Mondella Maestro Cross 5002377 User manual

INS 005 V1
PRODUCT INSTALLATION GUIDE
MONDELLA MAESTRO CROSS HANDLE TAP SETS
Mondella Maestro Cross Handle Basin Set(5002377)
1. Assemble the T-Piece into the basin bodies. Check the hole alignments with the basin/bench top. Un-assemble and cut the T-Piece
ends down to correct size if required.
2. Remove the top lock nuts and washers from the basin bodies.
3. Remove the plastic back nut and washer from the basin spout and place them loosely over the T-Piece nipple. (washer on top)
4. Position the Basin Tee assembly into the vanity basin/bench top so the top threads of the basin bodies are accessible through the top.
Bottom lock nuts can be lowered to suit.
5. Place the washer and lock nuts on the installed bodies and tighten. Tighten the bottom locks nuts up to bench level.
6. Push the basin spout down with a swiveling motion, locating it into the T-Piece nipple. Once fully down be sure to centre the spout
before tightening the plastic back nut. Note – the copper T-Piece can be bent up or down (within reason) to ensure the nipple is at the
correct position inside the spout base.
7. Install the basin flanges by threading them onto the spindle.
8 Install the cross handles by slotting them onto the spindle.
9 Thread the hot and cold button onto spindles, thus securing the handles.
10 Connect the hot and cold water lines to the basin bodies. If using flexible connectors, the bottom nuts and nylon olive fitted to the
basin bodies will not be required.
11 Remove the aerator from the basin spout. Turn on the taps to flush out any filings or debris from the pipes. Re-install the aerator. The
aerator contains a water reducing flow device.
12 Check for leaks above and below bench level. Silicone sealant can be used to seal flanges and spout bases to the bench top if
required*.
(* refer to caring instructions)
Mondella Maestro Cross Handle Wall Top Assembly(5002381)
1. Install the spindle assemblies into the wall bodies, ensuring the ceramic disc locates into the seat of the wall body as follows:-
Remover the locking nut and hand tighten the ceramic valves into postion, then nip with a shifting spanner one half of a turn only.
Re-install the locking nuts ensuring the red washer is in place also.
2. Install the wall flanges by threading them onto the spindle locking nuts.
3. Install the cross handles by slotting them onto the spindle.
4. Thread the hot and cold button onto spindles, thus securing the handles.
5. Check for leaks. Silicone sealant can be used to seal flanges if required*.
(* refer to caring instructions)
Mondella Maestro Cross Handle Bath Set(5002378)
1. Follow the instructions for Mondella Wall Top Assemblies (above) to install handles and valves.
2. Place a generous amount of thread tape lightly around the existing ½” threaded nipple in the wall prior to installing the bath spout.
3. Screw the bath spout into position, trying not to over tighten it in order to have the bath outlet in the desired vertical position.
4. Check for leaks. . Silicone sealant can be used to seal flanges if required*.
(* refer to caring instructions)
Mondella Maestro Cross Handle Shower Set(5002379)
1 Follow the instructions for Mondella Wall Top Assemblies (above) to install handles and valves.
2 Place a generous amount of thread tape lightly around the existing ½” threaded nipple in the wall prior to installing the shower head.
3 Place the chrome back plate over the nipple then screw the shower head into position until tight. Ensure the red water saving device is
in position at the inlet of the shower head. Use a shifter to gently tighten the shower arm into the correct vertical position.
4Check for leaks. Silicone sealant can be used to seal flanges if required*.
(* refer to caring instructions)

INS 005 V1
Mondella Maestro Cross Handle W/Machine Set(5002380)
1 Place a generous amount of thread tape lightly around the existing ½” threaded nipple in the wall prior to installing the washing
machine cocks.
2 Place the chrome back plate over the nipple then screw the washing machine cocks into position until tight.. Use a shifter to gently
tighten the bodies into the correct vertical position.
3 Install the handles by threading them onto the spindle.
4 Thread the hot and cold button onto spindles, thus securing the handles.
5 Check for leaks.
Mondella Maestro Cross Handle Wall Sink Set(5002376)
1. Follow the instructions for Mondella Wall Top Assemblies (above) to install handles and valves.
2. Place a generous amount of thread tape lightly around the existing ½” threaded nipple in the wall prior to installing the sink spout.
3. Screw the sink spout into position, trying not to over tighten it in order to have the sink outlet in the desired vertical position.
4. Remove the aerator from the sink spout. Turn on the taps to flush out any filings or debris from the pipes. Re-install the aerator. The
aerator contains a water reducing flowdevice.
5. Check for leaks. . Silicone sealant can be used to seal flanges if required*.
(* refer to caring instructions)
Working Specifications:
Maximum Temperature; 80 degrees C
Pressure; 800 kpa
Where normal working pressures exceed the maximum stated above, pressure limiting valve should be installed.
Minimum Temperature; 1 degree C
Pressure; 50kpa
Recommended working pressure: 300 to 700kpa
In accordance with Australian Standards requirements it is recommended that all tapware be installed
by a licensed plumber. Please refer to Warranty and Service agreement.
CARING FOR YOUR PRODUCT
•Under no circumstances should you install tapware using acetone silicones.
•Never use harsh detergents or abrasive cleaners, as these will scratch the surface. Using a soft dry cloth or a soft
cloth with warm soapy water is recommended.
•Where your tapware remains dry in use, a soft cloth can be used to remove surface dust. Alternatively, a wipe
over with warm soapy water is all that is required to maintain the finish in perfect condition for a lifetime of use.
•Use of wax based furniture cream should be avoided as these can result in a build up of deposits, which could
detract from the appearance.
•Do not use undue pressure and wipe in one direction only.
