Montigo L42DF ST Manual

L-Series See-Thru

Available at: Printed in Canada
P/N XB2102 091511
Ferndale, Washington
TF 1.800.789.6236
FX 1.866.300.0927
Langley, British Columbia
TF 1.800.378.3115
FX 1.604.607.6462
®
C US
Consult the owner’s manual for complete installation instructions and proper clearances to
combustible surfaces prior to installing fireplace.
All specifications, framing dimensions, product designs, materials and colors are subject to
change without notice. The actual flame pattern and color may vary slightly from the illustrations.
Diagrams and illustrations are not to scale.
Options & accessories may have associated surcharge.
Warranty: The manufacturer warrants this fireplace to be free from defects in materials and
workmanship at the time of manufacture. There is a limited 10 year warranty on the firebox; 5 year
limited warranty on the burner and 1 year limited warranty on the pilot burner assembly and fan
motors (if included). The valve carries a limited 1 year warranty unless otherwise specified in the
installation manual. Glass, plated/painted finishes and refractory lining are exempt.
Framing Dimensions
M N O P
L38DF-ST 40" 41" 23¾" 34½"
L42DF-ST 40" 45" 23¾" 36"
L52DF-ST 39" 60" 23¾" N/A
L42DF-ST
With Stainless Steel Surround shown
Fireplace BTU/H Input
Model# Natural Gas Liquid Propane
L38DF-ST 27,000 27,000
L42DF-ST 34,000 34,000
L52DF-ST 40,000 40,000
KBG
H
IJ
S
i
de
Vi
e
w
A
H
J
I
Top View
L
A
BC
D
E
F
Fr
o
n
t
Vi
e
w
A
H
KI
J
Top View
B
Side View
G
Features:
❏ Clean-Face design allows for brick or tile
installation over the fireplace frame
❏ Convertible using 5"/8" Top or Side vent on
on L38DF-ST & L42DF-ST
❏ L52DF-ST is 5"/8" Top Vent only
❏ Linear Contemporary burner with White, Silver,
Opaque Fire Stones‡
❏ Snap-Lock door system
❏ Hi/Lo control for adjusting flame level
❏ Millivolt control with Piezo spark ignition allows for
continuous operation, even during a power failure
❏ 100% fail-safe shut-off valve
Options:
❏ Various Linear Contemporary burner accessories‡
❏ Choose from 2 surrounds‡
❏ Digital Thermostat
❏ Various Remote Control options
❏ Safety door screen
❏ Various Fan Kits for L38DF-ST & L42DF-ST
❏ IPI Electronic Ignition with optional remote control for
flame modulation, thermostatic control, & battery backup
❏ Full stainless steel construction, approved for outdoor use
L-Series See-Thru Direct Vent ∙ Flush Face
Multi Sided Fireplace
‡ Go to www.montigo.com for colour images
Unit Dimensions
A B C D E F G H I J K L
L38DF-ST 37¾" 29½" 18" 35¼" 6¼" 5¼" 33¾" 24" 5" 8" 26¾" 7"
L42DF-ST 42" 30½" 19" 39½" 6¼" 5¼" 34¾" 24" 5" 8" 27¾" 7"
Unit Dimensions
A B C D E F G H I J K
L52DF-ST 52" 33¼" 21⅛" 47" 6⅞" 5¼" 23⅞" 58" 5" 8" 12"
A
BC
D
E
Fr
o
n
t
Vi
e
w
F
N
O
M
P
