Montigo C34-DV Owner's manual

■Check local codes
and read all
instructions prior to
installation.
■Leave this manual
with the owner.
Gas Fireplace
C34-DV
Installation
Operation &
Maintenance
What To Do If You Smell Gas:
 Do not try to light any appliance.
 Do not touch any electrical switch; do not use any phone in your building.
 Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
 If you cannot reach your gas supplier, call the fire department.
Warning:
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. efer to
this manual. For assistance or additional
information consult a qualified installer,
service agency or the gas supplier.
For Your Safety:
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.

Page 2
C34-DV Gas Fireplace
Part No. XG0117C
Introduction
Thank You for choosing a Montigo C-Series Firep ace.
About the C34 Fireplace:
The C34-DVinc udes a 20,000 BTU dua burner with embers and a
five piece ceramic fibre ogset. This mode is avai ab e in four versions.
C34DT-Top Vent, Mi ivo t Pi ot
C34DR-Rear Vent, Mi ivo t Pi ot
C34-DT-I-Top Vent, Intermittent Pi ot (HSI)
C34-DR-I-Rear Vent, Intermittent Pi ot (HSI)
The C34-DV is rated for Natura Gas at 20,000 BTU/H (7.33 Ki owatts)
Input or Propane at 20,000 BTU/H (7.33 Ki owatts) Input.
How to use this manual:
This manua covers a mode s and un ess otherwise specified, the
designation C34-DV refers to a mode s. Sections which are specific to a
particu ar mode are marked with a symbo , p us the
appropriate mode number.
Warranty and Installation Information:
The Montigo warranty wi be voided by, and Montigo disc aims any
responsibi ity for, the fo owing actions:
Modification of the firep ace and/or components inc uding Direct-Vent
assemb y or g ass doors.
Use of any component part not manufactured or approved by
Montigo in combination with this Montigo firep ace system.
Insta ation other than as instructed in this manua .
Consu t your oca Gas Inspection Branch on insta ation requirements for
factory-bui t gas firep aces. Insta ation & repairs shou d be done by a
qua ified contractor.
InstallationsinCanada must conform to the current CAN/CGAB-
149.1 and .2 Gas Insta ation Code and oca regu ations. If the optiona
air-circu ating fan kit is insta ed, it must be e ectrica y grounded in
accordance with CSAC22.1 Canadian E ectrica Code Part 1 and/or
Loca Codes.
InstallationsintheUSA must conform to oca codes, or in the
absence of oca codes to the Nationa Fue Gas Code, ANSIZ223.1-
1988. If the optiona air-circu ating fan is insta ed, it must be grounded in
accordance with oca codes or, in the absence of oca codes, with the
Nationa E ectrica Code, ANSI/NFPA70-1987.
Table Of Contents
Introduction ............................................................................ 2
Installation
Insta ing the Firep ace She ........................................... 3
Insta ing the Gas ine ....................................................... 4
The Remote Switch ........................................................ 4
Direct Vent Insta ation .................................................... 4
Genera Requirements ....................................... 4
Terminations ...................................................... 4
Top Vent Mode s with horizonta venting ............. 6
Top Vent Mode s with vertica venting ................. 8
Rear Vent Mode s .............................................. 9
Construction around the firep ace
Facing ............................................................. 11
Mante s and Surrounds.................................... 11
Wiring ....................................................................... 11
Removing and Insta ing the Door ................................. 12
Insta ing the Logset ...................................................... 13
Insta ing the Horizonta Trim ......................................... 13
Operation ........................................................................ 14 - 16
Maintenance ................................................................... 16 - 17
Warranty ................................................................................ 18
Appendix
A. Termination Locations .............................................. 19
CAUTIONS
Due to its high operating temperatures, the app iance shou d
be ocated out of traffic & away from furniture and draperies.
Chi dren and adu ts shou d be a erted to the hazards of
the high surface temperature, which cou d cause burns
or c othing ignition.
Young chi dren shou d be carefu y supervised when
they are in the same room as the app iance.
C othing or other f ammab e materia s shou d not be
p aced on or near the app iance.

Page 3
C34-DV Gas Fireplace
Part No. XG0117C
Installing The Fireplace Shell
The firep ace may be insta ed in any ocation that maintains proper
c earance to air conditioning ducts, e ectrica wiring and p umbing.
Safety, as we as efficiency of operation, must be considered when
se ecting the firep ace ocation. Try to se ect a ocation that does not
interfere with room traffic, has adequate venti ation, and offers an
accessib e pathway for Direct Vent insta ation. Refer to page 4 - Vent
Installationfor more information.
The firep ace dimensions are shown be ow:
Installation
When insta ing a she f over the top of the firep ace, the fo owing
guide ines must be adhered to: For Rear Vent mode s (C34-DR), the
minimum c earance from the top of the firep ace to a she f is 7". For Top
Vent mode s (C34-DT), the minimum c earance is 15". (Minimum1"
clearancemuststillbemaintainedaroundtheventpipes.)
Figure 4. Framing for shelves over the fireplace.
Top VentRear Vent
Figure 3. Corner framing dimensions.
Figure 2. Framing dimensions.
* When sheetrock is
not used behind the
firep ace, framing
depth may be
reduced to 13 3/4"
Framing
WARNING:
When this app iance is insta ed direct y on carpeting, ti e
or any combustib e materia other than wood f ooring, it
must be insta ed on a meta or wood pane extending the
fu width and depth of the app iance.
Top Vent
Front View Rear Vent
Clearances
These c earances app y to a dimensions excepttheframedopening,
where the c earance to combustib es is 0". The C34-DVc earances to
combustib e materia s are:
Top-RearVent* 7"
Top-TopVent 15"
Back 0"
Flue 1"
Sides 1"
Floor 0"
Mantle** 6"
* C earance from the top of the firep ace to a combustib e
cei ing within the firep ace enc osure.
** Refer to page 11.
Unprotected combustib e wa s which are perpendicu ar to the firep ace
opening, must not project beyond the shaded area shown in Figure 19b.
For protection against freezing temperatures, it is recommended that
outer wa s of the chase be insu ated with a vapour barrier. This wi
reduce the possibi ity of a co d-air convection current on the firep ace.
Figure 1. Fireplace dimensions.

Page 4
C34-DV Gas Fireplace
Part No. XG0117C
ent Installation
This section covers the insta ation of direct venting and terminations.
Installation Requirements
C34-DV firep aces are certified for use with Montigo Premium Series
(5"/ 8") venting components. The C34-DV TopVent may be used
with Standard Series (4"/7")components on vertica vent runs on y.
Minimum 1" c earance to combustib es required for vent pipes
Use ony certified Montigo vent components. (Use of other parts wi void the
Montigo warranty, and may impede the operation of the firep ace.)
A joints must be secured with a minimum of two screws per joint
Vent terminations must not be recessed in wa s or siding
Horizonta runs must be supported by a minimum of two supports
per horizonta run. A minimum of one screw on each side of
support is a so required
F ex vent sections may be stretched up to 50% of their tota ength
(eg. a 24" section may be stretched to 36")
Maximum horizonta run for a f ex section with no vertica rise is 3 feet.
F ex vent sections over 3 feet must fa within the imits set by the
venting graph and must have a minimum vertica rise of 3 inches
per foot of f ex.
So id vent sections may be cut ess than ha f way from the tapered end
Venting components can be used in any combination of so id/rigid
pipe or f ex pipe and in any orientation (Ma e connectors can face
in any direction)
Vent Terminations
Selecting A Termination Location
Choosing your vent termination ocation wi he p to determine whether
you need to use a top vent or rear vent firep ace. Figure 6, be ow,
shows typica firep ace ocations and the venting options they provide.
For a more detai ed diagram of a owed termination ocations, see
AppendixA.
Cautions:Cautions:
Cautions:Cautions:
Cautions:
Installing The Gas Line
The gas ine must be insta ed before finishing the C34-DV Firep ace.
NaturalGas requires a minimum in et gas supp y pressure of 5.5"
W.C. & a manifo d pressure of 3.5" W.C. PropaneGas requires a
minimum in et gas supp y pressure of 11" W.C. & a manifo d pressure of
10" W.C. Provision must a so be made for a 1/8" N.P.T. p ugged tapping
and be accessib e for test gauge connection immediate y upstream of the
gas supp y contro s to the app iance. The firep ace gas connection and
the main operating gas va ve is ocated behind the removab e brass trim
at the bottom of the unit and need on y be attached to the gas ine with an
approved fitting, as required by the applicable installation codes.
Installation
Figure 6. Fireplace locations and vent terminations.
Note: After gas ine is connected, each appliance connection,
valve and valve train must be checked whi e under
norma operating pressure with either a iquid so ution, or
eak detection device, to ocate any source of eak. Tighten
any areas where bubb ing appears or eak is detected unti
bubb ing stops comp ete y or eak is no onger detected.
DO NOT use a flame of any kind to test for leaks.
Installing The Remote Switch
The C34-DV's gas va ve, ocated behind the ower brass trim, may be
connected to a wa switch. The va ve generates its own power on a
millivoltcircuit. Use only low voltage wire, and DO NOT connect
any externa power to it.
Refer to Figure 27 for wiring requirements.
Note: The switch ocation must not exceed 30' from the firep ace.
Figure 5. Gas line access.
The app iance and its individua shutoff va ve must be disconnected from
the gas supp y piping system during any pressure testing of that system
at test pressures in excess of 1/2 psig (3.5 kPa).
The app iance must be iso ated from the gas supp y piping system by
c osing its individua manua shutoff va ve during any pressure testing of
the gas supp y piping system at test pressures equa to or ess than 1/2
psig (3.5 kPa).
Vent terminations can be very hot. If the termination
is ess than 7 feet above a pub ic wa kway, it shou d
be fitted with a certified Montigo Heat Guard. (Part no.
PTKOG)
Do not obstruct, or attempt to concea , the vent
termination. These actions wi affect the operation
of the firep ace, and may be hazardous.
In heavy snow areas, take extra care to prevent snow
bui dup from obstructing the vent termination.

Page 5
C34-DV Gas Fireplace
Part No. XG0117C
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Frame the termination opening to 12" x 12".
2. Fasten the termination to the studs using a minimum of 4 screws.
11
11
1. Frame the termination opening to 11" x 11".
2. Fasten the termination to the studs using a minimum of 4 screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Frame the termination opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs using a
minimum of 4 screws.
3. Insert the termination into the MOSR frame as shown here, and
attach by screwing through the four pi ot ho es in the termination.
MSR
PTO-3
PTO-3F
PTO-3
PTKOG
1. Ensure that the two longmounting brackets are facing the bottom of
the termination. (See inset). This wi provide more heat protection
at the top of the termination, where temperatures are highest.
2. Attach to the facep ate of the termination using four sheet meta
screws.
Installing Heat Guards over Terminations
Installation

Page 6
C34-DV Gas Fireplace
Part No. XG0117C
Installation
Top ent enting Runs
For the C34-DV TopVent, there are two types of insta ations: A)
Through-The-Wa Insta ations and B) Vertica (Through-The-Roof)
Insta ations.
A) Through-The-Wall Installations
Before you insta any venting, you must determine whether the venting
run wi be acceptab e. Unacceptab e venting can affect the firep ace's
combustion.
The Venting Graph
Measure the vertica height from the firep ace hearth to the centre of the
termination and the horizonta run from the from the firep ace f ue co ar to
the wa f ange of the termination. P ot on the Venting Graph (Fig. 7) with
an 'X'.
If the 'X' fa s on or above the top boundary of the shaded area, the
insta ation is acceptab e.
Example A: (Acceptable Installation)
If the vertica dimension from the hearth is 84" and the horizonta
run to the wa f ange of the vent termination is 36", this wou d be
an acceptab e insta ation.
Example B: (Acceptable Installation)
If the vertica dimension from the hearth is 90" and the horizonta
run to the wa f ange of the vent termination is 120", this wou d be
an acceptab e insta ation.
Example C: (Unacceptable Installation)
If the vertica dimension from the f oor of the firep ace is 72" and
the horizonta run to the wa f ange of the vent termination is 84",
this would NOT be an acceptable installation.
Figure 7. Venting Graph
Figure 8. Heat Shield. Install by sliding over the vent pipe where it
passes through combustible construction.
Heat Shields
Due to high f ue temperatures, heat shie ds are required on a C34-DV
insta ations (except those with vertica
terminations) at the point where the
venting connects to the termination. With
the heat shie d, vent c earances can be
maintained at 1".
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Available Top Vent Components
The fo owing venting components are avai ab e for the C34-DV Top
Vent:
A - Termination PTO-3 (3" ength)
PTO-3F (3" ength)
B - Stucco Kits MSR (stucco frame)
MOSR (stucco can)
BSR (brick can)
C - F ex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - Rigid sections PEXT-1 (12" m/f section)
PEXT-2 (24" m/f section)
PEXT-3 (36" m/f section)
PEXT-4 (48" m/f section)
PEXT-6 (72" m/f section)
E - E bows PEL-90MM (m/m 90° e bow)
PEL-90FF (f/f 90° e bow)
PEL-90FM (f/m 90° e bow)
NOTES: A dimension engths for vertica or horizonta runs are
measured from center of the vent pipe.
Venting runs must fa within the imits set by the venting
graph (see Figure 7).

Page 7
C34-DV Gas Fireplace
Part No. XG0117C
Installation
Termination
Example 1:
For our shortest venting configuration use components A and F (see
Figure 9a).
Figure 9a. ypical op Vent installation. If the 90° elbow is
installed directly on the fireplace, the height to the
center of the termination is 43½".
Horizontal Venting
Figure 9b. ypical op Vent installation. he solid sections can be
used in various combinations to obtain the desired vent
run. he vent run must fall within the limits set by the
venting graph.
90° Elbow
PEXT Section
Example2:
Rigid sections and an e bow used in conjunction with 3 ft. f ex section
(PFL-3) wi , when extended in a five foot chase, a ow for a maximum
horizonta run of twe ve and one-ha f feet from the centre of the firep ace
to outside wa and a minimum of 7'6" when retracted in opposite direction
(see Figure 10 and 11).
"C" f ex sections and "D" rigid sections may be used in conjunction with
one another to obtain different possib e horizonta ength insta ations.
NOTE:F ex section with no vertica rise must not exceed maximum
horizonta ength of 3 feet (seeFigure12). F ex runs over 3 feet must fa
within the imits set by the venting graph, and must have a minimum
vertica rise of 3" per foot of f ex.
Figure 10. Extended Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Figure 11. Retracted Installation using a combination of solid and
flex venting. Use the vent graph to determine your
allowable run, then select appropriate components.
Figure12. Horizontal flex installation with no vertical rise.
Hearth
Termination
Exterior
Wall
3' max.
Flex Section
Hearth
Flex Section Termination
Exterior
Wall
Solid Sections
Hearth
Flex Section
Solid Sections Termination
Exterior
Wall
150" max.
30" max.
RigidSection
PEL-90F/F E bow
RigidSection

Page 8
C34-DV Gas Fireplace
Part No. XG0117C
Storm collar
Support ring
MEXT
Solid Section
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support plate
Firestop
Firestop
2' min.
MXT-10
Adaptor
MEXT
Flue
Collar
2' min.
Storm collar
Support ring
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support plate
Firestop
Installation
B. Vertical (Through-The-Roof) Installations
5/8" with option for 4/7"
■Vertica rise >12' can be reduced
■Vertica Terminations must be insta ed:
•minimum 2' (two feet) above the highest point where
vent passes through the roof.
• minimum 6' (six feet) from a mechanica air in et
• minimum 18" (1 1/2 feet) from a parapet wa .
■Maximum vent height is 30 feet above firep ace.
Note: F ame characteristics wi change if the maximum vent height is
used.
■Minimum c earances 1" from vent to a combustib e materia s must be
maintained.
Figure13.a Straight, vertical venting using required adaptor.
■A maximum of two offsets (eachoffsethastwo90°bends) may be
made and sha not exceed tota ength of 25% of the vertica vent height,
when measured center to center of piping.
Examp e: Typica vent insta ation.
20' vertica vent
2 - 2' offsets required
25% of 20' = 5' max. offset a owed
This venting configuration meets requirements.
Figure14a. Vertical venting with 1 offset (1 offset= two 90° bends).
30'max.
30'max.
Rigid Section
A
A.Male/Female
B.Female/Female
C.Male Flue Collar
B
C
Figure 13b. Reducing Vertical Vent from 5/8" to 4/7".
Vent Restrictors
When venting vertica y, Vent Restrictors may be added to enhance the
burn characteristics of the firep ace.
Part Size 5"/8" Venting 4"/7" Venting
A - Termination n/a PVTK-1 MVTK-1
B - Flex sections 12" length PFL-1 MFL-1
24" length PFL-2 MFL-2
36" length PFL-3 MFL-3
48" length PFL-4 MFL-4
C - Solid sections 12" length PEXT-1 MEXT-1
24" length PEXT-2 MEXT-2
36" length PEXT-3 MEXT-3
48" length PEXT-4 MEXT-4
D - Support Ring
& Plate PSPXT-8 MSPXT-7
E - Firestop PS-8 FS-7
F - Roof Flashing (1/12-7/12 pt.) PRF-7 MRF-7
(7/12-12/12 pt.) PRF-12 MRF-12
G - Adaptor/ (5"/8" to 4"/7") PVA5487
Vent Reducer

Page 9
C34-DV Gas Fireplace
Part No. XG0117C
Installation
2. 45° Corner Installation.
Attach an PEL-45 (45° e bow) direct y onto the f ue co ar. Cut the
PXT-20 to suit, and attach it to the PEL-45. S ide the firep ace into
position and attach to the termination.
Heat Shields
Due to high f ue temperatures, heat shie ds are required on a C34-DV
insta ations (except those with vertica terminations) at the point where
the venting connects to the termination. With the heat shie d, vent
c earances can be maintained at 1". *Heat Shie ds are inc uded
See Figure 8.
1. Straight Installation.
The height from the hearth to the center of the termination is 28
3/8". C34-DV Rear Vent versions are supp ied with a 20" extension
pipe (PXT-20) with fema e/fema e connections. For shorter
insta ations, cut the PXT-20 to the desired ength.
For extended insta ations, use the PXT-20 section as supp ied for a
20" vent run.
Flue Collar
Heat Shield
EXT-18
Termination
Figure 15. Extended installation.
Heat Shield
EXT-18
Termination
EEL-45
Elbow
FlueCollar
Figure 16. Corner installation.
3. Corner Installation — 45° or less.
Use an PTO-3 termination and an PFL-1 or PFL-2 (12" or 24"
compressed ength) and a frame, if appropriate.F ex may be turned
to obtain desired degree of ang e required but must not exceed 45°.
Figure 17. Flex installation.
Heat Shield
Termination
Flex
Section
Flue Collar
PXT-20
PXT-20(cut to length)
PEL-45
Figure14b. Vertical venting with 2 offsets (1 offset= two 90° bends).
2' min.
2'
Storm collar
Roof flashing
30' max.
* Minimum 1" clearance to all combustibles
Support straps or
support plate & ring
Firestop
Firestop
Firestop
Support plate
& ring
30'max.
Rear ent enting Runs
The C34-DVRearVenthas three possib e insta ations which do not
require vertica ift:
Note: For Rear Vent mode s, maximum horizonta run with no
vertica ift must never exceed 20".

Page 10
C34-DV Gas Fireplace
Part No. XG0117C
Installation
B. Multi-Elbow Installations
For more diffiicu t insta ation situations, the C34-DV Rear Vent may be
insta ed with two — 90° e bows and up to 15' of horizonta run. If using
this insta ation option, you must adhere to the fo owing guide ines:
■the first 90° e bow must be p aced direct y on the f ue co ar
■you must have a minimum vertica ift of 50" (measured from the
hearth)
■your vent run must fa within the imits set by Figure 18a
Before you insta any venting, you must determine whether the venting
run wi be acceptab e. Unacceptab e venting can affect the firep ace's
combustion.
The Venting Graph
Measure the vertica height from the firep ace hearth to the centre of the
termination and the horizonta run from the from the firep ace f ue co ar to
the wa f ange of the termination. P ot on the Venting Graph (Fig. 18a)
with an 'X'.
If the 'X' fa s on or above the top boundary of the shaded area, the
insta ation is acceptab e.
Example A: (Acceptable Installation)
If the vertica dimension from the hearth is 84" and the horizonta
run to the wa f ange of the vent termination is 36", this wou d be an
acceptab e insta ation.
Example B: (Acceptable Installation)
If the vertica dimension from the hearth is 90" and the horizonta
run to the wa f ange of the vent termination is 126", this wou d be
an acceptab e insta ation.
Example C: (Unacceptable Installation)
If the vertica dimension from the f oor of the firep ace is 78" and the
horizonta run to the wa f ange of the vent termination is 108", this
would NOT be an acceptable installation.
Figure 18a. C34-DV Rear Vent Venting Graph
012 24 36 48 60 72 84 96 108 132120 144 156 168 180
Horizontal Run (in.)
Hearth
0
12
24
36
48
60
72
84
96
108
Installation Of Rear ent D
C34-DV Rear Vent versions are supp ied with an PXT-20 (fema e/
fema e) section. In addition, the fo owing venting components are
avai ab e for Rear Vent installations:
A - Termination PTO-3 (3" ength)
PTO-3F (3" ength)
B - Stucco Kits MSR (stucco frame)
BSR-4 (4" brick frame)
BSR-6 (6" brick frame)
MOSR (stucco can)
C - F ex sections PFL-1 (12" section)
PFL-2 (24" section)
PFL-3 (36" section)
PFL-4 (48" section)
D - So id sections PEXT-1 (12" section)
PEXT-2 (24" section)
PEXT-3 (36" section)
PEXT-4 (48" section)
E - 90 degree e bow PEL-90MM (m/m 90° e bow)
PEL-90FF (f/f 90° e bow)
PEL-90FM (f/m 90° e bow)
PEL-45FM (f/m 45° e bow)
Figure 18b. Multi-elbow installation. Distance 'H' must be a
minumum of 50". he vent run must comply with figure
18a.
NOTES: A dimension engths for vertica or horizonta runs are
measured from center of the vent pipe.
Venting runs must fa within the imits set by the venting
graph (see Figure 18a).
8"
H
L
18"

Page 11
C34-DV Gas Fireplace
Part No. XG0117C
Finishing Around the Fireplace
Combustib e mante s and mou dings may be safe y insta ed over the top
and on the front of the firep ace provided that they do not project beyond
shaded area shown in Figure 19a. Side wa c earances are 3".
Combustib e surrounds may be insta ed with 3" c earance to the side of
the firep ace as shown in Figure19b.
Fireplace Facing
When se ecting the finish materia for your firep ace, it is important to
remember the fo owing: MUSTNOTBEOBSTRUCTEDINANYWAY
- to do so restricts the air supply for the control compartments
and heat exchanger it also prevents access for servicing
controls.
The face of the firep ace may be painted to match the room decor,
provided you use a heat-resistant paint. Decorative facing must not
extend past the firep ace opening at a , because it wi interfere with the
access to retainers for remova of g ass door.
Installation
Figure 19a. Combustible mantles and facings.
Mantels & Surrounds
NOTE: Nationa Canadian Gas Association mante test requirements are
for fire hazard prevention to combustib e materia s.
New techno ogy, to meet consumer and government demands for the
wise use of energy, has prompted us to manufacture many mode s of
firep aces which are hot, fue and energy efficient.
P ease be aware; temperatures over the mante wi rise above norma
room temperature and wa s above firep ace may be hot to touch.
We recommend carefu consideration be given to the effects of e evated
mante temperatures which may be in excess of product design, for
examp e: cand es, p astic or pictures. This can cause me ting, deforma-
tion, disco oration or premature fai ure of T.V. and radio components.
Painting:
Specia care is recommended by the Master Painters and Decorators
Association, when painting the firep ace surrounds, to se ect and app y a
qua ity Alkydsealer prior to the app ying of atex paints. This is to
prevent eaching of water from evaporation and causing a brownish
staining effect to paint over coats.
Sheetrock/
Drywall
Header
3
4
5
°
Figure 19b. Combustible surrounds.
Wiring
Gas Control and Pilot Wiring C34-DV-I
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector Fuse
Limit
Switch Wall
Switch
Fan Plug
Receptacle
Junction Box
Junction Box Cover
White
Black
Green
40 VA
Transformer
115VAC
24VAC
Grnd Screw
Figure 20. Wiring for the C34-DV-I with Honeywell gas control and
pilot.

Page 12
C34-DV Gas Fireplace
Part No. XG0117C
Removing and Installing
the Door
Removingthe Door:
Remove the trim (as described on the next page) to access the door
atches. Open the atches by pu ing Part A upwards and towards you to
disengage Part B from the door. Lift Part B c ear of the door. Repeat for
a three atches. Be sure to ho d the door carefu y so it does not fa .
(Seefigure 23a.)
Installation
Once the three atches are unhinged, ti t the top of the door forward and
ift it out of the s ots.Seefigures23band23c.
Figure 23a. Operating the door latches.
Figure21. Wiring for optional air circulating fan kit.
G
L1-WH
L2-BLK
Quick Connect
plug to motor
Wiring for the optional Fan Kit
A C34-DV firep aces may be equipped with optiona fan kits (Part no.
RFK1001, RFK1003, RFK1006 or RFK1007)for circu ating heat into the
iving space.
InstallationsinCanada which emp oy the fans must be e ectrica y
grounded in accordance with CSAC22.1 Canadian E ectrica Code Part
1 and/or Loca Codes.
Installationsin theUSA which emp oy the fans must be grounded in
accordance with oca codes or, in the absence of oca codes, with the
Nationa E ectrica Code, ANSI/NFPA70-1987.
For more information see the FanKitInstallationGuide inc uded with
the fan kit.
NOTE: If any of the origina wire supp ied with the app iance is rep aced, it
must be rep aced with the same type, or its equiva ent.
Figure22.Wiring schematic for optional fan kit.
115/1/60 Supply
G L1 L2
Figure 23b. Removing the door.

Page 13
C34-DV Gas Fireplace
Part No. XG0117C
Installation
Cautions:
■If ogs are not p aced proper y, excessive sooting
wi resu t.
■The surface of the ogs wi crack due to the heat
from the f ames. This is a norma occurance.
Embers
Log 'D' Log 'E'
F ame Shaper
Log 'A'
Log 'C' Log 'B'
Figure 23c. Removing the door.
Re-installing the door:
To re-insta the door, ti t the top edge towards you and ine up the tabs of
the bottom of the door with the s ots on the firep ace. P ace the tabs into
the s ots, and ti t the top of the door back towards the firep ace as far as it
wi go. C ose the atches by hooking Part B onto the groove at the top of
the door and pushing Part A down comp ete y.
Figure25. Installing the horizontal trim pieces.
Installing the Trim & Baffle
The firep ace is shipped with 6 horizonta trim pieces (3 upper and 3
ower), which must be fie d-insta ed.
Insta the trim by p acing the top edge of the trim over to the retainer c ips
on either side of the firep ace. Push the bottom edge firm y inwards and
the trim wi snap on. (Seefigure25) Insta the upper trim pieces so that
the baff e is resting between the top and midd e piece, as shown be ow.
The trim piece with the Montigo Emb em shou d be insta ed on the ower
midd e c ips with the emb em on the right side.
Installing the Log Set
Installing the Logs:
The C34-DVis supp ied with five ceramic fibre ogs. Unpack the ogs and
hand e them very carefu y.
1. Remove the door cover and the g ass door.
2. P ace the Back og onto the back og rest as shown be ow in figure
24a. The og has ip on the bottom which fits into the sot on the og rest.
3. P ace the Front og onto the front og rest as shown in figure 24a.
Center the og from side to side, and push it against the back of
the og rest. Carefu y push the og onto the meta spikes on the og rest.
4. P ace the top ogs in position as shown in figure 24b, p ace the
centre og down first, then the right and eft ogs.
5. Start the firep ace. If the f ame appears satisfactory, rep ace the
g ass door and door cover.
Figure 24a.Positioning for the front and back logs.
Figure 24b.Proper log placement.

Page 14
C34-DV Gas Fireplace
Part No. XG0117C
WARNING: If you do not follow these instructions exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
■If you cannot reach your gas supp ier, ca the Fire
Department.
C. Use on y your hand to push in or turn the gas contro knob.
Never use too s. If the knob wi not push in or turn by
hand, don't try to repair it, ca a qua ified service techni-
cian. Force or attempt to repair may resu t in a fire or
exp osion.
D. Do not use this app iance if any part has been under water.
Immediate y ca a qua ified service technician to inspect
the app iance and to rep ace any part of the contro system,
and any gas contro which has been under water.
A. This app iance has a pi ot which must be ighted by hand.
When ighting the pi ot, fo ow these instructions exact y.
B. BEFORE LIGHTING sme a around the app iance area
for gas. Be sure to sme next to the f oor because some
gas is heavier than air and wi sett e on the f oor.
What To Do If You Smell Gas:
■Do not try to ight any app iance.
■Do not touch any e ectrica switch; do not use any
phone in your bui ding.
■Immediate y ca your gas supp ier from a neighbour's
phone. Fo ow the gas supp ier's instructions.
To Turn Off Gas To Appliance:
Operation - Model C34-D
3. Push in gas contro knob s ight y and turn c ockwise
to "Off". Do not force.
4. F ip up the ower trim.
1. Turn off remote switch.
2. F ip down the ower trim.
1. STOP! Read the safety information above on this abe .
2. F ip down the ower trims.
3. Push in gas contro knob and turn c ockwise to
"OFF."
4. Wait five (5) minutes to c ear out any gas. Sme for gas,
inc uding near the f oor. If you then sme gas, STOP!
Fo ow "B" in the safety information above on this abe . If
you don't sme gas, go to the next step.
5. Locate pi ot burner (See illustration at right.) and fo ow
steps be ow.
6. Turn knob on gas contro counterc ockwise to
"PILOT."
7. Push in gas contro knob comp ete y and ho d. Light with
Piezo Igniter button. Continue to ho d the contro knob in for
about (1) minute after the pi ot is it. Re ease the knob and it
wi pop back up. Pi ot shou d remain it. If it goes out repeat
steps 3 through 8.
■If knob does not pop up when re eased. Stop and
immediate y ca your service
technician or gas supp ier.
■If the pi ot wi not stay it after
severa tries, turn the gas contro
knob to "OFF" and ca your service
technician or gas supp ier.
8. Push in gas contro knob and turn counterc ockwise
to "ON."
9. F ip up the ower trim.
10.Turn on remote switch to ignite fire.
Lighting Instructions:
C34-DV
with Continuous Pilot
For Your Safety - READ BEFORE LIGHTING:
NOTE: Gas contro knob cannot be turned from
"PILOT" to "OFF" uness knob is pushed
in s ighty. Do not force.
Hi/Lo control knob
Gas control knob
(Shown in “Off” position)

Page 15
C34-DV Gas Fireplace
Part No. XG0117C
For Your Safety - READ BEFORE LIGHTING:
To Turn Off Gas To Appliance:
Lighting Instructions:
■If you cannot reach your gas supp ier, ca the Fire
Department.
C. Use on y your hand to push in or turn the gas contro knob.
Never use too s. If the knob wi not push in or turn by
hand, don't try to repair it, ca a qua ified service techni-
cian. Force or attempt to repair may resu t in a fire or
exp osion.
D. Do not use this app iance if any part has been under
water. Immediate y ca a qua ified service technician to
inspect the app iance and to rep ace any part of the contro
system, and any gas contro which has been under water.
A. This app iance is equipped with an ignition system that
ights the pi ot burner automatica y. Do not attempt to
light the pilot by hand.
B. BEFORE LIGHTING sme a around the app iance area
for gas. Be sure to sme next to the f oor because some
gas is heavier than air and wi sett e on the f oor.
What To Do If You Smell Gas:
■Do not try to ight any app iance.
■Do not touch any e ectrica switch; do not use any
phone in your bui ding.
■Immediate y ca your gas supp ier from a neighbour's
phone. Fo ow the gas supp ier's instructions.
1. Turn off remote switch.
2. F ip down the ower trim.
3. Turn the switch on the gas contro to "Off".
4. F ip up the trim.
1. STOP! Read the safety information above on this abe .
2. F ip down the ower trims.
3. Turn switch on the gas contro to OFF".
4. Wait 5 minutes to c ear out any gas. If you sme gas,
STOP! Fo ow "B" in the safety information above on this
abe . If you don't sme gas, go to the next step.
5. Turn switch on the gas contro to "ON". NOTE: This unit is
equipped with an ignition system that ights the pi ot burner
automatica y. Do not attempt to light the pilot by hand.
6. Turn on wa switch.
7. F ip up the ower trim.
8. If the firep ace does not operate, fo ow the instructions "To
Turn Off Gas To App iance" and ca your service techni-
cian or gas supp ier.
with Honeywell Electronic Ignition
WARNING: If you do not follow these instructions exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Operation - Model C34-D -I
C34-DV-I
Gas
Inlet
Gas Control Switch
Shown in "On" Position

Page 16
C34-DV Gas Fireplace
Part No. XG0117C
Maintenance
WARNING:
Do not attempt to c ean g ass when hot.
Do not c ean g ass with abrasive materia s as any
g ass etching may cause premature g ass fai ure.
CAUTIONS
Firep ace gas contro must be in the “OFF” position and
pi ot and main burners extinguished when c eaning
app iance with a vacuum.
Doors and ogs can get very hot. Hand e on y when coo .
General
Have the firep ace insta ation inspected year y, inc uding a visua
check of the vent system, the burner and the pi ot f ame. For your
convenience a 1/8" manifo d pressure tap is supp ied on the gas
va ve for a test gauge connection. See Figure 27.
For NaturalGas this app iance requires a minimum in et pressure of
5.5" W.C. and a manifo d pressure of 3.5" W.C.
For PropaneGasthis app iance requires a minimum in et pressure
of 11" W.C. and a manifo d pressure of 10" W.C.
A ways keep the firep ace area c ear and free of combustib e
materia s, as we as gaso ine and other f ammab e vapours and
iquids.
Do not use this app iance if anyparthasbeenunderwater.
Immediate y ca a qua ified service technician to inspect the app iance
and to rep ace any part of the contro system and any gas contro
which has been under water.
Operation
Lighting Instructions
See pages 14 and 15.
Burner Adjustment
The C34-DV is equipped with an adjustab e burner, a owing you to
raise or ower the f ames. To adjust the f ames, ocate the b ack knob
marked 'Hi-Lo', in the centre of the gas contro va ve (See Figure 26).
The front burners are not adjustab e.
■To raise the f ame height, turn the b ack knob ( ocated behind the
ower trim) counterclockwise.
■To ower the f ame height, turn clockwise.
Figure 26. 'Hi-Lo' Adjustment on the C34-DV's gas valve.
Cleaning
When the firep ace is first activated, there may be some smoking and a
visib e fi m may be eft on the g ass. This is a norma condition, and is the
resu t of burning of protective coatings on new meta .
G ass must be c eaned periodica y to remove any fi m (which is a
norma biproduct of combustion) which may be visib e. Fi m can
easi y be removed by removing the door, as shown on page 12-13.
Hand e the door carefu y, and c ean it with non-abrasive g ass
c eaners. One of the most effective products is Ke Kem.
Si icone sea s on inner door during initia firing wi "off gas", eaving a
visua deposit of a white substance on combustion chamber wa s.
This can easi y be removed using norma househo d products.
Use a vacuum c eaner or whisk broom to keep the contro
compartment, burner, and firebox free from dust and int.
Logs may be c eaned periodica y with a vacuum to remove soot or
other contaminates.
Note: C34-DV-Imodels(electronic ignition)donot
featurehi/lo adjustment.
Hi/Lo control knob
Gas control knob
(Shown in “Off”position)
Gas contro knob shown in "Off" position)
Hi/Lo contro knob

Page 17
C34-DV Gas Fireplace
Part No. XG0117C
Maintenance
Gas Control alve
Pilot Burner Adjustment
1. Locate Pi ot Adjustment Screw. (Seefigure27.)
2. Adjust pi ot screw to provide proper y sized f ame as shown in
figure 28).
3. After insta ing or servicing, eak test with a soap so ution with main
burner on. Coat pipe and tubing joints, gasket etc. with soap so ution.
Bubb es indicate eaks. Tighten any areas where the bubb es
appear unti the bubb ing stops comp ete y.
Figure 28. Pilot Burner
Troubleshooting
The fo owing is a troub eshooting chart of possib e prob ems:
PROBLEM CORRECTIVEACTION
Noisy Pi ot F ame Locate pi ot adjustement screw on
gas contro va ve. F ame is decreased by
turning adjustment screw c ockwise.
Pi ot won’t ignite Disconnect remote wires and try to ight
pi ot. If pi ot now works, remote
connections are fau ty. Check wiring
diagram figure27.
Main burner wi 1. Check wiring (seefigure27).
not ight 2. Check wa switch for proper
connection.
C34-DV
Troubleshooting
If your firep ace sti does not operate correct y, consu t your dea er or
the manufacturer.
All service and repairs should be performed by a qualified
agency.
A spare parts, optiona fans, and optiona trim finishes are avai ab e from
your oca dea er or the manufacturer.
HONEYWELL SV 9500 /SV9600
Troubleshooting Sequence
NOTE: Before Troubleshooting, Familiarize Yourself With
The Startup And Checkout Procedure.
· Turn Gas Supply off
· Set thermostat to
call for heat
SV9500/SV9600
is powered
(24 VAC nominal)
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
NO
NO
NO
START
Igniter warms up
and glows red.
Pilot Valve opens.
Turn gas on.
Pilot Burner lights?
Main Valve opens?
SYSTEM OK
Unplug Pilot Burner Cable,
Measure Voltage at
SV9500/SV9600 HSI
Terminals (24 VAC
Nominal, See INSET)
eplace Igniter/
Flame od Assembly.
eplace Igniter/
Flame od Assembly.
eplace SV9500/SV9600
Measure Voltage to SV9500
/SV9600. Voltage must
be at least 19.5 VAC
Discard old Igniter/
Flame od Assembly.
eplace Igniter/Flame
od Assembly and retain.
estart Troubleshooting
Sequence. Does main
valve open?
eplace
SV9500/
SV9600
Check
Transformer
Line Volt
Supply
eplace
SV9500/
SV9600.
Save old
Igniter/Flame
od Assembly
for service.
INSET
HSI
Terminals
CHECK:
· Line voltage power
· Low voltage transformer
· Limit Controller
· Thermostat
· Wiring
· Air proving switch on
combustion air blower system
· Vent damper (if used) is open
and end switch made
C34-DV-I
TH-TP
TP
TH
On/Off Switch
Power Generator
Figure27. Honeywell gas valve.

Page 18
C34-DV Gas Fireplace
Part No. XG0117C
The WarrantyThe Warranty
The WarrantyThe Warranty
The Warranty
The Companies warrants the Montigo Gas App iance to be free from defects in materia s and workmanship at the time of manufacture. On the Montigo, there is a ten-
year warranty on the firebox and its components, a five-year warranty on the main burner and pi ot burner, and a one-year warranty on the gas contro va ve and fibre ogs.
G ass, p ated/painted finishes, and refractory ining are exempt.
Remedy And Exclusions
The coverage of this Warranty is imited to a components of the Gas App iance manufactured by The Companies.
This Warranty on y covers Montigo Gas App iances insta ed in the United States or Canada.
If the components of the Gas App iance covered by this Warranty are found to be defective within the time frame stated (see The Companies right of investigation out ined
be ow). The Companies wi , at its option, rep ace or repair defective components of the Gas App iance manufactured by The Companies at no charge, and wi a so pay
for reasonab e abour costs incurred in rep acing or repairing components. If repair or rep acement is not commercia y practica , The Companies wi , at its option, refund
the purchase price of the Montigo Gas App iance.
This Warranty covers on y parts and abour as provided above. In no case sha The Companies be responsib e for materia s, components, or construction which are not
manufactured or supp ied by The Companies, or for the abour necessary to insta , repair or remove such materia s, components or construction. A rep acement or repair
components wi be shipped F.O.B. the nearest The Companies factory.
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The WarrantyQualifications To The Warranty
Qualifications To The Warranty
The Gas App iance Warranty out ined above is further subject to the fo owing qua ifications:
(1) The Gas App iance must be insta ed in accordance with The Companies insta ation instructions and oca bui ding codes. The Warranty on this Montigo Gas App iance
covers on y the component parts manufactured by The Companies. The use of components manufactured by others with this Montigo Gas App iance cou d create
serious safety hazards, may resu t in the denia of certification by recognized nationa safety agencies, and cou d be in vio ation of oca bui ding codes. This warranty
does not cover any damages occurring from the use of any components not manufactured or supp ied by The Companies
(2) The Montigo Gas App iance must be subjected to norma use. The Gas App iances are designed to burn gas on y. Burning conventiona firep ace fue s such as wood,
coa or any other so id fue wi cause damage to the Gas App iance, wi produce excessive temperatures and wi resu t in a fire hazard.
Limitations On LiabilityLimitations On Liability
Limitations On LiabilityLimitations On Liability
Limitations On Liability
It is express y agreed and understood that The Companies so e ob igation, and purchaser's exc usive remedy under this Warranty, under any other warranty, expressed
or imp ied, or in contract, tort or otherwise, sha be imited to rep acement, repair, or refund, as specified above.
In no event sha The Companies be responsib e for any incidenta or consequentia damages caused by defects in its products, whether such damage occurs or is discovered
before or after rep acement or repair, and whether or not such damage is caused by The Companies neg igence. Some states do not a ow the exc usion or imitation of
incidenta or consequentia damages, so the above imitation or exc usion may not app y to you. The duration of any imp ied warranty with respect to this Montigo Gas App iance
is imited to the duration of the foregoing warranty. Some states do not a ow imitation on how ong an imp ied warranty asts, so the above may not app y to you.
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against WarrantyInvestigation Of Claims Against Warranty
Investigation Of Claims Against Warranty
The Companies reserves the right to investigate any and a c aims against this Warranty and to decide upon method of sett ement.
The Companies Are Not Responsib e For Work Done Without Written Consent
The Companies sha in no event be responsib e for any warranty work done without first obtaining The Companies written consent.
Dea ers Have No Authority To A ter This Warranty
The Companies emp oyees and dea ers have no authority to make any warranties nor to authorize any remedies in addition to or inconsistent with those stated above.
How THow T
How THow T
How To Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Wo Register A Claim Against W
o Register A Claim Against Warrantyarranty
arrantyarranty
arranty
In order for any c aim under this Warranty to be va id, The Companies must be notified of the c aimed defect in writing or by te ephone, as soon as reasonab y possib e
after the defect is discovered. C aims against this Warranty in writing shou d inc ude the date of insta ation, and a description of the defect.
Other RightsOther Rights
Other RightsOther Rights
Other Rights
This Warranty gives you specific ega rights, and you may a so have other rights which vary from state to state.
NOTE: he Companies as stated above refer to - Canadian Heating Products Inc. and/or Montigo De Ray Corp.
Canadian Heating Products Inc. and/or Montigo DelRay Corp. reserves the right to make changes at any time, without
notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Warranty

Page 19
C34-DV Gas Fireplace
Part No. XG0117C
Appendix A - Termination Locations
A= clearancetotheterminationframeabovegrade,veranda,porch,deck,or
balcony[16inches(41cm)minimum]
B= clearancetodoor,orsidesandtopofwindow,thatmaybeopened[16
inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
C= clearancetobottomof windowthatmaybeopenedhorizontally[36inches
(92cm)minimumforappliances
≤ 100000BTU/H(30kW)]
D= noclearancetopermanentlyclosedwindowwheninstalledwithapproved
glasspenetrationtermination
E= clearancetopermanentlyclosed window[16inches41cmrecommended
topreventcondensationonwindow]
F= verticalclearancetoventilatedsoffitlocatedabovetheterminationwithina
horizontaldistanceof2feet(61cm)fromthecentrelineofthetermination
[22inches(56cm)minimum]
G= clearancetounventilatedsoffit
[16inches(41cm)minimumtonon-combustibles]
[22inches(56cm)minimumtocombustibles]
H= clearancetooutsidecorner[9inches(23cm)minimum]
I= clearancetoinsidecorner[12inches(31cm)minimum]
J= *nottobeinstalledaboveameter/regulatorassemblywithin
40"(103cm)horizontallyfromthecentrelineoftheregulator
K= clearancetoserviceregulatorventoutlet[3feet minimumintheUnited
States][*6feet (1.8m)minimuminCanada]
L = clearancetononmechanicalairsupplyinlettobuildingorthecombustion
airinlettoanyotherappliance[16inches(41cm)minimumforappliances
≤ 100000BTU/H(30kW)]
M= clearancetomechanicalairsupplyinlet
[*6feet (1.8m)minimum]
N= †clearanceabovepavedsidewalkorapaveddrivewaylocatedon
publicproperty[*7feet(2.1m)minimum]
P= clearanceunderveranda,porch,deck,orbalcony
[16inches(41cm)minimum‡tonon-combustibles]
[22inches(56cm)minimum‡tocombustibles]
Q= clearanceabovearoof[24inches(61cm)minimum]
R= clearancetoadjacentwallsandneighbouringbuildings
[18inches(46cm)minimum]
S= clearancefromcornerinrecessedlocation
[12inches(31cm)minimum]
T= maximumdepthinrecessedlocation
[48inches(122cm)minimum]
U= minimumwidthforbackwallofrecessedlocation
[24inches(61cm)minimum]
V= nohorizontalclearancebetweentheframesoftwoterminationsthatare
level.
W= horizontalclearancebetweentheframesoftwoterminationsthatare
notlevel. [36inches(92cm)minimum]
†aventshallnotterminatedirectlyaboveasidewalkorpaveddriveway
whichislocatedbetweentwosinglefamilydwellingsandservesboth
dwellings
‡onlypermittedifveranda,porch,deck,orbalconyhasanopensidethat
isequaltoorgreaterthanthedepthoftheenclosedarea
*asspecifiedinCGAB149InstallationCodes.Note:localCodesor
Regulationsmayrequiredifferentclearances

Canadian Heating Products Inc.
Lang ey, BC V4W 4A1
Montigo Del Ray Corp.
Fernda e, WA 98248
XG0117C Rev. 00 - 04/03
