Monessen Hearth Lo-Rider LCUF36C-R Installation instructions

PRODUCT SPECIFICATIONS
LCUF36C-R Lo-Rider Vent Free Firebox
37 3/8"
18"
9 3/4"
30 1/4"
32
41 1/4"
FRAMING DIMENSION
18"
FRAMING
DIMENSION
37 5/8"
FRAMING
DIMENSION
41
37 3/8"
36"
31 1/4"
41 1/4"
48 3/4"
16 3/8"
18"
34 1/2"
68 7/8"
32"
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes.Contact local building or fire officials about restrictions and installation inspection requirements.All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit.Appearance and specifications of the product are subject to change without notice. © 2007 Monessen Hearth Systems Co.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
MINIMUM HEARTH DIMENSIONS
Front opening width: 36"
Front opening height: 32"
Rear wall width:24-1/2"
Firebox depth: 16"
TECHNICAL INFORMATION
Clearance to Fireplace: Zero
CSA Design Certified
FIELD INSTALLED ACCESSORIES
Curved Trim: Brass, Pewter, Black
Brass Hood
Wide Profile Brass Hood
Wood Cabinet Surrounds and Hearths
Classic and Designer Facings
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
