TrueCap®RFCapacitance Level Sensor
odel K-2
BULLETIN
434A
o d e l K - 2
I N S T A L L A T I O N & O P E R A T I O N
®
Thank you for purchasing a quality product manufactured by Monitor
Technologies LLC. We realize that you do have a choice of vendors
when procuring RF Capacitance sensors and we sincerely appreciate
your business!
This manual contains the information necessary to ensure a safe and
successful installation. Please read and comply with the section on page
10 of this manual pertaining to SAFETY. Doing so will ensure proper
operation of the equipment and the safety of all personnel.
efore discarding shipping container, please inspect it thoroughly and
verify that all parts ordered are accounted for. Sometimes smaller parts
become stuck under carton flaps and other packaging materials.
In the event that information contained herein does not completely sat-
isfy your requirements or answer your questions, you may contact
Technical Support on our website www.monitortech.com, by e-mail at
[email protected] or by telephone at 1-800-766-6486
(1-630-365-9403). If your sensor ever requires service either in or out of
warranty, please contact us and obtain an RMA number prior to shipping
the unit to us.
www.monitortech.com

PR E- I NS AL L A ION C ON S I D ER A IONS
2
Choosing a Location: (See Figure 2)
1) aterial Flow - When selecting a location for the MK-2,
choose a point in the vessel where the probe will be out of
the direct flow of incoming and outgoing material to prevent
any mechanical damage that may be caused by the pres-
sure of the flow. The MK-2 must be positioned at a point
where incoming material will reach and cover the probe in its
normal flow, and when receding, will flow away from the
probe in an even manner. For best results, choose a posi-
tion where a majority of the probe, not just the tip, will be
covered. This is particularly important when detecting mate-
rials with low relative dielectric constants and low product
densities. The unit will not operate as a “tip sensitive”
device. For extended length models, allow for at least 8 to
12 inches (203-305 mm) of probe coverage. When sensing
highly conductive materials, or those with a high dielectric
constant, the MK-2 can perform as a “tip sensitive” sensor.
2) Vessel Contact - Select an area where the probe can not
contact any internal structure elements of the vessel. When
using the Cable Extension Probe, consider the angle of
repose of the material that will flow into and out of the ves-
sel. Insure that the expected swing of the cable will not
touch the vessel.
3) Driven Shield Penetration - Select a location which
ensures that the driven shield section protrudes into the ves-
sel and is not recessed in the mounting neck.
4) ultiple Probe Proximity - If more than one sensor is
mounted in the vessel, do not place the sensors closer than
18 inches (457 mm) from one another.
5) Pipe Extension Reinforcement - When top mounting a
probe with a pipe extension, select a location where it is fea-
sible to reinforce the extension to the vessel wall. See
Mechanical Installation portion of this bulletin for details.
6) Split Architecture Installation - When installing a sensor
with a remote probe, the restrictions above apply to the
remote probe. The remote electronics can be installed
either horizontally or vertically. The remote electronics must
be located within 12 feet (3.6 m) (wiring distance) of the
probe at a location that is free from excessive heat and/or
vibration.
Cover Removal: (See Figure 1)
efore loosening the cover, loosen or remove the cover lock
screw. Spanner slots are incorporated on the top of the cover
which should be used to loosen the cover from the housing.
Use a flat bar for initial loosening. DO NOT use a strap or chain
type wrench. Keep hands clear of threads on the cover and
housing to avoid contact with the thread lubricant.
Figure 2
Figure 1

Lagged Housing Version ounting: (See Figure 6)
1) Select a mounting location in accordance with the Pre-
Installation Recommendations.
2) Cut a hole into the side/top of the vessel corresponding to
the coupling used.
3) Weld coupling to the vessel wall.
4) Insert probe through coupling and thread unit tightly into
place by gripping and rotating the 15/16 inch (24 mm)
wrench flats provided on fitting closest to mounting point.
Do not use sealant tapes (e.g. Teflon tape) or putties. If flats
are inaccessible due to tank insulation, thread unit into place
by gripping and rotating lagging pipe with a strap/pipe
wrench. Continuity between sensor mounting point and vessel
wall must be maintained to assure proper probe operation.
3
ME CH A NI C AL IN S ALL A IO N
Standard, Food Grade, Stub, Cable Extension and Remote
Probe ounting: (See Figures 3, 4 & 5)
1) Select a mounting location in accordance with the Pre-
Installation Recommendations.
2) If using a welded coupling, cut a hole into the side/top of the
vessel corresponding to the mounting connection (i.e. 1-1/2”
SPT, 1-1/4” NPT or 3/4” NPT). If using a Monitor mount-
ing plate, cut a 2-1/2 inch (64 mm) center hole and six 11/32
inch (9 mm) mounting holes (for 5/16” bolts) on a 7 inch (178
mm) bolt circle. Use mounting plate gasket as a template.
3) Weld coupling or attach mounting plate to vessel wall.
4) Insert probe through coupling. Do not use sealant tapes (e.g.
Teflon tape) or putties. When using the 1-1/2” SPT or
1-1/4” NPT connection, grease threads with anti-seize then
thread unit tightly into place by gripping and rotating hous-
ing. When using the 3/4” NPT connection, thread unit tight-
ly into place by gripping and rotating 15/16 inch (24 mm)
wrench flats provided on fitting. Continuity between sensor
mounting point and vessel wall must be maintained to
assure proper probe operation.
Figure 4
Figure 3
Figure 5
Figure 6
DI ENSIONS ARE SHOWN IN INCHES WITH ILLI ETER EQUIVALENT IN BRACKETS

4
Pipe Extension Probe ounting: (See Figure 7)
1) Select a mounting location in accordance with the Pre-
Installation Recommendations.
2) If using a welded coupling, cut a hole into the top of the vessel
corresponding to O.D. of the 1-1/4” coupling used. If using a
Monitor mounting plate, cut a 2-1/2 inch (64 mm) center hole
and six 11/32 inch (9 mm) mounting holes (for 5/16” bolts)
on a 7 inch (178 mm) bolt circle. Use mounting plate
gasket as a template.
3) Weld coupling or attach mounting plate to vessel wall.
4) Insert probe through coupling, grease threads with anti-seize,
then, thread unit tightly into place by gripping and rotating
housing. Do not use sealant tapes (e.g. Teflon tape) or put-
ties. Continuity between sensor mounting point and vessel
wall must be maintained to assure proper probe operation.
5) Mechanical reinforcement of the pipe extension should be
considered whenever the overall probe length (from mount-
ing point to probe tip) exceeds 60 inches (1.5 m).
Mechanical clamping, such as “U” or “C” channel with “U”
bolts should be used. DO NOT USE HEAT to connect brace
to pipe extensions as wiring inside pipe could be damaged.
Figure 7
Remote Electronics ounting
The split architecture configuration is used to protect the elec-
tronics from excessive heat or physical vibration.
1) Select a location that is within 12 feet (3.6m) wiring distance
of the remote probe but where the extreme temperatures or
vibration is not present.
2) The Remote Electronics for Ordinary Locations has no holes
cut in the fiberglass box. Drill holes in enclosure insuring cir-
cuit separation between the remote probe interconnection
and the mains/outputs. Remove electronics (4 backpanel
screws) prior to drilling holes.
3) The Remote Electronics for Hazardous Locations has three
conduit entrances, one of which is plugged at the factory.
This plug may be relocated as desired. All openings must
be suitably sealed to insure environmental and hazardous
location protections.
4) Drill a hole pattern in the structure to which the Remote
Electronics will be mounted (See Mechanicals for details).
5) Secure the enclosure to the structure using 1/4" (6mm) screws.
Hazardous Location Precautions:
Observe the regulations listed in the National Electrical Code
regarding equipment in hazardous locations. In particular,
install a conduit seal fitting within 2 inches (50 mm) of the RF
Capacitance sensor (for Class I rated products only), ensure
power is disconnected whenever the cover is removed, upon
completion ensure cover is completed re-attached and termi-
nate IS ground screw to local intrinsically safe ground. Do not
substitute any electrical components as this may impair intrin-
sic safety and thereby compromise safety.
Factory Wiring:
The MK-2 probe wires are connected to the backside of the
PC . DO NOT alter this connection. Doing so will likely
cause improper operation of the sensor.
Permanently Connected Equipment:
Disconnecting devices shall be included in the system installation.
More on next page >
