montpellier MDI450 User manual

Installation and Operating Instructions
Model: MDI450
10 Place Fully Integrated Dishwasher
Please
read
these
instructions
carefully
before
attempting
to
install
or
use
this
appliance.
It is advisable to keep these instructions in a safe place for future reference.
1
(Image shown for illustrative purposes only)
(The decorative door shown is not part of the product)

Introduction
Thank you for choosing this
montpellier
appliance. It has been
designed to give years of trouble-free use provided it is installed and
maintained correctly.
Please
read
these
instructions
carefully
before
installing
or
using
your
appliance. It is advisable to keep your purchase and installation receipts
with these instructions in a safe place for future reference. Included is
some important safety information in addition to guidelines and
recommendations that will enable you to take full advantage of all the
functions available.
This
quality
appliance
has
been
tested
and
certified
to
meet
all
applicable
UK electrical and safety standards.
This
appliance
must
be
installed
and
connected
in
accordance
with
current regulations by a qualified electrician.
After unpacking the appliance ensure that there is no visible damage. If the
appliance has been damaged during transit, do not use it, contact your
retailer immediately.
2

Your
2
year
Manufacturer's
guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new montpellier appliance carries a free guarantee which protects you against the cost of
repairs during the first 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof
of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24
months prior to the date of claim.
What
is
not
covered
under
the
Guarantee
:
·
Any appliance not correctly installed and operated in accordance with the manufacturer's
instructions.
Any appliance that is used for anything other than domestic purposes.
Any defect caused by accident, misuse, unauthorized modification or inexpert repair.
Cost of Call-out where a fault cannot be found with the appliance.
Cost of Call-out for work covering routine maintenance, such as, but not exclusively,
cleaning of filters.
Cost of Call-out for work required to correct the alignment of doors following door
reversal procedures carried out by you.
Use of the appliance by anyone other than the Householder.
Use in any commercial environment.
Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable
items which require routine replacement.
Repair costs incurred that have not been authorised by Repairtech and/or carried out by
a non-approved Repairtech engineer.
·
·
·
·
·
·
·
·
·
YOUR
GUARANTEE
IS
VALID
ONLY
IN
THE
UK.
To
Register your Appliance
simply
complete
the
card
in
your
appliance
pack
and
return
it
with a stamp affixed or Alternatively you can Register online at www.repairtechuk.com
SERVICE
HELP
-
LINE
Should your appliance develop a fault, please call the
Repairtech Service Helpline on:
01527-888133
Please remember to have all your product details available, including the model
number, serial number, date of purchase and your retailer’s details before
registering a fault.
Your service call cannot progress without this information.
3

Description
of
the
Appliance
4

CONTENTS:
Section 1.
Installation
Section
2.
Safety
Advice
Section
3.
Operating
the
Appliance
Section 4.
Maintenance
5

Section
1.
Installation
·
Position the appliance in a dry, well ventilated room with a solid level floor.
The room temperature must not fall below +5° or rise above +35°.
This appliance is fitted with adjustable feet so that you can ensure it is sitting
level. Adjust the feet by turning left or right until the appliance is level.
The adjustable feet must never be removed.
Plug the 3pin moulded plug into a nearby 13amp plug socket. Always make
sure that you can easily gain access to switch the power on or off at the plug
socket.
N.B. This appliance must be earthed!
If you have installed this appliance underneath a work surface the plug
socket should have a fused switch located above the work surface so that
you can easily switch the appliance on or off.
You are advised to turn the power off at the plug socket when you have
finished using your appliance.
Before using the appliance for the first time, you must set the water softener,
add salt, add rinse aid and add detergent.
Your plumber will connect the water hose (supplied) to the water inlet
connection at the rear of the appliance and to an adjacent cold water supply.
It is your responsibility to ensure that the supplied washers have been used
and that both connections are water tight.
Ensure water pressure is within the range specified on the Rating Label.
Your plumber will connect the water drain pipe to an adjacent sink (see Pic.1
below)
Ensure that the water hose and water drain pipe are not kinked when the
appliance is pushed into place. If either of these pipes is kinked the appliance
will not operate correctly.
Ensure that the appliance is not standing on the power cable or hoses.
Do not use the water inlet hose of your old machine. Use the new water inlet
hose and connect the hose directly to the water inlet tap. The pressure
supplied by the tap should be a minimum of 0.03 Mpa and at a maximum of 1
Mpa. If the water pressure is above 1 Mpa, a pressure relief valve should be
fitted.
After the connections are made, the tap should be turned on fully and checked
that it is water tight. You should always turn off the water inlet tap after a wash
programme is finished.
Note: An Aquastop water hose is used in some models. In such
circumstances, heavy tension will exist. Do not cut the Aquastop water hose
and do not let it get folded or twisted.
·
·
·
·
·
·
·
·
·
·
·
6
·

Water Outlet Hose
The water drain hose can be connected either directly to the water
drain hole or to the sink outlet spigot using a special bent pipe (if
available). The hose connection should be at a minimum of 50cm and
at a maximum of 110 cm from the floor.
Please note that a drain hose longer than 4m must not be used as it
may prevent the appliance from washing correctly.
7

8
Section
2.
Safety
Advice
·
This appliance is manufactured and intended for DOMESTIC use only. Any
guarantee offered with the appliance is not valid for any installation in a
commercial environment.
This appliance MUST BE EARTHED!
Never try and disconnect the power by pulling the supply cable –hold the plug
firmly and pull it out of the socket.
Never touch the plug or power cable with wet hands.
Check the power cable periodically for signs of damage and ensure that it is
not trapped underneath the appliance. If the cable is damaged, turn off the
power at the socket and arrange for a qualified electrician to replace the
cable.
Never remove the power cable, open the appliance cabinet or try to modify
the appliance in any way. All service work must be carried out by a qualified
electrician.
The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Ensure that the appliance is sited well away from other heat sources, i.e. open
fires, boilers etc and in a dry, well ventilated room. The temperature must not
fall below +5° or rise above +35°.
Do not sit on the appliance or stand on the open door –the appliance could
tip forwards.
Keep children away from detergent and rinse aid, keep children away from the
open door of the dishwasher, there could still be some detergent left inside.
This appliance is not a toy –ensure that children are supervised at all times
whilst in the vicinity of this appliance.
Take care when loading the baskets with knives and cutlery. Always ensure
that sharp points are pointing away from you or down into the basket.
Only wash crockery and utensils that are clearly marked ‘dishwasher safe’.
Do not wash plastic items unless they are clearly marked ‘dishwasher safe’.
Only use dishwasher detergents and rinse aid clearly marked for use with
automatic dishwashers.
Never use non dishwasher detergent in this appliance, i.e. hand soap,
washing machine detergent, washing up liquid etc.
Always add dishwasher salt to your dishwasher, even when using 3-in-1
tablets. This will help protect your appliance against limescale.
If the power supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·

Section
3.
Operating
the
Appliance
3.1.
Before
Operating
t
he
Appliance
3.1.1.
Adding
Salt
·
The sole use of 3-in-1 tablets is not recommended as failure to add
salt to the salt container will leave your dishwasher exposed to
limescale damage which is not covered by the manufacturers
guarantee. Protect your appliance by adding salt as follows:
Remove the lower basket and then unscrew the salt container cap (1).
Add water and approximately 1kg of specialist dishwasher salt to the
container using the funnel provided (Image 3 & 4) until almost
overflowing. N.B. It is normal for a small amount of water to come out
of the container whilst filling it with salt.
Note: Fill the salt compartment with water at first use only.
Now replace the screw cap correctly and ensure that it is tight. If not,
salt may leak into the dishwasher chamber which can be detrimental
to the stainless steel interior. This is not covered by the manufacturers
guarantee.
After adding salt you should run a programme immediately to activate
the water softener and flush away any salt spilled into the machine.
If salt is low the indicator light will show on the control panel.
·
·
·
·
·
3.1.2.
Adding
Rinse
Aid
9

·
·
·
·
Remove the
Rinse Aid
Filler
Cap (1).
Add Rinse Aid until the rinse aid level indicator becomes dark (2).
Replace the Filler Cap (3).
If the rinse aid level is sufficient the indicator light will be dark on the control panel
(2B). If more rinse aid is required the indicator will be light (2A).
3.1.3.
Adding
Detergent
Use specialist dishwasher detergent powder or dishwasher tablets in
this appliance. However, please note that tablets do not always dissolve
fully during shorter wash programmes, so you are advised to operate
your appliance on a longer wash programme if using tablets.
In addition, the use of tablets may result in spots appearing on dishes
and glasses.
Push the latch to open the detergent container as shown in image 1. The
detergent pod has “level”lines inside to help measure the amount of
detergent you use. The pod can take a total of 40cm³ of detergent. If your
dishes are heavily soiled pour 25cm³ of detergent into the larger
compartment (b), if they are less soiled use only 15cm³.
If the programme selected has a pre-wash cycle you should add 5cm³ of
detergent to the pre-wash compartment (a).
If using combined detergents, make sure to check the specifications on
the product to ensure that it is appropriate for the wash programme, your
machine and the level of hardness of the mains water.
10

3.1.4.
Combined Detergent
–
Recom
mended Usage
3.1.5.
Adjusting
the
Water
Softener
If you are using a combined detergent, add a rinse aid agent to your
machine and switch the rinse agent setting to its lowest position (1) and
activate the tablet detergent button in order to obtain better results.
Depending on the water hardness you may n
eed to fill the salt container with
salt.
We do not recommended using 3 in 1 tablets on fast or rapid programmes
as the tablet may not fully dissolve. For these programs we suggest using
normal dishwasher powder.
11
The water softener in your appliance has been pre-set to the mid-
setting, but if you need to change the setting please proceed as
follows:

3.2.
The
Control
Panel
12
1. Power On/Off Button
2. Programme Display –Indicates the selected programme number.
3. Programme Selection Button –Allows you to select a suitable programme.
4. ½ Load Button –By using this feature, you can reduce the duration of selected
programs, and decrease the power and water consumption of your machine.
5. Delay Timer Button –You can delay the start of a programme by 3, 6 or 9 hours by
pressing this button. The delay will increase by 3 hours each time the button is pressed,
once you have the required delay press the programme selection button. If you wish to
change or cancel the delay, you can adjust it with the delay timer button as it will be
activated/deactivated according to the last value entered.
6. Salt Warning Indicator –When your machine needs salt the salt warning indicator will
come on. When this happens, add more salt.
Rinse Aid Warning Indicator –When there is insufficient rinse aid in your machine the
rinse aid warning indicator will come on. When this happens, fill the rinse aid chamber.
End of Programme Indicator –When a programme has ended the end of programme
indicator will come on. Additionally your machine will sound a buzzer 5 times.

3.3.
Loading
the
Baskets
3.3.1.
Upper
Basket
There are folding racks on the
upper basket of your machine.
You can use these racks in an
open or closed position
depending on whether you
want to place cups, long
glasses, or cutlery on them
Ensure that items are not
blocking the rotation of the top
spray arm.
Upper
Basket Height
Adjustment
The upper baskets location can be
altered as shown in the image to the
left.
The benefit of this is by dropping or
moving the basket up in the machine
you will have more space either
below or above for larger items.
In order to change the height,
remove the basket by shifting the
clip at the end of the rail to the side.
You can then reposition the basket
on the other wheels, do not forget to
shift the clip at the end of the rail
back into position to lock the basket
and prevent it from sliding out.
13

3.3.2.
Alternate
Basket Loads
Lower
Basket
Upper
Basket
Incorrectly Distributed Loads
14

15
15
3.4.
Programme
Selection
Table

3.5.
Selecting a Programme
16

17

Section
4.
Maintenance
4.1.
Cleaning
the
Filter
The filter helps prevent large pieces of food or other items entering the
pump and causing damage. It is important that you examine and clean
the filter system on a regular basis. Blocked filters are not covered
under the Guarantee!
The filter assembly is located
insidethe appliancejust
underneaththelower spray arm.
To remove the filter assembly,
turn it anti-clockwise and lift
the assembly out.
Pull out the metal/plastic filter and
then pull the coarse filter out of
the micro filter.
Rinse with lots of water under the
tap before refitting.
4.2.
Cleaning
the
Door
Periodically clean the inner stainless steel lining of the door with a warm
damp cloth. Pay particular attention to the edges so that food deposits do
not build up, causing the door seal to fail. Clean the door seal with warm
soapy water.
Never
use
abrasive
cleaners
or
polishes
on
the
stainless
steel!
18
a. Micro Filter b. Coarse Filter c. Metal/Plastic Filter

4.3.
Cleaning
the
Spray
Arms
Small particles of food will over time get into the spray arms and cause
blockages. Periodically remove the spray arms (as shown below) and
wash them in warm soapy water. Blocked spray arms are not covered
under the Guarantee!
To remove the lower spray arm
pull it upwards, so that the upper
spray arm nut can be removed by
turning the nut to the left.
Be sure that the nut is perfectly
tightened when refitting the upper
spray arm.
4.4.
Daily
Maintenance
Follow these useful tips to ensure your dishwasher stays in tip-top
working order:
·
Always switch off the power supply at the socket when your dishwasher
is not in use.
Always pay particular attention to the filter and spray arms –give them a
regular clean as described in 4.1. and 4.3. above.
Clean the door edges and door seal as described in 4.2. above.
Add salt to your appliance when prompted by the salt light on the control
panel. Always run a programme after to remove any spilled salt.
Add rinse aid to your appliance when prompted by the rinse aid light on
the control panel.
Only use Dishwasher salt, Dishwasher detergent and Dishwasher rinse
aid in your dishwasher.
Never use abrasive cleaners to clean your appliance.
When the appliance is not in use, leave the door slightly ajar in order to
avoid moisture and odours building up inside. However, this may not
be advisable if small children have unsupervised access to the area
where the dishwasher is sited.
If you are vacating the house for a long period, run a rinse cycle through
the machine and then ensure that the water and power supplies to the
dishwasher have been turned off. Leave the door ajar.
·
·
·
·
·
·
·
·
19

4.5.
Error Codes
20
Error
Code Error Description Control
F5 Inadequate water supply
Make sure the water inlet tap is totally open and that there is no
water leak
Close the water inlet tap, remove the water inlet hose from the
tap and clean the filter at the connection end of the hose
Restart your machine, contact
the Repairtech helpline if the error
resumes
F3
Continuous water input
Turn off the tap
Contact the Repairtech helpline
F2
The waste water in the machine
cannot be discharged
Water dischange hose is clogged
The filters of your machine might be
clogged
Power on/off your machine and activate the program cancel
command
If the error continues, contact the Repairtech helpline
F8
Heater error
Contact the Repairtech helpline
F1
Alarm is active showing water
overflow Power off your machine and turn off the tap
Contact the Repairtech helpline
FE
Faulty electronic card
Contact the Repairtech helpline
F7
Overheating error
Contact the Repairtech helpline
F6
Faulty heater sensor
Contact the Repairtech helpline
