Monoprice INDIO User manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES..............................................................................................3
INTRODUCTION .................................................................................................................................................... 4
CUSTOMER SERVICE......................................................................................................................................... 4
PACKAGE CONTENTS...................................................................................................................................... 5
PREPARATION FOR USE................................................................................................................................. 5
SWITCH AND KNOBS....................................................................................................................................... 6
CHECKING YOUR GUITAR'S SETUP........................................................................................................7
STRING REPLACEMENT.................................................................................................................................. 8
NECK ADJUSTMENT (all models)............................................................................................................9
BAR TAILPIECE (Route 66 models only)......................................................................................... 10
HARDTAIL BRIDGE (Retro Vision models only) .........................................................................11
WILKINSON BRIDGE (California Classic models only)..........................................................11
MAINTENANCE ....................................................................................................................................................13

3
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra
attention to these safety warnings and guidelines. Please keep this manual
in a safe place for future reference.
If using a strap, ensure that the strap is securely attached to the
guitar. Do not lift or swing the guitar about by the strap. The strap
could come loose, causing the guitar to fall to the ground or to hit
other persons nearby.
Do not treat the instrument roughly. Do not put excessive force on
the switches and knobs.
Do not put your face close to the guitar when changing the strings
or tuning the guitar. A string could suddenly break, which could
cause facial and eye injuries. It is recommended to wear safety
glasses when changing strings or tuning the guitar.
After changing the strings, use a pair of wire cutters to trim the
string ends. Be aware of the sharp ends of the strings after they are
trimmed.
Clean the guitar using a soft, dry cloth only. Take care to avoid
injury from the sharp string ends at the headstock.
To prevent damage to the guitar, do not lean it against a wall
where it could fall over. For best results, use a guitar stand.
Do not store the instrument near a heat source, such as a fireplace
or stove. Do not leave it in direct sunlight. Do not leave it in a hot
vehicle, especially during the summer.
Avoid exposing your instrument to extremes in temperature and
humidity. If exposure cannot be avoided, loosen the strings and
allow cold instruments to gradually warm up.
When connecting or disconnecting the guitar to an amplifier,
ensure that the amplifier is either powered off or that the volume
is turned all the way down.

4
INTRODUCTION
Thank you for purchasing this Indio Guitar! Your new guitar is a precision
musical instrument, which if properly cared for, will give decades of faithful
service.
Each Indio guitar is professionally setup to ensure that the neck is straight,
and that the action (string height) and intonation are correct. As you use
and transport your guitar, the strings will wear out and parts may come
loose or require adjustment. While you can take your guitar to a luthier for
maintenance, doing your own maintenance will help you fine tune the
guitar's setup to suit your individual playing style and preferences.
This manual includes instructions for basic operation, replacing the strings,
adjusting the neck, adjusting the action, adjusting the intonation, cleaning,
and other maintenance. Note that there are a lot of websites and
instructional videos with this information available, so feel free to
supplement the information in this manual with other sources.
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that
your ordering, purchasing, and delivery experience is second to none. If you
have any problem with your order, please give us an opportunity to make it
right. You can contact a Monoprice Customer Service representative
through the Live Chat link on our website www.monoprice.com during
normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-6pm PT) or via
email at [email protected]

5
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the
items listed below. If anything is missing or damaged, please contact
Monoprice Customer Service for a replacement.
1x Electric Guitar with Installed Strings
1x Heavy-Duty Zippered Gig Bag with Shoulder and Backpack Straps
1x Truss Rod Wrench (all models)
1x Saddle Height Adjustment and Tremolo Lock Wrench (California
Classic models only)
1x Saddle Height Adjustment Wrench (Retro Vision models only)
1x Bridge Height Adjustment Wrench (California Classic models only)
1x Hold Down and Intonation Adjustment Wrench (California Classic
models only)
1x Tremolo Bar (California Classic models only)
1x Electric Guitar User's Manual
PREPARATION FOR USE
Prior to first use, remove the plastic film from the pickups and other parts
of the guitar.
Next, tune the guitar. To help the guitar stay in tune, stretch the strings as
described in the STRING REPLACEMENT section.

6
SWITCH AND KNOBS
Each guitar has a switch to select which of the individual pickups or pickup
combinations will be used to alter the basic tone. Additionally, they each
have volume and tone adjustment knobs. Following are the switches and
knobs for each of the three electric guitar models. Note that the selected
pickups are depicted in a dark shade.

7
CHECKING YOUR GUITAR'S SETUP
Perform the following steps to check your guitar's setup. The guitar should
be tuned after each adjustment and before beginning the next step.
1. Replace the strings if desired. Refer to the STRING REPLACEMENT
section for details on how to change the strings.
2. Use a capo to fret all the strings at the 1st fret, then fret the 6th
string (low E) at the last fret. Use a feeler gauge to measure the
distance between the string and the top of the 8th fret. The gap
should be about 0.010" (0.25mm). If there is not enough gap, you
will need to increase the neck relief by loosening the truss rod. If
there is too large of a gap, you will need to reduce relief by
tightening the truss rod. See the NECK ADJUSTMENT section for
details on how to adjust the truss rod.
3. Use a ruler with markings every 1/64" or 0.5mm to check the
unfretted action (string height) for the 1st and 6th strings at both
the 1st and 12th frets. The amount of action is mostly a matter of
personal preference. If the action is too high, it will be difficult to
play, but if the action is too low, the strings will buzz against the
frets.
The ideal distance between the bottom of the 1st string (high E)
and the top of the 1st fret should be about 1/32" (0.8mm), while the
distance between the bottom of the 6th string (low E) and the top
of the first 1st fret should be about 1/64" (0.4mm).
The ideal distance between the bottom of the 1st string (high E)
and the top of the 12th fret is about 5/64" (2.0mm), while the
distance between the bottom of the 6th string (low E) and the top
of the 12th fret should be about 3/64" (1.2mm).
Refer to the BAR TAILPIECE , HARDTAIL BRIDGE , or WILKINSON
BRIDGE sections for details on how to adjust the string height for
each individual model.

8
4. Using a digital guitar tuner, check the tuning of each string when
unfretted and when fretted at the harmonic (12th fret). If the
tuning is different on any string, that string needs to have the
intonation adjusted.
Refer to the BAR TAILPIECE , HARDTAIL BRIDGE , or WILKINSON
BRIDGE sections for details on how to adjust the intonation for
each individual model.
STRING REPLACEMENT
Over time the strings will wear out, resulting in a dull and lifeless sound, or
even buzzing or inaccurate pitch. Replace the strings when they begin to
rust, become discolored, sound bad, or fail to hold tune. All of the strings
should be replaced as a set at the same time. Do not use strings that have
been bent, twisted, or otherwise damaged. Take care that the string does
not cross over itself. Replace the strings one at a time. Removing all strings
at once can cause stress on the neck or affect tremolo balance.
Feed the string through the
bridge, then wind the string
around the tuning machine
post two or three times from
above, using about 2-3 inches
of length.
New guitar strings will stretch and will easily lose tune during normal
playing, especially when doing bends. You can simply retune each time the
strings get out of tune or you can stretch the strings manually to get
through most of the stretch range before playing.
To do this, tune the guitar, then gently pull each string away from guitar
several times. Be careful not to pull too much, especially on the thinner
strings. Repeat this process of tuning and stretching several times until
pulling the strings does not change the tuning by any substantial amount.

9
NECK ADJUSTMENT (all models)
Caution! Improper truss rod adjustment can result in damage to your guitar,
including breaking the neck! Take great care when adjusting the truss rod
and make only minor adjustments. If you are unsure of any step, you should
have the truss rod adjusted by a professional luthier.
The neck is constantly bearing the tension of the strings, and its curvature
will be subtly affected not only by the state of tuning and the string gauge,
but also by changes in temperature and humidity. If you experience
problems such as string buzz or muted notes even after the action and
tuning are adjusted correctly, you should check and adjust the curvature of
the neck. Perform the following steps to check and adjust the curvature of
the neck.
1. Tune your guitar.
2. Use a capo to fret all strings at the 1st fret.
3. With the guitar in normal playing position, fret the 6th string (low
E) at the last fret, then use a feeler gauge to check the gap
between the bottom of the 6th string and the top of the 8th fret.
The gap should be about 0.010" (0.25mm).
If there is not enough gap, you will need to increase the neck
relief by loosening the truss rod by turning it counterclockwise
(towards the high E string).
If there is too large of a gap, you will need to reduce relief by
tightening the truss rod by turning it clockwise (towards the
low E string).
If the gap is correct, no adjustment is necessary.

10
4. If your guitar is a Route 66 model, use a #1 Phillips screwdriver to
remove the screws securing the truss rod cover to the headstock.
5. Using the included truss rod wrench, turn the truss rod no more
than 1/4 turn in the direction indicated in step 3 above.
6. Repeat steps 1-3 and 5-6 until no further adjustment is necessary.
BAR TAILPIECE (Route 66 models only)
Replace the strings by feeding the new string through the hole in the
tailpiece, then over the saddle.
Adjust the intonation by moving the saddle forward or backward using the
intonation adjustment screw and a flat head screwdriver.
Adjust the height by turning the screws at each end of the bridge using a
flat head screwdriver.
