Monarch Freshmarx 9417 User manual

FRESHMARX® 9417 QUICK REFERENCE
For more detailed information, refer to the Operator’s Handbook
available on our Web site (www.monarch.com).
Review the printer safety information in the Safety Sheet
provided with your printer.
1. Cover 6. Power Cord Connection
2. Display 7. Ethernet Port
3. Left Printer 8. USB (Type B) Port
4. Right Printer 9. USB (Type A) Port
5. Speaker 10. Power Button
Avery Dennison®, Monarch®, and Freshmarx® are
registered trademarks of Avery Dennison Corporation.
TC9417MCDQR Rev. AB 7/13 ©2013 Avery Dennison Corp. All Rights Reserved.

Using the Home Screen
Product Tabs Tools
Language
Toggle
Button
2-EN
Using Quick Tips
You can view the Quick Reference Guide information on the
printer. Push the Tools button then select Quick Tips.
Setting the Time and Date
1. Press the Tools button then select Admin.
2. Enter the Admin password and press Enter. The default
password is 1234.
3. Press Time/Date.
4. Press OK when you are finished.
Category
Button
s
Product
Buttons
Use First
Button

Loading Labels – Left Printer
1. Turn on the printer then open the cover.
2. Pull on the supply tab.
3. Unlock the supply guide and remove it.
4. Place a roll of labels (label side up) on the supply holder.
5. Place the supply guide on the supply holder.
EN-3

6. Lock the supply guide.
7. Put the supply tab back.
8. Guide the labels along the inside edge and into the slot. The
printer feeds the supply.
9. Slide the supply lever next to the supply. Close the supply
lever.
10. Close the cover.
4-EN

Loading Labels – Right Printer
1. Turn on the printer then open the cover.
2. Pull on the supply tab.
3. Unlock the outer supply guide and remove it.
4. Place a roll of labels (label side up) on the supply holder.
EN-5

6-EN
5. Place the outer supply guide on the supply holder and lock it
in place.
6. Unlock the inner supply guide and move it until it touches the
supply. Lock it into place.
7. Put the supply tab back.

8. Guide the labels along the outside edge and into the slot. The
printer feeds the supply.
9. Slide the supply lever next to the supply and close it.
10. Close the cover.
EN-7

Printing Labels
Before you print labels, make sure the time and date are set.
1. Turn on the printer.
2. Press the product button of the label to print.
3. Select the number of labels to print and press Enter. To print
a single label, press Enter.
4. Labels print for the selected product.
Note: To print a Use First label, press the Use First button
then select the number of labels to print.
Cleaning and Maintenance
Clearing Label Jams
1. Open the cover.
2. Tear the supply and remove the label roll.
3. Remove the jammed labels.
Caution: Do not use sharp or pointed objects to remove labels.
It may damage the printer.
4. Remove any adhesive that might be on the platen roller. See
“Cleaning the Platen Roller and Printhead” for more
information.
5. Reload the labels.
6. Close the cover.
Cleaning the Platen Roller and Printhead
Clean the platen roller and printhead after every five rolls of
labels or when you see voids in the print.
1. Remove any labels.
2. Use a plastic knife to remove the supply slot cover.
Supply Slot
Cover
8-EN

3. Use the plastic knife to press the L-shaped bar. The platen
roller is released.
Note: Art is cut-away to show detail.
4. Clean the platen roller and printhead using a cotton swab
moistened with isopropyl alcohol.
5. Allow time for the parts to dry.
6. Replace the platen roller.
7. Snap the cover into place.
8. Reload the labels.
Cleaning the Display and Case
Make sure the printer is turned off when cleaning the display.
Use a soft, lint-free cloth to wipe the display.
Caution: Do not use sharp objects or abrasive cleaners on the
display; they can cause damage.
Slightly dampen a cloth with water and wipe off the printer’s
case.
Open the cover and use a dry, soft-bristled brush to remove
paper dust.
Caution: Do not use household cleaners to clean the printer.
EN-9

10-EN
Troubleshooting
Problem Action
The screen is off or the
printer is not responding. Unplug the printer from the wall, wait 10 seconds, plug it back in.
The printer does not print,
has voids, or is too light. Make sure the printer is turned on and has power.
Correctly load supply.
Clean the printhead.
Printing stops OR the
printer does not correctly
advance from one label to
the next.
Clear any jammed labels.
Correctly load supply.
Make sure your printer is turned on
and has power.
If these solutions do not work or you get an error that is not
listed, call 1-800-543-6650.
