Monessen Hearth Direct Vent Insert System REVEAL (ILDV) Installation instructions

PRODUCT SPECIFICATIONS
REVEAL (ILDV) Direct Vent Insert System
28 1/8”
6 1/4”
14 5/8”
3”
9 7/8”
20 3/16”
20 3/4”
7 5/8”
2 5/8”
21”
HEIGHT
16"
DEPTH
20"
WIDTH
28"
WIDTH
Minimum Fireplace
Opening Dimensions
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the product are subject to change without notice. © 2007 Monessen Hearth ystems Co.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
G L A S S V I E W I N G A R E A
25 1/4”W x 16 3/16”H (409 Square Inches)
T E C H N I C A L I N F O R M A T I O N
Max. Btu Input: 30,000 BTU/HR
FE Rating (Cdn. Fireplace Efficiency): 71.9% NG/ 83.7% LP
Afue Efficiency: 66% NG/ 69% LP
Thermal Efficiency: Up to 88%
CSA De ign Certified
F I E L D I N S T A L L E D A C C E S S O R I E S
Surround : Bevelled & Colonial in Iron Age & Black Texture
Clean face design
Natural Flame™ burner with fiber ceramic log set
Cottage Clay firebrick
Thermostat blower (160 cfm) standard
3" flue outlet
18" flex line with On/Off shut-off valve
C A design certified
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
