIRATION OF THE THIRTY-SIX (36)
MONTH WARRANTY COVERAGE PERIOD DESIGNATED ABOVE. IF YOU
USE YOUR MOTORHOME FOR COMMERCIAL OR BUSINESS PURPOSES,
ANY ACTION TO ENFORCE THIS LIMITED WARRANTY OR ANY
IMPLIED WARRANTIES SHALL NOT BE COMMENCED MORE THAN ONE
YEAR AFTER THE EXPIRATION OF THE NINETY (90) DAY WARRANTY
COVERAGE PERIOD DESIGNATED ABOVE. THE PERFORMANCE OF
REPAIRS SHALL NOT SUSPEND THIS LIMITATIONS PERIOD FROM
EXPIRING. Some states do not allow the reduction in the statute of limitations, so the
above reduction in the statute of limitations may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
LARGER PRINT VERSION AVAILABLE WITHIN THE OWNERS MANUAL
AND UPON REQUEST ADDRESSED TO YOUR SELLING DEALER OR
WARRANTOR’S WARRANTY DEPARTMENT.
121605

Camelot 2007
Sections
Section 1 ~ General InformatIon ..................................................................................................... 1
Section 2 ~ DrIvInG & Safety...........................................................................................................15
Section 3 ~ exterIor & InterIor Care............................................................................................55
Section 4 ~ applIanCeS ......................................................................................................................77
Section 5 ~ equIpment.................................................................................................................... 103
Section 6 ~ Water SyStemS............................................................................................................ 137
Section 7 ~ lp-GaS SyStemS........................................................................................................... 153
Section 8 ~ eleCtrICal SyStemS - HouSe ..................................................................................... 163
Section 9 ~ eleCtrICal SyStemS - CHaSSIS..................................................................................... 183
Section 10 ~ CHaSSIS InformatIon .............................................................................................. 199
index .................................................................................................................................................. 249

The information contained in this document is intended to reect standard and optional equipment included in a typically equipped model at the time
of delivery to the initial retail owner. Your actual unit may vary from this document as a result of optional equipment that is not generally offered on
this model. In the case that you are not the initial retail owner of the unit, this document will not reect modications that may have been performed by
previous owners.
©Copyright Monaco Coach Corporation. All rights reserved. All other trademarks or registered trademarks are property of their respective holders.
Brand name products of other companies mentioned in this manual are not endorsed by the manufacturer of the motorhome.
Product information and specications are shown herein as of the time of printing.
The motorhome manufacturer reserves the right to change product specications,
designs and standard equipment without notice and without incurring obligation.
06109 JS

Camelot 2007
General Information — Section 1
WARRANTY INFORMATION FILE ............................................... 4
REPORTING SAFETY DEFECTS..................................................4
SAFETY TERMS......................................................................... 4
GLOSSARY OF TERMS .............................................................. 5
VENDOR LIST............................................................................ 7
OWNER’S MANUAL SURVEY: CAMELOT 2007 ........................11
LIMITED WARRANTY TRANSFER APPLICATION/
CHANGE OF OWNER INFORMATION .......................13

SECTION 1 — GENERAL INFORMATION
4
CAMELOT 2007
WARRANTY INFORMATION FILE
In addition to this Owner’s Manual you will
nd a Warranty Information File in your unit.
This le contains valuable documents about
your motorhome’s systems and equipment.
Many of the component manufacturer’s warranty
registration cards can be found in the box. They
will need to be lled out and mailed. Be sure
you read and understand all the information in
this le to help you safely operate, maintain and
troubleshoot those items.
Additional Information:
Changes, additions and supplemental
information in the form of Manual Addendums
and “Tech Tips” can be obtained by visiting our
Web Site at www.monaco-online.com. Select
one of the products from the product lineup. Go
to the Service menu. A submenu will appear.
It may also be helpful to browse the “Tech
Tips” menu for the other product lines. The tips
may not completely apply to your particular
model, but information contained therein can be
useful.
REPORTING SAFETY DEFECTS
If you believe that your motorhome has a
defect which could cause a crash or could
cause injury or death, you should immediately
inform the National Highway Trafc Safety
Administration (NHTSA) in addition to
notifying Monaco Coach. If NHTSA receives
similar complaints, it may open an investigation,
and if it nds that a safety defect exists in a
group of motorhomes, it may order a recall or
remedy campaign. However, NHTSA cannot
become involved in individual problems between
you, your dealer or Monaco Coach. To contact
NHTSA you may call the Auto Safety Hot line
toll-free at 1-888-327-4236 (TTY: 1-800-424-
9153) (or 1-202-366-0123 in the Washington
D.C. area), visit their websites at www.nhtsa.
gov or www.safercar.gov, or write to:
NHTSA
U.S. Department of Transportation
400 Seventh Street S.W.
Washington, DC 20590
SAFETY TERMS
Many of the safety terms are personal safety
instructions. Denitions for the terms are listed
below. It is important to thoroughly read and
understand the safety instructions displayed
throughout the manual. Failure to comply with
specic instructions may result in personal injury
or death. Many instructions are required by
National Safety Associations.
WARNING:
Warnings contain information regarding
personal safety and/or pertaining to potential
extensive or permanent damage to the
motorhome or its components by means of
hazards or improper use.
CAUTION:
Cautions pertain to potential damage to the
motorhome and/or its components.
POISON:
A warning or caution pertaining to safety
and/or use of a poisonous substance or
harmful chemical.
NOTE:
Information and reminders concerning
proper operation of the motorhome and/or its
components.
INSPECTION:
Inspection of the motorhome and/or
its components is required. Additional
instruction may follow.
LUBE:
Lubrication, or addition of a lubricant
product, to the motorhome and/or a specied
component or part is required. Additional
instruction may follow.
ASSEMBLE or REPAIR:
Assembly, disassembly or installation of
a component or part, and/or repair to the
motorhome may be required. Assistance of
Technical Support or Technician may be
necessary.
INFORMATION:
References to additional information
regarding operation of the motorhome and/or
its components found in additional sources,
other than the Owner’s Manual. Also refers
to the WARRANTY INFORMATION FILE,
found within the Warranty Information Box
in the motorhome.

5
SECTION 1 — GENERAL INFORMATION
CAMELOT 2007
TIP:
Tips contain information, helpful hints
and/or suggestion for ease of operation of the
motorhome or its components.
GLOSSARY OF TERMS
AC Electricity - Alternating current also
known as household power.
Air Compressor - Pumps air to and builds
air pressure in an air system.
Air Dryer - Cools, lters and dries the air
delivered by an air compressor.
Air Governor - Controls the operation of
the air compressor by constantly monitoring
air pressure in the supply tank of the air
system. The air governor initiates the unload
cycle when the cut-out pressure is reached.
The air governor also controls the air dryer
by sending an air signal (at the beginning of
the compressor unload cycle) to the control
port of the air dryer, initiating the purge
cycle. When this air signal is removed by the
governor (at the beginning of the compressor
load cycle) the purge valve closes and the
drying cycle begins.
Alternating Current (AC) - A current
that varies periodically in magnitude
and direction. A battery does not deliver
alternating current. Also referred to as
shore power, utility power, inverter power,
generator power, etc.
Ampere (Amp) - The unit of measure
of electron ow rate of current through a
circuit.
Ampere-hour (Amp-hr. AH) - A unit of
measure for a battery electrical storage
capacity, obtained by multiplying the current
in amperes by the time in hours of discharge.
Example: A battery which delivers 5
amperes for 20 hours, delivers 5 amperes
times 20 hours, or 100 Amp-Hr. of capacity.
ANSI - American National Standards
Institute.
ASTM - American Society for Testing and
Materials.
Black Water - Term associated with the
sewage holding tank. The toilet drains
directly into this tank.
CCA - Cold Cranking Amperage is the
amount of current a battery can deliver for
30 seconds at 0° F without dropping below a
specied voltage, usually 10.5 Volts DC.
Chassis Battery - Powers chassis 12 Volt
accessories and starts engine.
Circuit - An electric circuit is the path of
an electric current. A closed circuit has a
complete path. An open circuit has a broken
or disconnected path.
City Water - A term associated with
the water supply that you hook-up to at
campgrounds. It is called city water because
water is pulled from a central source (like in
a city) and not the fresh water tank.
Compressor Load Cycle - The time during
which the air compressor is building air
pressure in an air system.
Compressor Unload Cycle - The time
during which the air compressor is idling
and is not building air pressure in an air
system.
Curbside - This refers to the side of the
motorhome which faces the curb when it
is parked. Often called the door side or the
passenger side.
Current - The rate of ow of electricity
or the movement rate of electrons along a
conductor. It is comparable to the ow of
a stream of water. The unit of measure for
current is the ampere.
Cut-In Pressure - The pressure level in the
air system supply tank which tiggers the
compressor load cycle.
Cut-Out Pressure - The pressure level in
the air system supply tank which triggers the
compressor unload cycle.
Cycle - In a battery, one discharge plus one
recharge equals one cycle.
Desiccant - A granular substance that has a
high afnity for water and is used to retain
moisture from the air stream owing through
the air dryer cartridge.

SECTION 1 — GENERAL INFORMATION
6
CAMELOT 2007
Direct Current (DC) - Power that is
stored in a battery bank or supplied by
photovoltaics, alternator, chargers and DC
generators. Direct current is also known as
battery power. Current only ows one way.
Drain Trap - This is a curve that is in all
drains. Water is trapped in the curve and this
creates a barrier so tank odors cannot escape
through the drain.
Dry Camping - Camping in the motorhome
when there is no city water hook-up or shore
power. In other words, using only the water
and power that is in the motorhome and not
from another source.
Drying Cycle - The time during which the
air dryer cools, lters and removes moisture
from the air delivered by the air compressor.
The drying cycle begins and ends the same
as the compressor load cycle.
Dump Station - A site where the waste
(grey) and sewage (black) tanks can be
drained. In most states it is illegal to drain
waste tanks anywhere other than at a dump
station.
Dump Valve - Another name for the
T-handle valve used to drain the sewage
(black) and waste (grey) tanks.
Escape (Egress) Window - The formal
name for the emergency window located in
the rear of the motorhome. Egress windows
can be easily identied by their red handles.
Full Hook-Up Site - A campground that has
city water, shore power and sewer hook-ups
or connections available.
Grey Water - Term associated with the
waste water holding tank. Water from the
sink drains, the shower and the washer-dryer
(if equipped) go into this tank.
House Battery - Powers 12 Volt DC lights
and accessories inside motorhome.
LED (Light Emitting Diode) - Indicator
light.
Low Point Drain - The lowest point in the
plumbing. These drains must be closed when
you ll the water tank.
OEM - Term for Original Equipment
Manufacturer.
OHM - A unit for measuring electrical
resistances.
Ohm’s Law - Expresses the relationship
between Volt (E), amperes (I) in an
electrical circuit with resistance (R). It can
be expressed as follows: E = IR. If any two
of the three values are known, the third
value can be calculated by using the above
formula.
Potentiometer - A device for measuring
an unknown potential difference or
electromotive force.
Pounds Per Square Inch Gauge (psig) -
Pressure measured with respect to that of the
atmosphere. This is a pressure gauge reading
in which the gauge is adjusted to read zero at
the surrounding atmospheric pressure. It is
commonly called gauge pressure.
Purge - The initial blast of air
(decompression) from the air dryer purge
valve at the beginning of the air compressor.
Purge Cycle - The time during which the air
dryer is undergoing purge and regeneration.
This cycle starts at the beginning of the
compressor unload cycle and normally ends
well before the beginning of the compressor
load cycle.
Regeneration - The mild backow of air
through the air dryer and out the purge valve
that begins immediately after the purge
and lasts normally 10 to 15 seconds. This
backow of air, from the air system and
through the air dryer, removes moisture from
the desiccant cartridge and prepares the air
dryer for the next compressor load cycle.
Roadside - This refers to the side of the
motorhome which faces the road when it is
parked. Often called the off-door side or the
driver side.
SCA - Term for Supplemental Coolant
Additive. Chemical added to coolant for
diesel engines to help prevent cylinder liner
pitting and internal corrosion.

7
SECTION 1 — GENERAL INFORMATION
CAMELOT 2007
Shore Line - This is the electrical cord
which runs from the motorhome to the
campground 120 Volt AC electrical supply.
Shore Line Plug - The 120/240 Volt AC
outlet allows the motorhome to be hooked up
to a campground facility.
Stinger - An arm attachment on a tow truck
that is used to lift the motorhome slightly for
towing.
VIM - Vehicle Interface Module.
Volt - The unit of measure for electric
potential.
Watt - The unit for measuring electrical
power, i.e. the rate of doing work, in moving
electrons by or against an electric potential.
Wet Cell Battery - A type of battery that
uses liquid as an electrolyte. This type
of battery requires periodic maintenance
to clean the connections and check the
electrolyte level.
VENDOR LIST
Air Bags
Firestone
800-367-3872
www.bridgestone-restone.com
Air Conditioner - Dash
SCS/Frigette
800-275-7524
www.scsfrigette.com
Air Conditioner - Roof
Dometic Corp.
800-544-4881
www.dometic.com
Air Filter
Donaldson
952-887-3131
www.donaldson.com
Air Mattress (Optional)
Select Comfort
800-318-2231
www.selectcomfort.com
Aladdin™
Monaco Coach Corporation
Technical Support
877-466-6226
Alternator
Leece-Neville
800-354-0560
www.prestolite.com
Awnings
Carefree
303-469-3324
www.carefreeofcolorado.com
Axles - Brakes
Eaton Corporation
800-826-4357
www.truck.eaton.com
Batteries
Interstate
800-772-3600
www.interstatebatteries.com
Brakes-Anti-Lock Brake System
Eaton
800-826-4357
www.truck.eaton.com
Brakes-Automatic Traction Control
Eaton
800-826-4357
www.truck.eaton.com
Carbon Monoxide Detector
Safe-T-Alert
800-383-0269
www.safe-t-alert.com
Cooktop
Atwood
800-873-4328
www.atwoodmobile.com
Dumping System (Optional)
RV Sani-Con
866-410-1965
www.emptythetanks.com
Energy Management System
Intellitec
800-251-2408
www.intelliteccsve.com
Engine
Cummins
800-343-7357
www.cummins.com
Entry Step
Coach Step
800-275-7524
www.scsfrigette.com

SECTION 1 — GENERAL INFORMATION
8
CAMELOT 2007
Exhaust Brake
Pac Brake
800-663-0096
www.pacbrake.com
Jacobs Vehicle Systems
800-343-7357
www.jakebrake.com
Fan - Bathroom Exhaust
Fan-Tastic Vent
800-521-0298
www.fantasticvent.com
Faucet
Moen
800-289-6636
www.moen.com
Filters - Coolant, Fuel, Oil
Fleetguard
800-223-4583
800-22Filter
www.eetguard.com
Racor Fluid Filters
800-344-3286
www.parker.com/racor/
Gar-Ber Filters
206-789-2758
www.garberlters.com
Fire Extinguisher
Kidde
800-880-6788
www.kiddesafety.com
Furnace
Atwood Mobile Products
800-873-4328
www.atwoodmobile.com
Generator
Onan
800-888-6626
www.onan.com
Home Theater
Magnadyne
800-538-3600
www.magnadyne.com
Hydro-Hot
Vehicle Systems Inc.
800-685-4298
www.hydro-hot.com
Inverter
Magnum
305-386-5125
www.magnumteknologies.com
Keyless Entry
Trimark
800-447-0343
www.trimarkcorp.com
Leveling System - Air (Optional)
Valid Manufacturing
250-832-6477
www.validmanufacturing.com
Leveling Jacks - Hydraulic
Power Gear
800-334-4712
www.powergearus.com
LP-Gas Detector
Safe-T-Alert
800-383-0269
www.safe-t-alert.com
LP-Gas Tank
Manchester
800-877-8265
www.mantank.com
LP-Gas Controls
Marshall Gas Controls
(Division of S.H. Leggitt Company)
800-877-2495
www.shleggit.com
Microwave
Sharp Electronics Corp.
800-237-4277
www.sharp-usa.com
Navigation System
Audiovox
800-645-4994
www.audiovox.com
Outside Mirrors
Ramco Industries, Inc.
800-321-4819
www.ramco-eng.com

9
SECTION 1 — GENERAL INFORMATION
CAMELOT 2007
Power Cord Reel
TDI Products
866-713-1489
www.tdiproducts.com
Power Hose Reel
TDI Products
866-713-1489
www.tdiproducts.com
Power Sun Visors
Carefree of Colorado
303-469-3324
www.carefreeofcolorado.com
Radio
CD/DVD - Dash
Magnadyne
800-538-3600
www.magnadyne.com
CD/DVD - Bedroom (Optional)
Magnadyne
800-538-3600
www.magnadyne.com
Rear Vision System
Voyager
www.asaelectronics.com
Refrigerator
Norcold
800-543-1219
www.norcold.com
Dometic Corp. (Optional)
800-544-4881
www.dometic.com
Satellite Radio (Optional)
Sirius
888-539-7474
www.siriusradio.com
Satellite System (Optional)
Kingdome
800-982-9920
www.kingcontrols.com
Seats - Driver & Passenger
Villa International
888-707-7272
www.villainternational.com
Shock Absorbors
Monroe
800-880-7580
www.tenneco-automotive.com
Slide-out Motor - Cable
BAL Accu-slide
800-347-2232
www.norcoind.com
Slide-out Motor - Electric & Hydraulic
Lippert Components
866-524-7821
www.lippertcomponents.com
Smoke Alarm
Safe-T-Alert
800-383-0269
www.safe-t-alert.com
Solar Panels (Optional)
Moringstar Corp.
215-321-4457
www.morningstarcorp.com
Steering Gear
TRW
765-423-5377
www.trw.com
Steering Wheel (Smart Wheel)
Vehicle Improvement Products
847-395-7250
www.vipwheels.com
Storage Bay Slide-out Tray
Lippert Components
866-524-7821
www.lippertcomponents.com
Television - LCD
Sharp
800-237-4277
www.sharp-usa.com
Television Antenna
Winegard
800-288-8094
www.winegard.com
Tires
Goodyear Tire & Rubber
800-321-2136
www.goodyear.com

SECTION 1 — GENERAL INFORMATION
10
CAMELOT 2007
Toilet
Thetford
800-521-3032
www.thetford.com
Transfer Switch
Iota Engineering
800-866-4682
www.iotaengineering.com
Transmission
Allison Transmission
800-524-2303
www.allisontransmission.com
Vacuum
Eureka
800-282-2886
www.eureka.com
Washer/Dryer (Optional)
Splendide
800-356-0766 ext. 5
www.splendide.com
Water Filter
Everpure
800-323-7873
www.everpure.com
Water Heater
Atwood Mobile Products
800-873-4328
www.atwoodmobile.com
Water Pump
Aquatec
800-975-9995
www.aquatec.com
Wheels - Accushield
Accuride
812-962-5000
www.accuridewheels.com
Windshield Wipers
Diesel Equipment
800-632-4959
www.dieselequipment.com

Your suggestions are very important to us and we are continually striving
to improve the quality of our manuals. After becoming familiar with your
new recreational vehicle and the accompanying manual, please take the
time to answer the following questions. When you are nished please
return the survey via mail to our Technical Publications Department,
or you may fax the survey to: (541) 681-8031 Attention: Technical
Publications Department. Feel free to attach an additional page if you
desire.
1. Is this your rst recreational vehicle? YES / NO (circle one)
2. If no, what was your previous recreational vehicle brand/model?______
____________________________________________________________
________
3. Was the overall appearance and lay-out of this manual what you
expected to see in your new recreational vehicle?
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
4. Was the information within this manual helpful in acquainting you with
your new recreational vehicle? If not please address any area(s) we need to
expand or improve on.
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
5. Were the operating instructions clearly written, and were you able to
follow the steps without any difculty?
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
6. Is there any additional information you would like to see incorporated
within the owner’s manual?
____________________________________________________________
____________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
NAME: ___________________________
PHONE: (_____)____________________
ADDRESS:__________________________________________________
____________________________________________________________
____________________________________________________________
VIN # ___________________________________________________
OWNER’S MANUAL SURVEY: Camelot 2007
TEAR OFF PAGE AND MAIL TO:
TECHNICAL PUBLICATIONS PLT. 17
MONACO COACH CORPORATION
91320 COBURG INDUSTRIAL WAY
COBURG, OR 97408


LIMITED WARRANTY TRANSFER APPLICATION/CHANGE OF OWNER INFORMATION
Mail to:
Monaco Coach Corporation
Warranty Transfer
91320 Coburg Industrial Way
Coburg, OR 97408
Please read terms and representations below before signing.
Submitted By:
Name:
Address:
City: State: Zip:
Phone: ( )
Limited Warranty Transfer
Address Change
By your signature(s) on face side of this form, and in order to induce
Monaco Coach Corporation to transfer its Limited Warranty, you represent
the following:
1. That you have received and read a copy of the Limited Warranty.
2. You understand that the unit is to be used only for family camping and cross
country travel on improved roads.
3. All information provided by you on face side of this form is true and correct.
4. You understand that you are purchasing a pre-owned recreational vehicle
and Monaco Coach Corporation does not make any representation as to its
present condition.
TEAR OFF PAGE AND MAIL TO:
WARRANTY TRANSFER, MONACO COACH CORPORATION,
91320 COBURG INDUSTRIAL WAY
COBURG, OR 97408
A. Current Owner Information:
First Name Initial Last Name
–
Vehicle Identication Number Unit # (15 digits) (6 digits) Model/Year
B. New Owner Information, Transfer Coverage To:
First Name Initial Last Name
( )
Phone Number Street Address City State Zip
Date of Transfer (If Applicable) Odometer Reading at Transfer (If Applicable)
C. Signatures:
(New) Owner’s Signature Date Selling Dealer’s Signature (If Applicable) Date
Terms & Representations


Camelot 2007
Driving & Safety — Section 2
DRIVING & SAFETY........................................... 16
Inspections .................................................. 16
Familiarize Yourself....................................... 16
Mirror Adjust................................................ 16
Safety Seat Belts.......................................... 16
DRIVING TIPS ................................................... 18
TRIP PREPARATION .......................................... 21
HITCH .............................................................. 22
Using the Rear Receiver ............................... 22
Tow Plug Connection.................................... 22
REAR VISION SYSTEM...................................... 23
BACKING UP A MOTORHOME............................ 24
SET-UP PROCEDURES....................................... 25
DRY CAMPING .................................................. 26
BREAKING CAMP .............................................. 27
EMERGENCY ROADSIDE PROCEDURES ........... 28
In Case of Flat Tire ....................................... 28
Light - Retractable........................................ 28
Dead Chassis Battery................................... 29
TOWING PROCEDURES..................................... 30
Disabling Parking Brake................................ 31
TIRES ................................................................ 31
Importance of Air Pressure........................... 32
Tire Pressure Inflation Guideline.................... 32
Tire Chart - Goodyear................................... 33
Inspecting & Pressure .................................. 34
Air Pressure Checklist .................................. 35
Supporting When Leveling............................ 35
Tire Vibration................................................ 35
Tire Rotation ................................................ 36
Tread ........................................................... 36
Storage of Tires - Long Term........................ 36
WHEEL MOUNTING ........................................... 36
WEIGHING THE MOTORHOME........................... 37
Weight Terms............................................... 37
Weight Label................................................ 40
Four Corner Weighing (Example) .................. 40
Cargo Carrying Capacity Flowchart .............. 43
Weighing Procedure Worksheet .................... 44
Weight Record Sheet.................................... 45
Six-Point Weighing Example ........................ 46
Cargo Carrying Capacity Flowchart .............. 48
Weighing Procedure Worksheet ................... 49
Weight Record Sheet.................................... 50
SMOKE DETECTOR............................................ 50
Operation..................................................... 50
Testing......................................................... 50
Maintenance ................................................ 51
Troubleshooting ........................................... 51
CARBON MONOXIDE DETECTOR ....................... 51
Operation..................................................... 52
Alarm........................................................... 52
Testing......................................................... 52
Cleaning & Maintenance............................... 53
FIRE EXTINGUISHER......................................... 53
ESCAPE (EGRESS) WINDOW ............................ 54

SECTION 2 — DRIVING & SAFETY
16
CAMELOT 2007
DRIVING & SAFETY
Section Two contains information on driving
tips, emergency situations, towing, safety
devices, weighing the motorhome and tires.
NOTE
The motorhome has an electronic
data recording device that may record
information about direction, road speed,
engine speed, brake application, steering
attitude or other vehicle operating data.
Data recording devices can be present
in engines, transmissions, ABS (Antilock
Brake Systems) or other systems
affiliated with operation of the vehicle.
Information from data recording devices
can be examined in case of an accident.
Contact the component manufacturer to
learn more about these devices.
Inspections
There are signicant differences between a
passenger automobile and a motorhome. Always
be aware of these differences when traveling.
The key to safely operating a motorhome is
inspection. Undetected problems could cause
problems on the road and may result in lost
time and increased repair costs. Several states
require a special license endorsement and that
the motorhome be inspected prior to registration.
Know and observe the laws of the states in
which you will be traveling. Laws may vary
from state to state. A systematic inspection
conducted prior to moving the motorhome can
help ensure nothing is overlooked and will assist
in familiarizing the owner with the motorhome.
Prior to moving the motorhome perform a
general inspection, which includes examining
the condition of the motorhome and the
surrounding area of the motorhome. Look high
and low when walking around the motorhome.
Familiarize Yourself
Because the location of the driver’s seat in
the motorhome is higher and farther to the left
than most vehicles, a different perspective of
the roadway is created. Rely on the outside
mirrors to line up with the center of the road
and to check conditions behind the motorhome.
The dashboard may include more gauges and
controls than are normally found in passenger
automobiles. Become familiar with these gauges
and their indications before starting out.
Mirror Adjust
Prior to starting out, adjust the
mirrors. It is recommended that
an assistant help to simplify the
mirror adjustment process.
Mirror Adjusting:
Tools needed: Allen
wrench, at blade
screw driver and
socket wrench.
Adjust the driver seat
to the travel position.
Remove plug at the
bottom of the arm.
Using the socket wrench have the
assistant loosen the bolt located at the
base of the arm. (See point A on the
drawing.)
Adjust the mirror so that there is a clear
side view of the coach.
Tighten the bolt once the proper
adjustment is made.
Reinstall the plug.
To adjust the “head” of the mirror, loosen
the set screws located below the mirror
shown as point B. Adjust the head of the
mirror to the left or right.
Manually adjust the bottom section of the
mirror.
Tighten set screws once the proper
adjustment is made.
Repeat procedure for passenger side
mirror.
NOTE
Use the mirror adjust switch located on
the road side console to fine tune the
view.
Safety Seat Belts
All occupants must be furnished with and
use seat belts while the motorhome is moving.
The driver’s seat, and all other seats designed
to carry passengers while the motorhome is in
motion, are equipped with safety seat belts. DO
NOT occupy beds or seats that are not equipped
with a safety belt while the motorhome is in
motion. The driver’s seat must be locked in the
forward facing position while motorhome is in
motion. DO NOT use a seat belt on more than
one person.
031210e
080378
Mirror Adjust
Switch on
Driver’s
Console
Table of contents
Other Monaco Motorhome manuals

Monaco
Monaco 2008 Knight User manual

Monaco
Monaco Cayman 2006 User manual

Monaco
Monaco Cayman 2005 User manual

Monaco
Monaco 2002 Diplomat User manual

Monaco
Monaco 2008 LaPalma XL User manual

Monaco
Monaco 2009 Knight User manual

Monaco
Monaco Executive 2005 User manual

Monaco
Monaco Monarch 2000 User manual

Monaco
Monaco DIPLOMAT 2004 User manual

Monaco
Monaco CAYMAN 2007 User manual
Popular Motorhome manuals by other brands

Winnebago
Winnebago 1996 Adventurer Operator's manual

Renault
Renault Endeavour user manual

Fleetwood
Fleetwood 1984 Jamboree Rallye owner's manual

Airstream
Airstream International Serenity 23CB 2020 owner's manual

Winnebago
Winnebago 2010 Navion IQ Operator's manual

Bailey
Bailey Unicorn Seville Service handbook
