REVEAL DIRECT VENT INSERT SYSTEM
Monessen
Introducing t e Reveal from Monessen.
It’s easy to turn an old inefficient masonry fireplace into a cozy cost-effective heat source with
a direct vent insert from Monessen. Our Reveal insert is the perfect choice. With a large
viewing area, 30,000 BTUs and a host of sensible options, the Reveal will show you just what
a fireplace can do for your home. Standard features include Cottage Clay firebrick, a variable
thermostat controlled forced air blower and Natural Flame™ burner with a strikingly realistic
fiber ceramic log set. The valve is located conveniently on the outside of the box for easy
access and maintenance, and two styles and colors of designer facings make the unit a
perfect fit for any room.
MON7508INT_REVEAL_ILDV_DV_FNL.qxd:Final2007T mplat _V rmont_CastingsREVSt ph.qxd 11/6/08 5:00 PM Pag 1

To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the
product and all applicable building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this brochure
are for illustrative purposes only and are not intended for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the product
are subject to change without notice. © 2008 Monessen Hearth Systems Co.
A Brand of Monessen Heart Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
Ver.01 MON7508INT
Monessen
Direct Vent Insert System
Standard Features Surrounds & Options
Your Monessen Dealer:
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
On/Off shut-off valve with easy access panel
conveniently located on side of the firebox
Colonial and Bevelled surrounds offered in
Iron Age and Black Texture
Bevelled
Colonial
Model ILDV30
BTU / HR 30,000
FE Ratings (Cdn. Fireplace Efficiency) 71.9% NG / 83.7% LP
Afue Efficiency 66% NG / 69% LP
T ermal Efficiency Up to 80%
Dimensions (Actual) 34 3/8”W x 20 3/4”H x 17 5/8”D
Minimum Fireplace Opening 28”W (Front width) x 21”H x 16”D x 20” (Rear width)
Glass Viewing Area 409 sq. in.
• Clean face design
• Viewing area: ILDV30 409 sq. in.
• Natural Flame™ burner with fiber ceramic log set
• Cottage Clay firebrick
• Optional surrounds
• Thermostat blower (160 cfm) standard
• 3" flue outlet
• 18" flex line with On/Off shut-off valve
• CSA design certified
ILDV30 with Black Texture Bevelled surround
Cottage Clay
Firebrick Detail
Image on front - ILDV30 with Iron Age Colonial surround Colonial surround features cast iron 4 3/4” mantle shelf
